Model FM-RMB/SMB 600 Series Floor Gas Charbroiler
Model FM-RMB/SMB 600 Series
Floor Radiant or Ceramic Coal Gas
Charbroiler
OPTIONS & ACCESSORIES (AT ADDITIONAL COST)
Cooking Mode Conversion Kits
Ceramic Coal mode (from RMB to SMB)
SS Radiant mode (from SMB to RMB)
Cast Iron Radiants
Round Rod Top Grid
Fish spacing
MagiKrome Top Grids
Standard spacing Fish spacing
Scround Rod Top Grids
Standard spacing Fish spacing
6" Cast Iron Top Grids (3 independent adjustable
positions with reversible wide and thin marking)
Standard spacing Fish spacing
Service Shelf with towel bar
Low profile 8" (20.3 cm)
10" (25.4 cm) 12" (30.5 cm)
Supply shelf without towel bar
Pan Cutouts in Service Shelf (specify with order)
Divider for Pan cutouts
Cutting Boards (10” or 12” shelves only)
Fajita Rack Inserts
MagiGriddle (Replaces top grid)
Safety Pilot (supervised pilot system, see gas installation
requirements)
Quick Disconnect gas hose and lanyard kit
Back Shelf
Slip On Covers
Side and Back Extensions (N/A with back shelf)
6” casters
Lower Rack
Smoker Box
APPLICATION
The Model FM-RMB/SMB 600 Series is a high production
floor charbroiler. Many options and accessories are
available to tailor your charbroiler to match your menu
selection and operational needs in the kitchen. This series
is also available in a High Gas Output model for higher
temperatures for heavy production restaurants.
MODELS
FM-RMB-6xx-x FM-SMB-6xx-x
(Radiant Model) (Ceramic Coal Model)
Model Size Width and Gas Btu Output Rate
Standard Output** (H) High Output
624 60Kbtu/hr 624-H 80Kbtu/hr
630 90Kbtu/hr 630-H 120Kbtu/hr
636 105Kbtu/hr 636-H 140Kbtu/hr
648 150Kbtu/hr 648-H 200Kbtu/hr
660 195Kbtu/hr 660-H 260Kbtu/hr
672 240Kbtu/hr 672-H 320Kbtu/hr
STANDARD FEATURES & ACCESSORIES
FM-RMB-600 - V-shaped radiant for each burner
FM-SMB-600 - Ceramic coal screen
Free floating top grid ½” (1.3 cm) steel rods allows
expansion and contraction without warping
E-Z Tilt top grid drains grease into front trough
Round top grid with standard spacing with quick lift
handle
Convertible Radiant design to Coal style
Fully Insulated double walled outer cabinet
Stainless steel on all four sides
Water Tubs
6” (15.2 cm) stainless service shelf
Towel bar for utensil storage
Runner tube pilot system
Individual front burner controls for precise regulation
All stainless steel burners for long life
Single ¾” gas connection
Burners are 15Kbtu or optional High output 20Kbtu.
6” adjustable legs
Top Grid Scraper
APPROVALS
MEA Approved
Unit shown with optional lower rack
**Standard
Output Only

Model FM-RMB/SMB 600 Series Floor Gas Charbroiler
MagiKitch’n •P.O. Box 501, Concord, NH 03302-0501 •509 Route 3A, Bow, NH 03304
603 -225-6684 •FAX: [phone] •www.magikitch’n.com L10-136 Rev 3 08/07 Printed in the USA
We reserve the right to change specifications without notice and without incurring any obligation for equipment previously or subsequently sold.
Model FM-RMB/SMB 600 Series Floor Gas Charbroiler
111 211
22
23
Top
Grids
Cast Iron
Floating
Steel
20 3/4 x 24 3/4"
(52.7 x 62.9cm) 26 3/4 x 24 3/4" (67.9 x 62.9 cm) 32 3/4 x 24 3/4" (83.2 x 62.9 cm) 22 3/8 x 24 3/4" (56.8 x 62.9 cm)
Crumb Trays 1112
* Check plumbing / gas codes for proper gas supply line sizing to sustain burner pressure when all gas appliances are full on.
INSTALLATION INFORMATION
Natural Gas LP Gas
GAS PRESSURE REQUIREMENTS GAS CONNECTION REQUIREMENTS
Supply
Pressure*
Burner
Pressure
7 - 10" W.C.
(17.4 mbars/ 1.74 kPa)
4" W.C.
(10 mbars / 1 kPa)
11 - 13" W.C.
(27.4 mbars/ 2.74 kPa)
10" W.C.
