Model APM-RMB/SMB 600 Series Low Profile Counter Gas Charbroiler
Model APM-RMB/SMB 600 Series
Low Profile Counter Radiant or
Ceramic Coal Gas Charbroiler
OPTIONS & ACCESSORIES (AT ADDITIONAL COST)
Cooking Mode Conversion Kits
Ceramic Coal mode (from RMB to SMB)
SS Radiant mode (from SMB to RMB)
Cast Iron Radiants
Round Rod Top Grid
Fish spacing
MagiKrome Top Grids
Standard spacing Fish spacing
Scround Rod Top Grids
Standard spacing Fish spacing
6" Cast Iron Top Grids (3 independent adjustable
positions with reversible wide and thin marking)
Standard spacing Fish spacing
Service Shelf with towel bar
Low profile 8" (20.3 cm)
10" (25.4 cm) 12" (30.5 cm)
Supply shelf without towel bar
Pan Cutouts in Service Shelf (specify with order)
Divider for Pan cutouts
Cutting Boards (10” or 12” shelves only)
Fajita Rack Inserts
MagiGriddle (Replaces top grid)
Safety Pilot (supervised pilot system, see gas installation
requirements)
Quick Disconnect gas hose and lanyard kit
Back Shelf
Slip On Covers
Side and Back Extensions (N/A with back shelf)
4” adjustable legs
Equipment Stand
APPLICATION
The Model APM-RMB/SMB 600 Series is a Low Profile
counter high production charbroiler for space saving
installation on work tables, counter or on properly
insulated refrigerated / freezer bases. Many options and
accessories are available to tailor your charbroiler to
match your menu selection and operational needs in the
kitchen. This series is also available in a High Gas
Output model for higher temperatures for heavy
production restaurants.
MODELS
APM-RMB-6xx-x APM-SMB-6xx-x
(Radiant Model) (Ceramic Coal Model)
Model Size Width and Gas Btu Output Rate
Standard Output** (H) High Output
624 60Kbtu/hr 624-H 80Kbtu/hr
630 90Kbtu/hr 630-H 120Kbtu/hr
636 105Kbtu/hr 636-H 140Kbtu/hr
648 150Kbtu/hr 648-H 200Kbtu/hr
660 195Kbtu/hr 660-H 260Kbtu/hr
672 240Kbtu/hr 672-H 320Kbtu/hr
STANDARD FEATURES & ACCESSORIES
APM-RMB-600 - V-shaped radiant for each burner
APM-SMB-600 - Ceramic coal screen
Free floating top grid ½” (1.3 cm) steel rods allows
expansion and contraction without warping
E-Z Tilt top grid drains grease into front trough
Round top grid with standard spacing with quick lift
handle
Convertible Radiant design to Coal style
Fully Insulated double walled outer cabinet
Stainless steel on all four sides
Suspended crumb trays & grease box with handles
6” (15.2 cm) stainless service shelf
Towel bar for utensil storage
Runner tube pilot system
Individual front burner controls for precise regulation
All stainless steel burners for long life
Single ¾” gas connection
Burners are 15Kbtu or optional High output 20Kbtu.
Top Grid Scraper
APPROVALS
MEA Approved
**Standard
Output Only

Model APM-RMB/SMB 600 Series Low Profile Counter Charbroiler
MagiKitch’n •P.O. Box 501, Concord, NH 03302-0501 •509 Route 3A, Bow, NH 03304
603 -225-6684 •FAX: [phone] •www.magikitch’n.com L10-137 Rev 5 08/07 Printed in the USA
We reserve the right to change specifications without notice and without incurring any obligation for equipment previously or subsequently sold.
Model APM-RMB/SMB 600 Series Low Profile Counter Charbroiler
MOUNT FLUSH
OR WITH OPTIONAL
4" LEGS(SHOWN)
111 211
22
23
Top
Grids
Cast Iron
Floating
Steel
20 3/4 x 24 3/4"
(52.7 x 62.9cm) 26 3/4 x 24 3/4" (67.9 x 62.9 cm) 32 3/4 x 24 3/4" (83.2 x 62.9 cm) 22 3/8 x 24 3/4" (56.8 x 62.9 cm)
Crumb Trays 1112
* Check plumbing / gas codes for proper gas supply line sizing to sustain burner pressure when all gas appliances are full on.
INSTALLATION INFORMATION
Natural Gas LP Gas
GAS PRESSURE REQUIREMENTS GAS CONNECTION REQUIREMENTS
Supply
Pressure*
Burner
Pressure
7 - 10" W.C.
(17.4 mbars/ 1.74 kPa)
4" W.C.
(10 mbars / 1 kPa)
11 - 13" W.C.
