MacroAir Technologies X Series User manual

Operation Manual
MacroAir Local
Override Remote

Table of Contents
© 2020 MacroAir Technologies Toll Free: 866 668-3247 Fax: [phone] www.macroairfans.com
Local Override Remote Operation Manual 90-30059-00 Rev A-01 Date: 060120
1
Introduction
Wiring the Fan
Wiring Diagrams
Operation
Appendices
Caution & Safety .........................................2
Remote Enclosure,
Control Panel Enclosure ..............................3
Remote Panel Overview,
Control Panel Overview ..............................4
Remote Panel Schematic ............................7
Control Panel Schematic
Single Phase (Low Voltage) .........................8
Control Panel Schematic
Three Phase (Low Voltage) .........................9
Control Panel Schematic
Three Phase (High Voltage) ...................... 10
Basic Operation ......................................... 11
Warranty ................................................. 12
Technical Support .................................... 13

2Introduction
© 2020 MacroAir Technologies Toll Free: 866 668-3247 Fax: [phone] www.macroairfans.com
Local Override Remote Operation Manual 90-30059-00 Rev A-01 Date: 060120
Caution and Safety
ATTENTION: Safety. READ THE ENTIRE MANUAL BEFORE OPERATING THE FAN. Ensure that
all safety practices and instructions are followed during the installation, operation, and servicing
of the fan. Failure to apply these safety practices could result in death or serious injury. If you do
not understand the instructions, please call our Technical Department for guidance.
ATTENTION: Qualified Technicians. All fan controls and incoming power should only be
installed by qualified technicians familiar with the requirements of the National Electrical Code
(NEC) and local codes. Refer to appropriate portions of this manual for other important
ATTENTION: Damp and Corrosive Environments. MacroAir provides a stainless-steel fan
alternative especially for excessively damp, caustic, or corrosive environments. It is
recommended that the environmental conditions acting on a fan installation be reviewed to
insure the proper choice of a fan purchase and special warranty considerations.
ATTENTION: Code Compliance. Installation is to be in accordance with the NEC, ANDSI/NFPA
70-1999 and local codes.
Hazard of Electrical Shock, Explosion or Arc Flash:
ATTENTION: Read. Read and understand this manual before installing or operating a fan unit.
Installation, adjustment, repair, and maintenance must be performed by qualified personnel.
ATTENTION: Code Compliance. The user is responsible for compliance with all international
and National Electrical Code requirements with respect to grounding of all equipment.
WARNING: Do Not Touch. Many of the parts of this unit operate at line voltage. DO NOT
TOUCH.
WARNING: Covers. Install all covers before applying power or starting and stopping the unit.
Installation and Service
WARNING: Damage. Do not operate or install any fans or fan accessories that appear to be
damaged.
WARNING: Death and Injury. Failure to follow this instruction can result in death, serious
injury, or equipment damage.
WARNING: Disconnect Power. If the fan does not operate properly using the procedures in
this manual. BE CERTAIN TO REMOVE ALL POWER TO THE UNIT and contact our technical
department for further assistance.
CAUTION: Moving Parts. Keep all body parts clear of moving parts at all times.
ATTENTION: Qualified Technicians. All electrical troubleshooting and repair must be done by
a qualified technician and meet all applicable codes.
REFER TO FAN INSTALLATION MANUAL(S) FOR FURTHER MAINTENANCE INFORMATION.

3Introduction
© 2020 MacroAir Technologies Toll Free: 866 668-3247 Fax: [phone] www.macroairfans.com
Local Override Remote Operation Manual 90-30059-00 Rev A-01 Date: 060120
Remote Enclosure
Control Panel Enclosure
Images are not to scale

4Wiring the Fan
© 2020 MacroAir Technologies Toll Free: 866 668-3247 Fax: [phone] www.macroairfans.com
Local Override Remote Operation Manual 90-30059-00 Rev A-01 Date: 060120
Remote Panel Overview
Control Panel Overview
1 Phase (Low Voltage)

Wiring the Fan
© 2020 MacroAir Technologies Toll Free: 866 668-3247 Fax: [phone] www.macroairfans.com
Local Override Remote Operation Manual 90-30059-00 Rev A-01 Date: 060120
5
Control Panel Overview, cont.
3 Phase (Low Voltage)
3 Phase (High Voltage)

Wiring the Fan
© 2020 MacroAir Technologies Toll Free: 866 668-3247 Fax: [phone] www.macroairfans.com
Local Override Remote Operation Manual 90-30059-00 Rev A-01 Date: 060120
6
Control Panel Overview, cont.
1. Control Panels come pre-wired, as illustrated on pages 4-5.
2. Make sure the control wiring is CAT5e shielded, stranded or greater.
3. If removed from the enclosure, the disconnect switch must be in the OFF position when
removed, and in the OFF position when reinstalled to prevent misalignment of switch.
4. The Motor Cable Gland and the Cable Gland for Analog Control do not come pre-installed.
Use a unibit to drill installation holes.
5. Shielded motor cable is provided and must be used with no additional cable to maintain
factory warranty.
6. Mounting hardware for mounting enclosure to an I-beam, Glulam or wall is not supplied by
MacroAir.
7. Connect CAT5e ntroller.
This control panel overview supersedes and replaces that found in your fan Operation Manual.

