M-Spa PM-610S Tuscany Guide

EN
DO NOT RETURN MERCHANDISE TO YOUR DEALER STORE DIRECTLY. CALL MSPA AFTER
SALES SERVICE CENTER FOR PRODUCT QUESTIONS OR CONTACT MSPA AT
[email protected]
Due to MSpa continuous product improvement, MSpa reserves the right to change
specifications and product appearance, which may result in updates to the instruction
manual without notice.
®
Where Luxury Is Affordable
www.the-mspa.com
MSpa® Owner’s Manual
and Warranty Card
PM-610S Tuscany
PM-710S Tuscany

2
ENTER THE WORLD OF MSPA
CONTENT
Safety precautions………………………………………………………………......................................................
Specifications and product overview……………………………………..............………......................................
First use and set-up preparation…………………………………………….........................……………...............
Spa set-up……………………………………............................…………………………......….............................
Control panel operation…………………………………………........................…................................................
Water maintenance and chemicals………………......................................………..………………..…................
Drainage, cleaning and storage………………………...................................………………..………..……..........
Disposal and environmental protection………………………....................................…......................................
Troubleshooting…………………………………………….......……………………….…...…...…..........................
MSpa limited warranty policy.............................................................................................................................
MSpa service center locations...........................................................................................................................
MSpa warranty card…………………………............………................................………………..........................
3
8
10
12
16
18
20
21
22
23
24
25
Thank you for choosing MSpa and for your confidence in our brand. We believe that you will enjoy many benefits
of using MSpa products for years to come.
To guide you in your initial MSpa experience, we are pleased to present you with this instruction manual. Please
carefully and thoroughly read this manual entirety before using the product for the first time.
We are delighted to welcome you to the MSpa family, and look forward to sharing with you the full spectrum of
our expertise.
Enjoy your MSpa!
Scan the QR code to enter the MSpa official website
Welcome,

3
SAFETY PRECAUTIONS
For your own safety and that of your product, make sure to follow the safety
precautions below. Fail to follow the instruction may result in serious injury,
property damage or death. Improper installation or operation will void the warranty.
READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS
! DANGER
Risk of Accidental Drowning. Extreme caution must be exercised to prevent
unauthorized access by children.
Risk of drowning. Inspect the spa cover regularly for leak, premature wear and
tear, damage or signs of deterioration. Never use a worn or damaged cover: it
will not provide the level of protection required to prevent unsupervised access
to the spa by a child.
Risk of drowning. Always lock the spa cover after each use.
Risk of injury. If the supply cord is damaged, it must be replaced by the manu-
facturer, its service agent or similarly qualified persons in order to avoid a
hazard.
Risk of Electric Shock. Do not permit any electrical appliances, such as a light,
telephone, radio or television within 1.5m (5 feet) of a spa tub.
Risk of Electric Shock. Do not use the spa when it is raining, thundering or
lightning.
●
●
●
●
●
●
To reduce the risk of electric shock, do not use an extension cord, timers, plug
adaptors or converter plugs to connect the unit to electric supply; provide a
properly located outlet.
The spa electrical appliance should be supplied through a residual current device
(RCD) having a rated residual operating current not exceeding 30 mA.
Parts containing live parts, except parts supplied with safety extra-low voltage
not exceeding 12V, must be inaccessible to occupants in the spa.
Parts incorporating electrical components, except remote control devices, must
be located or fixed so that they cannot fall into the spa.
●
●
●
●
! WARNING

