Magnaflux Y-2 AC Yoke User manual

155 Harlem Avenue,
Glenview, Illinois 60025 USA
[phone] Fax: [phone]
www.magnaflux.com support@magnaflux.com Rev: 1.A.051419

Operating Manual
Y-2 AC Yoke
AC Yoke Yugo CA Electro-Aimant AC Handmagnet AC 交流电磁轭
Part Numbers:
628554, 628555, 628556, 628557,
628560, 628913, 628914
Manual de instrucciones
Manuel d’utilisation
Betriebsanleitung
操作手册

1
English
Y-2 Yoke Operating Manual
ENGLISH
TABLE OF CONTENTS
Precautions................................................ 2
Specifications ............................................ 2
Operation ................................................... 3
Accessories................................................ 3
Maintenance.............................................. 3
Service ........................................................ 3
Troubleshooting........................................ 4
Drawings & Service Parts........................ 5
EU Declaration of Conformity ................ 6
Warranty ..................................................... 6
Support....................................................... 6
ESPAÑOL
ÍNDICE
Precauciones............................................. 7
Especificaciones ....................................... 7
Operación................................................... 8
Accessorios................................................ 8
Mantenimiento .......................................... 8
Servicio....................................................... 8
Solución de Problemas............................ 9
Dibujos y Piezas de Servicio................... 10
Declaración de Conformidad de la UE . 11
Garantía...................................................... 11
Soporte....................................................... 11
FRANÇAIS
TABLE DES MATIÈRES
Précautions d’emploi ............................... 12
Caractéristiques Techniques .................. 12
Fonctionnement........................................ 13
Accessoires................................................ 13
Entretien..................................................... 13
Service ........................................................ 13
Dépannage ................................................ 14
Dessin et Pièces de Rechange............... 15
Déclaration de Conformité CE ............... 16
Garantie...................................................... 16
Soutien Technique.................................... 16
DEUTSCH
INHALTSVERZEICHNIS
Vorsichtsmaßnahmen.............................. 17
Technische Daten ..................................... 17
Bedienung.................................................. 18
Zubehör ...................................................... 18
Wartung ...................................................... 18
Service ........................................................ 18
Fehlerbehebung ....................................... 19
Zeichnungen und Ersatzteile.................. 20
EU-Konformitätserklärung ...................... 21
Garantie...................................................... 21
Support....................................................... 21
简体中文
目录
防范措施 ..................................................... 22
技术参数 ..................................................... 22
操作指南 ..................................................... 23
推荐附件 ..................................................... 23
维护 ............................................................. 23
维修 ............................................................. 23
故障排除 ..................................................... 24
图示和零部件............................................. 25
欧盟合规性声明......................................... 26
质保 ............................................................. 26
支持 ............................................................. 26

2
Y-2 Yoke Operating Manual
English
PRECAUTIONS
Inspect yoke before each use. If damage is present, see maintenance section for instructions.
WARNING
Yoke produces a strong magnetic field.
WARNING
Persons with pacemakers or medical implants must stay 1.5 ft / 0.5 m
away from yoke during operation.
WARNING
Immersing the yoke in liquid of any kind can result in electrical shock. Do
not use yoke in the rain.
CAUTION
GFCI / GFI / RCCB / ELCB protection is recommended to prevent
electrical shock.
CAUTION
Do not exceed the rated duty cycle. Continuous use of the yoke over
extended times will generate excessive heat and may permanently
damage the yoke.
CAUTION
Do not abuse cord. Never carry yoke by cord or yank to disconnect from
receptacle. Never retrieve yoke by pulling on cord. A suspension loop is
provided on the housing above the front coil to accommodate a belt clip
or hanger loop.
CAUTION
Only use outdoor rated extension cords
SW-A, SOW-A, STW-A, STOW-A, SJW-0A, SJOW-A, SJTW-A, or SJTOW-A
Cord Rating 0-6 A
0-25 ft / 0-7.6 m 18 AWG / 0.75 mm min
26-100 ft / 7.6-30.4 m 16 AWG / 1.5 mm min
101-150 ft / 30.4-45.7 m 14 AWG / 2.5 mm min
SPECIFICATIONS
Waveform AC
Magnetic Field > 2 kA/m RMS
Lift Strength > 10 lb / 4.5 kg / 44 N
Leg Span / Pole Spacing 2.5-10.5 in / 6.4-26.7 cm
Leg / Pole Contact Size 1.00 x 0.75 in / 25.4 x 19.0 mm
Cord Length 12 ft / 3.6 m
Duty Cycle 50%, maximum on time 90 sec
Ingress Protection (EN60529) IP54
Weight 4.9 lb / 2.2 kg
6.2 lb / 2.8 kg (with cord)
Electrical
115V 60 Hz
50 Hz
4.3A maximum
6.3A maximum
230 V 50/60 Hz 2.6A maximum

