Magneti Marelli EMS Link User manual

EMS Link
EMS Link—Installation and
User Manual
4
10 NC NC NC
11 NC NC NC
12 NC NC NC
13 NC NC NC
14 Comm. Line CAN1L CAN Bus low
15 NC NC NC
16 Power BAT+ KL30 permanent power
EMS Link
This file is in Glasscubes or ask through e-mail, download in
your computer and via USB cable put the file in your android
phone , If the App doesn't open, go to settings and unlock it.
Now you can start !
The diagnostic cable part. number :

4
10 NC NC NC
11 NC NC NC
12 NC NC NC
13 NC NC NC
14 Comm. Line CAN1L CAN Bus low
15 NC NC NC
16 Power BAT+ KL30 permanent power
4
10 NC NC NC
11 NC NC NC
12 NC NC NC
13 NC NC NC
14 Comm. Line CAN1L CAN Bus low
15 NC NC NC
16 Power BAT+ KL30 permanent power
EMS Link
This file is in Glasscubes or ask through e-mail, download in
your computer and via USB cable put the file in your android
phone , If the App doesn't open, go to settings and unlock it.
Now you can start !
The diagnostic cable part. number :
EXEC
EMSLinkMIU
Only for Android Phone
1. Download into your computer de Magneti Marelli.apk file.
2. Save it into a new folder
3. Connect your android smartphone via usb cable into your computer.
4. Paste the Magneti Marelli folder into the phone storage.
5. Restart your android phone and remove the usb cable.
6. Go to settings, other settings, security and privacy, allow unknown sources.
7. Search in the phone storage the Magneti Marelli file, open it.
8. Install the Magneti Marelli EMS link app.
9. It will be ready to go.
Download instruction

1
Requirement of your smart phone ............................................................................................ 03
2
Connector information ............................................................................................................. 03
3
Installation and step of use ....................................................................................................... 05
3.1 Installation ........................................................................................................................... 05
3.2 Step of use ........................................................................................................................... 05
3.2.1
Connection between the smart phone and vehicle ........................................................ 05
3.2.2
Operation of vehicle ..................................................................................................... 05
3.2.3
How to use EMS Link APP .......................................................................................... 05
3.3 Note ..................................................................................................................................... 12
4
Feature description ................................................................................................................... 13
4.1 DashBoard ........................................................................................................................... 13
4.2 Trip Meter ........................................................................................................................... 14
4.3 Service Tool ........................................................................................................................ 15
4.4 Reflashing............................................................................................................................ 19
4.5 Scan Tool............................................................................................................................. 21
4.6 Log In/Upload Data/Download ........................................................................................... 21
Contact us...................................................................................................................................... 23

3
1 Requirement of your smart phone
For android system, the OS of smart phone must be 4.2 and above; for IOS, the OS of
smart phone must be 7.0 and above
2 Connector information
Figure 1 is Dongle OBDII connector (male).
figure 1
Table 1 is pinout of OBDII connector.
Table 1 OBDII connector pinout
OBD Connector Pin N° I/O Type Signal Name Pin Description
1 NC NC NC
2 NC NC NC
3 NC NC NC
4 GND GND Chassis ground
5 GND GND Signal ground
6 Comm. Line CAN1H CAN Bus high
7 Comm. Line K-line K-line
8 NC NC NC
9 NC NC NC
Only Android Phone

4
10 NC NC NC
11 NC NC NC
12 NC NC NC
13 NC NC NC
14 Comm. Line CAN1L CAN Bus low
15 NC NC NC
16 Power BAT+ KL30 permanent power

5
3 Installation and step of use
3.1 Installation
Download the APK to your smart phone and click “install”
3.2 Step of use
3.2.1 Connection between the smart phone and vehicle
Please insert the Dongle to the vehicle‟s OBD connector, as shown in figure 2
figure 2
3.2.2 Operation of vehicle
Insert the key to the vehicle, and make sure the vehicle‟s status is “key on”. If you need
to test dynamic data, please crank the vehicle
3.2.3 How to use EMS Link APP
Note: The distance between the smart phone and Dongle must be within 5 meters. Make
sure the smart phone‟s Bluetooth is enabled before using APP.

