Lumex AltaDyne Sensor Plus 765000 User manual

765000
ALTERNATING PRESSURE MATTRESS SYSTEM
WITH ACTIVE SENSOR TECHNOLOGY
USER MANUAL
Important: Do not operate the Mattress System
without rst reading and understanding this manual!
Save this manual for future use.
Note: The most current version of this manual can be
found online at www.grahameld.com
765000-INS-LAB-RevB10

2 765000-INS-LAB-RevB10
CONTENTS
INTRODUCTION ..................................................................................... 3
INTENDED USE OF THIS DEVICE ........................................................ 3
IMPORTANT SAFETY PRECAUTIONS .................................................. 4
DANGER ................................................................................................. 4
WARNING ............................................................................................... 4
CAUTION ................................................................................................ 6
EQUIPMENT SYMBOLS ......................................................................... 7
PRODUCT DESCRIPTION...................................................................... 8
PUMP AND MATTRESS SYSTEM ......................................................... 8
PUMP: FRONT........................................................................................ 8
PUMP: REAR .......................................................................................... 8
PUMP: FRONT PANEL........................................................................... 9
INSTALLATION ...................................................................................... 13
UNPACKING ......................................................................................... 13
PUMP AND MATTRESS SETUP .......................................................... 13
OPERATION........................................................................................... 15
GETTING STARTED ............................................................................. 15
QUICK DISCONNECT.......................................................................... 15
TRANSPORT CAP ................................................................................ 16
CPR FUNCTION ................................................................................... 16
MAINTENANCE..................................................................................... 17
CLEANING ............................................................................................ 17
GENERAL MAINTENANCE.................................................................. 17
FUSE REPLACEMENT .................................................................. 18
AIR FILTER REPLACEMENT ........................................................ 18
STORAGE ............................................................................................. 18
SPECIFICATIONS.................................................................................. 19
LIMITED WARRANTY ........................................................................... 20
APPENDIX A: EMC INFORMATION ..................................................... 21
Graham-Field, Lumex and AltaDyne are registered trademarks of
GF Health Products, Inc.
GF Health Products, Inc. (“Graham-Field”) is not responsible for typographi-
cal errors. Packaging, warranties, specifications and products are subject to
change without notice.

765000-INS-LAB-RevB10 3
INTRODUCTION
Use this manual for set-up and operation of the Lumex®
AltaDyne®Sensor Plus 765000 Alternating Pressure
Mattress System with Active Sensor Technology. Read all
instructions before using the mattress system. Save this
manual for future reference.
INTENDED USE OF THIS DEVICE
The intended use of the Lumex®AltaDyne®Sensor Plus
765000 Alternating Pressure Mattress System with Active
Sensor Technology is:
• Aidinthetreatmentandpreventionofstage1,2,3and
4 pressure ulcers while optimizing user comfort.
• Painmanagementasprescribedbyaphysician.
• Asdescribedabove,ineitherahomecareorlong-term
care setting.

4 765000-INS-LAB-RevB10
IMPORTANT SAFETY PRECAUTIONS
The safety statements presented in this chapter refer to
the basic safety information that should be observed by
those using this Mattress System. There are additional
safetystatementsinotherchaptersorsections,whichmay
bethesameasorsimilartothefollowing,orspecictothe
operations.
DANGER: Indicates an imminent hazard situation that, if
not avoided, will result in death or serious injury.
WARNING: Indicates a potential hazard situation or
unsafe practice that, if not avoided, could result in
death or serious injury.
Caution: Indicates a potential hazard or unsafe prac-
tice that, if not avoided, could result in minor person-
al injury or product/property damage.
Note: Provides application recommendations or other
useful information to ensure that you get the most from your
product.
DANGER
To reduce the risk of electrocution:
DANGER: Always unplug this product immediately after use.
DANGER: Do not use this product while bathing.
DANGER: Do not place or store this product where it
can fall or be pulled into a tub or sink.
DANGER: Do not place this product in or drop into
water or other liquid.
DANGER: Do not reach for a product that has fallen into
water. Unplug it immediately.
WARNING
To reduce the risk of burns, electrocution, re,
or personal injury:
WARNING: Do not leave this product unattended when
plugged in.