4
Residential electrical connection box must be located safely with a distance of
at least 2m away from the spa.
Electric installation should fulfill the local requirement or standards.
Do not press down or uplift the control panel or put any heavy items on the
control panel after installations.
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of experi-
ence and knowledge if they have been given supervision or instruction concern-
ing use of the appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
To reduce the risk or injury, do not permit children use this product unless they
are closely supervised all times.
To reduce the risk of child drowning, supervise children all times. Attach and
lock spa cover after each use.
Make sure the floor is capable of supporting the expected load, which you can
find from the spec sheet, calculate the expected load of water capacity plus total
weight.
Adequate draining system must be provided around the spa to deal with over-
flow water.
To reduce the risk of injury:
a) Lower water temperatures are recommended for young children and when
spa use exceeds 10 minutes. In order to avoid the possibility of hyperthermia
(heat stress) occurring it is recommended that the average temperature of
spa-pool water should not exceed 40°C(104°F).
b) Since excessive water temperatures have a high potential for causing fetal
damage during the early months of pregnancy, pregnant or possibly pregnant
women should limit spa water temperatures to 38°C(100°F).
c) Before entering a spa or hot tub the user should measure the water
temperature with an accurate thermometer since the tolerance of water
temperature regulating devices varies.
d) The use of alcohol, drugs or medication before or during spa use may lead to
unconsciousness with the possibility or drowning.
e) The use of alcohol, drugs, or medication can greatly increase the risk of fatal
hyperthermia in spas.
f) The causes and symptoms of hyperthermia may be described as follows:
Hyperthermia occurs when the internal temperature of body reaches a level
●
●
●
●
●
●
●
●
●

5
several degrees above the normal body temperature 37°C(98.6°F). The
symptoms of hyperthermia include an increase in the internal temperature of
body, dizziness, lethargy, drowsiness, and fainting. The effect of hyperemia
include failure to perceive heat; failure to recognize the need to exit spa;
unawareness of impending hazard; fetal damage in pregnant women;
physical inability to exit the spa; and unconsciousness resulting in the danger
of drowning.
g) Obese persons or persons with a history of heart disease, low or high blood
pressure, circulatory system problem, or diabetes should consult a physician
before using a spa.
h) Persons using medication should consult a physician before using a spa
since some medication may induce drowsiness while other medication may
affect heart rate, blood pressure, and circulation.
i) Check with doctor before use if pregnant, diabetic, in poor health, or under
medical care.
People with infectious disease should not use a spa or hot tub.
To avoid injury exercise care when entering or existing the spa or hot tub.
Water temperature in excess of 42°C(108°F) may be injurious to your health.
Never use a spa or hot tub alone or allow others to use the spa alone.
Do not use a spa or hot tub immediately following strenuous exercise.
Spa heat in conjunction with alcohol, drugs, or medication can cause uncon-
sciousness.
Exit immediately if uncomfortable, dizzy, or sleepy. Spa heat can cause hyper-
thermia and unconsciousness.
Do not put the spa under 0°C(32°F) environment in order to avoid freezing if
there is still water in the pool.
It’s helpful to put temp barrier mat in between the spa pool and the ground.
Similar mat which is made of foam material or other materials with heat barrier
function can also be used. Do not turn on the spa when the water is frozen.
Never pour water with a temperature higher than 40°C(104°F) into the spa
directly.
Always unplug this product from the electrical outlet before removing, cleaning,
servicing or making any adjustment to the product.
Never jump or dive into a spa or any shallow body of water.
No part of the electric appliance is to be located above the bath during use.
Do not bury the electrical cord. Locate the cord where it will not be damaged by
lawn mowers, hedge trimmers and other equipment.
●
●
●
●
●
●
●
●
●
●
●
●

6
Do not attempt to plug in or unplug this product while standing in water or when
your hands are wet.
Do not use the spa if damaged in delivery and/or malfunctioning in any way.
Contact the MSpa service center for further direction.
Keep all pets away from the spa to avoid any damage.
Do not add bath oil or bath salt to the spa water.
●
●
●
●
●
Always add chemicals to water, never add water to chemicals. Adding water to
chemicals may cause strong fumes or violent reactions and hazardous chemical
spray.
For water already used, discharge it in time or use water chemicals for cleaning.
Usually,change water every 3-5 days.
Use Mspa chemical kit for disinfection in accordance with manufacture's
instructions.
Do not leave or set up the spa in temperature lower than 4°C(39°F) if heater is
not operating.
Always enter and exit the spa or hot tub slowly and cautiously. Caution of wet
floor.
To avoid damage to the pump, never turn on the spa or hot tubs unless it is
filled with water to the minimum water line.
Place the spa or hot tub only on a properly prepared site that can withstand the
floor loading requirement of the spa.
Do not leave the spa empty for extended period of time. Drain away water
inside the pool thoroughly for long time disuse. Do not expose the spa under
direct sunshine. Check regularly before each use. Put away the spa or fence it
up in time after using.
Open the spa top lid when the Bubble function is on.
In order to avoid a hazard due to inadvertent resetting of the thermal cut-out,
this appliance must not be supplied through an external switching device, such
as a timer, or connected to a circuit that is regularly switched on and off by the
utility.
Refer to relevant chapter for details concerning cleaning and other mainte-
nance.
●
●
●
●
●
●
●
●
●
●
●
! CAUTION

