Mactech MESD-BC Series User manual

MA-BC04
MESD-BC SERIES
Please read the instructions carefully before using the ionizer, and keep it for
future reference.
BAR TYPE IONIZER INSTRUCTIONS

2
INDEX
Product Description 3
Dimension 4
Product Specification 5
Abnormal Wiring Figure 5
Power Supply 6
Installation 6
Manual guide 7
ID Control / Adjust and Remote Setting 7
Remote Controller Instruction 8
Remote Controller Valid Range 8
Ion Proportion Setting 9
Status Display 11
Wiring Instruction 12
Consumable 12
Attention 13

3
Product Instruction
1. Input power DC24V
2. Serial connection port (Maximum 16 sets)
3. ID setting knob (Press ID channel on the remote controller before using the ionizer)
4. Remote controller infrared receive port
5. System status display
6. Assisting nozzle
7. Quick-released nozzle
Please ensure you have following items on hand when receive the product.
The needle point of electrode probe generates ion by corona discharge, and
transmits ion to object via air flow. Through this way can achieve static elimination
effectively; moreover, it can prevent pollution caused by the ionizer and improve
production rate and quality.
1
2
3
4
5
6
7

4
Dimension
Unit:mm
Model
A
B
C
D
No. of
Fixtures
No. of
Probes
MESD-BC036
434
390
356
180
0
4
MESD-BC060
568
524
490
413
0
8
MESD-BC084
801
757
723
646
0
12
MESD-BC108
1034
990
956
879
1
16
MESD-BC132
1267
1223
1189
1112
1
20
MESD-BC156
1500
1456
1422
1345
1
24
MESD-BC180
1733
1689
1655
1578
2
28
MESD-BC204
1966
1922
1888
1811
2
32
MESD-BC228
2199
2155
2121
2044
2
36
MESD-BC252
2432
2388
2354
2277
3
40
MESD-BC300
2898
2854
2820
2743
3
48
A. Total Length
B. Install Distance
C. Bar Length (=Effective length)
D. Electrode Spacing and Length

5
Product Specification
Abnormal Wiring Figure
Output method: Open collector
Brown
White
Black
Blue
Black

6
Power Supply
 Rated power output DC24V.
 Please ensure the product is connected with ground wire for safety
consideration.
Installation
Ambient temperature range: 0~50℃, humidity range: 35~65%RH
Avoid installing in which the ambient temperature rapidly changes.
Please check there are not volatile or inflammable material and corrosive
gases around the ionizer.
Avoid installing to the environment with heavy dust, fumes and iron
powder.
Please fasten the ionizer above the object and connect with the power,
ground wire and air pressure tube.
Please use clean air via air filter and adjust the proper air pressure at
0.1~0.5Mpa. (More detailed information please refer to specification )
After using for a period time, the needle point of electrode probe could
attach crystallized particle or dust due to moisture. If meet this problem,
please wipe the needle point of electrode probe slightly by alcohol cotton
or soft brush.
Please clean the needle point of electrode probe frequently in order to
extend the product's service life and achieve great static elimination
effectiveness.
Please contact service staff when the alarm sign shown, do not
disassemble the ionizer directly.
The ionizer with safety circuit detection, if there is abnormal adjustment it
will shut down automatically. By the time please restart the ionizer.
Due to the total length, the model above MESD-BC108 please fasten the
reinforce fixture at the mark position in order to prevent product bending.
When install longer ionizer, the model above MESD-BC180, it should be
at least two staff to complete the installation, in case of danger or product
damage.

7
Manual Guide
1. Install the ionizer in appropriate place.
2. Connect with the air pressure tube and power.
3. Adjust the ID setting knob on the ionizer. For example, the knob turns to
“1” which means the remote controller has to set up the same ID channel
“1”. (Please refer to the description as below)
4. The infrared transmitter on the remote controller corresponds to the
infrared receive port on the ionizer. Please follow the instructions to
complete the remote controller setting. (Please refer to the remote
controller valid range)
5. After setting up the channel, press the icon”” on the remote
controller to turn on the ionizer.
6. Press arrow icon “ ” and “ ” on the remote controller to adjust the
Ion proportion. And the icon“” which means factory reset (50% of +/-
ion).
7.
Press arrow icon “ ” and “ ” on the remote controller to adjust the
frequency, maximum is level ten. And the icon“” which means factory
reset (F=3)
ID adjustment & Remote Controller description
Signal
Description
Signal
Description
A-01~A-02
Internal communication
error
A-04
High voltage error
A-03
No high voltage output
A-08
Abnormal wiring
Remark：If there has other ionizers, please set up different ID channel to
avoid receiving mistaken signal.

