Writing purpose
Thank you for using SIP-H680W/SIP-H680L IP phone. H680 is a simple office handheld phone with rich
functions. In addition, it also has high-definition sound quality, unique appearance design, multi-language
interchange; supports WIFI module/4G LTE module; compatible with service platforms of many manufacturers,
such as IPPBX, Cloud PBX, IMS core network, softswitch, etc. and friendly user interface fully meet the
communication and collaboration needs of users.
SIP-H680W/SIP-H680L use the same firmware, the software functions are the same, and the difference lies in the
hardware. The following table describes the differences between these hardware.
Product model Description
SIP-H680W Carry WiFi module version
SIP-H680L 4G LTE version
This guide contains all the functions of the phone and instructions for use, so that users can be familiar with the
functions of the T790 IP phone. Before installing the phone, please read the safety instructions and the
contents of the packing list in this guide to use the phone safely and quickly.
For more help, please contact your network administrator or dealer.
Contents of the manual
This guide contains the following:
Ø1.Outline
Ø2.Notes for safe use
Ø3.Getting started with the Phone
Ø4.Phone customization
Ø5.Basic Function
Ø6.Advanced Features

SIP-H680 Series IP Phone User Manual
1.Outline
This chapter mainly provides a brief overview of the T790 IP phone. The main contents are as follows:
Ø1.1 Hardware composition
Ø1.2 Display icon description
Ø1.3 Configuration interface description
Ø1.4 Use documentation
1.1 Hardware composition
Item Name Description
1 Volume up key Increase volume
2Volumue down
key
Volume declined when in standby mode or ringing
interface,during a call.
3Up, down, left
and right buttons Options for switching the display.
4 Hands-free key Press for hands-free mode.
5 Off-hook key/dial Used for calling and entering into the dialing interface.

SIP-H680 Series IP Phone User Manual
(For example, 2 soft key functions are displayed on the
main interface:History ,Menu).
These two soft keys will change with the operation of the
phone keys. In the function description below, the soft
keys refer to these two keys, and the soft key functions
correspond to the text at the bottom of the display screen.
17 LCD screen
Display the information of the phone:
-Register account information(Display name,display
number)
- Time and date,battery level,wifi signal or LTE signal.
- Reminder icon(For details, please refer to the display
icon description)
- Messages(Incoming call, missed call, email message)
- Operation prompt
18 LED indicator Charging indicator.
19 Earphone Audio output when using the handset.
1.2 Display icon description
H680 display screen mainly used icons and their corresponding descriptions are as follows:

1.3 Configuration interface description
The H680 phone supports the following ways to configure the phone:
lPhone LCD configuration
lWeb interface configuration
lQR code configuration

SIP-H680 Series IP Phone User Manual
Quickly configure the phone, through the phone LCD screen and the phone keyboard panel, you can
configure and use the phone functions. After checking the IP address of the phone, you can also enter the IP
address of the phone in the browser to view all the functions of the phone, and configure it through the
browser. If there is no computer around, you can use your smartphone to scan the QR code provided by the
phone for configuration. The details are as follows:
1.3.1 Phone LCD Configuration
Enter the menu through the menu soft keys, you can configure basic settings (language, ringtones, etc.), and
configure advanced settings (account, network, etc.), enter the advanced settings need to enter the administrator
password, the initial administrator password of H680 is admin. At the same time, there are some basic functions in
the menu. Please refer to the function configuration chapter for specific function settings.
1.3.2 Web interface configuration
- To view the IP address (IPv4 or IPv6) of the phone:
It can be viewed in any of the following ways:
1. Press the button.
2. Press the menu soft key -> enter the status option.
After obtaining the IP address of the phone, enter the IP address in the computer web browser, for example:
IPv4 address input (192.168.1.123 or http://192.168.1.123), IPv6 address input ([2003:4998:c:e33::1004] Or
http://[2003:4998:c:e33::1004]),Enter the phone login page and use the login account password to enter the
main interface. The initial administrator account and password are admin. For specific function setting

SIP-H680 Series IP Phone User Manual
introduction, please see the function configuration chapter.
1.3.3 Mobile phone scan code configuration
Get the phone’s QR code through the phone’s QR code function. Before scanning, the smart phone needs to
be connected to the WIFI of the same network as the phone before you can use the smart phone to scan the
QR code to access the phone’s management page. For detailed feature settings, please refer to the function
configuration chapter .
For more help, please contact your network administrator.
The configurable functions of the three configuration ways are compared as follows:
Phone configuration Phone config
uration
Web code co
nfiguration
QR code con
figuration
Status
• •
• IPv4
•
• IPv6
• MAC address
• Version
• Account status
Account
• •
• User information •
• Display name •
• User name •
• Register name •
• Password •
• Server information
• Sip server 1 •
• Sip server 2 •
• Sip port number •
• Re-registration time •
• Proxy server •
• NAT •
• Codec setting ×
• DTMF setting ×
Network setting
• •
• IPv4/IPv6/IPv4&IPv6 •
• DHCP setting •
• Static IP setting •

SIP-H680 Series IP Phone User Manual
• Advanced network setting
• CDP •
• SNMP •
• STUN ×
Features
• •
• Call forward •
• Call transfer •
• Auto Answer •
• Anonymous Rejection •
• Anonymous Call •
• Hotline •
• QR code •
• DND •
• Conference •
•Call waiting • • •
• Auto redial • • •
Advanced features
• •
•Intercom •
•Paging list •
•Message •
•Configuration management ×
•Auto Provision •
Customization
• •
• Time&date •
• Multi language •
• Sound
• Button voice •
• Ring tone •
• Signal tone ×
• call out button •
• Dial plan ×
• DSS keys ×
• Keypad Lock •
• Directory •
• Local directory •
• Blacklist •
• Remote PhoneBook ×
•LDAP × • •
1.4 Us age Do