765000-INS-LAB-RevB10 5
WARNING: Always use close supervision when this
product is used by, on, or near children or those who
require close supervision.
WARNING: Use this product only as intended and
described in this manual. Do not use attachments or
accessories not recommended by Graham-Field.
WARNING: Never operate this product if:
a) It has a damaged cord or plug.
b) It is not working properly.
c) It has been dropped or damaged.
d) It has been dropped into water.
Return the product to your Graham-Field equipment
provider.
WARNING: Keep the cord away from heated surfaces.
WARNING: Never block the air openings of this product
or place it on a soft surface, such as a bed or couch,
where the openings may be blocked. Keep the air
opening free of lint, hair, and other similar particles.
WARNING: Never drop or insert any object into any
opening or hose.
WARNING: Do not use this product in the presence
of ammable anesthesia, or where oxygen or nitrous
oxide is being administered.
WARNING: Connect this product only to a properly
grounded power outlet.
WARNING: Maximum patient weight capacity for this
product is 400 lb (189 kg).

6 765000-INS-LAB-RevB10
WARNING: Patient entrapment with bed side rails
may cause injury or death. The bed frame and its
components, including the mattress, bed side rails,
head and foot board, bedding, and any accessories
added to the bed, can all affect the risk of entrapment.
Thorough patient assessment and monitoring are
necessary to reduce the risk of entrapment, including
establishing whether the use of a bed rail is in the
best interest of the patient. Read and understand the
User Manual before using this equipment. GF Health
Products, Inc. product manuals are available online at
www.grahameld.com.
Visit the FDA's Bed Safety page at www.fda.gov to
learn more about the risks of entrapment. It is the
responsibility of the facility and provider to be in
compliance with these guidelines. Refer to user
manuals for beds and rails for additional product safety
information.
After any adjustment, repair or service, and before use,
ensure all attaching hardware is securely tightened.
Bed rails with dimensions different than the original
equipment specied by the bed manufacturer may not
be interchangeable and may result in entrapment or
other injury.
CAUTION
Caution: The pump can be used only with the accom-
panying mattress. Do not use it for any other purpose.

765000-INS-LAB-RevB10 7
EQUIPMENT SYMBOLS
Manufacturer
Indicates that this product is according to the degree of protection
against electric shock for type BF equipment
Functional earth (for UL only)
Attention! Read the instructions!
Disposal of Electrical & Electronic Equipment (WEEE):
Do not treat this product as household waste. For more detailed
information with regard to returning and recycling this product,
please consult your local city ofce, household waste disposal
service, or Graham-Field equipment provider.
Consult operating instructions
Class II (for UL only)
The system has been tested and successfully approved with the following standards:
EN 60601-1, EN 60601-1-2, EN 550011 Class B, IEC61000-3-2,
IEC61000-3-3
For U.S. and Canada only
E228589
53DG
Medical Equipment: Air Pump
with respect to electrical shock, re and
mechanical hazards only in accordance with
UL60601-1 and CAN/CSA C22.2 No. 601.1

8 765000-INS-LAB-RevB10
PRODUCT DESCRIPTION
PUMP AND MATTRESS SYSTEM
pumpandmattresssystem
CPRvalves
quickconnectors
(mattress-pump
connectors)
mattress
footend
symbol
pump
PUMP: FRONT
quickconnector
front
panel
PUMP: REAR
mainpower
switch
powercord
receptacle
fuse
hanger
filter

765000-INS-LAB-RevB10 9
PUMP: FRONT PANEL
Front panel of pump is shown below. Descriptions of but-
tons and indicators follow.
Tuningbutton;
indicatorsatleftofbutton
Powerfailureindicator
Alarmmutebutton
Serviceindicator
Power(ON/OFF)button;
indicatoratrightofbutton
Panellockbutton;
indicatoratrightofbutton
Maxfirmbutton
Auto-Adjustbutton;
indicatorsatrightofbutton
Lowpressure
indicator
Therapyadjustbutton;
indicatorsatrightofbutton
Front panel, rst row
Auto-Adjust button: The auto-adjust button
adjusts the mattress pressure automatically based on the
patient's weight. To remind the user that the auto-adjust
processisongoing,theauto-adjustindicatorLEDswill
periodicallyashfromlefttorightuntiltheReadyLEDillu-
minates to show the process is complete. Three conditions
trigger the auto-adjust function:
1. Presstheauto-adjustbuttonfortwoseconds;themat-
tress system automatically readjusts pressure setting.
2. Wheninitialmattressinationiscomplete,themattress
system automatically starts the auto-adjust function.
3. Whenthemattresssystemdetectsasignicantchange
in patient's weight on the mattress (e.g. patient egress
oringress),thesystemautomaticallystartstheauto-
adjust function.
Whenauto-adjustiscomplete,theReadyindicatorwillillu-
minate.Todisabletheauto-adjustfunction,presstheauto-
adjust button until auto-adjust indicators de-illuminate.
Note: During the auto-adjust operation, it is normal for the
mattress system to cycle through a series of inflation and
deflation.

