Lumilum B34XTS Series User manual

SKU: LUM-B34XTS
Available Colors: RGB (Color Changing)
IP Rating: IP65 (Indoor and Outdoor)
Voltage: 120V AC
Power Output: 3 Watts/.
Reel Length: 164 . (50 meters)
Dimensions: 0.70” X 0.33” Inches (W X H)
CRI: -
LED Diodes: 24/.
Chip Type: SMD 5050
Lumens: -
Operating Temp: -13°F ~ 113°F
SPECIFICATIONS:
PRODUCT FEATURES:
PERFORMANCE:
USES:
©Lumilum LED Lighting (305)-233-2844
www.lumilum.com
Page 1 of 5
ETL Certified
Dimmable
Cuttable every 12 inches (1 .)
Controlled with DMX Decoder/Controller
50,000+ hours of rated life
UV protected and fire retardant
LUMILUM 120V LED LIGHT STRIP
120V B34XTS SERIES
LED MADE SIMPLE.
Color Model Color
Temp.
CRI Lumen/
.
Beam
Angle
Power
Consumption/.
Voltage Current/.
RGB
LUM-B34XTS-025 (25. reel)
LUM-B34XTS-050 (50. reel)
LUM-B34XTS-164 (164. reel)
Color
Changing
- - 120° 3W 120V 0.03A
Shipping Dimensions & Weight:
25. spool | 8.3” x 8.3” x 4.2”, 4.6 lbs
50. spool | 8.3” x 8.3” x 6.5”, 7.7 lbs.
164 . spool |13” x 13” x 9.1”, 24.6 lbs.
IP65
WARRANTY
3 YEAR
• Cove, Soffit, Indirect Lighting
• Commercial Building Exteriors & Signage
• Aquariums & Stages, Concert Venues
• Casinos, Nightclubs, Bars, Resorts
• Accent & Decorative Lighting
• Architectural Design & Wall Washing
• Restaurants, Hotels, Spas, Theaters
• Bridges, Columns, Exterior Structures
• Patios, Paths, Decks, Fences
• Game & Play Rooms
©Lumilum LED Lighting (305)-233-2844
www.lumilum.com
Page 2 of 5
ACCESSORIES
Connecting Pin
LUM-B34XTS-PSC
Mounting Clips (Set of 10)
LUM-B34XTS-CL
Splice Connector
LUM-B34XTS-IC
Shrink Wrap
LUM-SRKWAP-120B34
(Sold in 12” Increments)
Waterproof Inline Connector
LUM-B34XTS-IJC
(3 Wire/RGB)
Waterproof Inline Connector
LUM-B34XTS-IJ4
(4 Wire/RGB)
End Cap (Set of 2)
LUM-B34XTS-EC
CABLES
RGB Strip to DMX Extension Cable
LUM-B34XTS-XT-XX
(10, 75, & 175)
3 or 4 Conductor SJTW Cable
LUM-B34SJW3X-500
LUM-B34SJW4X-500
(Sold in 12” Increments)
Strip to DMX Connector Cable
LUM-B34XTS-CX-4FT
B34XTS Interconnector Cable
LUM-B34XTS-CC-XX
(6in, 12in, 20in, & 40in)
*Available in Black and White
8 Y-Connector Cable
LUM-B34XTS-YCO
©Lumilum LED Lighting (305)-233-2844
www.lumilum.com
Page 3 of 5
PVC U-CHANNEL
4. PVC U-Channel
LUM-B34XTS-PVCU4
(Not Recommended for Outdoor)
DMX DECODERS &
CONTROLLERS
ALUMINUM U-CHANNELS
DMX1 Decoder/Controller (IP20 Rated/Indoor)
LUM-B34XTS-DMX1
DMX Color Wheel Wall Panel
LUM-RGBUX8
DMX2 Decoder/Controller (IP65 Rated/Outdoor)
LUM-B34XTS-DMX2
0.5” Aluminum U-Channel
(Set of 6)
LUM-B34XTS-U0
Aluminum U-Channel
LUM-B34XTS-XX (1 or 4)
SURFACE MOUNT CHANNEL
WITH DIFFUSER
Aluminum Surface Mount
(Mega Channel)
LUM-P3535C-XX (4 or 8)
Endcap Solid
LUM-P3535C-ECN
Endcap with Hole
LUM-P3535C-ECH
COLOR OPTIONS:
INSTALLATION DIAGRAM : DMX DECODER/CONTROLLER
Please reference our DMX cutsheets for further instructions.
