Magner Magner350 User manual

Currency Fitness Sorter
Magner350 is smart, practical multi-currencies fitness sorter and banknote
counter designed for user’s convenience, optimized for high performance,
enhanced authentication and easy operation.
Rev. 1.1.2
Date: 2015. 4. 29

Magner350 USER Guide
Magner INT 2
- Contents –
Introduction .......................................................................................................................4
For Safety Use.....................................................................................................................4
Packing List.......................................................................................................................11
Options...............................................................................................................................11
Appearance........................................................................................................................12
1. Screen Description …………………………………………………………………………14
2. Operation Mode 1
2-1. ATM ................................................................................................................ 18
2-2. FIT .................................................................................................................. 20
2-3. ATM+FIT ........................................................................................................ 22
2-4. ADD ................................................................................................................ 22
2-5. GT ................................................................................................................... 23
2-6. MIX/SP/SG/DIR-MF/DIR-MO/DIR-SF/DIR-SO/SERIAL.................................. 26
3. Operation Mode 2
3-1. Currency ........................................................................................................ 35
3-2. Mode................................................................................................................ 35
3-3. Display............................................................................................................. 36
3-4. Print ................................................................................................................. 36
4.Others
4-1. Batch .............................................................................................................. 38
4-2. Counting Speed.............................................................................................. 39
4-3. User.................................................................................................................. 39
4-4. Language ........................................................................................................ 39
4-5. Date and Time................................................................................................. 40
4-6. Sound .............................................................................................................. 40
4-7. Operation ........................................................................................................ 41

Magner350 USER Guide
Magner INT 3
5. Menu
5-1. Machine Model .............................................................................................. 51
5-2. Help.................................................................................................................. 51
5-3. Machine State................................................................................................. 52
5-4. System Setting ............................................................................................... 53
5-5. Upgrade........................................................................................................... 54
5-6. Machine Setting.............................................................................................. 54
6. Specification ………………………………………………………………………………….55
7. Error Code ………………………………………………………………………………….55
8. Maintenance ………………………………………………………………………………….59

Magner350 USER Guide
Magner INT 4
Introduction
Thank you for purchasing MAGNER350.
MAGNER350 is smart, practical multi-currencies fitness sorter.
MAGNER350 sorts holes, tears, dog-ears, tape, soil, stains, folded and de-inked
banknotes with high speed.
The machine is designed for user’s convenience, optimized for high performance and
easy maintenance.
MAGNER350 has high connectivity interfaces and 7” full color graphic LCD display.
For Safety Use
In this section, the compliance matters are described in order to use the product safely,
and to prevent you and other people from the damages brought by the product to
the human bodies or properties.
Please read this instruction manual thoroughly in advance to use in the correct way.
This symbol indicates that the precautions for handling the product.
Please read the indications well and utilize the product safely.
This symbol indicates prohibited matters not to do. Please read the
indications well and never do the prohibited matters.
This symbol denotes that there are indication matters which should be
done without fail. Please read the indicated matters thoroughly and
perform the matters without fail.
Warning
Caution It denotes the contents in which mishandling of the product by
neglecting this indication may cause the people’s light injury or only
physical damage.
It denotes the contents in which mishandling of the product by
neglecting this indication may cause the people’s serious injury.