10 765000-INS-LAB-RevB10
Tuning button:Thetuningbuttonne-tunesthe
mattress system's auto-adjusted pressure. Three tuning
settings are available:
0System auto-adjusted pressure
-One level softer than auto-adjusted pressure
+ Onelevelrmerthanauto-adjustedpressure
Note: The tuning function is only available in alternate and
static therapy modes.
Front panel, second row
Therapy adjust button: The therapy ad-
justbuttonselectsthetherapymode.Afterpower-up,the
systemautomaticallyinatesthemattress,auto-adjusts
thepressure,andentersalternatetherapymode.Tothen
cycleamongthetherapysettings,pressthetherapyadjust
buttontoselectstatictherapymode;pressagaintoselect
alternate+seatinationtherapymode;pressagainto
selectstatic+seatinationtherapymode;pressagainto
selectalternatetherapymode,etc.
Alternate:Eachtubellsfor10minutes,thendeatesfor
10minutes,alternatelytothenexttube.Whenselected,
the alternate indicator illuminates.
Static: The pressure inside all tubes is adjusted to the
samepressure.Whenselected,thestaticindicatorillumi-
nates.
Alternate + Seat Inflation: For use when the head is
raised,toincreasepressureunderthebuttocks—inalter-
natingpressuretherapymode.Whenselected,boththe
alternate and seat ination indicators illuminate.
Static + Seat Inflation:Forusewhentheheadisraised,to
increasepressureunderthebuttocks—instatictherapy
mode.Whenselected,boththestaticandseatination
indicators illuminate.

765000-INS-LAB-RevB10 11
Maxfirm button: The pump will automatically enter
maxrmmodeeverytimethepoweristurnedon.Maxrm
mode ensures the pump is able to reach its maximum oper-
atingpressure.Maxrmmodewilllastfor20minutes,and
then the system will automatically enter auto-adjust mode.
Todisablemaxrmmode,pressthemaxrmbutton.When
enabled,themaxrmindicator,atleftofbutton,illuminates.
Front panel, third row
Panel lock button:Thepanellockbuttonsetsthe
panellocktoprotectthepanelsettingsfromaccidental
change.Pressfortwosecondstolock;pressFIRMLYfor
twosecondstounlock.Afterthepanelhasbeenuntouched
forveminutes,thepanellocklocksautomatically.When
thepanelislocked,thepanellockindicatorwillilluminate.
Power (ON/OFF) button: The power button turns
powertothemattresssystemONorOFF.PresstoturnON;
presstoturnOFF.Whenpowerison,thepower(ON/OFF)
indicatorwillilluminate.WhenpoweristurnedOFF,the
mattress system will slowly deate.
Note: Main power switch on side of pump, previously shown
in PUMP: REAR, must be ON in order for the front panel
power button to function.
Alarm Mute button: The alarm mute button temporar-
ilysuspendstheLEDindicatorandbuzzerwheneither
the low-pressure alarm or power failure alarm is activated.
Shouldtheproblemnotberesolvedwithinthreeminutes,
the alarm will resume.

12 765000-INS-LAB-RevB10
Low pressure indicator: The low pressure
indicator(yellowLED)illuminates,andthealarmsounds,
whenanabnormallylowpressureleveloccurs.Ifthelow
pressure indicator persistently illuminates inappropriately:
1. Checktoensureallconnectionsareproperlyandse-
curely connected per installation instructions.
2. Checkforanyleakage(tubesorconnectinghoses).If
necessary,contactyourGraham-Fieldequipmentpro-
vider to replace any damaged tubes or hoses.
3. Ifproblempersists,contactyourGraham-Fieldequip-
ment provider.
Note: Sometimes the low pressure indicator will illuminate
when a patient gets up to leave the bed. This is normal. The
indicator will turn off automatically after a short time.
The low pressure indicator will illuminate until the low-
pressure condition is resolved.
Power failure indicator: The power failure
indicatorilluminates,andthealarmsounds,whenthereis
a power failure. Depress the alarm mute button to disable
bothalarmandLED.
Service indicator:Mechanicalfailure,service
required;contactyourGraham-eldequipmentprovider.

