LUX dynamics IK10 User manual

Installation Instructions
IK10 and BAR
04 May 2017
IMPORTANT SAFEGUARDS
When using electrical equipment, the following safety precautions should always be taken:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. To avoid the possibility of electrical shock, turn off power supply before
installation or servicing.
2. Product must be installed in accordance with NEC and your local
electrical code. If you are not familiar with these codes and
  requirements,consultaqualiedelectrician.
3. Ensure the mounting surface is capable of supporting the weight of the
luminaire before installation.
4. Due to the weight of the luminaire, as many as 3 people may be necessary
during TANDEM installation.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE

To Install
Aircraft Cable Mounting for use with options:
Hx-xY
H4Px
Threadtheunnishedendoftheaircraft
cable through one end of AC cable
friction lock
Passtheunnishedendoftheaircraft
cable around the mounting point.
Thread end of cable through other
mouth of AC cable friction lock.
Snap hooks through the hanging
braketsontheendofeachxture.
Ensurethextureishanginglevelbeforeproceeding.
1 2
3 4

To Install
Surface Mounting for use with options:
SM
SMH
Fastenthexturedirectlytothe
mounting surface through the
electronics channel.
Please note, this can only be done with
BOTTOM ACCESS option.
Ensurethextureisrmlymounted,
withallhardwareushtothemounting
surface, before relpacing lid and
closing the electronics channel.
1 2

Electrical Connections
Make the following Electrical Connections:
a. Connect the green or green/yellow ground lead to the green wire position of
the terminal block.
 b. ConnecttheblackxtureleadtothevoltagesupplypositionorHot1(for
208/240V wiring).
 b1. Ifapplicable,connecttheRedxtureleadtothevoltagesupplypositionorHot
  2(formultiple-switchinstallations).
 c. ConnectthewhitextureleadtotheneutralsupplypositionorHot2(for
208/240V wiring).
d. Connect the purple/blue dimming positive lead to the supply dimming positive
lead.
e. Connect the grey/red dimming negative lead to the supply dimming negative
lead
