mabe FMM300HEWWX1 User manual

1
instruction
Read this instruction before installing your chest freezer
Chest freezer
model
FMM300HEWWX1、FMM400HEWWX1、 FMM420HEWWX1
FMM500HEWWX1、FMM140HEWWX1、 FMM200HEWWX1

2

1
Do not dam age the refrigerant circuit .
Do not use elect rical appl iances inside t he food st orage com partm ents
of t he appliance, unless they are of t he type recom mended by the
manufacturer.
Please contact service agent t o dispose t he
your appliance since
PRECAUTIONS
hildren shall not play with t he appl iance.
C
leaning and user m aintenance shal l not be m ade by children w it hout
supervision.
C
Do not store explosive substances such as aerosol cans that con tain flammable
propellants inside the appliance.
by children aged from 8years and above
and persons w it h reduced physical,sensory or mental capabilities or
and knowledge,if they have been given super-vision
or insturction concerning use of the appliance in a
The appliance can be used
safe way and understand
lack of experience
the hazards involved .
The plug must be accessible after the ap pliance is positioned .
Power cords pose serious hazards to users if it is damaged,please contact
acturer or its service agent to replace the cord before using the
the manuf
appliance again .
Do not use mechanical devices or ot her means t o
recom mended by t he m anuf act ure r.
accelerate the
defrostiong process,other than those
the chemicals in the blowing agent are flammable.
If the illuminating lamp is damaged,it must be replaced by the manufacturer, its
service agent or any qualified personnel in order to prevent any safety risks from
lighting hazards.
Ensure there is no obstructions preventing proper ventilation within the
closure or in the built-in structure
appliance en
.

2
caution
For flammable refrigerants is used in the freezer,please
when installing,handling,servicing and recycing the
A light swith is built into appliance operate the interior ligting .
a transparent cover.Strictly use
LED lights can not be replaced,for replacement,please contact the local
to
Regulation require the appliance to be earthed.
symbol on the product or on its packaging
The
exercise
When the appliance is opened the light goes on automatically an swithes off
automatically when closed.(not provided in all models)
220-240V/2W max.replacement bulbs.
indicates that this
handed over to the applicable collection point to recycle its electrical
and electronic parts.By ensuring this product is disposed of correctly,
you will help to prevent poten alnegave consequences for the
environment.For more detailed,please contact your local city office,
your househole waste disposal service or the shop where you
purchased the product.
appliance.
product may not be treatde as housedhold waste.Instead it shall be
The LED is protected
after-sales service.
with

3
SAVE THESE INSTRUCTIONS
For Future Reference Please
DANGER
Risk of child entrapment.Before you throw away your old
refrigerator or freezer,take off the doors.Leave the shelves in
place so that children may not easily climb inside.
Thank you for using our produt.
guide you in getting the best use
of your freezer.
Remember to record the model and
serial number.They are on a label
in back of the freezer
Staple your receipt to your manual
You will need it to obtain warranty service.
Model number
Serilal number
Date of purchase

4
Before Use
Installation
Start -up
Temperature Setting
Freezing food
Defrosting
Trouble Shooting
The Main Functions Of The Electric Control Panel
Cleaning and maintenance
Parts And Features
Food Storage Baskets
Defrosting And Draining
1
5
6
6
6
6
6
7
7
8
9
10
10
Precautions
Table of Contents

5
FIG 1.
A Lid
B Lid seal
C Interior light(if available)
D Cabinet
E Storage compartment
F
Ventilation grille
G Control panel
H Basket
I Compressor chamber
J Compressor
K Fan(if available)
L
Back condenser(if available)
DIAGRAMS

6
BEFORE USE
· This appliance is intended st rictly for household use for storing food only
· Check if the appliace is damaged after unpacked ,please contact your dealer
· The mains electricity supply must conform to the rating plate of the appliance.
· Fully unpack the appliance.Please keep packaging materials away from children.
They should be removed and properly disposed prior to installiation.
· This appliance should be installed in a dry and well ventilated room. Place the
appliace away from direct sunlight and any heat source.
· Leave at least 10cm between the appliance and surrounding for ventilationg and
heat dissipation.
· The electricity supply must conform to the rating plate and f ollow local regulations.
· It is recommended to wait at least two hours before plugging the appliance afer
installation.This helps the refrigerant circuit to stabilise.
·Insert the plug into the wall socket.The green light(2) goes on.
·Allow the appliance to cool down for an hour before placing food inside the
compartment.
TEMPERATURE SETTING
·Turn thermostat(1) to adjust the temperature between 1(warmer)
and 8 (colder).
·The temperature will decrease from 1.setting to 8.setting
FREEZING FOOD
·Wrap or seal food in alumin
i um foil,air tight containers or food storage bags prior to
freezing.
· Allow hot food to cool prior to placing it in the appliance.
· Smaller portion of food will freeze faste r .The recommended max portion weight is 2.5kg.
· Avoid to place warm food directly in contact with frozen food.Frozen food could defrost
and may not outlast the foreseen storage time.
·
The capacity of the applian ce, as shown on the rating plate,should not be exceeded.
· When filling the appliance with higher quantities of fresh food,it is recommended to turn
to the super freeze function(if available)
· The storage time for purchased deep-frozen products varies and depends on the type
of product and its packaging.Therefore,strictly observe the producer/manufactures
instructions on the packing.
START-UP
INSTALLATION
.