765000-INS-LAB-RevB10 13
INSTALLATION
UNPACKING
1. Carefullyremoveallcomponentsfromthecarton.
2. Inspectallcomponents.
3. Ifdamageisevidenttothecontents,pleasenotifythe
carrierandyourGraham-Fieldequipmentprovider.
PUMP AND MATTRESS SETUP
1. Removeallsheets,blankets,andpillowsfromthebed.
2. Placethemattressontopofthe
bedframe;ensurethatthefoot
end symbol faces up at foot end as
shown at right. Secure mattress to
bed with straps.
3. Foldopenthewirehangerson
thebackofthepumpasshownat
right.
4. Eitherhangthepumponthebed's
footend,asshownatright,or
place the pump on a at surface
easily accessible to the caregiver
and/ordoctor.
Caution: Place the device in a
position where the caregiver and/
or doctor can access it easily.
5. Connectthemattress-pumpair
hosequickconnector;ensurethat
theconnectorhasclickedsecurely
into place before continuing.
Caution: Ensure that the air hoses are not kinked or
tucked under the mattress.
hanger

14 765000-INS-LAB-RevB10
WARNING: Locate all cords so that they will not be
stepped on, tripped over, or otherwise subjected to
damage or stress.
WARNING: Do not use a household extension cord if the
electrical cord does not reach the power outlet. Use of an
improper extension cord could result in re and electric
shock. If an extension cord must be used, use a three
conductor cord with ground, properly wired, in good
electrical condition, and keep it as short as possible.
WARNING: Ensure that the local power voltage is
appropriate for the pump unit.
6. Plug the power cord into a properly grounded electrical
outlet.

765000-INS-LAB-RevB10 15
OPERATION
GETTING STARTED
1. Turnthemainpowerswitch
to the ON position.
2. Pressthefrontpanelpower
button. The power indicator
will illuminate.
Note: The mattress system will
automatically enter maxfirm mode for the quickest inflation
at set-up; when inflated, it will then automatically enter auto-
adjust mode to select the appropriate pressure.
3. Thepumpwillbegindeliveringairintothemattress.
Thelowpressureindicatorandthemaxrmindicator
will illuminate for approximately twenty minutes until
the mattress is fully inated.
4. Uponination,thesystemwillautomaticallyenterauto-
adjust mode to automatically select the appropriate
pressure according to the patient's weight. The auto-
adjustindicatorLEDswillashfromlefttoright,and
thesystemwillcyclethroughinationanddeation,
untiltheReadyLEDilluminatestoshowtheprocessis
complete,andthemattresssystemautomaticallyen-
ters alternate therapy mode.
5. Replaceallsheets,blankets,andpillowsonthebed.
6. Youcannowadjusttherapymodesortuning.Pleasesee
earliersection,PUMP: FRONT PANEL,foracompletede-
scriptionofavailableadjustments,buttonsandindicators.
QUICK DISCONNECT
Pull the power plug from the wall connector to disconnect
thedevicequickly.
main
power
switch
powerbutton

16 765000-INS-LAB-RevB10
TRANSPORT CAP
Incaseofpowerfailureortrans-
port:Disconnectthequickconnec-
tor and cap the mattress with the
transport cap to slow deation.
Note: This system is equipped
with cell-on-cell technology to
provide added support and prevent
bottoming out in the event of a
power failure. Lower cells will hold
air for approximately eight hours.
CPR FUNCTION
IfCPRmustbeperformedonthepatientwhilethemat-
tressisinuse,toimmediatelydeatethemattress,either:
1. PulltheCPRvalvesfromthe
mattress in the location of the
arrowshownatright,or
2. Disconnectthequickconnector
from the pump in the location of
the arrow shown at right.
quick connector
transport cap