SIP-H680 Series IP Phone User Manual
cumentation
The technical support manual provided by H680 is as follows:
Name Description Obtain Language
H680 quick
user manual
Includes easy
installation and
phone customization
With IP phone
Chinese/English
Lvswitch company
website download
H680 User
Guide for IP
Phone
Detailed function
introduction and use
Lvswitch company
website download Chinese/English

SIP-H680 Series IP Phone User Manual
2. Notes for safe use
Please read the safety instructions carefully before installing and using the phone to ensure safe and convenient
use of the phone!
lPlease use the power adapter specified by the product (supplied with the package).If you need to use the
power adapter provided by other manufacturers due to special circumstances, please confirm that the voltage
and current of the provided adapter comply with the specifications of this product (see the connection of power
supply and network cable for details), and it is recommended to use safety certified products, otherwise it may
cause damage to the equipment or may even cause a fire or electric shock. Before using this product, please
check whether the power cord is damaged. Do not use damaged power cords and abnormal conditions such as
twisted, stretched, or bundled power cords to avoid fire and electric shock.
lNon-technical service personnel must not disassemble or repair the product by themselves. Improper
installation or repair may cause electric shock, fire and other accidents. At the same time, the warranty service
of your product will also be invalid. If you need technical support, please contact the agent or your network
administrator .
lKeep the temperature and humidity of the product in line with the working requirements of the product. Make
sure that the product is placed flat on the workbench, and check that the non-slip glue on the product base
does not fall off and cause the phone to slide on the platform. Please keep away from electrical appliances with
strong magnetic or electric fields, such as microwave ovens or refrigerators, when placing the equipment. Keep
the equipment away from fire sources.
lDo not put metal objects such as pins and iron wires into vents or gaps. Otherwise, it may cause electric shock
and other injury accidents caused by current passing through metal objects. If similar metal objects fall into the
product, stop using it in time.
lThis product contains small parts inside. When placing the device, keep it out of the reach of children to avoid
accidentally swallowing small parts.
lIf you need to clean the phone, please cut off the power, wipe with a dry cloth, and place it in a ventilated place
to dry naturally after cleaning. The power adapter needs to be kept dry and clean, otherwise accidents may
occur.

SIP-H680 Series IP Phone User Manual
3. Getting started with the phone
This chapter introduces the basic operation of the H680 IP phone, including the following contents:
Ø3.1 Packing list
Ø3.2 Phone installation
Ø3.3 Phone initialization
Ø3.4 Phone standby interface
Ø3.5 Check phone status
Ø3.6 Set up phone network
Ø3.7 Register an account
Ø3.8 Phone input method
3.1 Packing list
H680 IP phone contains the following accessories:
3.2 Phone Installtion
Charge the phone:
Plug the power adapter into a power source socket to start using the charging base.

SIP-H680 Series IP Phone User Manual
3.3 Phone initialization
After the phone is correctly installed and powered on, the phone will start up and display the following
display:
lPhone initialization
The LCD screen displays “Welcome Initializing Please wait ... ” •
lConnect to network (the phone's initial network is automatically obtained by DHCP)
After the phone is successfully turned on, the phone will automatically obtain the assigned IP address,
subnet mask, default gateway, DNS server and other network configuration. If the network cable is
connected after the phone is turned on, the LCD screen will display the prompt of network acquisition.
3.4 Phone standby interface
The display interface after the phone starts normally is as follows:

SIP-H680 Series IP Phone User Manual
The phone standby interface can display the phone’s time, date, phone status (Do Not Disturb, Auto Answer),
account registration status, extension number, label, battery level and WIFI icon, and two soft keys at the bottom of
the LCD screen (History , Menu) label. For the description of the icons on the standby interface, please refer to the
display icon composition.
3.5 Check phone status
The phone status contains the following information:
lNetwork information
IP mode•IPv4 / IPv6 address•subnet mask•default gateway•DNS server
lAccount status
SIP account registration information
lDevice information
Firmware version•product name•hardware version•MAC address•Product ID.
You can check the phone status in the following waysŽ
- Phone interface
1. button or press soft key Menu->Status to check .
2.Press to select,Enter "More..." to view more detailed status.

SIP-H680 Series IP Phone User Manual
- Computer browser interface to view
1. Open the browser.
2.Enter the IP address of the phone (IPv4 /IPv6),192.168.17.39.
3.Enter the phone login page, enter the account and password to log in, the initial account and password
is (admin/admin).
3.6 Set up phone network
H680 can set three network modes:IPv4•IPv6•IPv4 &IPv6.
- Set the network mode
through the phone
interface

SIP-H680 Series IP Phone User Manual
1.Press Menu->WIFI->Wireless network•Select the SSID to connect•press Option->Configuration.
to select the desired mode in the IP mode(IPv4•IPv6•IPv4 &IPv6).
3.If it is IPv4&IPv6 mode, you can configure the mode priority.•Press or to enter selecting mode
priority•to switch.
If you want to set up a DHCP network, fill in other corresponding SSID information and save it.
- Set network mode through web interface
1.Log in to the phone page by IP address.
2.Click Network•N•->WIFI->SSID1•Fill in the corresponding ssid information and enable it, select it in
the WAN interface drop-down box.
