Lynk Roll-Out Double Drawer User manual

Glide Parts Bag
Unpack
Lower Drawer
Upper Drawer
Rods
www.lynkinc.com
3
45
in cabinet using Alignment Guide found
in parts bag
Align Glide Frame
Make sure
arrows are
pointing to
the front of
the cabinet.
Check for adequate clearance
around cabinet and doors
(Adjust glide frame position as needed.)
Check For Clearance
Temporarily place drawer from
step 3onto glide frame with holes
in drawer and glide aligned.
2”
min.
Alignment
Guide
2”
min.
2”
min.
Roll-Out Double Drawer REV 9 If you have questions, please call 800-733-5965. © 2014Lynk , Inc. 8241 Melrose Drive, Lenexa, KS 66214
®
•
•
Parts Bag
Mounting
Screws (4)
Wood
Screws (6)
Instructions
Alignment
Guide
Lower Drawer Indicated by
Mounting Plates
1
Rod
Slide Upper Drawer...
Corner
Tube
onto tops of rods until upper
drawer is fully in place
Note: Face drawer fronts
in same direction.
Insert Rods
into lower drawer (4 places)
Lower drawer indicated
by mounting plates.
2

wood
screws
2”
min.
2”
min.
2”
min.
6
7
• Remove drawer from glide frame
• Move inner glide rails slightly forward as shown
• Install glide frame into cabinet using wood screws
 foundinpartsbag.(Installfrontscrewsrst).
Install Glide Frame
Use outer holes.
• The use of a power screwdriver
• Drill 4 starter holes using a 1/8”
diameter drill bit.
Recommended:
Move inner glide rails forward.
Inner
glide rail
mounting
screws
Turn mounting
screws until
just snug.
With drawer and glide mounting
holes aligned, mount drawer to
glide frame with mounting screws
as shown.
Mount Drawer to Glide Frame
www.lynkinc.com
Roll-Out Double Drawer REV 9 If you have questions, please call 800-733-5965. © 2014Lynk , Inc. 8241 Melrose Drive, Lenexa, KS 66214
®
LIMITED WARRANTY AND DISCLAIMER OF LIABILITY
The manufacturer warrants this product against defects in manufacturing and workmanship for a period of ninety
(90)days from the date of purchase. For questions, call [phone] for customer service.
MANUFACTURER DISCLAIMS ALL OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE WITH REGARD TO THE PRODUCT. IN NO EVENT
SHALL MANUFACTURER BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES WHATSOEVER
(INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS PROFITS, INJURY TO PERSON OR PROPERTY, OR ANY
OTHER INCIDENTAL, CONSEQUENTIAL OR PECUNIARY LOSS), OR FOR ATTORNEY’S FEES OR COSTS, ARISING OUT OF THE USE
OR OPERATION OF THE PRODUCT.
