Luxor ECMBSKBC-B User manual

ECMBSKBC-B
Teacher Cart Assembly Instructions
www.luxorfurn.com | 800-323-4656
Tools Required:
Philips Screw Driver
(not included)
Place padded side of drawer (R)
facing up and attach left and right
drawer glides (Q). They will click
when in place.
Q
Q
R
T
T
A
Install the short and long rails
(T) with the included screws (N) onto
the underside of the top shelf (A)
using a Philips screw driver.
Using the screws (L) and wing
nuts (K), attach the electric
outlet (J) and cord wrap (I) to
the cabinet’s back panel (O).
Install the assembled drawer
with the included srews (N)onto
the underside of the top shelf (A)
using a Philips screw driver.
Install the casters into the
bottom shelf (B). Put two
locking casters (H) on the
same short side.
1 2 3 4 5
O (back)
I
J
AB
G
Parts Key
Box 1 Box 2 Box 3
Top
Middle (1)
Middle (2)
A
C
C
Bottom
B
Dx4 Ex4 Fx4
Gx2
Jx1
Ix1 Kx1
Lx1
Ox1
Mx1
Px5
Qx2
Rx1
Sx1
Tx1
Hx2
H
L
K
N
NN
N
Nx8

6
10
7
11
8
12
9
13
Install the fluted legs (F)
onto the bottom shelf (B).
Install the cabinet pack panels (O)
into the fluted legs (F).
Install the first middle shelf (C)
onto the fluted legs (F).
Install the short legs (D)
onto the middle shelf (C),
then install the bin system (M).
Install the second middle shelf (C)
onto the short legs (D).
Install the assembled top shelf (A)
onto the long legs (E).
Install the hooks (P) and
cup holder (S) onto the rails (T).
Final Assembly View
B
F
F
OC
FC
M
C
D
A
E
P
S
D
T
