Luraco LEGEND Series User manual

1
Congratulations on your purchase of the new
Luraco Legend PLUS Medical Massage Chair!
We are pleased that you have chosen Luraco for your massage chair
purchase, and we hope you will enjoy the quality, convenience, and
excellent performance of your new Luraco Legend PLUS Massage Chair.
We know from experience that you will soon be telling your friends and
family about the health benefits of using a massage chair at home, and how
enjoyable and easy it is to operate the Luraco Legend PLUS massage chair.
Customer Assistance
Any updates to this manual can be found at:
www.luracochair.com
Or call Luraco Customer Care toll-free at:
1-800-483-9930 Monday –Friday 8:30 am to 5:00 pm
To save time, please note your serial number and date of purchase
before calling.
© All Rights Reserved. Luraco Health & Beauty, LLC. January 2019
www.luracochair.com

2
TABLE OF CONTENTS
I) INTRODUCTION........................................................................ 3
II) IMPORTANT SAFETY INSTRUCTIONS .................................. 4
Grounding Instructions............................................................ 5
Medical Warnings ................................................................... 6
Emergency Stop ..................................................................... 6
Important User Information..................................................... 7
III) INSTALLATION INSTRUCTIONS............................................. 9
Step 1: Unpacking .................................................................. 9
Step 2: Assembly.................................................................... 9
Step 3: Connect Control Panel and Other Electrical
Accessory Devices ............................................................... 10
IV) UNDERSTANDING REMOTE CONTROL FEATURES.......... 11
Home Screen........................................................................ 11
Automatic & Manual Massage Modes.................................. 12
Manual-3D Modes ................................................................ 14
Chair Adjustments ................................................................ 14
Heating Feature.................................................................... 15
Intensity Adjustments............................................................ 15
Speed Adjustments (Available in Manual Mode Only) ......... 16
Users..................................................................................... 17
Bluetooth Media Streaming .................................................. 17
V) HEALTHCARE DEVICE (Optional)........................................ 18
About this device .................................................................. 18
Taking a Measurement......................................................... 19
VI) TROUBLESHOOTING ............................................................ 20
VII) WARRANTY INFORMATION.................................................. 22
For Home Use: ..................................................................... 22
For Commercial Use:............................................................ 23
VIII) DISCLAIMERS ........................................................................ 25
IX) EXTENDED WARRANTY REGISTRATION........................... 25

3
I) INTRODUCTION
Luraco L-Track Legend PLUS: The Newest Addition to The World’s #1
Medical Massage Chair®Product Line
INNOVATION + QUALITY + LUXURY
In an effort to revolutionize the massage experience, Luraco Health &
Beauty, LLC, an industry leader in massage chair manufacturing has
successfully developed an upgraded L-Track model of The World's #1
Medical Massage Chair product line. Bringing together all aspects of
innovative technologies, massage therapy techniques, and healthcare
features into one ingenious and comprehensive machine, the L-Track
Legend PLUS is truly among the industry's Best Massage Chairs.
Outstanding Features and Technologies:
•Latest technology in L-Track and 3D Robotics (Massage rollers go
from user's head to hamstrings)
•Easy-to-use touch screen controller
•Up to 5 personal user memory settings so the whole family can
enjoy
•5 levels of intensity control
•Powerful Bluetooth speaker for media streaming
•User height recommendations of up to 6' 5" and weight up to 265
pounds
•Latest in intelligent sensor technology for accurate automatic body
shape and neck detection
•Noise reduction technology - very quiet operation
•Body stretching
•Advanced foot massage with double-rollers and air-calf massage
•Body heat with 5 intensity levels
•Experience the latest in massage technologies featuring ZERO
GRAVITY (neutral body posture position) which has been proven to
heighten the state of relaxation and well-being
•9 automatic preset programs
•Limitless customizable individual body part massage profiles
•Sectional control with 5 levels of intensity and speed
•Intelligent self-diagnostics
•Research & Development in U.S.A., Structural Hardware & Leather
are made in Taiwan, Electronic Hardware made in U.S.A., Software
made in U.S.A., Final Assembly in U.S.A.
•U.S. based customer service and after sales support
•FDA, UL, and CE listed
Relax and enjoy an accurate automatic body shape detection preparing you
for the most advanced 3D robotic massage, providing an outstanding

