Lynk Roll-Out Drawer User manual

2 ” min.
50.8mm
Alignment
Guide
2 ” min.
50.8mm 2 ” min.
50.8mm
®
Roll-Out Drawer R14 If you have questions, please call 800-733-5965. © 2016 Lynk , Inc. 8241 Melrose Drive, Lenexa, KS 66214
1
2 3
Glide Frame Drawer
Mounting
holes
www.lynkinc.com
Aligning Glide Frame Checking Cabinet Clearance
Align glide frame in cabinet as shown
using alignment guide found in parts bag
Set drawer onto glide frame with
holes in drawer and glide aligned
Check for adequate cabinet and
door clearance
Adjust glide frame position if needed
•
•
Parts Bag Includes
Mounting
Screws (4)
Wood
Screws (4)
Instructions
Alignment
Guide
Discard
4 places
Make sure arrows
are pointing to the
front of the cabinet
clearance on sides
20” Drawers require
4”min.
101.6mm

Install front
screws first
Turn screws
until just snug
2 ” min.
50.8mm 2 ” min.
50.8mm
2 ” min.
50.8mm
4
5
clearance on sides
20” Drawers require
4”min.
101.6mm
Remove drawer from glide frame
Move inner glide rails slightly forward as shown
Mount glide frame into cabinet using wood screws
found in parts bag (install front screws first)
Recommended:
Use of a Power Screwdriver
Drill 4 starter holes using a
1/8” diameter drill bit
Set drawer back onto glide frame with drawer
and glide mounting holes aligned
Attach drawer by gently tightening drawer
mounting screws as shown
Mounting Glide Frame
Attaching Drawer
www.lynkinc.com
For 17” and 20” drawers
Use holes nearest to
glide rails (as shown)
Move inner
glide rails
forward
Optional for 20”drawers:
Use 2 extra screws in back
LIMITED WARRANTY AND
DISCLAIMER OF LIABILITY
The manufacturer warrants
this product against defects
in manufacturing and
workmanship for a period of
ninety (90) days from the date
of purchase. For questions, call
[phone] for customer
service.
MANUFACTURER DISCLAIMS
ALL OTHER WARRANTIES, EITHER
EXPRESS OR IMPLIED, INCLUDING
BUT NOT LIMITED TO IMPLIED
WARRANTIES OF
MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE WITH
REGARD TO THE PRODUCT. IN NO
EVENT SHALL MANUFACTURER
BE LIABLE FOR ANY SPECIAL,
INCIDENTAL, INDIRECT, OR
CONSEQUENTIAL DAMAGES
WHATSOEVER (INCLUDING,
WITHOUT LIMITATION, DAMAGES
FOR LOSS OF BUSINESS PROFITS,
INJURY TO PERSON OR PROPERTY,
OR ANY OTHER INCIDENTAL,
CONSEQUENTIAL OR PECUNIARY
LOSS), OR FOR ATTORNEY’S FEES
OR COSTS,ARISING OUT OF
THE USE OR OPERATION OF THE
PRODUCT.
®