3
English
Y-2 Yoke Operating Manual
OPERATION
1. Attach power cord, making sure connection is secure. Connect the power supply to line power.
2. Position yoke legs at right angles to the direction of suspected discontinuities. Adjust legs
as needed for best contact with surface.
3. Depress trigger to energize yoke. Apply magnetic particles to area between legs. While
energized, blow o excess powder to reveal indications. To switch from UV mode to
visible light mode, press and hold the power button for 3 seconds.
4. Evaluate indications for size, shape, and relevant locations.
5. Reposition yoke legs at 90-degrees to previous position and repeat steps 2-3 to reveal
indications in all directions.
6. Demagnetize by slowly withdrawing yoke from surface, up to 18 in / 45 cm distance, while
yoke is energized.
7. OPTIONAL YOKE LIGHT: To install, slide over the rear leg with LEDs facing in. Push up
onto the housing until tabs are secured. Yoke light will automatically operate when yoke is
energized. To remove, pull sides out and down to disengage tabs, then slide o. No tools
are necessary for installation or removal.
ACCESSORIES
Part No. Description
628840 Yoke Light, Y-2
624115 Calibrated Test Weight, 10 lb
MAINTENANCE
CLEANING
• Use mild soap and a damp cloth to clean the yoke housing
• Do not immerse any part of yoke in liquid
• Legs may be detached at the joints for cleaning
• Use a rust-preventative spray (LPS-3 or equivalent) on legs for lubrication
DISPOSAL
The Y-2 contains no hazardous materials and complies with EU RoHS regulations. Please
contact your local waste disposal authority for instructions on disposal of electrical waste.
SERVICE
CAUTION
To assure product safety and reliability, repairs should be performed by
Magnaflux Authorized Service Center using original parts.
WARNING
If the yoke housing is opened for any reason, warranty is voided on the unit.

4
Y-2 Yoke Operating Manual
English
Switch Replacement:
Use Y-2 Switch Replacement Kit p/n 629261. Refer to figure below.
1. Loosen TORX screw and remove the switch compartment cover.
2. Carefully unseat the switch and remove. NOTE: The torsion spring is under tension. Take
care not to lose the spring during disassembly of the switch compartment. If the spring
comes out, use the instructions below for reassembly of the trigger actuator.
3. Cut the wires to the old switch approximately halfway (1.5 in / 38 mm), leaving enough wire
for stripping and splicing. NOTE: Ensure that there is enough room to place the butt splice
underneath the switch.
4. Strip both ends of each wire (one from switch and other from yoke) and splice them
together, matching wire colors.
5. Fit the switch onto the alignment pins under the trigger actuator. Replace the switch
compartment cover and secure with the TORX screw until hand tight.
Trigger Actuator Assembly:
1. Place torsion spring into the housing with the straight leg in slot as shown in figure below.
2. Slide the pin through the two holes of the actuator.
3. To assemble actuator back into the housing, rotate bent spring leg to install angle and
place into the switch cavity area of the switch housing.
4. Place pin end into the boss hole and position the spring bent leg in the slot. Fit the actuator
into the switch compartment.
TROUBLESHOOTING
Problem Possible Cause Possible Solution/Troubleshooting Steps
Yoke will not
energize
Cord unplugged Plug cord into a fully grounded outlet or
extension cord
Damaged or Defective Cord Replace power cord
Damaged or Defective Switch
Follow service procedure for switch
replacement. Contact Authorized Service
Center for assistance.
Blown Fuse or Breaker in Power supply Reset Breaker or replace fuse
Defective Extension Cord Replace Extension Cord
Tripped GFI Reset GFI button
Yoke will not
lift 10lb test
weight
Foot Sections of legs worn or rounded File or grind feet back to original flat
condition or replace
Foot Sections turned and not making
full contact Adjust feet to make flat full contact with weight
Extension Cord too light to supply
adequate current See table in precautions for proper size
Improper test weight Part No. 624115 Test weight should be used
Leg bolts too tight Loosen slightly with properly sized wrench
Legs still or
not moving Legs rusted at joints
Remove bolts and legs. Clean with a wire
brush to remove rust buildup. Re-assemble
using a rust remover/preventer such as LPS-
2. Re-tighten bolts until legs are tight but still
move freely.

5
English
Y-2 Yoke Operating Manual
DRAWINGS & SERVICE PARTS
Item Part No. Qty Description
1 628294 1 PIN, DOWEL
2 628282 1 SPRING, TORSION
3 628280 1 ACTUATOR, SWITCH, Y-2
4 628277 1 SWITCH, Y-2
5 628278 1 COVER, Y-2 SWITCH (REF. ONLY)
6 - 1 SCREW, PLASTIC, DELTA-PT, M3X12mm, TORX
Ref 629261 1 KIT, SWITCH REPLACEMENT, Y-2, INCLUDES ITEMS 1, 2, 4, 6
7
628297 1 CORD ASSEMBLY, NORTH AMERICA, TYPE B PLUG
628298 1 CORD ASSEMBLY, EU / UK, TYPE F PLUG WITH TYPE G ADAPTER
628299 1 CORD ASSEMBLY, CHINA, TYPE I PLUG
SWV
SWV
1:2
1 OF 1
1/32
T
S
R
Q
P
O
N
M
L
K
J
I
H
G
F
E
D
C
B
A
12345678 109 1112131415161718192021 2322 24 25 26 27 28 29 30 31
MATERIAL:
±
ANGLE
±
.015.XXX
32
IF IN DOUBT; ASK
±
04/17/2019
DRAWN DATE:
TO MAGNAFLUX.
SCALE:
[phone]
FINISH:
D - 629261
YOKE,ASSY,Y-2,115V,BASE
MODELED BY:
SUCH MAY NOT BE COPIED NOR
DWG
SHEET NO:
REV:
TOLERANCES:
USED IN ANY WAY DETRIMENTAL
DE WITT, IA 52742
DIMENSIONS ARE IN INCHES
DRAWN BY:
.X
FRACTION
±
DESCRIPTION:
.060
.XX ±.030
THIS DRAWING CONTAINS
PROPRIETARY INFORMATION
WHICH IS THE SOLE PROPERTY
OF MAGNAFLUX AND AS
218 E. INDUSTRIAL ST
UNLESS OTHERWISE SPECIFIED:
1°
61 2 3 4 5
1
2
3
4
ITEM NO.
PART NO. DWG NO. QTY.
DESCRIPTION
4 628297 628297 1 CORD,ASSY,115V,Y-2,NA
3 628565 - 1 LABEL,CAUTION,Y-2,GLOBAL
2 628561 - 1 LABEL,NAMEPLATE,YOKE,Y-2,115V
1 628273 628273 1 YOKE,ASSY,Y-2,115V,BASE
T
S
R
Q
P
O
N
M
L
K
J
I
H
G
F
E
D
C
B
A
1 2 3 4 5 6 7 8 109 11 12 13 14 15 16 17 18 19 20 21 2322 24 25 26 27 28 29 30 31
32
IF IN DOUBT; ASK
±
03/06/2019
DRAWN DATE:
THIS DRAWING CONTAINS
PROPRIETARY INFORMATION
WHICH IS THE SOLE PROPERTY
OF MAGNAFLUX AND AS
SUCH MAY NOT BE COPIED NOR
USED IN ANY WAY DETRIMENTAL
TO MAGNAFLUX.
A
SCALE:
FINISH:
D - 628954
YOKE,W/CORD,NA
MODELED BY:
218 E. INDUSTRIAL ST
DE WITT, IA 52742
[phone]
DWG
SHEET NO:
REV:
TOLERANCES:
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES
DRAWN BY:
.X
FRACTION
±
DESCRIPTION:
.060
.XX
±
.030
.XXX .015
±
ANGLE
±
MATERIAL:
SWV
SWV
1:2
1 OF 1
1/32
1°

6
Y-2 Yoke Operating Manual
English
EU DECLARATION OF CONFORMITY
In accordance with EN ISO 17050-1:2010
Object of the declaration:
Product: AC Yoke
Model/type: Y-2
Manufacturer: Magnaflux
Address: 155 Harlem Avenue, Glenview, IL 60025, USA
This declaration is issued under the sole responsibility of the manufacturer.
The object of the declaration described above is in conformity with the relevant Union
harmonisation legislation:
2014/35/EU The Low Voltage Directive
2014/30/EU The Electromagnetic Compatibility Directive
2011/65/EU The Restriction of Hazardous Substances Directive
2011/65/EU Reduction of Hazardous Substances Directive
2009/125/EC Eco Design Directive
Conformity is shown by compliance with the applicable requirements of the following documents:
Reference & Date Title
EN 61010-1:2010 Safety requirements for electrical equipment for measurement, control,
and laboratory use - Part 1: General requirements
EN 61326-1:2013 Electrical equipment for measurement, control and laboratory use -
EMC requirements - Part 1: General requirements
EN ISO 9934-3:2015 Non-destructive testing – Magnetic particle testing – Part 3: Equipment
Signed for and
on behalf of: Magnaflux
Place of issue: DeWitt, Iowa, United States of America
Date of issue: June 2019
Name: Mike Fryauf
Position: Engineering Manager
Signature:
WARRANTY
Refer to the Magnaflux Warranty Statement at www.magnaflux.com.
SUPPORT
If you have a question please contact Magnaflux at:
1-847-657-5300
support@magnaflux.com
www.magnaflux.com
You can also contact your local Distributor or Magnaflux Authorized Service Center directly;
contact information is available at www.magnaflux.com.