(25 mbars / 2.4 kPa) Gas Regulator MUST be installed to broiler gas supply prior to connecting gas line.
Models without Safety Pilots
(1) 3/4" Gas Regulator
shipped unattached ,
(1) 3/4" NPT supply pipe
connection
624, 630, 636
(1) 1/2" to 3/4" adaptor &
(1) 3/4" Gas Regulator
shipped unattached ,
(1) 1/2" NPT supply pipe
648, 660, 672
(2) 1/2" to 3/4" adaptor &
(2) 3/4" Gas Regulator
shipped unattached ,
(2) 1/2" NPT supply pipe
Models with Safety Pilots
Provide MagiKitch'n model FM- RMB 6xx radiant or FM-SMB 6xx ceramic coal floor charbroiler. Unit shall be gas heated and shall cook by means of gas
burners. Unit shall be double-walled stainless steel construction, and fully insulated on all sides. Provide with independent gas burners. Individual burner
controls shall be mounted every 4 to 4-1/2 inches for flexible use. Convertible design allows operator to quickly change from radiant to coal style cooking
with an optional conversion kit. Provide Options and Accessories as follows:
Shipping Weight 220 lbs. (99.7 kg) 260 lbs. (118 kg) 295 lbs. (133 kg) 425 lbs. (192 kg) 565 lbs. (256 kg) 655 lbs. (297 kg)
Shipping Cube 53.3 ft3(1.5m3) 53.3 ft3(1.5m3)
Standard
Output
(H) High
Output
Gas
BTU/
HR
53.3 ft3(1.5m3)
SHIPPING INFORMATION (Approximate)
60,000Btu
(17.6 kW)
80,000Btu
(23.4 kW)
90,000Btu
(26.4 kW)
120,000Btu
(35.2 kW)
53.3 ft3(1.5m3) 53.3 ft3(1.5m3) 53.3 ft3(1.5m3)
105,000Btu
(30.8 kW)
140,000Btu
(41.0 kW)
150,000Btu
(44.0 kW)
200,000Btu
(58.6 kW)
195,000Btu
(57.2 kW)
260,000Btu
(76.2 kW)
56 x 35 x 47 "
(142 x89 x119 cm) 56 x 35 x 47 " (142 x89 x119 cm)
Cooking Area
20 3/4 x 24 3/4"
(52.7 x 62.9 cm)
18 x 24 3/4"
(45.7 x 62.9 cm)
56 x 35 x 47 "
(142 x89 x119 cm)
24 1/8 x 24 3/4"
(61.3 x 62.9 cm)
56 x 35 x 47 "
(142 x89 x119 cm)
Floor Space 24" x 35-1/2" 30" x 35-1/2"
CLEARANCES (Can Not Be Flush Mounted)
Front min Floor min. Combustible material Non-Combustible material Charbroiler Flue area
0" 8" (20.3 cm)
30"
(76.2 cm) 4" (10.2 cm) Sides min. Rear min.
636 / 636-H
SHORT FORM SPECIFICATION
Shipping Crate
H x W x L 56 x 35 x 47 "
(142 x89 x119 cm) 56 x 35 x 47 " (142 x89 x119 cm)
Sides min. Rear min. Do not block / restrict flue gases from flowing into hood or
install vent hood drains over the flue.
6" (15.2 cm) 8" (20.3 cm)
1404 in2(9,063cm2)1107 in2 (7,145 cm2)
48 x 35-1/2"
INDIVIDUAL CHARBROILER SPECIFICATIONS
320,000Btu
(94.1kW)
240,000Btu
(70 kW)
810 in2(5,233 cm2)662 in2 (4,271 cm2)
672 / 672-H
630 / 630-H
(61 x 90 cm)
513 in2 (3,314 cm2)
(76 x 90 cm) (91 x 90 cm)
1704 in2(11,001cm2)
72" x 35-1/2"60" x 35-1/2"
Burners 467
36" x 35-1/2"
10 13
22 3/8 x 24 3/4"
(56.8 x 62.9 cm)
FM Size 624 / 624-H
16
648 / 648-H 660 / 660-H
Floating Steel grids are standard as round rods with standard spacing, Optional are: MagiKrome Round
Rods, Scround Rod with Standard spacing 5/16" ( 0.79cm) or Fish spacing 3/16" (0.48cm)
(122 x 90 cm) (152 x 90 cm) (183 x 90 cm)
911
Cast Iron grids are 6 1/4 x 22 5/8" ( 15.9 x 57.5cm), Reversible with Thick(1/4") and Thin(1/32") Marking. Cast Grids are available in Standard(13/16"), or Fish(11/16") spacing.