4
head to leg massage with a roller track length of 58 inches. Experience a
3-layered calf and foot massage, heat therapy for the back and feet, a
comfortable full-arm massage and advanced foot massager with double
rollers, features not found on any other massage chairs.
II) IMPORTANT SAFETY INSTRUCTIONS
1) When using an electrical mechanism, basic precautions
should always be followed, including the following: Read
all instructions before using.
WARNING –To reduce the risk of burns, fire, electric shock, or
injury to persons:
1) The main power switch is marked with international symbols “O” and
“I”. The switch in position “I” means that system is on, and the switch
in position “O” means that system is off.
2) The chair should never be left unattended when plugged in. Unplug
from outlet when not in use and before putting on or taking off parts.
3) DO NOT wear shoes, jewelry, glasses, or watches of any kind.
4) Close supervision is necessary when this appliance is used near
children, invalids, or disabled persons. Keep children away from the
extended foot support (or other similar parts).
5) Use the chair only for its intended use as described in this manual.
Do not use attachments not recommended by the manufacturer.
6) Never operate the chair if it has a damaged cord or plug, if it is not
working properly, if it has been dropped, damaged, or exposed to
water. Return the chair to an authorized service center for
examination and repair.
7) Keep the cord away from heated surfaces.
8) Do not use outdoors.
9) Do not operate where aerosol (spray) products are being used or
where oxygen is being administered.
10) To disconnect, turn power switch to the off position, then remove
plug from outlet.
11) Connect this appliance to a properly grounded outlet only. See
Grounding Instructions.
12) Do not play with roller mechanism.
13) Do not play with actuators.
14) Keep the cord out of heavy traffic areas. To avoid fire hazard,
NEVER put the cord under rugs or near heat generating devices.
15) Always unplug the power cord from the electrical outlet immediately
after use and before cleaning.
16) Do not operate any chair with damaged parts.
17) Any other use not recommended by the manufacturer may cause
electrical shock or injury to persons.
18) Do not touch or re-wire the connectors to the master-box.

5
19) Do not attempt to repair or adjust any electrical or mechanical
functions on this unit. Doing so will void the warranty.
20) Please be aware that some household PESTS like to hide in
electronic devices. Rodent or bug damage are NOT the
responsibility of Luraco Health & Beauty. Keep back cover of the
chair free from dirt, dust, and household pests.
After reading this user’s guide, if you have any questions or
comments, please call 1-800-483-9930, contact our technical
support department at [email protected] or visit our website
www.luracochair.com for more information.
2) Grounding Instructions
This product must be grounded. If there is a malfunction or breakdown,
the grounding provides a path of least resistance for electric current to
flow, thus reducing the risk of electric shock. This product is equipped
with a cord having an equipment-grounding conductor and a grounding
plug. The plug must be plugged into an appropriate outlet that is properly
grounded in accordance with all local codes and ordinances.
DANGER - Improper connection of the equipment-grounding conductor
can result in a risk of electric shock. Check with a qualified electrician or
serviceman if you are in doubt as to whether the product is properly
grounded. Do not modify the plug provided with the product, if it does not
fit the outlet; have a proper outlet installed by a qualified electrician.
Followed by either instruction a) or b) below:
(a) This product is for use on a normal power circuit, and has a
grounding plug that looks like the plug illustrated in sketch A in
Figure 1. A temporary adapter that looks like the adapter
illustrated in sketches B and C may be used to connect this plug to
a 2-pole receptacle as shown in sketch B if a properly grounded
outlet is not available. The temporary adapter should be used
only until a properly grounded outlet (sketch A) can be
installed by a qualified electrician. The green colored rigid ear,
lug, or the like extending from the adapter must be connected to a
permanent ground such as a properly grounded outlet box cover.
Whenever the adapter is used, it must be held in place by a metal
screw.
(b) This product is for use on a normal power circuit, and has a
grounding plug that looks like the plug illustrated in sketch A in
Figure 1. Make sure that the product is connected to an outlet
having the same configuration as the plug. No adapter should be
used with this product.