7
Español
Yugo Y-2 Manual de instrucciones
PRECAUCIONES
Revise el yugo antes de cada uso. Si hay daños, consulte la sección de mantenimiento para
obtener instrucciones.
ADVERTENCIA
El yugo produce un campo magnético intenso.
ADVERTENCIA
Las personas con marcapasos o implantes médicos deben
permanecer alejados a una distancia de 1,5 pies/ 0,5 m del yugo
durante el funcionamiento.
ADVERTENCIA
Si se sumerge el yugo en un líquido de cualquier tipo, pueden producirse
descargas eléctricas. No use el yugo bajo la lluvia.
PRECAUCIÓN
Se recomienda protección GFCI/GFI/RCCB/ELCB para prevenir las
descargas eléctricas.
PRECAUCIÓN
No supere el ciclo de trabajo nominal. El uso continuo del yugo durante
un tiempo prolongado genera un calor excesivo y puede dañar el yugo de
manera definitiva.
PRECAUCIÓN
No maltrate el cordón. Nunca levante el yugo por el cordón ni jale el cordón
para desconectarlo del tomacorriente. Se proporciona un arillo, delante de la
bobina, para colgarlo de un cinturón o colgarlo de un soporte.
PRECAUCIÓN
Solo use extensiones con calificación nominal para exteriores
SW-A, SOW-A, STW-A, STOW-A, SJW-0A, SJOW-A, SJTW-A o SJTOW-A
Calificación nominal de la extensión 0-6 A
0-25 pies / 0-7,6 m 18 AWG / 0,75 mm mín
26-100 pies / 7,6-30,4 m 16 AWG / 1,5 mm mín
101-150 pies / 30,4-45,7 m 14 AWG / 2,5 mm mín
ESPECIFICACIONES
Forma de onda CA
Campo magnético > 2 kA/m RMS
Fortaleza de levantamiento > 10 lb / 4.5 kg / 44 N
Rango de las patas / espaciamiento entre postes 2.5-10.5 pulg. / 6.4-26.7 cm
Tamaño del contacto de patas/postes 1.00 x 0.75 pulg. / 25.4 x 19.0 mm
Longitud del cordón 12 pies / 3.6 m
Ciclo de servicio 50 %, tiempo de encendido máximo 90 seg.
Protección de acceso (EN60529) IP54
Peso 4.9 lb / 2.2 kg
6.2 lb / 2.8 kg (con cable)
Electricidad
115V 60 Hz
50 Hz
4.3A máximo
6.3A máximo
230 V 50/60 Hz 2.6A máximo

8
Yugo Y-2 Manual de instrucciones
Español
OPERACIÓN
1. Conecte el cable de alimentación y asegúrese de que la conexión quede segura.
2. Posicione las patas del yugo en ángulos rectos en la dirección de las discontinuidades
sospechadas. Ajuste las patas para mejor contacto con la superficie.
3. Presione el gatillo para energizar el yugo. Aplique las partículas magnéticas entre las
patas del yugo. Durante la aplicación de energía, sople el exceso de polvo para revelar
las discontinuidades.
4. Evalúe el tamaño, forma y ubicación relevante de las discontinuidades.
5. Vuelva a posicionar las patas del yugo a 90 grados de la posición anterior y repita los
pasos 2 y 3 para revelar las discontinuidades en todas las direcciones posibles.
6. Retire lentamente el yugo de la superficie para desmagnetizar, a una distancia de 18 pulg. /
45 cm, con el yugo energizado.
7. LUZ OPCIONAL PARA YUGO: Para instalarla, coloque sobre la pata posterior con la cara
del LED hacia adentro. Empuje en el inserto hasta que las lengüetas queden fijas. La luz del
yugo funcionará automáticamente cuando el yugo esté energizado. Para retirarla, tire de
los extremos hacia afuera y hacia abajo para desenganchar las lengüetas y, a continuación,
deslice para extraerla. No se requieren herramientas para desinstalarla o extraerla.
ACCESSORIOS
Número de Parte Descripción
628840
Luz para yugo, Y-2
624115 Pesa de prueba calibrada, 10 lb
MANTENIMIENTO
LIMPIEZA
• Use jabón suave y un paño húmedo para limpiar la carcasa del yugo
• No sumerja ninguna parte del yugo en líquido
• Las patas pueden desconectarse en las uniones para limpiarse
• Use un aerosol lubricante para prevenir la oxidación (LPS-3 o equivalente) en las patas
ELIMINACIÓN
The Y-2 contains no hazardous materials and complies with EU RoHS regulations. Please
contact your local waste disposal authority for instructions on disposal of electrical waste.
SERVICIO
PRECAUCIÓN
Para garantizar la seguridad y confiabilidad del producto, un centro de
servicio autorizado de Magnaflux debe llevar a cabo las reparaciones con
piezas originales.
ADVERTENCIA
Si se abre la carcasa del yugo, por cualquier motivo, se anulará la garantía de
la unidad.
