Pakronics PAKR-A0458 User manual

solar car
1
The solar car No. 2 uses solar panels to convert sunlight into electricity to
motor power . Assemble the solar car by yourself, open up your mind, cultivate the
spirit of exploration and creativity。
Principle
roof panel
Tail panel
left side
panel
right side panel
gear shaft
long axis short axis
Bushing
green gasket
big gear
solar
panel
silver screw small
screw
screw driver
wheel Vinyl
cover black
screw
motor
small gear
Assembly
process
1.when the solar car is installed, it can only be moved under direct sunlight. It does not need batteries and can be moved as long as there is sunlight.
2.A space of 1--1.5MM is reserved between the bushing and the wooden bracket to ensure that the wheels can rotate freely.
3.If there is a protective film on the battery board, first remove the protective film and then test
4.To install the wheel, you can put the wheel and the shaft vertically on the table, and tap it in with a small hammer or a hard object
Notes
Accessory
install small gear Install the motor
Secure with small screws
Gently press down to leave a gap
between the gear and the motor
left side panel
1 2

2
安装电机
Short shaft installation vinyl
sleeve
back
diagram
install short shaft
Install the spacer
Schematic diagram of the back
Fix with black screws
install green gasket
install big gear
install gear shaft
The gear bumps out
The gears bite each other
Insert the Tail panel
Tail
3 4
5 6
7 8

install right side panel
3
fix right side pannel
Fix with black screws
install Vinyl cover
9 10
11 12
13 14
roof plate
Place the roof plate
fixed with screws
Install shaft and wheels
Keep a distance of 1--1.5MM
between the shaft sleeve
Wheels can be installed by lightly tapping
in with a small hammer
Paste the solar panel
tear off the pro-
tective film

4
Solar panels convert sunlight into electricity. The solar panel transmits
electricity to the motor, and the motor starts to rotate after receiving
the electricity. The rotating motor shaft drives the gear, and the prin-
ciple of gear transmission makes the wheel rotate again, and the car
starts to move!
After the car is installed, put it
under direct sunlight, and the car
will move! The stronger the sun, the
move the fast.
Finished and start testing
solar car
solar car