(27.4 mbars/ 2.74 kPa)
10" W.C.
(25 mbars / 2.4 kPa) Gas Regulator MUST be installed to broiler gas supply prior to connecting gas line.
Models without Safety Pilots
(1) 3/4" Gas Regulator
shipped unattached ,
(1) 3/4" NPT supply pipe
connection
624, 630, 636
(1) 1/2" to 3/4" adaptor &
(1) 3/4" Gas Regulator
shipped unattached ,
(1) 1/2" NPT supply pipe
648, 660, 672
(2) 1/2" to 3/4" adaptor &
(2) 3/4" Gas Regulator
shipped unattached ,
(2) 1/2" NPT supply pipe
Models with Safety Pilots
Provide MagiKitch'n model APM- RMB 6xx radiant or APL-SMB 6xx ceramic coal low profile counter charbroiler. Unit shall be gas heated and shall cook by
means of gas burners. Unit shall be double-walled stainless steel construction, and fully insulated on all sides. Provide with independent gas burners.
Individual burner controls shall be mounted every 4 to 4-1/2 inches for flexible use. Convertible design allows operator to quickly change from radiant to
coal style cooking with an optional conversion kit. Provide Options and Accessories as follows:
Shipping Weight 210 lbs. (95.2 kg) 280 lbs. (127 kg) 350 lbs. (159 kg) 425 lbs. (193 kg) 565 lbs. (256 kg) 705 lbs. (320 kg)
Shipping Cube 21.6 ft3(0.6m3) 79.8 ft3(2.3m3)
Standard
Output
(H) High
Output
Gas
BTU/
HR
55.8 ft3(1.6m3)
SHIPPING INFORMATION (Approximate)
60,000Btu
(17.6 kW)
80,000Btu
(23.4 kW)
90,000Btu
(26.4 kW)
120,000Btu
(35.2 kW)
55.8 ft3(1.6m3) 55.8 ft3(1.6m3) 79.8 ft3(2.3m3)
105,000Btu
(30.8 kW)
140,000Btu
(41.0 kW)
150,000Btu
(44.0 kW)
200,000Btu
(58.6 kW)
195,000Btu
(57.2 kW)
260,000Btu
(76.2 kW)
42 x 45 x 73 "
(107 x114 x185 cm) 42 x 45 x 73 " (107 x114 x185 cm)
Cooking Area
20 3/4 x 24 3/4"
(52.7 x 62.9 cm)
18 x 24 3/4"
(45.7 x 62.9 cm)
42 x 45 x 51 "
(107 x114 x129 cm)
24 1/8 x 24 3/4"
(61.3 x 62.9 cm)
42 x 45 x 51 "
(107 x114 x129 cm)
Counter Space 24" x 35-1/2" 30" x 35-1/2"
CLEARANCES (Can Not Be Flush Mounted)
Front min Floor min. Combustible material Non-Combustible material Charbroiler Flue area
0" 8" (20.3 cm)
30"
(76.2 cm) 4" (10.2 cm) Sides min. Rear min.
636 / 636-H
SHORT FORM SPECIFICATION
Shipping Crate
H x W x L 31 x 28 x 43 "
(79x71x109 cm) 42 x 45 x 51 " (107 x114 x129 cm)
Sides min. Rear min. Do not block / restrict flue gases from flowing into hood or
install vent hood drains over the flue.
6" (15.2 cm) 8" (20.3 cm)
1404 in2(9,063cm2)1107 in2 (7,145 cm2)
48 x 35-1/2"
INDIVIDUAL CHARBROILER SPECIFICATIONS
320,000Btu
(94.1kW)
240,000Btu
(70 kW)
810 in2(5,233 cm2)662 in2 (4,271 cm2)
672 / 672-H
630 / 630-H
(61 x 90 cm)
513 in2 (3,314 cm2)
(76 x 90 cm) (91 x 90 cm)
1704 in2(11,001cm2)
72" x 35-1/2"60" x 35-1/2"
Burners 467
36" x 35-1/2"
10 13
22 3/8 x 24 3/4"
(56.8 x 62.9 cm)
APM Size 624 / 624-H
16
648 / 648-H 660 / 660-H
Floating Steel grids are standard as round rods with standard spacing, Optional are: MagiKrome Round
Rods, Scround Rod with Standard spacing 5/16" ( 0.79cm) or Fish spacing 3/16" (0.48cm)
(122 x 90 cm) (152 x 90 cm) (183 x 90 cm)
911
Cast Iron grids are 6 1/4 x 22 5/8" ( 15.9 x 57.5cm), Reversible with Thick(1/4") and Thin(1/32") Marking. Cast Grids are available in Standard(13/16"), or Fish(11/16") spacing.
3457
