MachPower WL-ICNAP48F-060 User manual

ACCESS POINT 300MBPS
WL-ICNAP48F-060

2

3
Thanks
for choosed our product
___________________________________________________________________
INDEX
Chapter 1 Hardware and Operation mode Instruction
1.1 LED indicator
1.2 AP Interface
1.3 Power Supply
Chapter 2 Login
Chapter 3 WEB GUI interface Setting
3.1 Status
3.2 Wizard Configuration
3.2.1 Gateway Mode
3.2.2 WiFi Repeater mode
3.2.3 WISP Operation mode
3.2.4 AP operation mode
3.3 Advanced Setting
Chapter 4 Share Internet and Obtain IP address automatically
Chapter 5 Trouble Shooting
Chapter 6 SMB Products

4
CHAPTER1
HARDWARE AND OPERATION MODE INSTRUCTION
1.1 LED indicator
Green: Power Indicator
Blue: WiFi Indicator
1.2 AP Interface
RST: Reset Button, it make AP revert to default data after press it 15 seconds.
WAN: WAN Port, connect with ADSL modem or Internet mainly. It will be LAN port under Wireless AP and WiFi Repeater operation mode
LAN: LAN Port to end users
LED: LED Indicator of WAN port and LAN port
DC: DC power connector
1.3 Power Supply
1. PoE Adapter Power Supply
The connection diagram showed as next image, internet cable connect to PoE adapter’s LAN Port, Ceiling AP’s WAN port connect to PoE
adapter’s PoE Port, then PC will access into ceiling AP through cable or wireless The PD wireless AP support 48V IEEE 802.3af standard
PoE, so PoE adapter should be 48V PoE standard.
2. Powered by PoE Switch
The connection diagram shows as next image, Internet cable from PoE Switch to Ceiling AP’s WAN Port, then PC access into ceiling AP
wired/wireless. Please notevthe PD wireless AP support 48V IEEE 802.3af standard PoE, m the PoE switch should comply with 802.3af 48V
PoE standard.
Connect Wireless AP with PC
Use can connect the PC with wireless AP by Wireless SSID and LAN cable
The diagram of wireless connection showed as follow: Please note: the default SSID is MachPower2.4, SSID’s password is 12345678

5
The diagram of LAN cable connection showed as follow
CHAPTER2
LOGIN
1. Connect the Ceiling AP with computer
2. Configure the PC’s local connection IP address as 192.168.188.X (X is number from 2 to 254), subnet mask is 255.255.255.0, follow
next image to finish.
3. Input 192.168.0.254 into IE browser, then pop up the login page, the default login password: admin, then login, following next
image.

6
4. After login, then P7 Device Status will be showed;
This page will show the AP’s default operation mode, channel, connection status, CPU usage, Wireless settings, LAN Setting, AP’s
Location, CPE’s hardware/firmware version.
CHAPTER3
WEB GUI INTERFACE SETTING
3.1 Status
After login, then P8 Device Status will be showed
In this page, show the AP’s default operation mode is AP mode, channel is 9, end user QTY of this AP, connection status, CPU usage
status. Then in Wireless Setting, GUI configuration page showed as below:
User can configure the SSID, password, band width, channel here, then Apply to finish.

7
LAN Setting to configure the DHCP or Fix IP
AP location setting: can mark where the AP set up, and AP name as next image.

8
3.2 Wizard Configuration
Click Wizard in Status page, will pop up following page to configure the operation mode:
There are four operation mode of this ceiling wireless AP, and there are explanation for each operation mode for better application.
3.2.1 Gateway Mode
Click Gateway mode, will pop up following pictures: Please choose the right WAN setting mode, then click next to continue.

9
To make the AP in some clear channel, user can click wireless analyzer at first. Picture showed as below
When click Next, then will complete the Gateway mode setting and show following picture

10
When return to Status, the page showed as follow
3.2.2 WiFi Repeater mode
Click WiFi Repeater operation mode in Wizard, then following page will pop up, and choose the right SSID to bridge, then next to
complete.
Click Return button, will back to Status, show Repeater mode data, show fail or success, and user can configure this data in this
page if required.

