MAGNA LENS Eye/Ear Safety System User manual

MAGNA
lens®
Comfort enhanced eye/ear safety systems
• Eliminates the uncomfortable pinching associ-
ated with wearing safety eyewear under hearing
protection earmuffs.
• Magnetically attachable safety eyewear engi-
neered for unsurpassed comfort.
• Premium earmuffs with integrated magnets
MAGNAlens ® Magnetic eye/ear Safety
System includes the following:
NRR 30db earmuffs with integrated magnets (earmuffs
are con ertible to low profile NRR 27db earmuffs)
Magnetically attachable, clear polycarbonate safety
eyewear (ANSI Z87.1+ compatible)
Yellow tint polycarbonate eyewear lens (ANSI Z87.1+
compatible)
Blue tint polycarbonate eyewear lens (ANSI Z87.1+
compatible)
Optional - snap-in insert for the addition of custom
prescription lenses
About the product
MAGNAlens was designed by an engineer and lifelong user of eye/ear protection who became
increasingly dissatisfied with the pain and discomfort caused when wearing earmuffs over traditional
eyewear, thus causing the dreaded “pinching" discomfort. Up until now this discomfort has been an
accepted byproduct of using earmuffs over safety eyewear.
The solution to this problem lies in the use of , extremely
strong magnets, which securely connect the patented
MAGNAlens eyewear to the outside of the
earmuffs. This unique patented connection prevents
the eyewear from being compressed under the
earmuff cushions. This connection system also
eliminates the “brea ” in the ear cushion seals which
compromise the noise reduction effectiveness of the
hearing protection. MAGNAlens utilizes optical
polycarbonate, one-piece, wrap around lenses. These
2.9mm (.115") thic lens were designed by one of the
best optical engineers in America with major
objectives being optical quality and impact
resistance.
Tooling, injection molding, optical coating and CNC lens finishing are all accomplished here in the USA. The
extra thic lens is designed to exceed ANSI ballistic impact specifications as well as ANSI optical
specifications. Each it includes one set of earmuffs and three lenses (clear, yellow, and blue). Eliminate the
"pinch" today and try the most comfortable eye/ear protection you will ever wear. Patent numbers:
8621664 and 9168176

www.MagnaLens.com 941-932-2333 Scott Peebles
CONGRATULATIONS ON YOUR PURCHASE OF YOUR NEW MAGNAlens EYE/EAR PROTECTION SYSTEM!
WE THANK YOU FOR YOUR BUSINESS! WE ARE SURE THAT THIS PRODUCT WILL BE THE MOST COMFORTABLE EYE/EAR
PROTECTION SYSTEM YOU WILL EVER WEAR. NOT ONLY WILL YOU FIND THAT THE MAGNETIC CONNECTION DESIGN
ELIMINATES THE PINCHING DISCOMFORT WE ARE ALL FAMILIAR WITH, BUT YOU WILL ALSO NOTICE THAT THE OPTI-
CAL QUALITY OF OUR LENSES WILL ALLOW YOU TO WEAR OUR EYE PROTECTION FOR MUCH LONGER PERIODS OF
TIME WITHOUT THE EYE FATIGUE NORMALLY ASSOCIATED WITH LOWER QUALITY EYEWEAR.
MAGNALENS EYEWEAR
WITH MAGNETS AT END
OF ARMS FOR ATTACHMENT
TO EARMUFF ASSEMBLY
EARMUFFS SHOWN IN
CORRECT ORIENTATION
FOR EYEWEAR ATTACHMENT
DO NOT TILT EARMUFFS
FORWARD OR TO THE REAR.
ADJUSTABLE SLIDING
MAGNET ARMS ALLOW
FOR PROPER SIZING OF
EYEWEAR ASSEMBLY TO
ENSURE PROPER FIT
MAGNALENS EARMUFFS
WITH BUILT-IN MAGNETIC
ATTACHMENT POINTS
ADJUSTABLE SLIDING
HEADBAND ON EARMUFFS
FOR PROPER FIT WITH USER
VISIT OUR WEBSITE FOR ADDITIONAL OPTIONS AND ACCESSORIES SUCH AS:
SNAP-FIT PRESCRIPTION Rx FRAME INSERT THAT ATTACHES TO THE NOSEPIECE OF YOUR MAGNALENS EYE-
WEAR. ONCE YOUR OPTOMETRIST ADDS YOUR CORRECTIVE PRESCRIPTION TO THIS OPTIONAL FRAME, YOU CAN
EASILY INSERT IT TO THE INSIDE OF YOUR MAGNALENS EYEWEAR.