Zone 2 Zone 2
h
h
Zone 1
Zone 0
Zone 0
2.5 m
2.5 m
1.5 m 1.5 m2.0 m 2.0 m
7
Warning: Water protection levels of appliance at different product zones are
different see the following scheme. ( Installation regulations comply to IEC
60364-7-702)
NOTE-The measured zone dimensions are limited by walls and fixed partitions.
Zones
Zone 0
Zone 1
Zone 2
Description of the zones
Zone 0 is the interion of the basin including any recesses in their
walls or floors.
Zone 1 is limited by
•Zone 0
•A vertical plane 2m from the rim of the basin.
•The floor or the surface expected th be occupied by persons
•The horizontal plane 2.5m above the floor or the surface
Zone 2 is limited by
•A vertical plane external th zone 1 and parallel plane 1.5m
from the former.
•By the floor or surface intended to be occupied by persons.

8
SPECIFICATIONS
4 - 5
5 - 6
BUBBLE SPA
Model No.
/ Code
Control System Specs
Control System
Total Power
Heater
Massage Air Blower
Filter Pump
Integrated Ozone Generator
Top Lid
Pool Cover
Pool Material
Shape Seating
Capacity Water Capacity Outside
Dimensions Height Weight
PM-610S
/ Tuscany Octagon
Octagon
860 Ltr
(227 gal)
1200 Ltr
(317 gal)
1.62m
(64”)
1.93m
(76”)
0.68m
(27”)
0.73m
(29”)
59.5kg
(131.2lbs)
71.5kg
(157.6lbs)
PM-610S/710S
220-240V / 50Hz
2300W
1500W
3 Levels (Level 1: 300W, Level 2: 500W, Level 3: 720W)
12V / 60W
5.5W, 30-50mg/Hr
Leather cover with foil inside
Plastic wood
Rhino-Tech™ reinforced PVC
Note: The symbol “S” after model number (e.g. PM-610S) is for purpose of lab testing updating, S means zodiac
sheep year English initials.
PM-710S
/ Tuscany

®
9
PRODUCT OVERVIEW
Packaging content
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
A. B. C. D.
E. F. G. H.
I. J. K.
N. O. P. Q.
L./M.
®
®
L
M

10
FIRST USE AND SET-UP PREPARATION
The spa can be installed indoor and outdoor. For household use only.
The spa must be set up on a flat, smooth and supporting surface that is capable of supporting the
maximum load of the filled spa with listed maximum occupants.
Make sure the area is free of sharp objects under or around the spa. Uneven of unsound surfaces can
damage the spa and void your warranty. Level the surface before filling spa with water.
Provide adequate drainage system around the spa to deal with overflow water and splashes.
Make sure there is enough clearance around the spa for full access to the spa equipment for maintenance
and/or service.
●
●
●
●
●
Site preparation and requirements
Verify the supporting floor can support the filled weight of spa with maximum number of occupants. Check
with a qualified contractor or structural engineer to verify the requirement.
Make sure the floor is water resistant and provides non-slip surface. Do not install the spa on a carpet of
any other material that could damaged by the moisture.
Humidity is a naturally side effect of indoor spa installation. The room shall be properly ventilated to allow
moisture to escape. Install a ventilating system to prevent excess condensation moisture in the room.
●
●
●
Additional requirements for indoor installation
REF. NO. PARTS DESCRIPTION QTY.
NOTE: When ordering parts, be sure to quote the model number and part numbers.
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
1
1
1
8
8
1
7
1
1
1
1
1
1
1
1
1
1
Spa cover with aluminum foil inside
Spa liner
Control panel
Corner beam
Sponge rail
Open-end panel
Plastic wood panel
Heat preservation ground mat
Filter cartridge (twin pack)
Spa drain valve adaptor
Repair kit
Spa cover inflatable bladder
Inflation hose for bladder
Wrench
Control box without plug and leather cover
Foam connection and PVC leather strip
Instruction DVD