6
Fig.1: Grounding Instruction
Medical Warnings
•Pregnant women
•People with distorted joints, broken bones, skin infection or
injury
•Children under 12 years of age
If you have any of the above medical issues or any other concerns,
please consult your doctor before using the massage chair.
Do Not
•Allow children or pets to play near the chair, especially during
operation.
•Use any massage function on the head.
•Massage abdominal area or knee cap region.
•Leave mobility impaired or speech impaired people alone in
chair.
•Wear shoes, jewelry, glasses, or watches of any kind.
Emergency Stop
In case of emergency, press the power button on the remote one time
to stop the system.
Additional Safety Precautions
•Do not use more than 30 minutes per session.
•Do not place or store the chair near damp places such as
swimming pools or bathrooms.
•Do not forcibly press on the massage rollers.
•Do not stand on the footrest or store heavy items on the chair.

7
•Do not use in an environment which is dusty, greasy, or lacking
oxygen.
•Do not place near steam, oven, open fire, or heat.
•Do not place directly in the sun.
•Do not use electric blanket while using the massage chair.
•Do not use outdoors.
•Do not use while smoking.
•Do not eat or drink in the chair when operating.
•Do place this machine horizontally with space over 81 inches,
enough for full recline mode.
•Do place on level floor.
•Do always wear suitable clothing while using.
Note: Do not use the chair as a bed or to sleep on over a long period of
time. The recommended time of use is 20 minutes. Prolonged massaging
may cause aches, muscle or nerve issues. (The preferred total duration of
massaging within the day should be 30 minutes or less).
Important User Information
•This device should not be used until grounded.
•Do not move the chair while in use
•Do not place heavy objects or sit on the armrest, foot rest or back of
the chair to avoid overturning or damaging the chair.
•Do not pull the fabric forcefully or stab it with sharp objects which
can result in personal injury or damage to the chair.
•Do not move the chair on wooden floor, carpet, or other easily
damaged flooring.
•Children and pets should not be allowed to play around chair.
•Please be sure that no people, pets, or other objects are behind the
chair or under the legs before reclining the leg massager.
•Do not put your hands or head under the chair.
•When entering or exiting the chair, make sure that the foot rest is in
the lowest position.
•Do not use immediately after meals.
•Do not use the massage chair when your body is wet or moist as it
may result in electrical shock.
•Do not operate with more than one person in the chair.
•Do not use when wearing head ornamentation as it can result in
injury.
•Do not stumble over electrical wires or connections
•Do not touch the inner parts of the chair as this can cause damage
and electrical shock.
•Do not dismantle and remove inner parts, or repair the massage
chair.

8
Do Not Use the Chair under the Following Conditions
•When the chair has been exposed to water or fails to operate.
•If power cable is damaged.
•Please stop using the massage chair immediately and consult a
doctor if you feel abnormal or extremely achy during the course of
the massage.
•If power failure occurs.
•When the massage chair malfunctions during the course of
operation.
•Do not operate during a thunderstorm.
Methods of Storage
•Do not dismantle the back of the chair.
•Keep the massage chair free of dust.
•Cover the chair with a dust-free cloth to prevent dust from collecting.
•Do not store in a hot, humid, damp place nor in direct sunlight or
heat.
Cleaning Methods
•Before cleaning, to avoid shock, unplug from electrical source.
•Clean the chair surface with neutral or mild detergent.
•Use leather cleaner and leather conditioner.
•Dust can be cleaned off with a damp cloth and let air dry.
•Do not spray pesticide on device.
•Do not use a damp cloth on the electrical components which can
cause shock and damage.
Fig.2: Space Requirement for Chair Operation
47in(119cm),Max
81in
(205cm),
Max
37in
(94cm)