7Wiring Diagrams
© 2020 MacroAir Technologies Toll Free: 866 668-3247 Fax: [phone] www.macroairfans.com
Local Override Remote Operation Manual 90-30059-00 Rev A-01 Date: 060120
Remote Panel Schematic

Wiring Diagrams
© 2020 MacroAir Technologies Toll Free: 866 668-3247 Fax: [phone] www.macroairfans.com
Local Override Remote Operation Manual 90-30059-00 Rev A-01 Date: 060120
8
Control Panel Schematic - Single Phase (Low Voltage)
This control panel schematic supersedes and replaces that found in your fan Operation Manual.

Wiring Diagrams
© 2020 MacroAir Technologies Toll Free: 866 668-3247 Fax: [phone] www.macroairfans.com
Local Override Remote Operation Manual 90-30059-00 Rev A-01 Date: 060120
9
Control Panel Schematic -Three Phase (Low Voltage)
This control panel schematic supersedes and replaces that found in your fan Operation Manual.

Wiring Diagrams
© 2020 MacroAir Technologies Toll Free: 866 668-3247 Fax: [phone] www.macroairfans.com
Local Override Remote Operation Manual 90-30059-00 Rev A-01 Date: 060120
10
Control Panel Schematic -Three Phase (High Voltage)
This control panel schematic supersedes and replaces that found in your fan Operation Manual.

11 Operation
© 2020 MacroAir Technologies Toll Free: 866 668-3247 Fax: [phone] www.macroairfans.com
Local Override Remote Operation Manual 90-30059-00 Rev A-01 Date: 060120
Basic Operation
OFF: To turn off the fan set to FWD (forward) or REV (reverse) with a speed of 0.
This will turn the fan off and prevent the BMS from running the fan.
AUTO: When
the BMS and will start and stop automatically.
AIRLYNK: Refer to the AirLynk manual for information regarding the AirLynk.
FAN: Refer to the fan manual for information regarding the fan.
REMOTE FAIL: If the Local Override Remote fails to operate the fan, check the
wiring, and/or check the VFD for faults.

12 Appendices
© 2020 MacroAir Technologies Toll Free: 866 668-3247 Fax: [phone] www.macroairfans.com
Local Override Remote Operation Manual 90-30059-00 Rev A-01 Date: 060120
Warranty
MacroAir warrants the products listed in the table below will be free from defects in materials and workmanship
under normal use and maintenance for the applicable warranty period. Other than the warranty set forth in this
document, no other written or oral warranties apply, and no employee, agent, dealer, or other person is authorized
to give any other warranties on behalf of MacroAir.
START DATE OF WARRANTY COVERAGE
Warranty period for X Series and AVD fans with 50,000 operating hours covers the Motor, Electrical Controls, and
Remote for 50,000 hours of run time. For all other fans, the warranty period begins fifteen (15) days following
shipment of the product, or on the date the product is installed (not to exceed sixty (60) days Customer receives the
product), whichever date is later. Customer should retain necessary documentation to verify the date of receipt and
installation of the product. Customer will be required to produce this documentation in order to obtain warranty
services from MacroAir. The warranty specified herein applies only to products purchased on or after October 31,
2019.
PRODUCTS AND SYSTEMS COVERED BY THIS WARRANTY AND APPLICABLE WARRANTY PERIODS:
Fan Type Mechanical: Blades, Hub & Frame Standard Electrical1: Motor,
Electrical Controls, Remote Labor
X Series Lifetime 50,000 Operating Hours 1 Year
Y Series Lifetime 7 Years 1 Year
Z Series Lifetime 5 Years 1 Year
AirVolution-D 780 Lifetime 50,000 Operating Hours 1 Year
AirVolution-D 550 Lifetime 50,000 Operating Hours 1 Year
AirVolution-D3 Lifetime 50,000 Operating Hours 1 Year
AirVolution-D 370 Lifetime 50,000 Operating Hours 1 Year
Airlite Shop Fan Lifetime 2 Years N/A
WARRANTY COVERAGE:
Subject to the exclusions herein, the MacroAir warranty covers any defects in workmanship or materials of the
covered products under normal operation and prescribed maintenance when those defects adversely affect the
ability of the product to operate properly.2 The warranty only covers products which have been installed in
compliance with MacroAir's written installation instructions by a MacroAir approved installation technician or
licensed electrical contractor and operated and maintained by the customer in conformity with MacroAir's written
instructions, and when the product is purchased directly from MacroAir or a MacroAir Authorized Dealer.
This warranty is subject to all provisions, conditions, limitations, and exclusions explained in
this warranty document.
* If your product is not listed on this warranty page, scan this QR code or visit macroairfans.com/warranty
for full warranty information.
1 "Standard Electrical" means any common electrical component that is utilized across more than one fan line will assume the higher warranty period.
2 "Operate properly" applies only to mechanical, electrical, and structural systems of the product.

13 Appendices
© 2020 MacroAir Technologies Toll Free: 866 668-3247 Fax: [phone] www.macroairfans.com
Local Override Remote Operation Manual 90-30059-00 Rev A-01 Date: 060120
Technical Support
Thank you for purchasing the Local Override for MacroAir Fans.
Please call MacroAir Fans for Technical Support of the Local Override product.
Support Contact Information:
MacroAir Fans
794 S. Allen Street
San Bernardino, CA. 92408
MacroAir Fans Service:
866-668-3247 option 2
Website: www.macroairfans.com/support
For Installation assistance, application questions, technical support, and any other inquiries,
please contact our Technical Support team at [phone].

794 South Allen Street
San Bernardino, CA 92408
[phone]
Macroairfans.com