11
Make sure to set up the spa on a firm, level and smooth surface that is strong enough to support the full
weight of the filled spa and maximum occupants.
Do not set up the spa on grass or dirt, as this increases the amount of debris entering the spa, and
damage the spa floor.
Do not leave the spa tub exposed to direct sun light for extend period of time.
It is the possible to install and leave the spa outside at a temperature not lower than 4°C(39°F) and the
water inside the circulation system, pump, pipe are not frozen. Put a Heat Preservation Mat or the Electric
Heating Mat (*Optional) in between the spa bottom and the ground to prevent heat loss from the bottom of
the spa and to provide better heat retention.
●
●
●
●
Additional requirements for outdoor installation
Plug the machine into the mains.
Press the RESET button on the PRCD. The indicator turns red.
Press the TEST button on the PRCD. The PRCD indicator should shut off. If the PRCD indicator does not turn
off, the PRCD is faulty.
Do not use the spa. Contact a qualified electrician to correct the fault.
Press the RESET button on the PRCD again. The indicator should turn red. If yes, the spa is ready for use.
1.
2.
3.
4.
PRCD Testing
Risk of electric shock: This product is provided with a PRCD located at the end of the power cord. The
PRCD must tested before each use. Do not use the spa if the PRCD does not function properly. Disconnect
the power cord until the fault has been identified and corrected. Contact a licensed electrician to correct the
fault. There are no serviceable parts in side the PRCD. Opening the PRCD will void the warranty.
! WARNING
LOAD
LINE
TEST BEFORE USE
TEST
RESET
TEST
RESET
ONOFF
RED BLACK
1. 2.
RESET
3.
TEST
LOAD
LINE
TEST BEFORE USE
TEST
RESET
TEST
RESET
ONOFF
RED BLACK
Spa Control Unit Connected
External Equipotential Bonding
Conductors
A qualified electrician shall wire the spa control
unit to the household equipotential terminal using
a minimum 1.5mm² solid copper conductor as
follow.

12
SPA SET-UP
Move the entire package to the selected site. Open the carton carefully as it can be used to store the spa
during long term storage or when not in use.
Lay out all the parts on the ground and make sure all parts are accounted for. (*For missing or damaged
part, contact MSpa Service Center)
Spread out and connect the 9 pcs foam mat at a cleared area. Heat Preservation Mat prevents heat loss
from the bottom of the unit.
1.
2.
3.
Spa wall assembly
4.1 First find the "Open-end panel" and place it to where you wish to locate your control box.
Install the "Slide Corner Beams" onto each side of the "Open-end panel".
Note: Make sure the Corner Beams with the buckle plate side should face out. The silver twist end on
the Corner Beam should be the upward side.
4.2 Continue attaching the side Corner Beams to the Wood Panels until the eight sides of the spa wall
are installed completely, and shows a octagon shape.
4.
1 2 3
4.1 4.2
this side
face up
®
4.3 Place the Sponge Rails onto the wood panels top accordingly.
Note: The shorter side of the Sponge Rail should be face inside the spa pool.
4.3

13
5.1
6.2
6.1
6.3 6.4
5. Spa liner assembly
5.1 Take out the Spa Liner, put it inside the spa
wall frame. Make sure the Connection Pipe
Joint Side on the liner stuck out the
"Open-end panel" and go through the open
section on the panel.
5.2 Stretch the top trim of the liner (Silver or
Brown Trim) over the Sponge Rails. Lock the
silver buckle on the trim onto the metal Twist
Lock on the Corner Beams.
6. Control box installation
6.1 Connect the Ozone pipe to the PVC transparent pipe
protruding from the Liner firstly and then fixed with nylon
tie belt (Figure 6.1)
6.2 Connect the control box fittings to the pipes protruding
from the Liner. Ensure the rubber gaskets are in place
on the control box fittings. (Figure 6.2)
6.3 Place the Foam Connection pieces in between the spa
pool and the control box. Wrap the foam connection
piece with the leather cover. (Figure 6.3)
6.4 Connect the digital cable. Find the digital cable, loose
the cap on the end, and plug into the cable port on the
control panel. Once the cable is connected properly,
the backlight of the buttons area will light up on the
panel.
5.2

