Lufft XC200 User manual

XC200
Manual XC200
www.lufft.com
·
·
·
aa
a
p
pp
p
asas
as
s
si
si
si
i
on
on
on
n
ff
f
f
f
oror
or
or
r
pp
p
p
p
p
re
re
re
re
re
re
e
e
e
ci
ci
ci
ci
ci
si
si
si
si
on
on
on
on
n
n
··
·
·
pp
p
p
p
p
p
asas
as
as
as
as
a
s
s
sisisisi
si
si
si
si
s
o
ononon
on
onon
on
ppp
p
p
p
p
ou
ou
ou
ou
ou
ou
u
o
rr
rr
r
r
r
la
la
la
la
la
la
l
la
la
l
pp
p
p
p
p
p
p
réréréré
ré
ré
ré
cicicici
ci
ci
ci
ci
c
sisisisisi
si
si
s
ononon
on
onon
o
o
·
·
·
·
·
p
p
p
p
p
p
p
p
p
p
p
a
a
a
as
as
as
a
ióió
i
i
nn
n
popo
po
rr
lala
la
a
pp
p
rere
re
cici
ci
sisi
si
ón
ó
ón
ón
n
·
·
·
·
p
p
p
p
p
p
p
as
asas
a
s
s
sisi
si
si
si
si
si
si
s
ononononon
n
n
n
e
e
e
e
e
e
e
e
e
pepe
pe
rr
lala
pp
re
re
r
e
ci
ci
ci
c
sisi
si
onon
on
on
ee
e
e
·
·
a
a
a
pp
p
p

EN Manual XC200 1
Symbols
Danger!
Warns of a hazard which can lead to personal injury.
Caution!
Warns of a hazard which can lead to damage to
property.
The current version of the operating manual can be found at:
www.lufft.de
Legal notice
This release replaces all previous versions. No part of this
publication may be reproduced without written permission from
Lufft®. The same applies for electronically processing,
duplicating or spreading the publication. Subject to technical
changes. All rights reserved. Trademarks are used without
guarantee that they may be used freely and primarily following
the spelling of the manufacturer. Product names are registered.
Changes to construction in the interests of constant
improvements to the product, as well as changes to the shape
and colour are reserved.
The scope of delivery may vary from product images. This
document was created with all due care. Lufft®accepts no
liability whatsoever for possible mistakes or omissions.
The only party responsible for determining measured results to be
valid, drawing conclusions and deriving actions is the user! Lufft®
accepts no claims of warranty for correctness of detected
measured values or measured results. Further, Lufft®accepts no
liability whatsoever for possible mistakes or damage which have
been caused by utilising the detected measured results. © Lufft®
Warranty
The warranty is for 12 months. Damages caused by incorrect use
by untrained people or start-up by unauthorised people are
excluded from the warranty.
The device complies with the fundamental health and safety
requirements of the applicable EU regulations and was tested at
the factory for perfect functionality multiple times. However, if
faults in the functionality occur and cannot be remedied with the
measures in the chapter Errors and faults, please get in touch
with your dealer or distributor. When making a warranty claim,
supply the device number (see the rear of the device). The invoice
acts as warranty certificate. When manufacturer's instructions or
legal regulations have not been followed, or after unauthorised
changes to the device are made, the manufacturer is not
responsible for the resulting damages. Changes to the device or
unauthorised replacement of individual parts can drastically
impact the electrical safety of this product and leads to the forfeit
of the warranty. Liability does not extend to damages to people or
property caused by the device being used other than as described
in the instructions in this operating manual. Subject to changes to
technical design and model changes as part of constant
development and product improvement without prior notice.
No liability is accepted for damages resulting from improper use.
In such cases, entitlements to a warranty are then also forfeited.
Table of contents
Notes regarding the operating manual .................................... 1
Information about the device................................................... 2
Technical data ........................................................................ 3
Safety ..................................................................................... 3
Transport and storage............................................................. 4
Operation................................................................................ 4
PC software ............................................................................ 7
Errors and faults ..................................................................... 7
Maintenance........................................................................... 8
Disposal.................................................................................. 8
Declaration of conformity ........................................................ 8
Notes regarding the operating manual

