Magnavox TB600MG2F User manual

Owner’s Manual
TB600MG2F
HD Streaming Player with Built-in WiFi
© 2011 Funai Electric Co., Ltd.
X6060UDTB600MG2FF7OMENWEBv1AppChannel削除版0711.indd1X6060UDTB600MG2FF7OMENWEBv1AppChannel削除版0711.indd1 2011/07/1513:24:002011/07/1513:24:00

EN-2
1. CONTENTS................................................................................2
2. FEATURES.....................................................................................3
2.1 Features........................................................................................... 3
2.2 Product Info.................................................................................. 4
3. FUNCTIONAL OVERVIEW...............................................5
3.1 Top / Front Panel....................................................................... 5
3.2 Rear Panel......................................................................................5
3.3 Remote Control......................................................................... 6
3.4 Guide to On-Screen Display..............................................8
4. CONNECTIONS .....................................................................9
4.1 HDMI Video / Audio Connection.................................... 9
4.2 Standard Video + Standard Audio Connection ...... 9
4.3 Connection to an Audio System................................... 10
4.4 Connection to the Network........................................... 11
5. BEFORE YOU START..........................................................13
5.1 Finding the Viewing Video Source Input
on Your TV................................................................................. 13
5.2 Initial Setup................................................................................. 13
6. USING NETWORK FEATURES....................................14
6.1 Preparation for Network Features .............................. 14
6.2 Information on Network Services ............................... 14
7. LIST OF SETTINGS..............................................................15
8. SETUPS........................................................................................17
8.1 Network Connection........................................................... 17
8.2 fun-Link (HDMI CEC).......................................................... 22
8.3 HDMI Video Resolution...................................................... 22
8.4 Software Update..................................................................... 23
8.5 Initialize ......................................................................................... 24
9. TROUBLESHOOTING.......................................................25
10. SPECIFICATIONS..................................................................28
11. NETWORK SERVICE DISCLAIMER...........................29
12. SAFETY INSTRUCTIONS................................................30
13. MAINTENANCE ...................................................................31
14. SUPPLIED ACCESSORIES................................................31
15. INSTALLING ON A WALL OR SHELF....................32
16. TRADEMARK INFORMATION ....................................33
17. GLOSSARY...............................................................................34
18. ESPAÑOL...................................................................................36
18.1 Mando a Distancia................................................................. 36
18.2 Encontrar la Entrada de Fuente
de Video en su TV ................................................................ 37
18.3 Instalación Inicial...................................................................... 37
LIMITED WARRANTY..............................................back cover
1. CONTENTS
X6060UDTB600MG2FF7OMENWEBv1AppChannel削除版0711.indd2X6060UDTB600MG2FF7OMENWEBv1AppChannel削除版0711.indd2 2011/07/1513:24:002011/07/1513:24:00

EN
EN-3
2. FEATURES
2.1 Features
VUDU
This unit supports VUDU which is the leading HD on-demand video service. With VUDU, you can also enjoy
various kinds of Internet applications. In order to use this feature, you must connect this unit to the Internet.
(This feature is only available in the United States.)
Netflix
With this unit, you can enjoy movies and TV episodes streamed instantly from Netflix via the Internet. In order to
use this feature, you must visit netflix.com/Magnavox on your PC and become a Netflix member. (This feature is
only available in the United States.)
Film Fresh / Blockbuster
With this unit, you can enjoy movies and TV episodes streamed instantly from Film Fresh / Blockbuster via the
Internet. In order to use this feature, you must visit the below websites on your PC and become a Film Fresh /
Blockbuster member. (This feature is only available in the United States.)
- Film Fresh : filmfresh.roxionow.com/Login
- Blockbuster : www.blockbuster.com/auth/login
Pandora®internet radio
This unit supports Pandora internet radio service. You can instantly listen to free personalized radio stations
streamed over the Internet from Pandora. In order to use this feature, you must visit the below website on your
PC and become a Pandora member. (This feature is only available in the United States.)
- www.pandora.com/magnavox
Picasa
With Picasa application, you can browse your web albums on your TV screen. Picasa helps you organize a number of
photographs of yours, so you can easily find particular photographs with an easy operation.
Easy and simple connection to your HDTV with an HDMI (High-Definition Multimedia Interface) cable
Connect this unit to your HDTV with one single HDMIcable. It is recommended to use a High Speed HDMI cable
for better compatibility. The high-definition video output signal will be transferred to your HDTV without conversion to
analog signals, so you will get excellent picture and sound quality, completely free from noise. Thanks to other multiple
outputs, you can also easily connect to your home theater system or amplifier.
fun-Link (HDMI CEC) (Consumer Electronics Control)
This unit supports fun-Link (HDMI CEC), which allows integrated system control over an HDMI cable and is part of
the HDMI standard. This function may not work properly on some devices.
HDMI Deep Color
Deep Color reduces posterization (color banding) effect of the playback image.
X6060UDTB600MG2FF7OMENWEBv1AppChannel削除版0711.indd3X6060UDTB600MG2FF7OMENWEBv1AppChannel削除版0711.indd3 2011/07/1513:24:002011/07/1513:24:00

EN-4
2.2 Product Info
“Product Info” screen provides information about this unit’s software version. When a newer version of software is
available, you can update the software via the Internet.
To access “Product Info”, follow the procedure below.
1. Press [HOME].
2. Use [Í/ Æ]to select “Settings”, then press [OK].
3. Use [Î/ ï]to select “Product Info”.
■Netflix ESN
You can view the ESN (Electronic Serial Number, which Netflix uses to identify your device) on the “Product Info”
screen.
X6060UDTB600MG2FF7OMENWEBv1AppChannel削除版0711.indd4X6060UDTB600MG2FF7OMENWEBv1AppChannel削除版0711.indd4 2011/07/1513:24:002011/07/1513:24:00

EN
EN-5
3. FUNCTIONAL OVERVIEW
3.1 Top / Front Panel
FrontTo p
1
2
DNote
• Due to new ENERGY STAR®requirements, this unit will automatically turn On the screen saver after 5 minutes
of inactivity and enter Standby mode after 25 minutes of inactivity.
3.2 Rear Panel
12345
CCaution
• Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent damage
to the unit.
• This unit does not have a TV RF modulator.
1. Infrared sensor window
2. Standby/on indicator
1. LAN terminal
2. HDMI OUT jack
3. VIDEO output jack
4. AUDIO output jacks (L/R)
5. DC IN jack
X6060UDTB600MG2FF7OMENWEBv1AppChannel削除版0711.indd5X6060UDTB600MG2FF7OMENWEBv1AppChannel削除版0711.indd5 2011/07/1513:24:002011/07/1513:24:00

EN-6
3.3 Remote Control
1
3
6
8
5
4
10
2
9
7*
14
15
17
11
13
12
16
* The unit can also be turned On by pressing this button.
1. .(Standby/on) button
Press to turn On the unit, or to switch the unit into
Standby mode. (To completely turn Off the unit,
you must unplug the AC adapter.)
2. HOME button
Press to display the home menu.
3. OPTION button
If a newer software is found when “Auto Update
Check” is set to “On”, the update notification
appears in the home menu screen. Press this button
to start update.
4. Î/ ï/ Í/ Æbuttons
Press to select items or settings.
5. NET APP button
Press to display the network application menu.
6. ¢(reverse) button
During playback, press to fast reverse the playback.
7. B(play) button*
Press to start playback or resume playback.
8. H(skip) button
During playback, press once to return to the
beginning of the current title.
9. Ê(stop) button
Press to stop playback.
10. NETFLIX button
Press to launch Netflix.
11. DISPLAY button
Press to display the on-screen display menu.
12. OK button
Press to confirm or select menu items.
13. RETURN button
Press to return to the previous menu screen or
screen function.
14. ∫(forward) button
During playback, press to fast forward the playback.
When playback is in pause, press to slow forward
the playback.
15. G(skip) button
During playback, press to skip to the next title.
16. Δ(pause) button
Press to pause playback.
17. VUDU button
Press to launch VUDU.
DNote
• When the unit receives a signal from the remote
control, the Standby/on indicator on the top panel
turns Off.
Continued on next page.
X6060UDTB600MG2FF7OMENWEBv1AppChannel削除版0711.indd6X6060UDTB600MG2FF7OMENWEBv1AppChannel削除版0711.indd6 2011/07/1513:24:012011/07/1513:24:01

EN
EN-7
■Installing the Batteries in the Remote Control
Install 2 AAA (1.5V) batteries matching the polarity indicated inside the battery compartment of the remote control.
CCaution
Incorrect use of batteries can result in hazards, such as leakage and bursting. Please observe the following:
• Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh, etc) batteries.
• Do not mix new and old batteries together.
• Do not use different kinds of batteries together. Although they may look similar, different batteries may have
different voltages.
• Make sure that the + and - ends of each battery match the indications in the battery compartment.
• Remove batteries from the battery compartment when the remote is not going to be used for a month or more.
• When disposing of used batteries, please comply with governmental regulations or environmental public rules
that apply in your country or area.
• Do not recharge non-rechargeable batteries.
• Do not short-circuit, heat or burn any batteries.
■Using the Remote Control
Remote Control Usage Guidelines:
• To check remote operation, aim the remote at the unit then press any arrow button. The Standby/on Indicator
on the unit will turn Off when the button is pressed and turn On again when the button is released. This
confirms that the unit is receiving the IR remote signal.
• Make sure that there are no obstacles between the remote control and the infrared sensor window on the unit.
• Do not mount the device on the wall behind the TV as this would block the infrared sensor window from the
remote infrared signal.
• Remote operation may become unreliable if strong sunlight or fluorescent light is shining on the infrared sensor
window of the unit.
• Remote controls of different devices can interfere with each other. Avoid using a remote control of another
device which is located close to the unit.
• Replace the batteries when you notice a fall-off in the operating range of the remote control.
• The maximum operable ranges from the unit are as follows.
30˚ 30˚ 30˚ 30˚
Line of sight : approx. 23 feet (7 m)
Either side
of the center : approx. 16 feet (5 m) within 30°
Above : approx. 16 feet (5 m) within 15°
Below : approx. 10 feet (3 m) within 30°
X6060UDTB600MG2FF7OMENWEBv1AppChannel削除版0711.indd7X6060UDTB600MG2FF7OMENWEBv1AppChannel削除版0711.indd7 2011/07/1513:24:012011/07/1513:24:01

EN-8
3.4 Guide to On-Screen Display
■Home Menu
When you turn On the unit, the home menu will automatically appear. Otherwise, press [HOME].
NET APP
1 2 3
1. “NET APP” :To access the menu of network services
2. “Settings” :To access the setup menu
3. “Network Setup” :To configure network settings
■Setup Menu
Video Out
Audio Out
System
Network Setup
Product Info
Video Resolution
TV Aspect
Deep Color
: HDMI Auto
: 16:9 Wide
: Auto
1
2
1. Categories
2. Menus / Options : Displays options for the highlighted item on the left whenever available.
X6060UDTB600MG2FF7OMENWEBv1AppChannel削除版0711.indd8X6060UDTB600MG2FF7OMENWEBv1AppChannel削除版0711.indd8 2011/07/1513:24:022011/07/1513:24:02

EN
EN-9
4. CONNECTIONS
4.1 HDMI Video / Audio Connection
(Supports up to 1080p (outputs video data with a frame rate of 60 frames per second.)
HDMI cable (not supplied) HDMI IN
No audio connection required.
• Make sure the shapes of the jack and the connector are matched and do not tilt the HDMI connector when
inserting it into the HDMI jack.
• When connected to an HDCP incompatible display device, the picture will not be displayed properly.
• Use an HDMI cable with the HDMI logo (a certified HDMI cable) for this connection.
High Speed HDMI cable (also known as HDMI category 2 cable) is recommended for better compatibility.
4.2 StandardVideo + Standard Audio Connection
(Supports only 480i resolution.)
Audio cable (supplied)
Video cable (supplied)
AUDIO IN
LRVIDEO IN
• Connect this unit directly to the TV. If the audio / video cables are connected to a VCR, then the pictures may
be distorted due to the copyright protection system.
X6060UDTB600MG2FF7OMENWEBv1AppChannel削除版0711.indd9X6060UDTB600MG2FF7OMENWEBv1AppChannel削除版0711.indd9 2011/07/1513:24:022011/07/1513:24:02

EN-10
4.3 Connection to an Audio System
• When you change the connections, you should turn Off all the devices.
• When making connections with external devices, please refer to their user manuals for additional setup help.
■2-Channel Analog Audio Connection
Stereo system with analog audio input jacks
Audio cable (supplied)
AUDIO IN
LR
■HDMI Audio Connection
AV receiver/amplifier with an HDMI input jack
HDMI cable (not supplied)
HDMI IN
■HDMI Audio Out
Audio Source PCM Stereo Bitstream PCM 5.1ch
VUDU Dolby Digital Plus 2cn LPCM Dolby Digital Plus Multi LPCM*
MP3 2cn LPCM 2cn LPCM 2cn LPCM
Netflix WMA 2cn LPCM 2cn LPCM 2cn LPCM
Film Fresh AAC 2cn LPCM 2ch AAC 2cn LPCM
Blockbuster AAC 2cn LPCM 2ch AAC 2cn LPCM
Pandora®MP3 2cn LPCM 2cn LPCM 2cn LPCM
* Fully decoded.
DNote
• If the connected device is not compatible with the HDMI BITSTREAM then audio will be output as multi LPCM
or 2-channel down-mixed LPCM based on the capability of the connected device even if you select “Bitstream”
in “Audio Out” setting.
• If the connected device is not compatible with AAC, audio will be output as LPCM based on the capability of the
connected device.
X6060UDTB600MG2FF7OMENWEBv1AppChannel削除版0711.indd10X6060UDTB600MG2FF7OMENWEBv1AppChannel削除版0711.indd10 2011/07/1513:24:042011/07/1513:24:04