7
(a)
(b)
(c)
14
6.5 Connect the control panel to the control box.
Fasten and secure the rings to the pipe adapter
on the spa tub. (Figure.6.5) Make sure the
rubber O-rings are properly placed on the air
pipes. Close the panel zipper cover once the
panel is installed.
CAUTION: Lost of the O-rings may result spa
and the bubbling function working improperly,
and also cause the air pump rusted. (Spare
O-rings can be founded in the package).
O-rings
Air pipe
6.5
7. Spa Bladder Inflation
a) Open the air valve (a) on the bladder. Insert the
inflation hose (b) into the valve.
b) Press the Bubble button to inflate until it is
firm to touch but not hard.
c) Press Bubble button for more than 3
seconds to turn off the function. Disconnect the
inflation hose from the air blower outlet and the valve
d) Replace the air valve cap (c) back on the control
panel. Close and recess the inflation valve (a).
8.3 Place the inflated air bladder and the top lid cover over the spa tub, and make sure the spa cover are
closed with buckles and lock the buckles by the key.
NOTE: Deflation Instruction
Spa Bladder Deflation
1. Pull the valve cap out and squeeze the valve at its base until deflated.
2. Close and recess the valve back.
8. Water Filling
8.1 Check the spa liner is at the selected area and point the rain valve
toward a suitable draining area.
8.2 Fill the spa tub with fresh water to a level between
Minmum and Maximum line marked on the
inside of the spa wall. Do not over fill the spa. It is
recommended to fill the spa with lukewarm water
for quick heating and energy saving.
WARNING:
● Water level must reach the Minmum water line but not exceed the Maximum line to avoid
pump failure.
● Never pour water with a temperature higher than 40°C(104°F) into the spa directly.
● To avoid control system failure, do not operate the spa until water reaches the Minmum line.
8.2

15
®
8.4 Turn on the Heater on the spa control panel, refer to the “Control Panel Operation” section.
Maximum heating temperature is 42°C(108°F). Hourly heating rate is about 1.2°C-1.8°C (2°F-3°F) for
PM-610S and 0.5°C-1.5°C (1.5°F-2°F) for PM-710S.
8.3
®
®
®
®
9. Buckle Operation
Lock the Buckle
●Insert the spa cover buckle into the buckle on the corner beam, until you hear a “Click” sound
●Lock the buckles by the key which is attached with top lid cover in original package.
Unlock the Buckle
●Use the key to release the lock. Keep well the keys.
Lock Unlock
9

16
CONTROL PANEL OPERATION
ON/OFF Button: To activate the control panel.
LCD displays the current temperature and backlight is white when the power is on, all
functions can be opened.
Bubble Button: Can adjust among 3 levels of bubbling power. The default bubbling
massage power is level 2 (500W) . Press the BUBBLE button again, switching to level 3
(720W) . Press again made to level 1 (300W) . To shut down the function, press
the BUBBLE button for 3 seconds.
NOTE: The bubbling massage function will be shut down automatically after every 20
minutes operation for safety concern. It can not be operated within 10 minutes after shut
down. The bubbling massage function will be filtered automatically after 4-hour.
Filter Button: Activate the filter pump. The Filter icon shows when the filtration system is
activated.
NOTE: Filtration cannot be turned off when heating is activated. When the Heating function
is turned off, Filtration will be stopped after 30 seconds. Filtration function can be then
activated separately.
NOTE: Auto-filtration system every 4 hours.
Heater Button: Use this button to activate the HEATING and FILTRATION function at the
same time. The heater will heat the spa water until the water temperature reaches the pre-set
temperature. After the current water temperature drops below the set temperature, the
heating system will restart automatically. The Heater icon shows when the heating system is
activated. When the Heater icon is flashing, the heating system is at rest and the water is at
set temperature.
NOTE: If you want to open the HEATING and FILTRATION functions, just press on the
HEATER button.
Temperature Adjustment Buttons: To adjust the current temperature, press the UP or
Down button, and the LCD screen flashes to display the set temperature. The temperature
interval is one degree. The LCD displays the current temperature if no further operation more
than 3 seconds.
NOTE: The default temperature is 38°C(100°F).
NOTE: Temperature adjustment ranges from 20°C(68°F) to 42°C(108°F).
1. ON/OFF Button
2. Bubble Button - Adjust the bubble
level by pressing the button
(L1:300W, L2: 500W, L3:720W)
3. Filter Button
4. Heater Button
5. Temperature UP & DOWN Button
6. Celsius/Fahrenheit Toggle Button
7. Ozonator Button