ADD-ON MAGNET KIT FOR NON- MAGNALENS EARMUFFS. DO YOU HAVE A FAVORITE PAIR OF EARMUFFS YOU
WOULD LIKE TO MAKE COMPATIBLE WITH MAGNALENS EYEWEAR? NO PROBLEM, THIS KIT COMES WITH PLASTIC
HOUSINGS AND MAGNETS THAT CAN BE ATTACHED TO MOST BRANDS OF EARMUFFS MAKING THEM COMPATIBLE
WITH MAGNALENS EYEWEAR.
TRADITIONAL EYEWEAR SIDE COMPONENTS WOULD YOU LIKE TO CONVERT YOU MAGNETIC EYEWEAR TO
TRADITIONAL EYEWEAR? SIMPLY PULL OUT YOUR EYEWEAR SIDE ARMS WHICH CONTAIN THE ROUND MAGNETS
AND INSERT THESE FULL LENGTH COMPONENTS TO HAVE A TRADITIONAL SET OF MAGNALENS EYEWEAR.

-LENS INTERCHANGE INSTRUCTIONS-
YOUR NEW MAGNALENS EYEWEAR INCORPORATES SNAP FIT HARDWARE TO FACILITATE QUICK INTERCHANGE OF LENSES.
THE NOSEPIECE CAN EASILY BE REMOVED AND REATTACHED TO A DIFFERENT LENS BY PINCHING THE SIDES OF NOSEPIECE TO-
GETHER TO ACCOMPLISH REMOVAL AND REINSTALLATION.
THE HINGE BRACKET SNAP FIT IS DESIGNED TO PROVIDE A VERY TIGHT AND SECURE ATTACHMENT POINT BETWEEN THE LENS
AND HINGE BRACKET. THE PROPER PROCEDURE FOR INTERCHANGING LENSES IS ILLUSTRATED BELOW. IF THIS PROCEDURE IS
NOT PROPERLY FOLLOWED, INTERCHANGE OF LENSES CAN BE QUITE DIFFICULT. FOR INSTRUCTIONAL VIDEO ON THIS PROCEDURE
PLEASE VISIT MAGNALENS.COM
MAINTAIN PRESSURE
HERE IN ORDER TO
KEEP "SNAP LUG" "A"
ENGAGED WITH ITS
MATCHING SOCKET "A"
WHILE MAINTAINING PRESSURE
ON OPPOSITE END OF BRACKET,
APPLY PRESSURE HERE UNIL
"SNAP LUG" "B" ROTATES
DOWN INTO SOCKET "B"
SNAP LUG "A" MUST
STAY ENGAGED WITH
SOCKET IN ORDER TO
ROTATE LUG "B" INTO
SOCKET "B"
IN ORDER TO REMOVE
BRACKET, PULL UP HERE
(IN DIRECTION SHOWN
BY CURVED ARROW LINE
PRESS THIS END
OF BRACKET ONTO
THE LENS FIRST
SOCKET “B” SOCKET “A”
MAGNALENS WARRANTY INFORMATION
YOUR NEW MAGNALENS EYE / EAR PROTECTION SYSTEM IS GUARANTEED AGAINST DEFECTS IN MATERIAL AND WORKMANSHIP FOR A PERIOD OF ONE YEAR FROM
THE DATE OF PURCHASE. THIS WARRANTY COVERS THE EARMUFF ASSEMBLY AND EYEWEAR ASSEMBLY. YOUR LENSES ARE MANUFACTURED, IN THE USA, FROM THE
FINEST, HARDCOATED, OPTICAL POLYCARBONATE AVAILABLE. EVEN THOUGH YOUR LENSES ARE DESIGNED TO BE AS SCRATCH RESISTANT AS POSSIBLE, YOU WILL
EVENTUALLY INCURE INCIDENTAL SCRATCHES OR DAMAGE DUE TO NORMAL SAFETY LENS USAGE. YOUR MAGNALENS WARRANTY DOES NOT COVER INCIDENTAL
SCRATCHING OR DAMAGE TO LENSES DUE TO NORMAL USE OR IMPROPER CLEANING.
PROPER CARE OF YOUR LENSES
1. Wash an ry your han s thoroughly. Before cleaning your eyeglasses, make sure your hands are free from dirt, grime, lotion and anything else that could be trans-
ferred to your lenses. Use lotion-free soap or dishwashing liquid and a clean, lint-free towel to clean your hands.
