Converters.TV 15382 User manual

HDMI UHD 4k2k 1 In 2 Out Splitter
with HDCP 2.2 - # 15382
Operati n Manual

Intr ducti n
This high performance HDMI splitter with HDCP 2.2 is an advanced solution
designed to distribute an single HDMI input to two simultaneous HDMI
outputs and supports resolutions up to 4 2 @60Hz (YUV420), as well as
High Definition Lossless Audio formats. Capable of receiving and
transmitting up to 9Gbps of bandwidth with no data loss, it also supports the
latest features so you can be assured of reliable and high quality HDMI
distribution.
Applicati ns
• Simultaneously display an HDMI source on 2 TVs/projectors
Showroom display
University lecture hall display
Retail sales displays
Features
• HDMI (with 3D & 4 2 support) and HDCP 2.2 compliant
Supports HDTV resolutions up to 4 2 including
3840×2160@24/25/30Hz, 3840×2160@50/60Hz (YUV420),
4096×2160@24/25/30Hz, 4096×2160@50/60Hz (YUV420) and PC
resolutions up to WUXGA@60Hz (RB)
Supports pass-through of audio formats: LPCM 2/5.1/7.1CH, Dolby
Digital 2/5.1CH, DTS Surround, Dolby Digital Plus, Dolby TrueHD and
DTS-HD Master Audio
Supports simultaneous outputs of an single HDMI signal to two HDMI
outputs
Supports HDMI data rates up to 9 Gbps and ‘Deep Color’ up to
1080p/36-bit
Supports EDID selection functions
Note: For playback of 4 2 HDMI source signals, a 4 2 capable
display and High Speed HDMI cables are required.
System
Requirements
HDMI source device such as a DVD/Blu-ray player and HDMI equipped
display (TVs/monitors) with High Speed HDMI cables.

Operati n Fr nt Panel
C ntr ls and
Functi ns
1. POWER:
This LED will illuminate when the unit is connected to an active power
supply and switched on.
2. SYNC IN:
This LED will illuminate when the unit is connected with active signal from
the source device.
3. HDCP 2.2 IN:
This LED will illuminate when the source signal is HDCP 2.2 encrypted.
4. SYNC OUT 1~2:
These LEDs will illuminate when the output detects a connected display.
5. HDCP 2.2 OUT 1~2:
These LEDs will illuminate when the connected HDMI display are HDCP
2.2 compatible.
Rear Panel
1. HDMI IN:
Connect this input to the HDMI or DVI output of your source device such as
a DVD player or Set-top Box with an HDMI
cable.
2. HDMI OUT 1~2:
Connect to an HDMI equipped display (TV/monitor) or HD Amplifier for
simultaneous HDMI distribution.
3. EDID TV/STD:
Use this switch to set HDMI EDID setting.
TV:
When in 'TV' mode, the unit will read the EDID settings of the
display connected to HDMI OUT 1. If it detects a 4 2 capable
EDID setting it will transmit the signal in that format to all outputs. If
no 4 2 capable EDID setting is detected then the unit will output

the best resolution that all displays can support.
Note: When Output 1 is connected to a 4K2K display and Output 2
is connected to non-4K2K display no picture may be displayed. To
ensure proper display all screens must all be capable of displaying
the same resolution.
STD:
When in 'STD' mode, the unit will use its own built-in EDID
settings. In this mode, the video output will be set to 1080p@60Hz
and the audio output at LPCM 2CH Stereo. Use this mode if there
are display problems in 'TV' Mode.
Note: The unit ill retain and use the EDID settings of the last display
connected to the HDMI OUT 1 output if no display is connected to
this output even after s itching EDID modes or a po er cycle.
4. FIRMWARE:
Manufacturer use only.
5. DC 5V:
Plug the supplied power supply into the unit and connect the adaptor to an
AC outlet.
Specificati ns
Vide Bandwidth 
Input P rts 
Output P rts 
HDMI Cable Distance 

P wer Supply  !"#$%#&'(&)(*"%+""#,
-.)/.(
ESD Pr tecti n 0&'1(21(.34
56&)7&(-8&)7.
56-1'&-(-8&)7.
Dimensi ns 9:;&-6
%<-30(.(
9:  
;&-6'-30(.(
Weight 7
Chassis Material .&3
C l r =3&-6
Operating Temperature >?@ABC>?@ADEF?@GBH>C?@G
St rage Temperature IF>?@ABJ>?@ADIC?@GBHC>?@G
Relative Humidity KLM'1-1'(.'&1'
P wer C nsumpti n  9

C nnecti n
Diagram

Supp rted
Res luti ns
Res luti n Input Output
:: N N
: N N
:: N N
:: N N
::: N N
: N N
: N N
: N N
 N N
 N N
: N N
 N N
 N N
 N N
M= N N
 N N
O# N N
 N N
O# N N