6
(1) Click the icon “EMS Link” to use the APP, as shown in figure 3
figure 3
(2) After clicking „‟EMS Link”, you will enter the “Take A Look” page, as shown in figure 4. In
this page, you can slip picture to learn how to use APP. Click the “Skip” button, you will enter
the “welcome” page.
figure 4

7
(3) The “welcome” page is shown in figure 5. Click the “Introduction” button, you will open the
user manual; click “Take A Look” button, you will learn how to use app briefly; click the “Go”
button, you will enter the “Main” page.
figure 5
(4) When you are in main interface, the APP will scan the available devices automatically, as
shown in figure 6
figure 6

8
(5) when scanning finished, the APP will list all available devices to user, and the user can click
the name of device to connect, as shown in figure 7
figure 7
(6) If the dongle is connected successfully, the “Connect” will become “Disconnect”, as shown
in figure 8
figure 8

9
(7) Click the “Settings” button to enter the “Settings” page, as shown in figure 9
figure 9
(8) In “Settings” page you can select the language, click “Language” button, you will see the
“Chinese” and “English”, you can select either one, as shown in figure 10
figure 10

10
(9) In “Settings” page, click the “Bluetooth Device” to clear the paired device, as shown in
figure 11
figure 11
(10) In “Setting” page, you can select the “important parameters” which will be shown in
“Dashboard”. Click the “Important Parameters” to select. The “Engine RPM” and “Vehicle
Speed” are mandatory, as shown in figure 12
figure 12

11
(11) In “Setting” page, you can select the “other parameters” which will be shown in
“Dashboard”. Click the “Other Parameters” to select, as shown in figure 13
figure 13
(12) Click the “Back” button on Smart Phone or Tablet, you will go back to the “Main” page, as
shown in figure 14
figure 14
Note: to perform diagnostic features, you have to establish the connection by pushing the
“Connect” button.

12
3.3 Note
1 One dongle only can be connected with one smart phone at the same time
2 If you want to use other smart phone to connect dongle, please kill the running EMS Link APP
in the running smart phone, as shown in figure 15
figure 15

figure 17
13
4 Feature description
The EMS Link APP includes “Dashboard” function, “Trip meter” function, “Service
Tool” function, “Reflashing” function and “Scan Tool” function, as shown in figure 16
4.1 DashBoard
figure 16
The “DashBoard” function can display real-time parameters such as “RPM”, “SPEED”,
“Manifold Pressure”, “Battery Voltage”, “Gear Position”, “Water Temperature”, “Air
Temperature” and so on, as shown in figure 17

figure 19
14
The “other parameters” which is selected in “Other Parameters” page will be shown in
“Information” page, as shown in figure 18
4.2 Trip Meter
figure 18
The “Trip Meter” function through the GPS to display the “Max Speed”, “Acceleration”,
“Altitude” and the “Speed” on your trip. The “Trip Meter” function need to enable the GPS
function, as shown in figure 19

figure 21
15
4.3 Service Tool
“Service Tool” can do the diagnostic function for your vehicle, it includes several
modules, as shown in figure 20
figure 20
（
1
）
Read Data
The “Read Data” function is used to read the system parameter, as shown in figure 21.
Click “Start” button and “Search” icon to read data.

16
The test result of “Read Data” function is shown in figure 22
figure 22
（
2
）
Configure Data
The “Configure Data” function is used to read the configuration information, such as
ECU version. Click “Start” button and “Search” icon to read data, as shown in figure 23
figure 23

17
（
3
）
Actuator Control
The “Actuator Control” function sends the command to test the actuator of the
vehicle, as shown in figure 24
figure 24
The test result of “Actuator Control” is shown in figure 25
figure 25

18
（
4
）
Monitor Mode
The “Monitor Mode” allow the users to edit the command to test the vehicle, as shown in
figure 26
figure 26
You can edit the command in edit box, and click the “Send” button to send the command,
the test result of “Monitor Mode” is shown in figure 27
figure 27

figure 29
19
（
5
）
DTC Management
The “DTC Management” function is used to read the DTC, and you can clear the DTC by
it, as shown in figure 28. Click the “Start” button to scan DTC, click the “Clear” button to clear
DTC.
4.4 Reflashing
figure 28
The “Reflahing” function permits to update the engine control software code into the
ECU. Click the “Reflashing” button to enter the “Reflashing” page, as shown in figure 29
