MULTI
TURN-ONLY AND
TURN&TILT HARDWARE
Maintenance and adjustment instructions
for turn-only, turn&tilt, tilt-first and
tilt windows
CERTIFIED SPECIALIST

- 2 -
Contents
Safety and warning information 3 - 4
Measures to preserve the surface finish 5
Setting the turn-only, turn&tilt and tilt-first sash 6 - 11
Setting the scissor stay or turn-only hinge - sash part – lift/lower 6 - 7
Setting the scissor stay or turn-only hinge – gasket compression 7 - 8
Pivot post setting 9 - 11
Tilt-only sash setting 12
Setting the closing element, the bullet catch and
the sash lifter 13
Hinging and unhinging the sash 14 - 15
Exchange of window rebate seals 16
WARNING! These maintenance instructions are only
intended for certified specialists and their trained
employees.
In addition to these maintenance instructions, the
operation and maintenance instructions for the
end user must always be observed (757071EN).
These instructions can also be downloaded from
www.maco.eu, order number 757070EN.

- 3 -
Safety and warning information
WARNING! Risk of injury due to improper maintenance
operations.
Improper maintenance can lead to serious personal
injury or material damage.
For this reason:
› Before starting work, ensure there is sucient
room for carrying out assembly work.
› Ensure that the assembly site is kept clean and
tidy. Loose components and tools lying around or
on top of each other can cause an accident. Only
use intact tools.
› Work, such as the adjustment of hardware –
particularly near to the pivot post and the scissor
stay – as well as the replacement of parts and the
hinging and unhinging of the sash must only be
carried out by trained, skilled personnel.
WARNING! Risk of injury due to heavy sashes.
Non-compliance can result in serious personal injury
or material damage.
For this reason:
› Correctly assess the weight of the sash before
starting work.
› Large and/or heavy sashes should always be
hinged and unhinged by several people.
Overloading can result in serious long-term eects
(back problems).
WARNING! Windows with damaged or defective hardware
components must be secured to prevent any kind of
use. Damaged or defective hardware components
must be replaced immediately.
NOTE! When replacing hardware components, you must
observe the relevant assembly instructions and/or
the package leaet.
Once hardware components have been replaced, the
plastic drive track retaining clip must be‚ ‘snapped‘
on rst operation. You must always check that the
repaired sash functions correctly.

- 4 -
NOTE! Warranty claims can only be accepted if all
maintenance operations have been carried out in full
and according to the maintenance intervals
(specied in the end user operating instructions), and
this can be veried.
NOTE! Warranty claims can only be accepted if the unit has
been installed correctly and by a certied specialist.

- 5 -
Measures to preserve the
surface nish
Protection against soiling:
› The hardware should be kept free of debris and soiling.
Immediately remove soiling during the building stage caused by
plaster, mortar or similar with water.
› Protect hardware components from contamination (dust, dirt,
paint, etc.).
WARNING! Faulty or damaged parts must be immediately
put right.
Protection against corrosion:
› Ventilate the hardware and or the rebate areas so that they are
not exposed to direct moisture or condensation (important during
the building stage).
› Aggressive vapours in conjunction with small formations of
condensation can lead to fast corrosion of the hardware
components.
› Timber frames and sashes with a high concentration of (tannic)
acid must be treated with suitable surface coatings to ensure that
these contents do not evaporate from the timber.
› No acetic acid or cross-linked acidic sealing compounds or those
with the above mentioned contents may be used.
› The hardware must not be damaged with sharp edged tools.
› Clean the ttings with a moist cloth, avoid permanent wetness!
Protection against corrosive, acidiferous cleaning agents:
› Clean the ttings with a so, lint-free cloth and a mild, pH-neutral
cleaning agent in diluted form only. Never use aggressive, acidic,
solvent-based or abrasive cleaners (scouring pads, steel wool,
etc.). This can result in damage to the hardware!
› If hardware is damaged in this manner, it may impair the
function and the safety characteristics. This can result in personal
injury.
Defective or damaged points must be repaired and restored
immediately.
› We recommend re-treating the cropped edges of TRICOAT-PLUS
ttings with the TRICOAT-PLUS touch-up paint.

