Magnum M9-RTS1 User manual

Magnum Innovations
5675 Hudson Industrial Pkwy, Suite 3 - Hudson, OH 44236 - phone [phone] - fax [phone] - www.magnum-innovations.com - [e-mail]
Room Temperature Sensor
Mx-RTS1
Application
Solar-powered sensors, with an intelligent transmission management, are used to measure the room temperature,
and transmit this information wirelessly using the non-proprietary EnOcean wireless protocol. Special indoor
solar cells collect the power required for operation and data transfer from ambient light. In unlit periods,
maintenance-free gold-cap capacitors continue to feed the transmitter. The wireless transmission technology
gives you a great deal of freedom in choosing the installation location.
Technical Data
Function Temperature Sensor
Power Supply Solar-powered via internal energy storage unit
Protocol Wireless EnOcean Telegram
Profile EEP A5-02-05 temperature sensor
Transmission Range Standard: Approximately 100 ft (30m) depending on building structure
Long Range: Approximately 1600 ft (487 m) LINE OF SIGHT
NOTE: Range can vary greatly based on building materials, device positioning,
interferance, etc. Reference the EnOcean Range Planning Guide prior to installation.
Duty Cycle < 0.4%
Transmission Interval Configurable in AirConfig. The default is based on change of value or every 15 minutes
Transmission Power < 10 mW
Darkness Reserve Up to 100 h via gold-cap capacitors
Operating Life With No Light Up to 4 days
Illumination Strength Min. 150 lx, constant
Measuring Range 0°C to 40°C
Ambient Conditions 0°C to 50°C (humidity non-condensing)
Housing Plastic Housing, RAL9010 (pure white)
Degree of Protection IP20
Weight 0.10 kg
Dimensions WxHxD mm 82.5 x 82.5x 30
FCC FCC (United States) SZV-TCM3XXX, 2ANUH-LSTM300U
Part Numbers
(Frequency Dependant)
M9-RTS1 (902 MHz - North America)
M8-RTS1 (868 MHz - Europe and China)
MJ-RTS1 (928 MHz - Japan)
Learn-In
Button
Proudly Made
In America

Magnum Innovations
5675 Hudson Industrial Pkwy, Suite 3 - Hudson, OH 44236 - phone [phone] - fax [phone] - www.magnum-innovations.com - [e-mail]
Room Temperature Sensor
Mx-RTS1
Wall Mounting:
Flush Mounting:
