Lumenpulse DMXrdm User manual

1/3
RDM Reference Guide
5-year limited warranty.
Consult www.lumenpulse.com
for our complete Standard Terms
and Conditions of Sales.
© Copyright Lumenpulse 2015
1751 Richardson, Suite 1505
Montreal (Quebec) Canada
H3K 1G6
1.877.937.3003
P.514.937.3003
F. 514.937.6289
[email protected]
www.lumenpulse.com
Lumenpulse reser
ves the right to make changes to this product at any time
without prior notice and such modication shall be effective immediately.
E. Martin - Rev.1
23/OC/2015
DESCRIPTION
FEATURES AND BENEFITS
Remote Device Management (RDM) is an enhancement of
DMX that allows bi-directional control and feedback from
lighting xtures and devices.
DMX/RDM provides a number of benets for stakeholders
throughout the construction, commissioning and property
management stages.
• Simplify xture discovery: RDM controllers can discover
any RDM-enabled devices on the network.
• Improve error reporting: An alert system reports back
potential issues, including “Over Temperature” and “Over
Voltage”.
• Enable remote DMX addressing: With RDM,
technicians can remotely query and update the DMX
address and other parameters of the xture prole.
• Update rmware: Allows for easy discovery and
updating of the xture rmware via the new xture
rmware bootloader.
DMX/RDM PROTOCOL LIMITS
Data length: 1000’ between boosted devices
Number of devices connected to a CBX: 32 per output
Cascading CBX limit: 4
Client Project name
Order# Type Qty
DMX/RDM
DMX
› Hello my name is Lumenbeam™Small
› My DMX address is 125
› My temperature is 32° C
› My personality is 16-bit
› Remaining hours till L70: 102,567
› My serial number is 06500005
Your xture
has a lot to say.

2/3
RDM Reference Guide
5-year limited warranty.
Consult www.lumenpulse.com
for our complete Standard Terms
and Conditions of Sales.
© Copyright Lumenpulse 2015
1751 Richardson, Suite 1505
Montreal (Quebec) Canada
H3K 1G6
1.877.937.3003
P.514.937.3003
F. 514.937.6289
[email protected]
www.lumenpulse.com
Lumenpulse reser
ves the right to make changes to this product at any time
without prior notice and such modication shall be effective immediately.
E. Martin - Rev.1
23/OC/2015
ADDITIONAL FEATURES
Key New RDM Parameters
• Fixture Name (Customizable)
• Manufacturer Label
• Device Model Description
• Serial Number
• DMX Address
• DMX Footprint
• Fixture Resolution
• Fixture Personality (Multiple Options)
• DMX Address Direction
• Dimming Curve
• Start-Up Color
• Firmware Version Number
On-Board Fixture Sensors
• Device Power
• LED Temperature
• PSU Temperature
Other Available Parameters for Both Lumenpulse and Third-Party Devices
• Device Hours
• Device Power Cycles
• Device Clock
• Device Slot Information (per channel)
• Display Invert (if applicable)
• Display Level (if applicable)
• Pan Invert (if applicable)
• Tilt Invert (if applicable)
• Pan/Tilt Swap (if applicable)
• Factory Default Reset
Lumenlife™
Lumenlife™, featured in the xture monitoring section of the LumenID™ V3 software, is a patented method for estimating the life
expectancy of a xture, which takes into account environmental factors that inuence lifetime, rather than merely the past hours of
operation.
With Lumenlife, we can better estimate when a luminaire reaches L70 and issue alerts as the luminaire starts to approach the end of its
useful lifetime. For more information, please consult the Lumenpulse Terms and Conditions at http://www.lumenpulse.com/en/terms.

3/3
RDM Reference Guide
5-year limited warranty.
Consult www.lumenpulse.com
for our complete Standard Terms
and Conditions of Sales.
© Copyright Lumenpulse 2015
1751 Richardson, Suite 1505
Montreal (Quebec) Canada
H3K 1G6
1.877.937.3003
P.514.937.3003
F. 514.937.6289
[email protected]
www.lumenpulse.com
Lumenpulse reser
ves the right to make changes to this product at any time
without prior notice and such modication shall be effective immediately.
E. Martin - Rev.1
23/OC/2015
TYPICAL DMX/RDM LAYOUTS
100-277V
100-277V
Standard DMX
fixture
Standard DMX
fixture
RDM-enabled
controller
DMX/RDM
DMX
USB
100-277V
100-277V
100-277V
Standard DMX
fixture
Standard DMX
fixture
RDM-enabled
controller
During Operation
During Commissioning or Monitoring