2Manual XC200 EN
Description of the device
The thermohygrometer enables a quick and precise
determination of the air temperature and relative humidity
indoors. Both measured values are indicated in real time on a
pseudo colour display.
In addition to the relative humidity, further climate parameters
such as the dew point or absolute moisture content in the air can
be calculated with this device.
The temperature indication can be switched from °C to °F and
back.
A minimum, maximum and average function is available for the
direct analysis of the measured data. Besides, the currently
measured value can be recorded via the hold function.
The device can be operated via a capacitive touchscreen control
panel.
When not in use, an automatic switch-off saves the battery.
Device depiction
Cross control
Display
Information about the device
No. Operating element
1 Display
2 Cross control
3 Battery compartment with battery cover
4 On/Off key
5USBinterface
6 Measuring sensor
1
2
6
3
45
No. Operating element
7 Up key
8 Right/back key
9Downkey
10 OK button
11 Left/menu key
No. Display element
12 Configuration mode display
13 Measuring mode
14 Temperature display
15 Temperature unit
16 Humidity display
17 Unit for humidity
18 Configuration mode options
7
8
11
10
9
TH
HOLD
%WT
g/m
3
g/kg
Pabs[hPa]
SENS MAT TEMP Alarm
Alt.[ft] CAL12
gr/lb dp °C °F % rH
CM m/s ppm °F °C
IR
MAX
DP
MIN AVG
CFG
ACT
14
16
18
15
12
13
17

EN Manual XC200 3
Scope of delivery
Scope of delivery includes:
• 1 x Thermohygrometer XC200
•1xUSBcable
• 4 x Alkaline LR6 AA, 1.5 V batteries
• 1 x Getting started guide
• 1 x Factory test certificate
Carefully read the operating manual before using the device
and keep it within reach!
• Do not use the device in atmospheres containing oil, sulphur,
chlorine or salt.
• Never use the device for measurements at live parts.
• Ensure that all connection cables are protected from
damages (e.g. from kinks or crushing).
• Protect the device from permanent direct sunlight.
• Observe the storage and operating conditions (see chapter
Transport and storage).
Intended use
Only use the thermohygrometer XC200 for indoor measurements
of temperature and humidity. Here, read and observe the
technical data.
To use the device for its intended use, only connect and use
accessories and spare parts which have been approved by
Lufft®.
Improper use
Do not use the device in potentially explosive atmospheres, or for
measurements in liquids. Lufft®accepts no liability for damages
resulting from improper use. In such a case, entitlements to a
warranty are forfeited. Any unauthorised modifications,
alterations or structural changes to the device are forbidden.
Personnel qualifications
People who use this device must:
• have read and understood the operating manual, especially
the Safety chapter.
For maintenance or repair work which requires the housing
to be opened, contact Lufft®customer service. Devices
which have been opened unlawfully are void of any warranty
and warranty claims.
Residual risks
Danger!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Danger!
The device is not a toy and does not belong in the hands
of children.
Danger!
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way.
Observe the personnel qualifications.
Caution!
To prevent damages to the device, do not expose it to
extreme temperatures, extreme humidity or moisture.
Caution!
Do not use abrasive cleaners or solvents to clean the
device.
Technical data
Parameter Value
Temperature sensor NTC
Measuring range -20 to +50 °C
Tolerance +/- 0.2 °C (0 to 40 °C), otherwise +/-0.4 °C
Resolution 0.1 °C
Humidity sensor Capacitive
Measuring range 0 to 100 % RH
Tolerance +/- 2 % RH
Resolution 0.1 % RH
Measuring frequency 2x per second
Operating temperature -20 °C to 50 °C
Storage temperature -20 °C to 60 °C
Battery type 4x AA 1.5 VDC
Dimensions (LxWxH) 202 mm x 63 mm x 35 mm
Safety

4Manual XC200 EN
Transport
Use a suitable bag to transport the device safely.
Storage
When the device is not being used, observe the following storage
conditions:
•dry,
• protected from dust and direct sunlight,
• with a plastic cover to protect it from invasive dust, if
necessary.
• The storage temperature is the same as the range given in
the chapter .
• When storing the device for a long time, remove the batteries.
Accessories
Optionally, the following accessories are available for transport
and storage:
•Lufft
®case
• Sinter protection cap
For further information please contact your Lufft®customer
service.
Inserting batteries
• Insert the supplied batteries before first use.
Caution!
Make certain that the surface of the device is dry and the
device is switched off.
1. Open the cover of the battery compartment (3).
2. Insert the batteries with correct polarity.
3. Close the cover of the battery compartment (3).
– The device can now be switched on.
Transport and storage Operation

