Lumex 574RG User manual

574RG-INS-LAB
©Graham-Field Health Products 2005
574RG Ortho-Biotic
3-Position Recliner
Operating Instructions
IMPORTANT: READ THIS MANUAL BEFORE OPERATING
YOUR ORTHO-BIOTIC 3-POSITION RECLINER

574RG 3-Position Ortho-Biotic Recliners Operating Instructions2 2
Warning: Periodically inspect all parts and
replace as needed.
Warning: Do not use near an open flame, as
the chair may be a "combustion source".
Warning: Occupant weight should not
exceed 290 lbs.
Warning: Caster wheels should be locked
during occupant transfer.
OrdinaryDirt: Wash with warmwater and a mild
soap or detergent.
Stubborn Dirt: Using a soft bristle brush, follow
directions above.
Ground-in Dirt: Scrub with powdered cleanser or
similar detergent.
Chewing Gum: Scrape carefully; remove with
kerosene or naphtha.
Nail Polish and Remover: Blot immediately to
prevent damage.
Ball Point Pen: Blot immediately with a white
cloth dampened in water or mineral oil.
Paint, Shoe Polish, Heel Marks: Remove
immediately! Use a white cloth dampened in
kerosene, naphtha or turpentine. Do not use
paint remover or liquid brush cleaners.
Tars, Asphalt, Creosote: Remove to prevent
staining. Clean area with kerosene or naphtha.
Caution: When using kerosene or naphtha, do so
in a well ventilated area and keep away
from fire and flame.
Waxing and Refinishing: Improves wearability.
Use any quality paste wax.
Adiluted solution of 10% (or less) of bleach or
Clorox may be used when cleaning this chair.
Every three months:
•Check and clean casters • tighten nuts • check brakes on casters •
•check and clean lock recline mechanism •
For upholsterymaintenance and stain removal, the following hints will be helpful:
WARNINGS
CARE & MAINTENANCE

3574RG 3-Position Ortho-Biotic Recliners Operating Instructions 3
1. Remove back assembly from unassembled
chair and put aside momentarily.
2. Slide the 1 piece back assembly into the
square tubes of the lower frame assembly so
that the holes in the back rest line up with the
holes located on the horizontal brace of the
lower frame assembly.
3. Raise recliner lock bar and adjust position of
back assembly until lock release button
positively engages middle slot on lock bar
link when chair is in storage position.
4. Insert screws through holes of the horizontal
brace and tighten all screws with screwdriver.
NOTE:Make sure that the top screw on both sides
of the coated square tubing from the back
assembly are sufficiently secure before
using recliner.
ASSEMBLY INSTRUCTIONS
Upholstered Back
Back Assembly
Lower Frame
Lower Rear SupportTube
Lock Release Pull Button
Recliner Lock Bar Storage
Position
Holes with Screws
Padded Push Handle
Holes in Back Rest
Locking Pins
Label Specifying Date of
Manufacture
Holes in Horizontal Brace
Table Storage
Figure 1

574RG 3-Position Ortho-Biotic Recliners Operating Instructions4
To place unit in reclining positions:
By Occupant:
1. Place hands on armrests and push against
seat back. Legrest will automatically adjust to
each recline position.
Note: The table can only be used in upright sitting
position. Patient should be transported in
TV position with recliner lock set.
By Attendant:
1. Ensure that recliner lock bar is in stored
position. See fig. 1.
2. Stand at either side of recliner.
3. Grasp armrest with one hand, and Padded
Push Handle.
4. Push down on push bar to recline the back to
the first recline position, to achieve second
recline position, push on push bar again.
5. To raise upright, pull forward on push bar.
6. Set recliner Lock Bar.
Recliner Lock Operation
To Lock Recliner:
1. Place recliner into desired position.
2. Pull out Lock-Release Pull Button to release
Lock bar from stored position.
3. Rotate recliner Lock Bar down until notches
are fully engaged over Locking Pins.
To Unlock Recliner:
1. Lift recliner Lock Bar up to disengage from
Locking Pins.
2. While holding Lock-Release Pull Button out,
rotate recliner Lock Bar all the way up until
completely against seat back.
3. Release Lock-Release Pull Button to hold
recliner Lock Bar in stored position.
Note: Do not attempt to change position of chair
with recliner lock bar engaged. This could
cause damage to mechanism.
OPERATING INSTRUCTIONS
Side Panel
SIDE PANEL REMOVAL
To Remove: Depress push buttons located on
the lower sides of frame. Pull side panel gently
away and down from frame.
To Install: Insert side panel into chair frame by
lining up side panel clips with tubes on frame
and pushing firmly.
Push Buttons
Panel Tabs

5574RG 3-Position Ortho-Biotic Recliners Operating Instructions
Articulating headrest may be adjusted to desired
position by pulling forward or pushing back.
Operating Instructions for Molded Table
ToOperate:
1. Underneath each arm, pull down and hold
pull and twist the pull button until it holds
into place. (Fig. 2) and slide lockout keys
forward on both sides.
2. Pick up table by circular table arm and slide
into receiving tubes in front of each arm.
3. Table can slide on and off by keeping lock/
lockout key forward.
4. Table can be locked into one of five positions.
Pull down the pull button, hold the pull
button and slide the key backwards. Proceed
to the other arm and move that key
backwards. Table will now be locked.
Storage:
The molded table stores in the small round tube
underneath the left armrest, leaving the table
top facing out.
Padded Push Handle Articulating Headrest
Table
Pull buttons
OPERATING INSTRUCTIONS
Figure 2