765000-INS-LAB-RevB10 17
MAINTENANCE
CLEANING
WARNING: To reduce the risk of increased bacterial
growth, infection, illness, or injury from contamination,
thoroughly clean and dry the mattress system before
use and as necessary during use as follows:
Pump:Wipethepumpwithaclean,dampclothandmild
detergent,andkeepitawayfromdust.Airdry.
Caution: Do not use phenolic products or corrosive or
powdered cleansers to clean the pump. Do not im-
merse or soak the pump.
Mattress:Wipethemattressunitwithaclean,dampcloth
and mild detergent. The mattress may also be cleaned us-
inga10%solutionofsodiumhypochlorite(bleach)diluted
in water. Air dry all parts thoroughly before use.
Caution: Do not clean the mattress with phenolic
products. After cleaning, air dry the mattress without
direct exposure to sunlight.
GENERAL MAINTENANCE
1. Checkmainpowercordforabrasionorexcessivewear.
2. Checkmattresscoverforsignsofwearordamage.En-
sure mattress cover and tubes are connected correctly.
3. Checkairowfromtheairhoseconnector.Theairow
should alternate between each connector every half-
cycle time while in alternating mode.
4. Checktheairhosesforanykinkorbreak.Forreplace-
ment,pleasecontactyourGFequipmentprovider.

18 765000-INS-LAB-RevB10
Fuse replacement
tool needed: small screwdriver
1. Ifyoususpectablownfuse,discon-
nect the plug from the wall outlet
immediately.
2. Use a small screwdriver to remove
the cover of the fuse holder (fuse lo-
cations are shown in picture at right).
3. Insertanewfuseofthecorrectrating(T1A/250V,VDE
approved).
4. Replacethefuseholdercover.Ensurethatfuseholder
cover is securely installed.
Air lter replacement
tool needed: small screwdriver
1. Useasmallscrewdrivertoremove
theairlterplatelocatedatrearof
pump(lterlocationisshownin
picture at right).
2. Removethelter.Thelterisreus-
able,ifnottorn,andcanbewashed
gently with a mild detergent and
water.Drythelterbeforeuse.
3. Replacethelterandcover.Ensurethatltercoveris
securelyinstalled.Replacetheairlterregularlyifitis
gray,torn,ortheenvironmentisdirty.
STORAGE
1.Laythemattressoutatandupsidedown.
2.Rollfromtheheadendtowardthefootend.
3.Stretchthefoot-endstraparoundtherolledmattressto
prevent unrolling.
4. Store mattress and pump in a dust-free environment
with no exposure to direct sunlight.
Caution: Do not fold, crease or stack the mattress.
fuse
filter

765000-INS-LAB-RevB10 19
SPECIFICATIONS
Pump Specication
Power Supply (Note: see rating
label on product)
AC 120V 60 Hz 0.17A (for 120V system)
Fuse Rating T1A, 250V
Cycle time Fixed / 10 minutes
Dimensions (L x W x H) 11.4" x 7.9" x 4.6" (29.1 x 20 x 11.7 cm)
Weight 5 lb (2.2 kg)
Environment Temperature Operation: 50°F to 104°F (10°C to 40°C)
Storage: 5°F to 122°F ( -15°C to 50°C)
Shipping: 5°F to 158°F ( -15°C to 70°C)
Humidity Operation: 10% to 90% non-condensing
Storage: 10% to 90% non-condensing
Shipping: 10% to 90% non-condensing
Classication Class II with functional earth, Type BF, IPX0
Applied Part: Air Mattress
Not suitable for use in the presence of a
ammable anesthetic mixture (No AP or APG
protection)
Mattress Specication
Dimensions (L x W x H) 78.7" x 35.4" x 8" (200 x 90 x 20.3 cm)
Note: Specifications are subject to change without notice.

20 765000-INS-LAB-RevB10
LIMITED WARRANTY
GFHealthProducts,Inc.warrantstheLumex®AltaDyne®
Sensor Plus 765000 Alternating Pressure Mattress Sys-
tem with Active Sensor Technology for a period of twelve
monthsfordefectsinworkmanshipandmaterials.Ifa
productisdeemedtobeunderwarranty,GFHealthProd-
ucts,Inc.shallprovide,atitsoption,(1)replacementof
anydefectivepartorproductor(2)acreditoftheoriginal
sellingpricemadetoGFHealthProducts,Inc.'sinitialcus-
tomer. The warranty does not include any labor charges
incurred in replacement part(s) installation or any associ-
atedfreightorshippingchargestoGFHealthProducts,Inc.
The warranties contained herein contain all the represen-
tations and warranties with respect to the subject matter
ofthisdocument,andsupersedeallpriornegotiations,
agreements and understandings with respect thereto.
Therecipientofthisdocumentherebyacknowledgesand
representsthatithasnotreliedonanyrepresentation,as-
sertion,guarantee,warranty,collateralcontractorother
assurance,exceptthosesetoutinthisdocument.
