Lutron Electronics Sivoia QED SVQ-3PIT User manual

Description
The SVQ-3PIT Infrared Hand-held Remote
Control provides remote blind operation from
the palm of your hand.The Infrared Hand-held
Remote Control transmits signals to Sivoia®or
Sivoia QEDTM Electronic Drive Units (EDUs).The
Infrared Hand-held Remote Control is
compatible with learnable remote controls.To
access advanced features, please refer to the
Sivoia QED Wiring and Programming Guide or
the Sivoia QED Technical Reference Guide.
Operation
Point the Infrared Hand-held Remote Control
at the Sivoia or Sivoia QED IR receiver, then
use the buttons as shown below.
The Infrared Hand-held Remote Control is
safe for use around baths and spas.
DO NOT SUBMERGE IN WATER.
Battery Replacement
The SVQ-3PIT Infrared Hand-held Remote
Control uses 3 AAA batteries which are pre-
installed (see diagram). For best results use
Energizer®brand alkaline batteries. Do not
use NiCad batteries.
To replace batteries:
1.Remove the battery cover.
2.Replace with 3 size AAA alkaline
batteries as shown.
3.Replace the battery cover.
Press Open
button once:
Blind(s) will open.
Press Preset 1
button once:
Blind(s) will go to
preset level 1.
Press Preset 2
button once:
Blind(s) will go to
preset level 2.
Press Preset 3
button once:
Blind(s) will go to
preset level 3.
Pressing any
button while the
blind(s) are
moving will stop
the blind(s).
Install 3 AAA
Alkaline batteries
with terminals as
shown.
Press on arrow, slide and
lift off battery cover.
Press Close
button once:
Blind(s)
will close.
Press up
to raise:
Blind(s).
Press down
to lower:
Blind(s).
Operating Instructions
Please Leave for Occupant
SVQ-3PIT
Infrared Hand-held
Remote Control
Note: Pressing any button while the
blind is moving will stop the blind.
Easy Preset Programming
1. Adjust blind(s) to desired position.
2. Point the SVQ-3PIT at any of the
Sivoia or Sivoia QED IR receivers.
3. Press and hold the desired Preset
button for 5 seconds.
LUTRON
Sivoia QEDTM

Lutron Electronics Co., Inc.
7200 Suter Road
Coopersburg, PA 18036 U.S.A.
Made and printed in the U.S.A. 4/05 P/N 040-208-12
Troubleshooting
Electronic Drive Unit (EDU) power is OFF.
Dead, low,or no batteries in the Infrared
Hand-held Remote Control.
Infrared Hand-held Remote Control is
too far away from the IR receiver.
Batteries inserted incorrectly.
The desired preset button was held for
less than 5 seconds.
Presets are locked.
Infrared Hand-held
Remote Control has no
effect on the Electronic
Drive Unit (EDU).
Presets are not
being saved.
Restore power.
Install new batteries.
Try moving closer to the
blind(s) you wish to
control.
If an IR receiver is
installed on the Electronic
Drive Unit (EDU), verify
that it is properly installed
and the IR receiver is not
obstructed (e.g. by
curtains, fascia, drapes).
Install batteries per
diagram.
Press and hold the
desired preset button for
at least 5 seconds.
Unlock presets. Refer to
the setup guide that
accompanied the EDU.
CausesProblem Remedies
Limited WarrantyTechnical Assistance
Lutron will, at its option,repair or replace any unit that is
defective in materials or manufacture within one year after
purchase. For warranty service,return unit to place of purchase
or mail to Lutron at 7200 Suter Rd., Coopersburg, PA 18036-
1299, postage pre-paid.
This warranty is in lieu of all other express warranties, and the
implied warranty of merchantability is limited to one year from
purchase.This warranty does not cover the cost of installation,
removal or reinstallation, or damage resulting from misuse,
abuse, or damage from improper wiring or installation.This
warranty does not cover incidental or consequential damages.
LUTRON’S LIABILITY ON ANY CLAIM FOR DAMAGESARISING
OUT OF OR IN CONNECTION WITH THE MANUFACTURE, SALE,
INSTALLATION,DELIVERY, OR USE OF THE UNIT SHALL NEVER
EXCEED THE PURCHASE PRICE OF THE UNIT.
This warranty gives you specific legal rights, and you may have
other rights which vary from state to state. Some states do not
allow the exclusion or limitation of incidental or consequential
damages, or limitation on how long an implied warranty may
last, so the above limitations may not apply to you.
These products may be covered under one or more of the
following U.S. patents:5,467,266; 5,671,387; 5,848,634;
6,100,659; 6,201,364; 6,313,588; 6,346,781; 6,497,207;
DES 310,349; DES 370,663; and corresponding foreign
patents. US and foreign patents pending.
Lutron, the Sunburst logo,and Sivoia are registered
trademarks, and Sivoia QED, Spacer System, and “Lutron
Lighting Controls” are trademarks of Lutron Electronics Co., Inc.
©2005 Lutron Electronics Co., Inc.
