Where do you want to install SIGMA?
1
A
B
TOP VIEW
B
A
Max 30 cm
ENTRANCE
Min 0 cm
In a pathway, an entrance, above a sliding door... Above a swing door
- Install SIGMA in the center of the pathway
- Mount it parallel and at a maximum distance of 30
cm from the entrance.
Sigma ts anywhere (doors, walls, ceilings).
Just make sure you place it overhead
Single leaf When possible, install SIG-
MA on the closing side in
the middle, outside the
swing path (option 1).
When that is not possible,
you can install SIGMA on
the opening side. Make
sure you place it right
above the cutting edge
(option2).
Install SIGMA in the cen-
ter. Preferred side is the
closing side, outside the
swing path (option 1).
Double leaf
closing side
closing side
1
2
1
2
