Lynk 430121 User manual

© 2016 Lynk, Inc. 8241 Melrose Dr. Lenexa, KS 66214
430121 Roll Out Bin Holder R1 1
Rear
Support
Hex Nut
Additional
holes for
larger bins
Place bin at the front of base to identify
rear holes that match bin size.
Attach rear support into holes that match
bin size using hex nuts.
Tighten hex nuts using wrench.
Attach Rear Support
3
Wrench
Front
2
Hex Nut
Wrench
Attach front support onto base
using hex nuts found in parts bag.
Tighten hex nuts using wrench
found in parts bag.
Attach Front Support
Front
Support
with handle
Back
Glide
Frame
Parts
Bag
Rear
Support
Base
1Unpack
Hex Nut (4x)
Mounting Screw (4x)
Wood Screw (4x)
Wrench
Instructions
Alignment Guide
•
•
Parts Bag Includes:
Front
Support
with handle
#430121
Roll Out Bin Holder

© 2016 Lynk, Inc. 8241 Melrose Dr. Lenexa, KS 66214
LIMITED WARRANTY AND DISCLAIMER OF LIABILITY
The manufacturer warrants this product against defects in manufacturing and workmanship for a period of ninety (90) days from the date of purchase. For questions, call
[phone] for customer service.
MANUFACTURER DISCLAIMS ALL OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE WITH REGARD TO THE PRODUCT. IN NO EVENT SHALL MANUFACTURER BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES
WHATSOEVER (INCLUDING,WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS PROFITS, INJURY TO PERSON OR PROPERTY, OR ANY OTHER INCIDENTAL, CONSEQUENTIAL OR
PECUNIARY LOSS), OR FOR ATTORNEY’S FEES OR COSTS, ARISING OUT OF THE USE OR OPERATION OF THE PRODUCT.
If you have questions, please call 800-733-5965
430121 Roll Out Bin Holder R1
www.lynkinc.com
2
Mount assembled base and supports to glide frame
using mounting screws found in parts bag.
Tighten until snug.
Attach Assembled Base and Supports
5
Optional:
Use 2 extra screws in
back for large bins
*
Recommended:
Use of a Power Screwdriver
Drill 4 starter holes using a
1/8” diameter drill bit
*
Move inner glide rails slightly forward as shown.
Mount glide frame into cabinet using alignment
guide and wood screws found in parts bag
(install front screws first).
Mounting the Glide Frame
4
Move inner
glide rails
forward
Install front screws first.
Use holes nearest to glide rails
as shown.
2 ” min.
50.8cm
2 ” min.
50.8cm
2 ” min.
50.8cm