Magner350 USER Guide
Magner INT 5
Warning Installation
1. At installation and relocation of the products, please contact our distributor near
you or our designated dealers. If installation is not perfect, there is a risk of a falling
accident, electric shock, and fire and burn injury.
2. At installation and use of the products, keep the space sufficient for opening and
closing the door, cover and operation. If a part of the product touches a human
body, it may cause an accident.
3. In case of installing the product at the following places, you should confirm the
Road Law, Road Traffic Law and Fire Protection Law, etc. If compliance conditions
are not clear, please consult with the authorities concerned.
- The place which may disturb traffic or accident prevention.
- The place adjacent to the fire extinguishing and detecting apparatus.
- The place adjacent to the road signs or traffic signals.
- The place where combustible materials or gas are treated (gas stations, etc.)
Passages and facilities for evacuation Illegal installation may cause an accident.
4. Keep an installation space as described in the instruction manual, and do not
choke up the ventilation inlet. If the ventilation inlet is choked, heat is accumulated
inside and it may cause fire.
5. Depending on the installation place, mounting of an earth leakage breaker is
required by Electricity Enterprises Law. Illegal installation may cause an accident.
1. Do not install the product at the place where water may spill on it. If water enters
into the product, insulation performance degrades and it may cause fire and/or
electric shock.
2. Do not install the product at the place where the floor cannot bear the load of the
product, or at the unstable place with inclination and/or irregularity. It may cause the
accidents of floor caving and sudden move of the product.
3. Installation at the following places should be avoided.
There are safety problems and deterioration of the product may be accelerated,
which leads to a cause of failure.
- 1m or less from volatile combustible materials or curtains.
- 1m or less from heating apparatus such as stoves, heaters etc.
- The place with direct winds blown from air conditioners, ventilating openings
etc.

Magner350 USER Guide
Magner INT 6
Grounding work should be made for safety and prevention of static electricity and
noise failure. In addition, a ground wire should be installed independently without
sharing the wire with other products. At grounding work, please be sure to contact
our distributor near you or our designated dealers. In case of electrical leakage
when grounding is insufficient or not connected, it may cause fire and/or electric
shock.
The place where a ground wire can be fitted:
- Ground terminals for power receptacle.
- The copper piece etc. with a length of 65 cm or more, buried in the ground.
- The ground terminals on which grounding work is made.
The place where is a ground wire must not be fitted.
- Gas pipes
- Telephone wires for exclusive use
- Lightning rods
- Water pipes or faucets with plastic materials at their intermediate part.
-The place with high temperature, high humidity, or low temperature.
-The place with direct sunlight.
-The place with much dust.
When installing the product at the following places, please contact our distributor
near you or our designated dealers.
-The place exposed to salty winds or corrosive gas.
-The place with much swinging or vibration.
Do not use or put the combustible materials such as thinner, combustible gas, or a
high-volatile object around/inside the product. Otherwise, it may cause explosion
and/or fire due to heating from the product or flashing from power supply.

Magner350 USER Guide
Magner INT 7
Warning Power Supply
1. When using the product, connect it to the power supply specified in the instruction
manual. If it is connected to the power supply, other than the product’s specification,
it may become a cause of fire, electric shock, and/or electrical leakage.
2. Do not use a power supply cord and the plug other than the attached ones. If a
current that exceeds the rating flows in the power supply cord, it may cause fire.
3. Be sure to insert the blade part of the power supply plug into an outlet. Insufficient
insertion may cause fire.
1. When the earth leakage breaker frequently operates, please contact our
distributor near you or our designated dealers. If the product is used or left as it is, it
may cause fire and/or electric shock.
2. Do not modify, process, or repair the power supply cord and the plug. In addition,
do not convert a 3-prong power supply plug into a two-pole type. Grounding
becomes insufficient and there may cause electric shock.
Please follow the items below to prevent electric shock and/or fire due to damage
of the power supply cord.
- Do not pull the cord part when pulling out the power supply plug.
- Do not put anything on the cord part.
- Do not pass the cord near a source of heat.
- Do not bend or pinch the cord.
- Do not tread or twist the cord.
- Do not spill chemicals on the cord.
- Do not use it while it is bundled.
- Do not fix it with a stapler etc.
1. Do not use the power supply cord and the plug for other products or purposes.
Further, when they are lost or damaged, please purchase them at our distributor
near you or our designated dealers. The attached power supply cord and the plug
are designed and confirmed the safety for connecting to this product to use. If
they are used for other products or purposes, it may cause fire and/or electric
shock.
2. The product should be used at the specified frequency. If it is used at other than
the s
p
ecified fre
q
uenc
y,
it ma
y
cause an accident.

