M-Power UNI 321 User manual

Read Before Operating
The User’s Guide must be carefully read by all
individuals who have or will have the responsibility
of using, maintaining, or servicing this product.
The product will perform as designed only if it is
used, maintained, and serviced in accordance
with the manufacturer’s instructions.
User Interface
The UNI 321’s user interface consists of the LCD
display, LEDs, an alarm buzzer, two keys: Left Key
[Confirm/Increase Number] and Right Key
[Power/Move Cursor], an alligator clip, & a sensor.
2
Display
1. Gas name, includes: CO, H2S, O2
2. Remaining time unit: Months, Days or Hours
3. Question mark
4. Unit status indicator “OK”
5. Gas unit, for alarm setting display
6. Remaining operating time
7. Battery status
3
UNI 321
Quick Start Guide V0.3
mPower Electronics Inc.
3046 Scott Blvd. Santa Clara, CA 95054
www.mpowerinc.com
[e-mail]
LED alarm
window
LCD
Confirm/
Number
Increasing
key
Alligator clip
LED alarm
window
Power/Cursor
Moving key
Sensor
Buzzer

Turning the Unit On
Press and hold the Right Key for 3 seconds, until the
LCD displays “on”, the buzzer beeps, and the green
LED is on. After power on, the unit enters a warm up
and self-test sequence, followed by normal mode.
Once in normal mode, the unit will run continuously
until the remaining life time ends, and cannot be
turned off.
Normal & Alarm Modes
In normal mode, the unit continuously monitors the
gas concentration, while the LCD displays the
remaining life time, as long as there is no gas alarm.
If an alarm concentration is exceeded, the LCD
shows either “Low Alarm” or “High Alarm”, depending
on which level is triggered.
Bump Test
A bump test can be performed manually or using the
mPower Suite software and MP300 CaliCase.
Please refer to the software user manual. 4
Maintenance and Service
The UNI 321 is maintenance free.
Year of Manufacture
The fifth and sixth digits in the serial number of
the instrument indicate the year of manufacture,
i.e., 00-99 indicate years 2000 to 2099.
Intrinsic Safety
UL/cUL:
Class I, Groups A, B, C, D
Class II, Groups E, F, G
Class III
T4, -20℃≤Tamb ≤50℃
5
Proper Product Disposal
at End Of Life
The Waste Electrical and
Electronic Equipment (WEEE)
directive (2002/96/EC) is
intended to promote recycling of
electrical and electronic
equipment and their
components at end of life. This
symbol (crossed-out wheeled
bin) indicates separate collection of waste electrical
and electronic equipment in the EU countries. This
product may contain one or more nickel-metal hydride
(NiMH), lithium-ion, or alkaline batteries. Specific
battery information is given in this user guide.
Batteries must be recycled or disposed of properly. At
the end of its life, this product must undergo separate
collection and recycling from general or household
waste. Please use the return and collection system
available in your country for the disposal of this
product. 6