©Lumilum LED Lighting (305)-233-2844
www.lumilum.com
Page 4 of 5
Model: LUM-B34XTS-DMX2
IP65 DMX Decoder | Controller
IP65
Button: 1
Change between Modes & DMX Address
Button #4: -Enter- Function
When using Mode Functions:
Press once and then use buttons #2 or #3 to set
variables within the chosen mode function using
DMX-Address 1 or 2: Press onceand the use button
#2 or #3to set exact address.
Button: 4
Button: 3
Button: 2
Toggle Up
Toggle Down
Button #4: -Enter- Function
1. Press Button #1 until DMX Address or Mode
shows.
2. Press Button #4 (enter)
3. Use Buttons #2 and #3 to toggle between
Navigation Sequence
R
G
B
+
R
G
B
+
R
G
B
+
Output: 3 Pin DMX Output: 5 Pin DMX Output: RJ45 DMX
Input: 3 Pin DMX
Vent Valve Fuse 12A Power In
110-125V
Input: 5 Pin DMX Input: RJ45 DMX
DMX-Decoder Controller
• LUM-B34XTS-DMX2
OR
3 Pin DMX XLR
or
5 Pin DMX XLR
or
Cat 5 (RJ45) or Cat 6
Ethernet Cable
DMX Control Panel
Compatible with most DMX Control Panels
Channel Type: SKU: Channel Profile: End Caps: Channel Mockup:
Aluminum
U-Channel
LUM-B34XTS-U0/U1/U4 N/A
PVC
U-Channel
LUM-B34XTS-PVC N/A
Aluminum
Surface Mount
Mega Channel
LUM-P3535C-XX
(4 or 8)
Using Lumilum®Mounting Bracket (LUM-B34XTS-CL)
Mounting Bracket
35mm (1.38")
35mm (1.38")
32mm (1.26")
31mm (1.22")
RGB Color Changing
©Lumilum LED Lighting (305)-233-2844
www.lumilum.com
Page 5 of 5
R
G
B
+
R
G
B
+
B34XTS RBG Interconnector Cable
(4 Pin Female Hub to 4 Pin Male Hub)
• LUM-B34XTS-CC-XX
(Available in 6in., 12in., 20in., and 40in.)
Model: LUM-B34XTS-DMX1
IP20 DMX Decoder | Controller
IP20
Button: 1
Change between Modes & DMX Address
Button: 4
Button: 3
Button: 2
Toggle Up
Toggle Down
Navigation Sequence
R
G
B
+
R
G
B
+
Output: 3 Pin DMX
Output: 5 Pin DMX
Output: RJ45 DMX
Input: 3 Pin DMX
Input: 5 Pin DMX
Input: RJ45 DMX
Co
lor Wheel Wall Panel
DMX C
ontroller
• L
UM-RGBUX8
DMX-Decoder Controller
• LUM-B34XTS-DMX1
Cat 5 (RJ45) or Cat 6
Ethernet Cable
For experienced DMX
users, 3 or 5 Pin XLR may
be used.
Model: LUM-B34XTS-DMX1
IP20 DMX Decoder | Controller
IP20
Button: 1
Change between Modes & DMX Address
Button: 4
Button: 3
Button: 2
Toggle Up
Toggle Down
Navigation Sequence
Output: 3 Pin DMX
Output: 5 Pin DMX
Output: RJ45 DMX
Input: 3 Pin DMX
Input: 5 Pin DMX
Input: RJ45 DMX
R
G
B
+
R
G
B
+
DMX-Decoder Controller
• LUM-B34XTS-DMX1
B34XTS RBG Extension Cable
(4 Pin Male Cup to 4 Pin Female Hub)
• LUM-B34XTS-CX-4FT
Model: LUM-B34XTS-DMX1
IP20 DMX Decoder | Controller
IP20
Button: 1
Change between Modes & DMX Address
Button: 4
Button: 3
Button: 2
Toggle Up
Toggle Down
Navigation Sequence
R
G
B
+
R
G
B
+
DMX-Decoder Controller
• LUM-B34XTS-DMX1
Output: 3 Pin DMX
Output: 5 Pin DMX
Output: RJ45 DMX
Input: 3 Pin DMX
Input: 5 Pin DMX
Input: RJ45 DMX