EN Manual XC200 5
Switch-on and measurements
Note:
The cross control is very sensitive. Therefore, avoid dirt on the
control panel, because it could be misinterpreted by the device as
keystroke.
Before use make sure that the touchscreen control panel is
dirt-free.
If required clean the touchscreen control panel according to
chapter Cleaning the device on page 8.
1. Press the On/Off key (4) until a beep is emitted.
2. The device performs a short self-test.
– The device name and firmware version is shown on the
display.
– The battery charge is indicated on the display.
– The device is ready for operation.
– The displayed units are based on the settings of the last
utilization.
3. Select the desired measuring mode.
4. Point the device at the area to be measured.
– The measured values will be displayed.
Note:
Note that moving from a cold area to a warm area can lead to
condensation forming on the device's circuit board. This physical
and unavoidable effect can falsify the measurement. In this case,
the display shows either no measured values or they are
incorrect. Wait a few minutes until the device has become
adjusted to the changed conditions before carrying out a
measurement.
Key lock
1. Briefly press the On/Off key (4) during operation.
– The device emits a short beep.
– The following message appears on the display: LoC on.
– Key lock is activated.
2. Press the On/Off key (4) again.
– The device emits a short beep.
– The following message appears on the display: LoC off.
– Key lock is no longer activated.
Configuration mode
1. Press the Left/menu key (11) for approx. 2 seconds.
– The device emits a short beep.
– The CFG symbol (12) is displayed in the upper right corner.
2. Use the Right/back or Left/menu key to choose from the
available settings.
– Please note that some of the settings can only be selected
with a certain measuring mode.
Configuration
mode Description
Lamp Setting brightness.
Available are values between 20 and 100 %.
Switch-off after 30 min unless with setting AL.on.
Pabs[hPa] Only available when the unit g/kg is active.
Specifying the absolute pressure (value range: 600 and
1200 hPa).
1. Enter the value using the cross control (2).
2. Confirm with the OK button (10).
Alt.[ft.] Only available when the unit gr/lb is active.
Specifying the local altitude in feet
(value range: -999 and 9999 ft).
1. Enter the value using the cross control (2).
2. Confirm with the OK button (10).
CAL1 Specifying the temperature offset.
1. Enter the value using the cross control (2).
2. Confirm with the OK button (10).
CAL2 Only available, when % rH is active.
Specifying the offset for relative humidity
(value range: +/- 30 % RH).
A negative offset allows no measured values of less than
0.00.
1. Enter the value using the cross control (2).
2. Confirm with the OK button (10).
TH
HOLD
%WT
g/m
3
g/kg
Pabs[hPa]
SENS MAT TEMP Alarm
Alt.[ft] CAL12
gr/lb dp °C °F % rH
CM m/s ppm °F °C
IR
MAX
DP
MIN AVG
CFG
ACT
18
12

6Manual XC200 EN
Temperature display configuration
The temperature can be displayed in either Celsius (°C) or
Fahrenheit (°F).
1. Press the Up key (7) to switch between °C and °F.
– The temperature will be displayed in the selected unit.
– The unit (15) will be indicated on the display (1).
Humidity display configuration
The humidity can be displayed in % RH, g/m3, g/kg and gr/lb, and
the dew point temperature in dp °C and dp °F.
1. Press the down key (9) until the desired unit is displayed.
– The humidity or dew point temperature will be displayed in
the selected unit.
– The unit (17) will be indicated on the display (1).
Measuring mode
1. Press the keys Right/back (8) or Left/menu (11) until the
desired measuring mode is displayed.
– The selected measuring mode (13) will be indicated on the
display (1).
The thermohygrometer comes with the following measuring
modes:
Holding the measured value
1. Set the measuring mode to HOLD.
– The current measured value will be held and displayed.
– The device will hold this value until the measured values
are set back or the device is switched off.
Resetting the measured values
1. Press the OK button (10) for approx. 2 seconds.
– All previously stored measured values of the measuring
modes AVG, MIN, MAX and HOLD will be set back.
– All measured values are then determined anew based on
the measurement proceeding in the background.
Measured value storage
Please note that measured values cannot be saved on the device
itself. In order to save measured values, the device has to be
connected to a PC via a USB cable using the SmartGraph3
software.
1. Briefly press the OK button (10).
– The displayed measured value will be saved in the
software.
USB interface
The device can be connected to a PC via the USB interface (5).
See chapter PC software on page 7.
Switch-off
1. Press and hold the On/Off key (4) for approx. 3 seconds until
a beep is emitted.
– The device will be switched off.
Unit Description
g/m3Absolute humidity in g/m3
g/kg Mixing ratio in g/kg
gr/lb Mixing ratio in gr/lb
dp °C Dew point temperature in °C
dp °F Dew point temperature in °F
% RH Relative humidity in per cent
%WT CM m/s ppm °F °C
15
g/m
3
g/kg
Pabs[hPa]
SENS MAT TEMP Alarm
Alt.[ft] CAL12
gr/lb dp °C °F % rH
pp
17
Measuring
mode Description
ACT Measured value in real time
AVG Average value of measurements since switch-on
MIN Minimum measured value
MAX Maximum measured value
HOLD Measured value will be held
TH
HOLD
%WT CM m/s ppm °F °C
IR
MAX
DP
MIN AVG
CFG
ACT
13