17
Celsius/Fahrenheit Toggle Button: The temperature can be displayed in either Celsius
or Fahrenheit. The system's default is Celsius.
Ozonator Button: Activate the Ozone. The Ozone icon shows when the Ozone function is
activated. For bathers' safety concern, the ozonator cannot be operated at the same time
when the Bubbling function is on. The Ozonator will be off automatically after opearting for 2
hours. Ozone output is 50-80mg/Hr.
NOTE: Please do not soak in the spa when the Ozone is on. The Ozonator will not work
when the spa has no water or when the Bubble Button is on.
IMPORTANT：The following conditions will lead to slow water heating
● The ambient temperature is lower than 10°C(50°F)
● Outdoor wind speed is above 3.5-5.4m/s(8-12mph)
● The air bubble function is activated when heater is on
● The spa is not properly covered with the spa cover when heater is on
ERROR CODE CHART
LCD READING CAUSE SOLUTION
Water temperature is lower than zero
degree or exceed 55°C(131°F)
Temperature sensor failure
Water pressure switch failure
Filter failure
Water level is not at the minimum water line
Detecting function failure
No water in the spa tub
Contact the MSpa Service Center.
Contact the MSpa Service Center.
Add more water to the minimum line.
Add more water to the minimum line.
System self-checking
Step 1: Fill water to the water line, and make
sure that there is no bather or
object in the spa tub.
Step 2: Connect the power supply, press
RESET button on the PRCD.
Step 3: If E3 shows, contact the MSpa
Service Center. If E3 is flashing,
press ON/OFF, C/F,TEMP+ buttons
once insequence, enter to the
self-checking system. If no error
code shows, failure is not detected.
It is OK to use the spa. If error code
shows after self-checking, contact
the MSpa Service Center.
Contact the MSpa Service Center.
Change the water or contact the MSpa
Service Center.
Heating failure
System failure
E3
E4
E0
E1
E2

18
WATER MAINTAINCE AND CHEMICALS
Water Sanitation
The spa owner must regularly check and keep the spa water sanitized with scheduled maintenance (daily, if
necessary). Adding sanitizer or other chemical will control bacteria and viruses present in the spa water. The
maintenance of a proper water balance through appropriate use of sanitizers is the most important factor in
maximizing the life and appearance of the spa as well as ensuring clean, healthy and safe water.
Proper technique is important for water testing and treating the spa water. See your spa professional for
chemical, sanitizer, test kit and testing procedures questions.
CAUTION:
● Always follow the chemical manufacturer’s direction, and the health and hazard warning.
● Do not add chemicals if the spa is occupied. This can cause skin or eye irritation.
● Concentrated chlorine solutions can damage the spa tub. Improper chemical use will void the warranty.
Maintenance of Spa Water and Cartridge
Protect all the spa occupants from possible water related illness by keeping the spa water clean and sanitized.
Always practice good hygiene. To ensure proper spa water quality by following these procedures:
1. Inspect and clean the filter cartridge after each use, and change the filter cartridge after it works
continuously for 72 hours.
● Unscrew the cartridge assembly from the spa tub wall and remove the cartridge by turning it
counter clockwise (Fig. 1.1)
● Use a garden hose to rinse off the cartridge. If the cartridge remains soiled and discolored it should be
replaced. Keep spare cartridges on hand.(Fig.1.2). There are two filter cartridges from the original
package, one is for use, one is spare.
● Reinstall the clean or spare cartridge back onto the spa tub wall but turning it on clockwise. (Fig.1.3)
1.1 1.2 1.3
2. Change the spa water every 3-5 days depends on the spa use. See “Cleaning, draining and storage”
section for instruction.
3. Use spa chemicals to maintain proper water chemistry. Spa damage resulting from misuse of chemicals
and mismanagement of spa water is not covered by the warranty. Consult with your local spa or pool
retailer for more information on chemical use.
4. All occupants must shower before entering the spa.
5. When spa inlet or outlet is stuck with dirt. Use the
Wrench to check the problem and clean the inlet
or outlet.
5