- 6 -
max. 1
+2,85 / -1,8
4
1.
90 °
90 °
Setting scissor stay or turn-only hinge
1. Lift/lower
› MULTI-MATIC / MULTI-TREND corner hinge version
DANGER!
The adjusting screw
must not protrude
more than a
maximum of 1 mm!
Adjustment values are always specied in regard to the
hinge-side air gap and/or the bottom horizontal air gap.
The bayonet bolt on the rebated scissor stay
support arm is only for the side adjustment! CHECK
that the bayonet bolt is exactly at 90°! If it is not,
the sash can fall out of the window frame.
DANGER!
Version up to 2020
Version from 2020

- 7 -
-3 / +5
9
-4,1 / +1,7
4
› MULTI-MATIC / MULTI-TREND stay and hinge
DANGER!
The sash may only be lowered to the third notch and/or to
the red mark, otherwise the sash can fall out!
› MULTI MAMMUT
The side adjustment of the scissor stays up to
version 2 requires the mandatory use of feeler gauge
item no. 468684 to ensure that the minimum
adjustment measurement is not underrun!
DANGER!

- 8 -
15
-2,5 / +1
2.1.
4
-1 / +1
› MULTI POWER
2. Gasket compression
› MULTI-MATIC scissor stay

- 9 -
4
-1 / +1
-0,7 / +0,7
15
2.1.
-1,5 / +1,5
4
› MULTI POWER scissor stay
› MULTI POWER turn-only hinge - sash part
› MULTI-MATIC turn-only hinge - sash part

- 10 -
-1 / +1
15
-1 / +1
4
=
=
-2 / +2
4
-2,3 / +2,3
4
-2 / +3
4
-2 / +2
4
-2,3 / +2,3
4
Pivot post setting
› PVC / DT / TO / AS pivot post
› PVC / AS rebated corner support

- 11 -
-0,75 / +0,7
5
15
-2 / +2
4
4
-2 / +2
4
-3 / +3 -2 / +3
4
› Drill-in pivot post
› MULTI MAMMUT pivot post

- 12 -
-1 / +2
4
-1 / +2
4
-0,5 / +0,5
15
› MULTI POWER pivot post

- 13 -
4
-2 / +2
-1 / +1
4
=
3.
2.
1.
-2,5 / +2,5
Tilt-only sash setting
› Gasket compression
› Side adjustment
› Lift/lower

- 14 -
15
-0,55 / +0,55 -0,75 / +0,75
9
-3 / +3
15
-3 / +3
15
-0,5 / +0,5
-2 / +2
4
MULTI-MATIC MULTI-TREND
Setting the closing element, the bullet
catch and the sash lier
› Setting the gasket compression on the cam
› Setting the sash lifter
› Setting the door catch and/or the bullet catch roll
i.S. Security roller cam Locking cam

- 15 -
1.
2.
3.
2.
1.
1. Remove the cover, if there is one.
2. Pull the scissor stay-hinge pin downwards with a suitable tool. The
scissor stay hinge pin can only be withdrawn when the window is
closed.
3. Open the sash 90° (secure against tilting on the espagnolette
side), move the rebated scissor stay support arm out of the
scissor stay hinge and li the sash out of the pivot post. For
hinging, carry out the above steps in reverse order.
› MULTI-MATIC / MULTI-TREND scissor stay hinge – stay and hinge
As above, with the exception that a catch must be also clipped into
the scissor stay hinge pin.
Correct position of the
pin aer hinging
Correct position of the
pin aer hinging
Hinging and unhinging the sash
› MULTI-MATIC / MULTI-TREND scissor stay hinge – PVC / DT / AS
DANGER!
DANGER!

- 16 -
1.
2.
3.
1.
2.
1.
2.
3.
3.
4.
2
1
4
5
6
3
1. Remove the locking screw.
2. Remove the scissor stay hinge pin.
3. Pull the scissor stay hinge pin
downwards and open the sash 90°.
4. Move the rebated scissor stay
support arm out of the scissor stay
hinge and li the sash out of the
pivot post.
For hinging, carry out the above
steps in reverse order.
DANGER!
It is essential that the
scissor stay hinge pin is
installed.
› MULTI MAMMUT scissor stay hinge
› MULTI POWER (see also video at www.maco.eu):
1. Open the sash 90°.
2. Trigger the mishandling
device 1(only on turn&tilt
windows), turn the handle to
the tilt position 2.
3. Open the scissor stay arm safety
device/turn-only hinge arm safety
device 3.
4. Li the scissor stay and/or
turn-only hinge arm until it is
completely free 4, then move it
into the frame 5.
5. Close the sash.
6. Tilt the sash slightly and li it up and
out 6.
For hinging, carry out the above steps
in reverse order.

- 17 -
Disposal of hardware and hinge components must comply
with local regulations or laws.