Magner350 USER Guide
Magner INT 8
Caution Handling
1. The product should be used under the environment specified in the instruction
manual. If it is used under the other environment of the specification, there may
cause fie and electric shock.
2. When operating inside the product for error or clearing or cleaning etc., the
operation should be made in accordance with the description in the instruction
manual. Operation other than the description may cause an accident.
1. Do not turn off the power, pull out the power supply plug, or open the cover of
the product during the operation. Otherwise, it may cause an accident.
2. Do not put a vase or glass with an object and/or water etc. on the product.
Otherwise, it may cause fire, electric shock, and/or injury by spilling water or
dropping.
3. Do not apply shock on the product. There is a risk of damaging the product and
normal operation cannot be performed.
4. Do not use chemicals such as thinner or benzene when removing dirt of the
product. Otherwise, it may cause damages.
5. Do not use an interface cable other than the attached one. When cables are
other than the attachment, it may cause the interface error or machine trouble.
Do not us a combustible spray etc. around product. If spray gas etc. contacts the
electrical parts inside the product, it may cause explosion and fire.
1. When touching inside the product for cleaning or parts replacement etc., be sure
to turn off the power. If you work with turning the power on, it may cause electric
shock and/or injury.
2. Do not touch the product and power supply plug and cord with a wet hand.
There is a risk of electric shock.
3. The electrical parts inside the product should not get wet by rain or water at
cleaning etc. if they get wet, it may cause electric shock and/or shock.
4. Do not turn of air heating suddenly when the product is completely cold.
Moisture may adhere inside the product due to sudden air heating and it may
cause electric shock.

Magner350 USER Guide
Magner INT 9
5. There is a charging part inside. Be sure to open the cover with turning off the
power. If the cover is opened without turning off the power, it may cause electric
shock.
1. Do not drop any metallic piece such as a clip, staple etc. inside or in a clearance
of the product. If a metallic piece drops inside the product and contacts the electric
circuit, it may cause fire.
2. When the product is not use for a long time, be sure to pull out the power supply
plug from an outlet for safety. Otherwise, it may cause heating and/or firing due to
dust accumulation.
Do not modify the product or mount modified parts on the product. Further, do not
dismount the portion which is not indicated to be opened/closed in the manual or
the cover and parts etc. fixed with screws etc. Otherwise, it may cause fire,
electric shock, and/or injury.
1. Do not approach your hand or cloths during operation to moving parts of the
product reachable. There may cause injury and/or pinching of a finger.
2. When closing a door, pay attention not to pinch a finger. It may cause of injury.
3. When working with a door opened, confirm it is locked. It may become a
cause of injury because the door may suddenly close.
Do not touch the gear etc. It may cause injury.

Magner350 USER Guide
Magner INT 10
Warning Maintenance
1. For repairing the product, please contact our distributor near you or our
designated dealers. Insufficient repair may cause fire, electric shock, and/or injury.
2. When the product has sunk under the water due to a disaster etc., stop using it
and please ask for repair/check to our distributor near you or our designated
dealers. If used as it is, it may cause fire and/or electric shock.
3. Check periodically whether its installation place is unstable or not. If there is any
abnormality, please contact our distributor near you or our designated dealers. If it
is continuously used with insufficient installation, it may cause a falling accident.
4. Check and clean the power supply plug and the cord regularly. It the power
supply plug is broken or the cord is damaged, stop using and please replace it by
contacting our distributor near you or our designated dealers. It may cause fire
and/or electric shock.
When smoke, abnormal smell or abnormal sound is generated from the product,
stop using it immediately, cut off power supply and pull out the plug from the outlet.
Then, please contact our distributor near you or our designated dealers. It used or
left as it is; it may cause fire and/or electric shock.