7
CLEANING AND MAINTENANCE
Always ensure that the power supply is switched off prior to conducting any
If the appliance is not going to be used for an extended period,leave the door
smells building up inside.
DEFROSTING
Defrost the freezer once the frost on the freezer walls reaches
Do not use any electrical sharp or mechanical objects to
but use a plastic or wood scraper without sharp edges.Never use a metal scraper.
Proceed as follows:
1.Make sure to unplug the appliance.
2.Dry your hands thoroughly to prevent skin damage by contact
with ice (it is advised to use gloves).
3.Remove all frozen food from the appliance and put it into a
to help keep it very cold,then place the container or cool box in a cool,dry room.
4. Pull out the water drain plug (if available) located at the
so that the defrost water will drain out.
5.Scrap the ice carefully from the inner of appliance and put
6.Thoroghly clean and rinse the interior of the appliance with warm water and
remove any food or liquids.
7.Wipe the appliance with an absorbent cloth or sponge and
will help speed up the drying process.
8.Replace the drain-plug(if available).
9.Close the appliance door,replace the plug in the socket and
turn the appliance on.
10.Now re-fill the frozen food.
To prevent frozen food from defrosting,carry out the defrosting
maximum of two hours to reduce sign
of the frozen food that would shorten the storage life.
maintenance or cleaning of the appliance.
open to prevent odour and unpleasant
5-6mm thick.
remove the frost,
container or cool box,
bottom of the appliance,
in your kitchen sink.
leave the door open
procedure within a
ificant rise in temperature of

8
TROUBLESHOOTING
1.Freezer does not operate (appliance not running/getting cold).
· Is there a power failure
· Is the plug in good condition and properly plugged into the
socket?
2.
· Is the door of th e appliance closed properly?
· Is the heavy frost on the inner walls?
· Is the appliance exposed to direct sunlight or heat source?
· Are there too much warm food inside the appliance?
· The climatic class can be found on the rating label on the
back of appliance.The ambient temperature of each class is:
Climatic class Ambient temperature
SN
N
ST
T
+10°C to 32°C
+16°C to 32°C
+16°C to 38°C
+16°C to 43°C
3. The appliance make s noise.
This noise is produced when the motor in the compressor
operates and also when the refigerant circulating
throughout the system.These noises are normal.
4.Consensation build up on exernal walls
Under certain atmospheric conditons,condensation can
form on external walls of the appliance.This is normal
an will not affect the function of the appliance
If the appliance is not functionally properly

9
Fi g u ra 1
The main functions of the electric control panel
1.The control panel is numbered 1.2.3.4.5.6.7.8 and "super",this
temperature on the inside of the freezer.Reduce the temperature by turning
the dial in the clockwise direction.
· Refrigeration function:when dial is near the "1~3"position,
average temperature of freezer is approximately
Freezer function:when dial is near the "4-8"position,the interior
average temperature of freezer is approximately -2°C ～-26°C.
· Super Freeze function:when dial is near the "super",the interior
average temperature of freezer is approximately -30°C ～-32°C.
·When you change the function from the refrigeration function
to the freezer function,the foo d in the freezer should be taken
out to avoid freezen.
2.The green light is used to indicate that the appliance is
connected to a power supply and is "on".The green light will be
illuminated when the freezer is connected to an appropriate
power supply.
POWER RUN
Temperature
Control
FREEZING
super
COOLING
1
23
1. Temperature control (Thermostat)
2.Control light (green)
3.Running light (red)
light indicators
Green=CONTROL (the appliance is running)
Red=RUNNING (compressor is running )
If the red light is on,which means the compressor is running.
Once the compressor has stopped operating,the red light will turn of f.
interior
the
9°C ～1°C.
refers to the

10
There is an interior light switch in the freezer.
When the appliance is opened the
light goes on automatically and will switch off
automatically when the appliance is closed
(not provided in all models).
The LED is protected with a transparent
cover.Strictly use 220-240V/2w max.replacement
bulbs. LED lights can only be replaced by
the local after-sales
service.
Food Storage Basket (Not in all models)
see fig. 3
()
Your freezer has one or two baskts.
Removable baskets allow you to store
food more accessibly you can remove
them if not needed.
Interior light (Not in all models)
Defrosting and Draining
Defrost wheneven the frost becomes1/4 thick.Never
metallic instrument to remove the frost
coils.(A punctured coil will void the warranty)
use a sharp or
as it may damage the cooling
Unplug the unit
Remove the drain plug from the inside of the freezer.Defrosting
usually takes a fews hours.To defrost faster keep the freezer door
open.
For draining place a tray beneath the outer drain plug.Pull out the
drain plug(see fig. 4).This will let the water flow out in the tray)
(see fig.
When done,push the drain plug in.Re-plug inside the
freezer compatment.Note:monitor the container under the drain to
avoid overflow.
Wipe the interior of the freezer and replace the electrical plug in
the electrical outlet
2)

23

24