EN Manual XC200 7
Use the SmartGraph3 PC software to carry out a detailed analysis
and visualisation of your measured results. Only by employing
this PC software can all options of the measuring device for
visualization and functioning be utilized (e.g. data export into an
Excel/PDF file or data output in form of a printout).
Installation conditions
Ensure that the following minimum requirements for installing the
SmartGraph3 PC software are fulfilled:
• Supported operating systems (32 or 64 bit version):
– Windows XP from service pack 3
–WindowsVista
–Windows7
–Windows8
• Software requirements:
– Microsoft .NET Framework (is automatically installed
during the software installation, where applicable)
• Hardware requirements:
– Processor speed: min. 1.6 GHz
–USBconnection
– 2 GB RAM, minimum
– 1 GB hard disk space, minimum
Installing the PC software
1. Download the current PC software from the Internet. To do
so, visit the website www.smartgraph3.de/download.
2. Double-click the downloaded file.
3. Follow the instructions of the installation wizard.
Starting the PC software
1. Start the SmartGraph3 software.
2. Switch on the device (see chapter Switch-on and
measurements) if necessary.
3. Connect the device to your PC via the USB connection cable
provided in the scope of delivery. After a few seconds (up to
one minute) the device is automatically detected and added
to the device list in the SmartGraph3 software.
Information about using the PC software is provided in the online
help.
The accurate functionality of the device was tested during
production a number of times. However, if functionality faults do
occur, then check the device according to the following list.
The device does not switch on:
• Check the charging status of the batteries. Change the
batteries when the message Batt lo is displayed upon
switch-on.
• Check that the batteries are properly positioned. Check the
polarity is correct.
• Never carry out an electrical check yourself; instead, contact
your Lufft®customer service.
PC software
Errors and faults

8Manual XC200 EN
For maintenance or repair work which requires the
housing to be opened, contact Lufft®customer
service. Devices which have been opened
unlawfully are void of any warranty and warranty
claims.
Cleaning the device
1. Use a soft, lint-free cloth for cleaning.
2. Dampen the cloth with clean water. Do not use sprays,
solvents, alcohol-based or abrasive cleaners to dampen the
cloth.
3. Remove dirt from the housing, the connections and the
display.
Battery change
Change the batteries when the message Batt lo is displayed upon
switch-on or the device can no longer be switched on. See
Inserting batteries on page 4.
In the European Union, electronic equipment must not
be treated as domestic waste, but must be disposed of
professionally in accordance with Directive
2002/96/EC of the European Parliament and Council of
27th January 2003 concerning old electrical and electronic
equipment. After the end of its use, please dispose of this device
in a manner appropriate to the relevant legal requirements.
In the European Union, batteries must not be treated as domestic
waste, but must be disposed of professionally in accordance with
Directive 2006/66/EC of the European Parliament and Council of
6th September 2006 concerning batteries and accumulators.
Please dispose of batteries in a manner appropriate to the
relevant legal requirements.
in accordance with the EC Low Voltage Directive 2006/95/EC and
the EC Directive 2004/108/EC about electromagnetic
compatibility.
Herewith, we declare that the XC200 thermohygrometer was
developed, constructed and produced in compliance with the
named EC directives.
The marking is found on the rear of the device.
Manufacturer:
G. Lufft Mess- und Regeltechnik GmbH
Gutenbergstr. 20
D-70736 Fellbach
Phone: [phone]
Fax: [phone]
Email: inf[email protected]
Fellbach, 31/03/2014
Managing Director: Axel Schmitz-Hübsch
Maintenance Disposal
Declaration of conformity

a
pa
a
s
ss
io
n
n
fo
r
pr
pr
ec
ec
ision · passio
n
n
po
o
ur la précis
io
n
n
· pa
si
si
ón
ó
p
p
or
o
la
pr
pr
ec
is
is
ión ·
pa
a
ss
ss
io
i
ne
per la precisione ·
G. LUFFT Mess- und
Regeltechnik GmbH
Lufft Germany:
Postal Address:
Gutenbergstrasse 20
70736 Fellbach
Address:
P.O. Box 4252
70719 Fellbach
Tel. +49 (0)711 - 51 822 - 0
Fax +49 (0)711 - 51 822 - 41
www.lufft.com
[email protected]
Lufft North America:
Lufft USA, Inc.
820 E Mason St #A
Santa Barbara, CA 93103
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
www.lufft.com
Lufft China:
Shanghai Office:
Lufft (Shanghai)
Measurement & Control
Technology Co., Ltd.
Room 507 & 509, Building No.3,
Shanghai Yinshi Science and
Business Park,
No. 2568 Gudai Road,
Minhang District,
201199 Shanghai, CHINA
Tel: [phone]
Fax: [phone]
E-Mail: [email protected]
www.lufft.cn
Beijing Office:
B501 Jiatai International Mansion
No. 41 East 4th Ring Road,
Chaoyang District,
100025 Beijing, CHINA
Tel: [phone]
Fax: [phone]
E-Mail: [email protected]