Magner350 USER Guide
Magner INT 11
Packing List
Options

Magner350 USER Guide
Magner INT 12
Appearance
Speaker
Touch Screen Hopper
Reject
Pocket
Operation Button
Pocket 1 Display
Pocket 2 Display
Pocket 3 Display
Pocket 1
Pocket 2
Pocket 3
<Front View>

Magner350 USER Guide
Magner INT 13
<Rear View>
Handle
Fan
Power Switch
Power Connector
Top Cover
Release handle
Front
Release
Button
USB B type
RS232
Serial Port OSD Port Video Out (External Full Color LCD)
LAN
USB A type

Magner350 USER Guide
Magner INT 14
1. Screen Description
1) Operation Mode 1
zATM
Machine sorts good condition notes.
zFIT
Referring to Fitness condition, the machine sorts banknotes.
zADD
Machine cumulates the accounted result.
User Information Date and Time
Currency
Counting Value
Counting Number
Counting Speed
Batch
Menu Key
Operation
Mode 1
Operation
Mode 2
Pocket
Information

Magner350 USER Guide
Magner INT 15
zGT
Machine settles accounts during the period which customer sets.
zMIX/SP/SG/DIR-MF/DIR-MO/DIR-SF/DIR-SO
- MIX: Count all denominations of selected currencies. The counted notes are stacked to the
first Pocket in order.
- SP: The first inserted denomination is stacked to the first Pocket and next recognized note
is stacked to the next Pocket.
- SG: The selected denomination is stacked to the selected Pocket.
- DIR-MF: By face of the note, a machine sorts the notes to each Pocket.
(Sorts all denominations)
- DIR-MO: By orientation of the note, a machine sorts the notes to each Pocket
(Sorts all denominations)
- DIR-SF: By face of the note, a machine sorts the notes to each Pocket.
(Sorts single denomination)
- DIR-SO: By orientation of the note, a machine sorts the notes to each Pocket
(Sorts single denomination)
- SERIAL: Recognize serial numbers from the counted notes.

Magner350 USER Guide
Magner INT 16
2) Operation Mode 2 ( icon & key operation)
Currency Icon& short Key Change local currency.
Long Key Holding Currency key shows local currencies that machine has.
Mode Icon& short Key Select Operation Mode, MIX, SP, SG and DIR Mode.
Long Key Holding Mode key shows drop-down menu of Operation Mode 2.
Display Icon& short Key Shows each denomination counting result.
Long Key Empty
Print Icon& short Key Print the counting result via serial printer or PC.
Long Key Show the last counting information.
Start/Clear Icon& short Key Start the counting manually or clear total counting result.
Long Key Clear counting result.
Icon Key

Magner350 USER Guide
Magner INT 17
3) Pocket Information
By pressing each pocket icon, user can check counting information of banknotes which are in the certain
pocket.
4) Others
zBatch
Set batch number of each pocket.
zCounting Speed
Set count speed.
zMenu
Check and Setting machine status.
zUser Information
Select the user who uses the machine. Each user has their own settings and the settings are
automatically changed by changing user. Only engineer can add new user to the machine.
zLanguage
Select Display Language.
zDate and Time
Show current date and time. In System Setting menu, user can set date and time.
zOperation
User can select some operations for individual preference.

Magner350 USER Guide
Magner INT 18
2. Operation Mode 1
2-1. ATM
When ATM mode is on, Pocket 1 and 2 are for fit notes and Pocket 3 is for unfit notes.
By pressing each pocket icon, user can check counting results.

Magner350 USER Guide
Magner INT 19
In case of Reject result, you can save the data to USB Stick.
By pressing Display icon or key, total counting result is shown.
2-2. FIT

Magner350 USER Guide
Magner INT 20
When FIT mode is on, Pocket 1 and 2 are for fit notes and Pocket 3 is for unfit notes.
By pressing each pocket icon, user can check counting results.
In case of Reject result, you can save the data to USB Stick.
By pressing Display icon or key, total counting result is shown.