11
In wifi repeater operation mode, the default is SSID disable. If want to enable SSID, then click Wireless Setting.
Please note, when click wireless relay setting, following page will pop up, you can make change from here easy:
3.2.3 WISP Operation mode
Click WISP operation mode in Wizard, then will pop up the configure page, pls set the WISP operation mode based on the stepes
showed in picture

12
Configure the right WAN setting in WISP operation mode, then next to complete
Then complete and back to status, will show the connection fail or success, then can configure the data based on request

13
Remark: When click WAN Setting, will pop up following picture:
3.2.4 AP Operation mode
Set the wireless data, AP Location info as required, then click next to continue and enter into LAN setting. After LAN setting, com-
plete the AP mode configuration and back to Status

14
3.3 Advanced setting
In advanced setting, user can check the ceiling AP’s firmware version, working status, wireless, LAN Status, upgrade firmware,
Reset. Let’s Click Advanced Setting in status page, will show return home, Setup Wizard which we showed before. Let’s shown mode
in Device Status, Wireless, Network and Management.
Device Status: In this page, mainly to check the ceiling AP’s status in firmware version, Wireless status and LAN status

15
2.4G Wireless Setting: In this part, will show the Basic Setting, Virtual AP, Access control and Advanced Setting
2G Wireless Analyzer: Mainly to analyze the AP’s singal strength in some channel, to make user more easy to choose the
right channel and avoid the wifi interface.

16
Virtural AP: There are 3 virtural AP in 2.4G wireless, if need virtural SSID, then users can configure it showed in following picture
2.4G Access Control: Mainly show MAC allow or deny
Advanced Settings: In this page, will show the regional, RF Power, Max user access

17
Network setting: In this page, mainly to show the LAN setting and VLAN as follow

18
Management: In this part, show the system time, Logs, upgrade firmware, system, user info. And we show System time, how to
upgrade firmware and system page to users:

19
CHAPTER4
SHARE INTERNET AND OBTAIN IP ADDRESS AUTOMATICALLY
Set computer’s TPC/IP as Obtain an IP address automatically, Obtain DNS server address automatically as following picture showed.
the computer will obtain the IP address from router or base station to get Internet.
CHAPTER5
TROUBLE SHOOTING
The Failure phenomenon and solution
Failure phenomenon Solution
SYS Indicator off Pls make sure the PoE module connection is right. POE Port connect with
AP, LAN port connect with computer
Can’t land to Wireless AP through Web page
Pls check the IP address of computer and Wireless AP to see whether
they are in same networking segment, The method is click “start”-“Run”
input“cmd”,ping 192.168.0.254 to test the Wireless AP connectivity.
Reset Wireless AP and load it again;
Pls make sure the IP address 192.168.0.254 is not occupied by other device
in Wireless AP’s networking;
Check computer and cable problem, recommend to use 10/100M UTP
unshielded cable;
Clean up Arp binding from “Start”-“Run” input“cmd” arp –d
Clean the IE Brower’s temporary files and Cache file.
Wireless AP can’t connect with AP (the status display unconnected)
Try to scan the avaliable wireless networking again;
Make sure the Wireless AP’s wireless standard is correct;(2.4Ghz
signal should connect 2.4Ghz, 5.8Ghz signal should connect 5.8Ghz signal; )
The Security and passwords are matched between Wireless AP and AP;
The signal strength of AP is too weak to connect, should be more than
-75dBm;
Can’t scan the wireless AP
Scan it several times more;
If using 5Ghz to scan, please make sure there are 5G signal existed.
Reset the Wireless AP, scan it again after Wireless AP restart;
The connection of Wireless AP and AP is success, but the computer can’t
share internet
Pls Check the computer’s IP address and DNS setting. If it is dynamin, set
the network card as automatically obtain. If it is static IP, pls contact with
ISP for correct IP address and DNS address.
How to Reset Wireless AP Press the “Reset” button more than 15 seconds after power on. The Wire-
less AP will restore factory default after the Wireless AP restart.

20
