MachPower WL-IWNAP48-062 User manual

IN WALL ACCESS POINT 300MPBS
WL-IWNAP48-062
USER MANUAL

Thanks
for choosing a product Mach Power®
3

4

5
INDEX
Chapter 1 AP Interface
1.1 Top Side
1.2 Back Side
1.3 Led indicator
1.4 Set the in wall AP into cassette
1.5 Working diagram
Chapter 2 Login
Chapter 3 WEB GUI interface Setting
3.1 Status
3.2 Wizard Configuration
3.2.1 Gateway Mode
3.2.2 WiFi Repeater mode
3.2.3 WISP Operation mode
3.2.4 AP Operatipon mode
3.3 Advanced Setting
3.3.1 Device Status
3.3.2 2.4G Wireless Setting
3.3.3 2G Wireless Analyzer
3.3.4 Virtual AP
3.3.5 2.4G Access Control
3.3.6 Advanced Settings
3.3.7 Network setting
3.3.8 Management
Chapter 4 Share Internet and Obtain IP address automatically
Chapter 5 Trouble Shooting

6
This is the user manual of 300Mbps In Wall Wireless AP with Qualcomm QCA9531 chipset,
which will approximate guide you how to set and apply the In Wall Wireless AP, it provide a
convenient graphical interface for network construction and maintenance person, as well
as a user through a simple and accurate operation, and configuration management of the in
wall wireless access point.
CHAPTER 1
AP INTERFACE
1.1 Top Side

7
1.2 Back Side
RST: Reset Button, it make AP revert to default data after press it 15 seconds.
LAN: LAN Port to end users, like PC, TV
RJ11 port: Telephone port to connect with telephone
LED: LED Indicator to show the working status
WAN: WAN Port, connect with ADSL modem or Internet mainly. It support IEEE 802.3af PoE.
1.3 Led indicator
LED LED Name LED Status Instruction
WiFi LED Light Twinkle WiFi SSID on
Internet LED Light Twinkle WAN Port work
System Status LED Light Twinkle System Run

8
1.4 Set the in wall AP into cassette
Before set the in wall AP into cassette, make sure the cassette’s size is 86mm x 86mm
Then set the in wall AP as following steps
1.5 Working diagram
In this diagram, please pay attention in following points:
1. PoE Switch: If AP support 24V Passive PoE, then PoE switch should comply with 24V Pas-
sive PoE, if AP support 48V IEEE802.3af/at standard PoE, then PoE switch should comply
with IEEE802.3af/at standard PoE.
2. Recommend to make WLAN Controller to central manage the wireless AP
3. If end user will do captive portal authentication or accounting, better to make Gateway
access into cloud server.
4. If PC or smart phone connect with wireless AP in WiFi, the SSID is MachPower2.4,
default password is 12345678

9

10
CHAPTER 2
LOGIN
1. Connect the In Wall Wireless AP with computer in LAN cable
2. Configure the PC’s local connection IP address as 192.168.0.X (X is number from 2 to
254), subnet mask is 255.255.255.0, follow the image1.
3. Input 192.168.0.254 into IE browser, then pop up the login page, the default login pas-
sword: admin, then login, please do following image2.
4. After login, then image3 Device Status will be showed;
This page will show the AP’s default operation mode, channel, connection status, CPU
usage, Wireless settings, LAN Setting, AP’s Location, CPE’s hardware/firmware version.
image1: Setting of computer’s IP address

11
image2 : Login
image3: Device Status

12
CHAPTER 3
WEB GUI INTERFACE SETTING
3.1 Status
After login, then image5 Device Status will be showed
image5: Device Status
In this page, show the AP’s default operation mode is AP mode, channel is 11, end user QTY
of this AP, connection status, CPU usage status...
Then in Wireless Setting, GUI configuration page showed as below:
User can configure the SSID, password, band width, channel here, then Apply to finish.
LAN Setting to configure the DHCP or Fix IP
AP location setting: can mark where the AP set up, and AP name as image6:

13
image6: Wireless setting, LAN Setting, AP Postion setting
3.2 Wizard Configuration
Click Wizard in Status page, will pop up following page to configure the operation mode:
There are four operation mode of this in wall wireless AP, and there are explanation for
each operation mode for better application.

14
image7: Operation mode
3.2.1 Gateway Mode
Click Gateway mode, will pop up following pictures:
Please choose the right WAN setting mode, then click next to continue.
image8: WAN setting in Gateway Mode

15
image9: Wireless Setting in Gateway Mode
To make the AP in some clear channel, user can click wireless analyzer at first. Picture
showed as below:
image10: Channel Analysis

16
When click Next, then will complete the Gateway mode setting and show following picture:
image11: Complete the setting in Gateway Mode
When return to Status, the page showed as follow
image12: Status in Gateway Mode

17
3.2.2 WiFi Repeater mode
Click WiFi Repeater operation mode in Wizard, then following page will pop up, and choose
the right SSID to bridge, then next to complete.
image13: Repeater Mode
Click Return button, will back to Status, show Repeater mode data, show fail or success,
and user can configure this data in this page if required
image14: Status in Repeater Mode

18
In wifi repeater operation mode, the default is SSID disable. If want to enable SSID, then
click Wireless Setting.
Please note: when click wireless relay setting, following page will pop up, you can make
change from here easy:
image15: Wireless Relay Setting
3.2.3 WISP Operation mode
Click WISP operation mode in Wizard, then will pop up the configure page, please set the
WISP operation mode based on the stepes showed in picture:

19
image16: WISP Mode
Configure the right WAN setting in WISP operation mode, then next to complete
image17: WAN setting in WISP mode

20
Click WISP operation mode in Wizard, then will pop up the configure page, please set the
WISP operation
image18: Status in WISP mode
Remark: When click WAN Setting, will pop up following picture
image19: WAN setting in WISP mode
