mabe FMM200UESX0 User manual

model
FMM200UESX0

2

4
important safety instructions
• Do not use electrical appliances such as a hair dryer or heater to defrost
temperatures.
•
•
lollies can cause “Freeze burns”. If consumed straight from the
Freezer.
• Do not remove items from the Freezer compartment if your hands are
damp/wet, as this could cause skin abrasions or “Freezer burns”.
Bottles and cans must not be placed in the Freezer compartment as they
can burst when the contents freeze. Manufacturer’s recommended
storage times should be adhered to. Refer to relevant instructions.
• Do not allow children to tamper with the controls or play with the Freezer.
The Freezer is heavy. Care should be taken when moving it. It is dange
way.
•
If the power cable is damaged, it must be replaced by the manufacturer,
• This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.
• Children shall not play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
• This appliance is intended to be used in household and similar applica
environments;
- farm houses and by clients in hotels, motels and other residential
type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
•
Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
•Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Do not use electrical appliances inside the food storage compartments of
the appliance, unless they are of type recommended by the manufacturer.
•
propellant in this appliance.

5
installation
operation instructions
-
Avoid locating your
and
Freezer near a heat source, eg, cooker, boiler or radiator.
Also avoid direct sunlight in out-buildings or sun lounges.
If you are placing your Freezer in an out-building such as a garage or annex
ensure that the Freezer is placed above the damp course, otherwise con-
densation will occur on the Freezer cabinet.
when your Freezer is working, the grille at the back may become hot and the
sides warm.
It must therefore be installed so that the back of the Freezer has at least
9 cm (31/2”) of free space and the sides have 2 cm (3/4”).
Do not drape the Freezer with any covering.
Wipe the inside of the Freezer with a weak solution of bicarbonate of soda.
Then rinse with warm water using a damp sponge or cloth. Wash the
baskets and shelves in warm soapy water and dry completely before
replacing in the Freezer. The external parts of the Freezer can be cleaned
with wax polish. See page 8 for more details on cleaning.
4 3 C.
If the Freezer is not level, the door and magnetic seal alignment will be
them.
leveling the freezer
location

6
testing
1. Clean the freezer with lukewarm water and detergent,and wipe dry.
Note: Electrical components should be cleaned with a
dry cloth.
2. Turn the thermostat knob to the “2” position, and plug the freezer into
the wall outlet.The compressor will begin to run.
3. Check, after 30 minutes of operation, to ensure that the freezer is cold.
temperature control
CAUTION:
• BEFORE PLUGGING IN
YOU MUST CHECK THAT YOU HAVE A SOCKET WHICH
IS COMPATIBLE WITH THE PLUG SUPPLIED WITH THE
FREEZER. IF NOT SEE THE SECTION CALLED ELECTRI-
CAL INFORMATION ON PAGE 9.
• BEFORE SWITCHING ON!
DO NOT SWITCH ON UNTIL FOUR HOURS AFTER
MOVING THE FREEZER.
Before storing foods in your Freezer, turn the Freezer on and wait for 24
hours, to make sure it is working properly and to allow the Freezer to fail to
the correct temperature.
1. The temperature control (thermostat knob，turned by coin) is located
near the top of the unit.
2.Turning the thermostat knob adjusts the temperature of the freezer.
warmest and setting “4” is the coolest.
4. The factory recommended setting is “2” for normal operating
conditions.
1 2
34

7
in use
moving the freezer
tips and hints
1. Food should be wrapped in aluminum foil, or some other type of airtight
packing.
2. Do not allow frozen food in freezer to touch foods just placed into
freezer. It can damage the food.
3. Frozen foods from the store should be placed in the freezer promptly, so
they do not thaw.
4. Never place fresh vegetables and fruits into the freezer as they can get
freezer burn.
recommended storage periods
For recommended food storage time, refer to the information given on your
food packaging.
defrosting
1. When the freezer operates for a long period of time,the surface of the
evaporator and the drawers may become covered with a layer of white
should be promptly removed.
2. When defrosting, unplug the freezer, and remove all items from the
freezer. Either allow the frost to melt naturally from the warm air in the
room, or carefully use a plastic scraper. Finally, wipe away any remaining
ice and water, plug the freezer in, and return the food to the freezer.
CAUTION:
• NEVER USE SHARP TOOLS TO CHIP ICE AWAY.
Note: Do not turn on the freezer for 4 hours.
After the Freezer is in place it needs to be left for 4 hours.
This allows time for the coolant to settle.
location
Do not place your Freezer near a heat source, eg. Cooker, boiler or
radiator. Also avoid direct sunlight in out-buildings or sun lounges.
leveling the freezer
Make sure the Freezer is level. Use the rotating leveling feet at the front. If
the Freezer is not level, the doors and magnetic seal alignments will be

8
cleaning
cleaning interior
cleaning exterior
After defrosting you should clean the Freezer internally with a weak
solution of bicarbonate of soda. Then rinse with warm water using a damp
sponge or cloth and wipe dry. Wash the baskets in warm soapy water and
ensure they are completely dry before replacing in the Freezer.
Condensation will form on the back wall of the Fridge; however it will
normally run down the back wall and into the drain hole behind the salad
bin.
The drain hole will have a“cleaning spike” inserted into it. This ensures that
inside of your Fridge and removed any food residues from around the whole,
use the “cleaning spike” to make sure that there are no blockages.
Installation
Don’t cover or block the vents or grilles of your appliance.
troubleshooting and maintenance
power cut
the power returns, your food is safe. The food in your Freezer will remain
frozen for approx 16 hours with the door closed. Do not open the Freezer
door more than necessary.
the freezer is exceptionally cold
You may have accidentally adjusted the thermostat control dial to a higher
position.
the freezer is exceptionally warm
The compressor may not be working. Turn the thermostat control dial to
the maximum setting and wait a few minutes. If there is no humming noise,
it is not working. Contact the local store where your purchase was made.
18 C

9
condensation appears on the outside of the freezer
residue of moisture. If the problem continues contact the local store
where your purchase was made.
noises inside the freezer
If you have not owned a Freezer before, you may notice that it makes
some rather unusual noises. Most noises are perfectly normal; however
you should be aware of them!
gurgling, whooshing
These noises are caused by the circulation of the refrigerant liquid in
the cooling system. It has become more pronounced since the
performance of your Freezer.
humming, purring or pulsating
This is the compressor motor working, as it pumps the refrigerant
around the system
electrical information
this appliance must be earthed.
and carefully disposed of. To avoid a possible shock hazard, do not insert
the discarded plug into a socket.
correct disposal of this product
This marking indicates that this product should
not be disposed with other household wastes
throughout the EU. To prevent possible harm to
the environment or human health from uncontro-
lled waste disposal, recycle it responsibly to
promote the sustainable reuse of material
resources. To return your used device, please use
the return and collection systems or contact the
retailer where the product was purchased. They
can take this product for environmental safe
recycling.
the freezer is not working
Check it is plugged in and switched on. Check that the fuse in the plug
has not blown.
In another appliance, such as a lamp, to see if the socket is working.
The Freezer should be placed in a well ventilated room with an
ambient temperature of between 16 C . Leave the Freezer
for 30 minutes.
and 4 3 C
oo

Total Volume 195L

19

20
