Lyman 7777758 User manual

PART DESCRIPTION PART NO.
A) Power Driver Only 7777746 *
B) Adapter-AC/DC Charger 7999032 *
C) 38 Cal. Case Mouth Brass Brush 7633160 *
D) 45 Cal. Case Mouth Brass Brush 7633161 *
E) Small Steel Primer Pocket Brush (not shown) 7994360
F) Large Steel Primer Pocket Brush (not shown) 7994359
G) Primer Pocket Reamer (Lg. & Sm.) 7999034 *
H) Primer Pocket Cleaner (Lg. & Sm.) 7999035 *
I) Outside Chamfer Tool 7999036 *
J) Inside Chamfer Tool 7999037 *
K) Hex Adapter 7994475 *
* Included With Power Deburring Kit
OPERATING INSTRUCTIONS FOR
LYMAN’S POWER DEBURRING KIT
Power Deburring Tool Kit (#7777758)-110V
(#7777742)-220V
INTRODUCTION
Now reloaders can perform all the important case prep functions
faster and more efficiently than ever before with Lyman's Power
Deburring Kit. High torque rechargeable power driver turns at the
perfect speed for performing inside and outside deburring opera-
tions in seconds. Kit includes all the essential case prep acces-
sories, including large and small primer pocket cleaners and ream-
ers, case neck brushes, and inside and outside deburring tools.
With the hex adapters (included), accessories simply pop in and
out of the driver. (No threading or chucking required). Also includes
standard and phillips driver bits. This new kit takes the drudgery
out of your case preparation. Any questions on the use of this
product after reading the attached instructions can be answered by
calling 1-800-22-LYMAN, Monday through Friday between 9:00am
- 4:30pm Eastern time.
Visit Us At: www.lymanproducts.com
Specifications: Power Source-2x1.2Nickel Cadmium
Rechargeable Battery, Speed=250RPM, Weight=0.75Ib/350g
Charging Time: 18 Hrs.
Charging: Be sure to charge 10-12 hours prior to first use.
Insert the charging plug of your charger to the screwdriver, then
plug the charger into the power source. LED charging indicator will
also light up.
Lyman Products Corp.
475 Smith Street
Middletown CT 06457
[phone]
02/08 #7960894
K)
D)
C)
H)
H)
G)
G)
I)
J)
A)
B)

CAUTION
As with any revolving tool, safety glasses must be worn. Do
not allow children to play unsupervised in the reloading area.
This tool is not a toy and children should not be allowed
unsupervised access to the tools. Keep your reloading area
clean. Work your reloading into a system. Use caution when
handling your cutting tool as the cutting edges are extremely
sharp.
PRIMER POCKET CLEANING AND REAMING
Large quantities of cartridge cases can be quickly processed
after resizing and decapping to prepare the primer pocket for
reloading. The primer pocket reamers and cleaners are dou-
ble ended in small and large bit diameters to precisely fit
primer pockets. Simply insert the appropriate reamer or
cleaner into the chuck of the power driver. A turn or two of
the cleaner bit removes the fouling. Now process the rest of
your cartridge cases in the same manner. A clean primer
pocket allows even primer seating.
NOTE
Removing the primer pocket crimp from once-fired military
brass is a one-time operation involving the appropriate ream-
er bit, large or small. The procedure should be done before
primer pocket cleaning.
CASE NECK BRUSHING
Case Neck Brushes should be used to remove fouling and
residue from inside case necks. Install the appropriate brush
into one of the hex adapters provided and insert the adapter
shank into the power driver chuck. Clean your case necks by
running the appropriate brush into each case mouth. Your set
includes the 38 and 45 caliber brushes. Other sizes of bore
cleaning brushes are available from your local dealer.
CASE CHAMFERING AND DEBURRING
Your Inside/Outside Deburring Tool will cleanly deburr your
case mouth in one easy operation. Cases should be sized
and trimmed to length first, then chamfered. Assemble your
Inside/Outside Deburring Tool with one of the hex adapters
provided and insert the adapter shank into the Power Driver.
Hold your case straight and in line with the cutter to get a
uniform chamfer. A few turns of the cutter pressed flush
against the case is sufficient.
OPERATING YOUR POWER DRIVER
When performing any of the case prep functions it is impor-
tant that your Power Driver turn in the appropriate direction.
Press the upper portion of the button to drive the cutter in a
clockwise direction and the lower portion for counter-clock-
wise.
NOTE
The cutting tools will not cut properly if turning in the wrong
direction.
After extended use, your case prep accessories may wear
beyond usefulness. When that happens, order the appropri-
ate replacement items according to the chart located on the
back page of these instructions. You can order by calling the
toll-free number listed at the beginning of this manual.
WARNING
This product contains nickel cadmium batteries and when the
battery life is exhausted, the batteries must be recycled or
disposed of properly. For additional information regarding dis-
posal, contact your local county solid waste authority.
SEE NEXT PAGE FOR ORDERING OF ADDITIONAL COM-
PONENTS AS WELL AS POWER SPECIFICATIONS FOR
YOUR LYMAN POWER DEBURRING KIT DRIVER.