MSpa Water Treatment Kit
19
Water Balance
Maintain the spa water pH level between 7.2 and 7.8, total alkalinity between 80 and 120ppm and free chlorine
level between 3 to 5ppm. Use the *optional Test Strips to test the spa water chemistry before each use of the
spa and continue to test the water no less than once a week.
The Test Strips can test the “Free Chlorine”, “pH”, and “Total Alkalinity” level at the same time:
1. Dip the entire strip into the water and remove immediately
2. Hold the strip level for 15 seconds. Do not shake excess water from the strip
3. Compare the strip pad to the color chart on the packaging label. If necessary, adjust the chemical level in
the pool water
NOTE:
● Low pH will damage the spa tub and pump. Damage resulting from the chemical imbalance will void the
warranty.
● High pH (hard water) will result in white coagulations inside the filter pump; which may lead to pump
damage.
IMPORTANT:
● MSpa Water Treatment kit is strongly
recommended for spa use.
● Press the Bubble button on the
spa control panel to turn on the bubble air
blower and help to dissolve the chemicals
into the water.
● Never mix chemicals together. Add the
chemicals to the spa water separately.
Thoroughly dissolve each chemical before
adding one to the water.
MSpa Water Treatment Kit (*Optional)
● B0301858 MSpa Chemical Starter Kit (20 X 20g Bromine Tablets + 500ml Algaecide + Floating
Dispenser)
Disinfectant for water spas and pools. disinfectant, algaecide and bactericide.
● B0301859 Bromine Tablets - 50 X 20g Bottle
Slowly dissolve in water to provide active bromine sanitizer in the form of hypobromous acid.
● B0301860 Chlorine Granules - 1Kg Bottle
Adds isocyanuric acid to the spa water which resists chlorine loss from UV rays. Does not contain calcium,
can be used to sanitize hard water without increasing the calcium hardness. Contains troclosene Sodium,
dehydrate 100%.
● B0301861 Algaecide - 1L Bottle
Kills all types of algae, including green and mustard algae. Non-foaming algaecide for improving and
conserving water in spas. Contains polymeric quaternary ammonium chloride 7%.
● B0301862 pH Plus - 1Kg Bottle
For increasing the pH in the spa water. Contains sodium Carbonate 100%.
● B0301863 pH Minus - 1.5Kg Bottle
For decreasing the pH in the spa water. Contains sodium bisulphate 100%.

20
DRAINAGE, CLEANING AND STORAGE
Spa Drainage
1. Turn off all the buttons (heater, filter and bubble) on the control panel unit.
2. Connect the drain valve adapter to a garden hose and point the other end of the garden hose to a
suitable draining area with local environmental regulations (Fig.1)
3. Remove the drain valve cap from the outside of the spa tub and attach the drain valve adapter with the
garden hose to the drain valve (Fig.2)
4. From the inside of the spa tub, open the drain valve cap, water will start to flow out through the garden
hose (Fig.3)
5. When the water stops draining, release the buckle and lift the spa liner from the opposite to the drain,
leading any remaining water to the drain and empty the spa water completely. (Fig.4)
6. Press Bubble button to dry out any water in the piping system. Operate the bubbling function
for 15 minutes to blow out all the remaining water. (Fig.5)
7. When the water stops draining, use a clean towel to wipe up any remaining water and moisture on the
spa tub and spa control panel. (Fig.6)
garden hose
1
4 5 6
2 3
17
15
Spa Tub Cleaning
If dirt is visible in the water or water becomes cloudy and proper water chemistry does not clear it up, change the
water and clean the spa tub.
While spa water is empty, remove the cartridge from the inside of the spa tub wall, clean and /or replace the filter
cartridge. Use a sponge and mild soap solution to wipe away any soil or stains on the inside of the spa wall. Rinse
thoroughly before refilling with clean water.
IMPROTANT: Do not use steel wool, hard brushes or abrasive cleaners.
Spa Tub and Air Bladder Repair
Use the enclosed repair patch to repair any puncture:
1. Clean and dry the area to be repaired thoroughly
2. Apply the glue to the PVC patch and quickly attach it onto the damaged surface. (Glue is not included)
®