9
III) INSTALLATION INSTRUCTIONS
There must be enough space around the chair for proper operation. There is
a required minimum clearance of 32 inches (81cm) from the front of the chair
and 24 inches (68cm) from the wall to the back edge of the base of the chair.
1) Step 1: Unpacking
Carefully take out the armrests, main body, and toolkit (contains control)
from the boxes.
Note: The Luraco Legend PLUS requires at least two people to assist
with assembly.
2) Step 2: Assembly
i) Please refer to Fig.3 and follow the steps (1-3) below to install
the armrests.
ii) Connect the air tubes (1). Please note: The alphabetic labels
on each air tube must be matched in order for the chair to
operate correctly.
iii) Insert the armrest guides (2)
iv) Install the mounting screws (3)
Fig.3: Armrest Installation
ATTENTION: Be sure no children, pets,
or objects are around chair.
Allow enough space for installation.

10
ATTENTION!
•Be sure no objects are behind the chair before reclining
•For a higher intensity foot massage, remove the pads located on top
of the foot rollers.
•For a higher intensity neck and shoulder massage, flip the pillow to
the back of the chair
3) Step 3: Connect Control Panel and Other Electrical
Accessory Devices
i) Please refer to Fig.4 below for remote control and other
accessory devices connections.
Note: This panel is located on the right side of the chair slightly below the
armrest
Fig.4: Side Panel
ii) Plug the power cord into the back of the chair.
iii) Power is turned on/off by a switch on the back of the chair
(Switch to position I to turn on and position 0 to turn off).
iv) Use the remote to choose the massage functions.

11
IV) UNDERSTANDING REMOTE CONTROL FEATURES
Fig.5: Home Screen
The Luraco Legend PLUS comes with an advanced touchscreen keypad. It’s
extremely easy to operate and user-friendly.
Please note: The default passcode is: 1111
1) Home Screen
•Auto:
Allows user to select one of the 9 automatic massage
programs.
•Manual:
Allows user to customize a massage profile that best fits their
body needs for optimal results. After an optimized profile is
created, user can save it under “User Profile.” User can then
recall the saved profile next time chair is used.
•Manual-3D:
Allows user to fully control the 3D robotic system.
•Adjustment:
Allows user to adjust the chair to their preferred positions. The
chair position will be stored in user profile when saved.
•Heat:
Allows user to turn on/off the heat and to adjust the heat level.

12
•Intensity:
Unlike many other chairs on the market, the Legend PLUS
gives the user control of the massage intensity for different
parts of the body. Intensity levels are also stored in user profile
when saved.
•Speed:
Allows user to adjust speed of the massagers while in the
manual mode. Speed levels are also stored in the user profile
when saved.
•Settings:
Allows user to setup system preferences and passcode
protection.
•Users:
Allows up to 5 users to save their customized massage
profiles, chair position, and intensity levels.
•Power Button:
Starts/Stops the massage chair. The default timer for each
massage session is 20 minutes. Pressing this button a second
time will put the chair back to its initial position automatically.
Outer ring allows navigation around and between screens.
2) Automatic & Manual Massage Modes
Fig.6: Automatic and Manual Mode Screen

13
i) Automatic Massage Modes
•Health Massage Mode:
Specifically designed for health enhancement that mainly
focuses on health aspects like releasing muscle strain,
improving blood flow, soothing anxiety, and helping to relieve
depression. This mode is the default massage mode when you
start the chair.
•Demo Mode:
Provides a full-body massage. It combines the best features of
all massage into a short cycle.
•Shiatsu Massage Mode:
Provides a high-intensity and point-based massage with varied
and rhythmic pressure on different parts of the body. It helps
relieve severe tension in muscles and connective tissues,
relieves blockages and rejuvenates the body.
•Stretch Massage Mode:
Provides stretching and promotes flexibility throughout the
body. It relaxes muscles, enhances muscular coordination,
helps improve posture, and provides a greater sense of well-
being.
•Night Massage Mode:
Designed specifically for evening/night use to enhance sleep,
focusing on relieving postural stress after a day’s work. It also
helps relieve anxiety, depression, and headaches.
•Air Massage Mode:
Provides air massage only. The 3D system is turned off in this
mode.
•Morning Massage Mode:
Designed specifically for morning use, focusing on energizing
the body by providing stretching, mobilizing joints, and
promoting flexibility with some muscle exercise.
•TV Mode:
Puts the chair into a comfortable position for watching TV.
•Soft Massage Mode:
Applies a very soft and gentle massage throughout the body.
This mode is good for relieving headaches, muscle strains and
helps to improve sleep.
ii) Manual Massage Modes
As shown in Figure 6, this mode allows user to customize a
massage profile that best fits their body needs for optimal results.
After an optimized profile is created, user can save it under ”Users
Profile”. User can then recall the saved profile next time chair is
used. Simply press on the buttons connected to the body part
diagram to turn the massage on/off.