2. Rinse your glasses un er a gentle stream of lukewarm tap water. This will remove dust and other debris, which can help avoid scratching your lenses when you
are cleaning them. Avoid hot water, which can damage some lens coatings.
3. Apply a small rop of lotion-free, citrus free ishwashing liqui to each lens. Most dishwashing liquids are very concentrated, so use only a tiny amount. Or
apply a drop or two to your fingertip instead. Use only brands that do not include lotions or hand moisturizers (Dawn original formula, for example .
4. Gently rub both si es of the lenses an all parts of the frame for a few secon s. Make sure you clean every part, including the nose pads and the ends of the
temples that rest behind your ears. And be sure to clean the area where the edge of the lenses meet the frame, where dust, debris and skin oils can accumulate.
5. Rinse both si es of the lenses an the frame thoroughly. Failing to remove all traces of soap will cause the lenses to be smeared when you dry them.
6. Gently shake the glasses to eliminate most of the water from the lenses. Inspect the lenses carefully to make sure they are clean.
7. Carefully ry the lenses an frame with a clean, lint-free towel. Use a dish towel that has not been laundered with a fabric softener or dryer sheet (these sub-
stances can smear the lenses . A cotton towel that you use to clean fine glassware is a good choice. Make sure the towel is perfectly clean. Dirt or debris trapped in the
fibers of a towel can scratch your lenses; and cooking oil, skin oil or lotion in the towel will smear them.
8. Inspect the lenses again. If any streaks or smudges remain, remove them with a clean microfiber cloth — these lint-free cloths are available at most optical shops or
photography stores.
When using individually packaged, pre-moistened disposable lens cleaning wipes, first inspect the lenses for dust or debris. Blow any particles off before wiping the lenses,
to avoid scratching.

HIGH NOISE REDUCTION CONFIGURATION
(NRR:30db
LOW PROFILE CONFIGURATION
(NRR:27db
EXPLODED VIEW OF EARMUFF COMPONENTS
REMOVE EAR CUSHION
PLATE BY HAND, BEING
CAREFUL NOT TO LOSE
DISC MAGNET.
REMOVE THIS SPACER USING
FLAT HEAD SCREWDRIVER
NEODYMIUM MAGNET WARNING
Neodymium magnets are not for children. Neodymium magnets are not toys. Children should not be allowed to
handle neodymium magnets. Small magnets can pose a choking hazard. If multiple magnets are swallowed, they can
attach to one another through intestine walls. This can cause a severe health risk, re uiring immediate, emergency
surgery if correctly diagnosed.
Neodymium magnets can affect pacemakers. The strong magnetic fields near a neodymium magnet can affect
pacemakers, ICDs and other implanted medical devices. Many of these devices are made with a feature that deacti-
vates it with a magnetic field. Therefore, care must be taken to avoid inadvertently deactivating such devices.
Magnets can affect magnetic media. The strong magnetic fields near neodymium magnets can damage magnetic
media such as floppy disks, credit cards, magnetic I.D. cards, cassette tapes, video tapes or other such devices. They
can also damage televisions, VCRs, computer monitors and CRT displays. Avoid placing neodymium magnets near elec-
tronic appliances.
-EARMUFF CONVERSION INSTRUCTIONS-
YOUR NEW MAGNALENS EARMUFF ASSEMBLY IS A SNAP FIT MODULAR DESIGN ALLOWING YOU TO CONVERT YOUR EARMUFFS
FROM THE FULL 30 b NOISE REDUCTION CONFIGURATION TO A LOWER PROFILE 27 b CONFIGURATION.
THE EAR CUSHION PLATE CAN BE REMOVED BY HAND BY PLACING FINGERS INSIDE EAR OPENING AND USING THUMB TO PUSH
AGAINST THE HINGE POINT ON OUSTIDE OF CUP.
ONCE EAR CUSHION PLATE IS REMOVED, YOU WILL NEED A LARGE FLATHEAD SCREW DRIVER. FROM INSIDE OF CUP, WEDGE
SCREWDRIVER BETWEEN THE SPACER AND THE SHALLOW END OF THE MAIN EAR CUP. THE SCREW DRIVER CAN BE TWISTED TO
“POP” THE SPACER OFF OF THE MAIN EAR CUP .
THE EAR CUSHION PLATES CAN NOW BE SNAPPED ONTO THE MAIN EAR CUPS COMPLETING THE CONVERSION PROCESS. FOR IN-
STRUCTIONAL VIDEO ON THIS PROCEDURE PLEASE VISIT MAGNALENS.COM
