Mad SCIENCE The Home Lab Circuit Maze User manual

Your Circuit Maze Kit Includes
Assembling Your Circuit Maze
Step 1: Fit the buzzer in the
round hole in the base.
Step 2: Fit the bottom of the
wire spiral into the
square hole in the
middle of the base.
Step 3: Remove the plastic
wrap from the battery,
and slip the clip's loop
over the positive(+)
battery end.
Step 4: Put the battery into the
battery holder. Attach
the clip to the bottom
of the wire spiral.
Step 5: Connect the battery
wire to one buzzer wire.
Step 6: Connect the other
buzzer wire to the
looped wand.
Make the connection!
Step 1
Step 3 Step 4
Step 5 Step 6
Electrical plugs always have
two prongs so electricity can
flow in and out.
Step 2
1 Clip
1 Base 1 Buzzer 1 Wire Spiral
1 Battery (AA)
(1.5 Volts)
1 Looped Wand

How to Use Your Circuit Maze
Step 1: Touch the looped wand to the
wire spiral. What happens?
Step 2: Slide the looped wand over the
open end of the wire spiral.
Don't let them touch!
Step 3: Move the wand slowly along
the wire.
Step 4: Try to move the wand to the
bottom of the wire spiral and
back without triggering the
buzzer.
Step 5: Challenge your friend to try.
You Will Need
Directions
The Science Behind Your Circuit Maze
Electricity comes from a power source. It
only works when it flows in a loop. This
loop is called a circuit. The battery in your
Circuit Maze is the power source. The
buzzer sounds when the metal wand
touches the wire spiral. Electricity flows
from the battery through the buzzer,
wand, and wire spiral back to the battery.
If you have very steady hands, you may
be able to avoid triggering the buzzer!
Step 1 Step 2
Step 3 Step 4
1 Circuit Maze 1 Friend
Humans are good electrical conductors! Be very
careful. Electricity can hurt if it flows through you.
Electric cords have metal on the
inside, and plastic on the outside. This
lets electrons flow through them, but
keeps you safe from a shock!
Item # BP0168 © 2014 The Mad Science Group. All rights reserved.
Safety Note: Do not mix
old and new batteries. Do
not mix alkaline, carbon-
zinc, or rechargeable
(nickel-cadmium)
batteries.
1 AA Battery (1.5 Volts)
