macromatic COKP Series User manual




Installation & Wiring
Mount the appropriate 8 pin octal socket (such as the Macromatic 70169-D or Custom Connector OT08-PC)
in a suitable enclosure. When making connections to the socket, make sure to match the terminal numbers
on the socket to the ones shown on the wiring diagram (the wiring diagram on the relay is the view looking
towards the bottom of the relay vs. the top of the socket). Use one or two #12-22 solid or stranded copper or
copper-clad aluminum conductors with terminals on Macromatic or Custom Connector sockets - a terminal
tightening torque of 12 in-lbs should be used.
901-0000-331










Wiring
See back page


If the unit fails to operate properly, check that all connections are correct per the appropriate wiring diagram on the product. If problems continue, contact
Macromatic via email at [email protected] for assistance.
Warranty
All catalog-listed COKP Series Relays manufactured by Macromatic are warranted to be free from defects in workmanship or material under normal service
and use for a period of ve (5) years from date of manufacture.
Macromatic Industrial Controls, Inc. • 2201 Corporate Drive • Waukesha, WI 53189
For product information and technical support go to www.macromatic.com/contact
 
The pick-up current setting is user-adjustable within one of three ranges. An
external current transformer can be used to extend the range beyond 10 am-
peres. The drop-out setting is adjustable from 50-95% of the selected pick-up
setting. The relay will energize when the monitored AC current is above the
pick-up setting for a period longer than the adjustable time delay (t) of 0.1-10
seconds. This delay prevents nuisance tripping caused by inrush currents. It
will de-energize when the monitored AC current is below the drop-out setting.
