Magna-Matic MAG-200 Series User manual

Box Contents for MAG-200
• (1) MAG-200
• (1) Rubber hose
• (5) Extra 200-15 pad lters
• (1) Pleated lter 200-17 (installed)
• (7) Yellow thumb screws
WARNING
NEVER ALTERNATE A MAG-200
BETWEEN A SHARPENER AND THE
MAG-12008 BLADE CLEANER
SPARKS MAY IGNITE GRASS AND DE-
BRIS GENERATED BY THE MAG-12008
BLADE CLEANER
MAG-200 Dust Collector Set-up
1. Connect rubber hose to 2.5” outlet on top of MAG-200
2. Ensure the ON/OFF switch is in the OFF position (red switch cover closed)
3. Plug in to 110v 60hz outlet
4. Turn on MAG-200 to test
ORIGINAL INSTRUCTIONS for MAG-200 Series Dust Collector Generation 2 (October 16,2017 to present)
Cleaning of the MAG-200
1. Remove the yellow bottom cover by unlatching the two catch clamps.
2. The bottom cover collects the grit and dust. Dispose of the grit and dust, then
wipe out the bottom cover. Inspect seals in bottom cover, replace if damaged.
3. Pull the aluminum mesh lter out of the MAG-200. This lter is cleanable, the grit
and dust can be shaken out of this lter. When it is clean, place it back inside of
the MAG-200 as shown to the right. The lter sits at an angle inside the MAG-200
to block all incoming large grit and sparks from the pad lter.
4. Install the yellow bottom cover back onto the MAG-200.
Pad & Pleated Filter Cleaning
While both of these lters are designed to be discarded and replaced, it is possible to shake them
out or clean them with compressed air.
WEAR PROPER SAFETY GEAR if you decide to use compressed air to clean the lters. New
lters will always provide the greatest air ltration and are strongly recommended.
Pleated 3rd Stage Filter Replacement
1. The 3rd stage lter cover of the MAG-200 must be removed to access lters.
2. Remove the three screws to remove the cover. (Replace with thumb screws if you desire for easier access.)
3. Pull the pleated lter out of the cover - discard and replace with part 200-17 lter.
4. Replace with a new pleated lter ensure air ow direction arrow it is in the correct direction.
5. Gently push the pleated lter into the 3rd stage lter cover and ensure it is seated.
Pad Filter Replacement
6. Remove the four screws and pad lter cover. (Replace with thumb screws if you desire for easier access.)
7. Pull the pad lter out and replace with part 200-15
8. Ensure the white surface is pointed outward and the green surface inward when installing new pad lter.
200-17
Pad lter
cover
Foam seal
3rd stage
lter cover

Installing the **OPTIONAL** 200-20 Stand Mounting Brackets for
hanging the MAG-200 on the MAG-10400 Stand
1. Remove the yellow bottom cover
2. Remove the 5/16-18 bolts and nuts from the MAG-200 body. These bolts/nuts act as
plugs if the brackets are not installed.
This hardware is used to connect the brackets to the MAG-200.
3. The brackets interlock - make sure the hook end is pointing downward.
4. The long support bracket ts on the inside to make the bottom bracket more rigid, this
bracket shares two #10 screws from the body.
5. Mount the other two brackets on the MAG-10400 stand, with the hooks facing upward.
6. The hooks will interlock and allow the MAG-200 to hang on the MAG-10400 stand
or other surface.
Best Placement for MAG-200
Typically the best placement on the stand for the MAG-200
is on the right side of the stand as shown in the two
images. This way the hose is out of your way when
sharpening or balancing lawn mower blades. It also
provides the best access to the ON/OFF switch.
200-20-Kit