8
Remote Controller Instruction
System status display
Remote Controller Effective Range
The infrared
transmitter on
the remote
controller
corresponds to
the infrared
receive port on
the ionizer.
The infrared
transmitter
Press ID channel on the
remote controller
corresponds to ID setting
knob on the ionizer.
ID adjustment panel
Press and pull out the
battery pack to change the
battery.
Battery pack
Power
Press arrow icon
to adjust the
frequency,
maximum is level
ten.
Output High
Voltage
frequency
Maximum: D70
Minimum: D30
Factory reset: D50
Ion proportion Setting

9
Static Elimination Performance
Static elimination effective zone and time
Ion proportion Setting
Ion proportion
Setting
d70
d65
d60
d55
d50
Positive ions
Negative ions
70:30
65:35
60:40
55:45
Ion proportion
Setting
d30
d35
d40
d45
50:50
Positive ions
Negative ions
30:70
35:65
40:60
45:55

10
Frequency Setting
Location
Operating Distance(mm)
Frequency
Short Distance
100-300
45-30Hz
Middle Distance
300-1000
30-20Hz
Far Distance
1000-2000
15-10Hz

11
Status display
Signal
Display
Decription
Standby mode.
It shows the current ion proportion and can adjust
it.
It shows the current frequency and can adjust it.
n- 1
The current ID is 1 and so on.
Balance
Ion output achieves an ion balance state.
－
Negative ions more than positive ions.
＋
Positive ions more than negative ions.
Alarm
It shows the abnormal state and needs to restart
the ionizer. Otherwise, please contact the service
staff.

12
Wiring
Consumable
MESD-BP301 MESD-BP302
放電針 輔助噴嘴
Electrode probe Assisting nozzle
Wire color
Description
Brown
DC24V Voltage
Blue
Ground wire (0V)
White
Abnormal output signal
Black
GND output signal
Orange
Ground wire for connecting with the machine.
Orange Black (Gray)
N.C
Blue
N.C
Brown
N.C

13
Attention
If there is a volatile or inflammable material or corrosive gas around the
ionizer that may cause fire and explosion, please do not use the ionizer in
this kind of environment.
Due to the high voltage generates from the ionizer, please keep water, oil
and inflammable material away from the ionizer; otherwise, it may cause
danger or product damage.
Due to the high voltage generates from the ionizer, please keep the metal
stuff, wire, and even finger away from it; otherwise, it may cause danger or
product damage.
Please do not use the ionizer in a stuffy room, it may cause ozone
poisoning.
Avoid installing in which the ambient temperature rapidly changes;
otherwise, it may cause danger or product damage.
Do not operate the ionizer when your hand is wet; otherwise, it may cause
danger or product damage.
Most important is that you must turn off the power before maintenance;
otherwise, it may cause danger or product damage.
It may cause danger due to touch the electrode probe directly during the
maintenance.
Please contact service staff when the alarm sign shown, do not
disassemble the ionizer directly.
Do not use tool or hard stuff to touch the electrode probe, if the probe is
damage, the static elimination effectiveness will decline.
After using for a period time, the needle point of electrode probe could
attach crystallized particle or dust due to moisture. If meet this problem,
please wipe the needle point of probe slightly by alcohol cotton or soft
brush. Keep the needle point of electrode probe clean to maintain the
static elimination effectiveness well. (Please clean the electrode probe
every two months)
Please fasten well the ionizer avoid falling down or collision; otherwise, it
may cause danger or product damage.
The ionizer is only suitable for static elimination not for another
application.
