Lutron®Homeworks®QS
Luxor® Controllers with ZD Technology® and ZDC Technology®
Lighting Accessories by Hunter Industries
Integration Guide
LUXOR

2
Table of Contents
3 System Requirements
4 Getting Started
5 Adding Devices
8 Link Assignments
9 Edit Integration IDs
10 Telnet Logins
11 Program Keypads
12 Transfer Project
13 Luxor Controller Conguration
14 Enable Lutron
15 Troubleshooting
LUXOR

3
Getting Started
Creating a Project
1. Name the project.
2. Click on the Activate tab.
3. Select "processors" in drop-down box.
4. Uncheck the "4HHuunntteerr" box.
5. Record the processor IP address.
System Requirements
Lutron Homeworks QS Requirements
Soware: Homeworks QS

4
Getting Started
6. In the Design tab, select Controls from the drop-down box.
7. Press "+" next to Exterior to add the location.
Note: The location name should correspond to the Luxor location (e.g., front yard, backyard, etc.).

5
Adding Devices
Adding Devices
1. In the Controls section, select the Dimmer/QSG tab.
2. Click "+" to add the HQR-3LD 300W Lamp Dimmer.

6
Adding Devices
3. Enter "Luxor All Groups" in the Device Location eld.
4. Enter "Luxor Zone All" in the Name eld.
5. Click "Done."

7
Adding Devices
6. For the device named Luxor All Groups, click "+."
7. Add HQR-3LD 300W Dimmer to the Luxor All
Groups device.
8. Enter "Luxor1" in the Device Location eld.
9. Enter "Luxor Zone 01" in the Name eld.
10. Click "Done."
Repeat steps 6–10 until a device has been added for
all available Luxor Groups.

8
Link Assignments
Link Assignments
1. Conrm all Luxor groups have been added as a device.
2. In the Design tab, select "link assignment" from the drop-down box.
3. Assign the link to Luxor Group devices.

9
Edit Integration IDs
Edit Integration IDs
1. In menu bar, select "Tools" and click "Congure
Integration."
2. Select "Zones" in the "Assign integration IDs to:"
drop-down box.
3. Double-click the ID eld for the "Luxor Zone All"
group and enter 500.
4. Double-click the ID eld for the "Luxor Zone 01"
group and enter 501.
5. Edit ID numbers for the remaining Luxor Groups.
6. Click "Done."

10
Telnet Logins
Telnet Logins
1. From the menu bar, select "Tools" and click
"Congure Integration."
2. In the Conguration Integration menu, select
Telnet Logins.
3. At the bottom of the screen, click
"+ Add Telnet Login."
4. Enter "hunter" in the Username eld.
5. Enter "4HHuunntteerr" in the Password eld.
6. Uncheck the "Allow Homeowner Editing" box.
Note: The "Bad Login" error message will be
displayed if the Username and Password are
not named "hunter" and "4HHuunntteerr."

11
Program Keypads
Program Keypads
1. From the Program tab, select Keypad
to control Luxor Groups.
2. Select the Device Location.
3. Select the Keypad button.
4. Select "Luxor Groups" to be controlled by
the Keypad button.
5. Set a dimmer level.
Repeat steps 3–5, until all Luxor Groups have
been assigned to the Keypad.
Note: Default levels remain unchanged for Fade
and Delay.

12
Transfer Project
Transfer Project
1. In the Transfer tab, click the "Start Transfer"
button.
2. Wait until the transfer is complete.
3. Next, congure the Luxor controller (refer to
pages 13–14).
Note: Ignore all "Device not addressed" warnings.
Luxor Group devices do not need to be activated
since they are used as placeholders.
If additional Luxor Groups and devices are added in
the future, the project must be re-transferred.

13
Luxor Controller Conguration
Luxor Controller Conguration
1. From the Luxor home screen, select "Setup."
2. Select Wi-Fi (or LAN for hardwire connection).

14
Luxor Controller Conguration
3. Verify the router connection.
4. Select "Lutron."
5. Enter the Lutron IP address.
Note: The IP address can be found on the Main
Repeater (refer to page 4).
6. Enter 500 in the "Integration ID Start #" eld.
Enable Lutron
7. Select the "Lutron Enabled" box.
8. Conrm "Connected to Lutron."
Note: The Luxor controller will attempt
to connect if the Lutron system is running.

15
Troubleshooting
Connection Error
If the Luxor controller fails to connect, verify the
Lutron IP address is correct.
"Bad Login" Message
The "Bad Login" error message occurs when
the Lutron login username and password do
not match "hunter" and "4HHuunntteerr"
(refer to page 10).
If changes are made, the project will need
to be transferred again (refer to page 12).