14
3) Manual-3D Modes
This screen allows user to fully control the 3D robotic system for the
back.
Fig.7: Manual 3D Mode Screen
4) Chair Adjustments
Fig.8: Chair Adjustment Screens

15
These screens allow user to adjust the chair angle to their favorite
position.
The shoulder position can also be adjusted after the body scanning.
The sensor sensitivity feature allows user to adjust the body scanning
sensor sensitivity for a more accurate body scanning and shoulder
detection. If the chair detects your shoulder position higher than your
actual shoulder position, decrease the number on the sensor sensitivity
in the figure on right below. Please note: Chair position adjustments
can be saved in a user’s profile. However, in some modes, chair
adjustments may be not available.
5) Heating Feature
This screen allows user to turn the heating feature in the back & feet
on/off and to control the intensity level.
Fig.9: Heat Adjustment Screen
6) Intensity Adjustments
This feature allows user to adjust the massage intensity for different
parts of the body.

16
Fig.10: Intensity Adjustment Screens
7) Speed Adjustments (Available in Manual Mode Only)
This feature allows user to control the speed of the Tapping and
Kneading rollers in the 3D system.
Fig.11: Speed Adjustment Screen

17
8) Users
The Luraco Legend PLUS provides an advanced feature for multiple
users. This feature allows each user to save customized massage
profiles, chair positions, and intensity levels. All data (chair position,
body scanning, intensity, heat, and massage modes) can be saved
and opened in User’s Profile setting. Up to 5 different user profiles
can be saved.
Fig.12: Users Profile Save/Open Screen
9) Bluetooth Media Streaming
The Legend PLUS uses an integrated, high-quality, and high-power
(10 Watts) speaker system using the latest Bluetooth technology for
music streaming.
Connecting to the Luraco Bluetooth speaker is just like
connecting to any other Bluetooth device in your home.
Please refer to your phone Manufacturer's Handbook for
guidelines but generally speaking, these are the steps to be
followed:

18
On your Smartphone, Tablet or Laptop (that has the Bluetooth
feature):
1. Go to Bluetooth setting
2. Select Search for available Devices
3. Select - "Luraco" and pair together. If “Luraco” is not
visible on your device, reboot the chair and/or your device
4. Play whatever you want on your Smartphone, Tablet or
Laptop
5. Listen, relax, and enjoy
V) HEALTHCARE DEVICE (Optional)
1) About this device
The L-Track Legend PLUS Massage Chair has the capability to
operate an optional health monitoring device made by OMRON. The
device measures blood pressure and heart rate of the user. Connect
the blood pressure monitor to blood pressure port on the side panel
of the chair before operating (Refer to Fig.4).
Fig.13: Wrist Blood Pressure & Heart Rate Monitor
Power
connector is
located in the
bottom of the
device. Use
the cable
provided to
connect this
device to the
chair. See Fig.4
for more
details.

19
Fig.14: Display Screen
2) Taking a Measurement
i) Wrap the cuff directly against your skin. Place the cuff over
your left wrist as shown in Fig. 15. Fold the remaining part of
the wrist cuff back out of the way.
Fig.15: Device Setup Before Taking a Measurement
ii) Sit comfortably on the chair in the upright position with your
legs uncrossed, your feet flat on the footrest and place your
elbow on the armrest in order to relax before starting blood
pressure measurement
iii) Hold your arm with the device at heart level. Hold your elbow
firmly to avoid body movement. Sit still and do not talk or move
during the measurement (Fig. 16)
iv) Press the START/STOP button
