Magtek MDYNAMO User manual

mDynamo with Outdoor Bezel| IP34 Rated EMV Chip Card Module | Installation and Operation Manual
Page 2 of 23 (D998200546-10)
Copyright © 2006 - 2022 MagTek, Inc.
Printed in the United States of America
INFORMATION IN THIS PUBLICATION IS SUBJECT TO CHANGE WITHOUT NOTICE AND
MAY CONTAIN TECHNICAL INACCURACIES OR GRAPHICAL DISCREPANCIES. CHANGES
OR IMPROVEMENTS MADE TO THIS PRODUCT WILL BE UPDATED IN THE NEXT
PUBLICATION RELEASE. NO PART OF THIS DOCUMENT MAY BE REPRODUCED OR
TRANSMITTED IN ANY FORM OR BY ANY MEANS, ELECTRONIC OR MECHANICAL, FOR
ANY PURPOSE, WITHOUT THE EXPRESS WRITTEN PERMISSION OF MAGTEK, INC.
MagTek®, MagnePrint®, and MagneSafe® are registered trademarks of MagTek, Inc.
Magensa™ is a trademark of MagTek, Inc.
AAMVA™ is a trademark of AAMVA.
American Express® and EXPRESSPAY FROM AMERICAN EXPRESS® are registered trademarks of
American Express Marketing & Development Corp.
D-PAYMENT APPLICATION SPECIFICATION® is a registered trademark to Discover Financial
Services CORPORATION
MasterCard® is a registered trademark and PayPass™and Tap & Go™are trademarks of MasterCard
International Incorporated.
Visa® and Visa payWave® are registered trademarks of Visa International Service Association.
ANSI®, the ANSI logo, and numerous other identifiers containing "ANSI" are registered trademarks,
service marks, and accreditation marks of the American National Standards Institute (ANSI).
ISO® is a registered trademark of the International Organization for Standardization.
UL™and the UL logo are trademarks of UL LLC.
PCI Security Standards Council® is a registered trademark of the PCI Security Standards Council, LLC.
EMV® is a registered trademark in the U.S. and other countries and an unregistered trademark elsewhere.
The EMV trademark is owned by EMVCo, LLC. The Contactless Indicator mark, consisting of four
graduating arcs, is a trademark owned by and used with permission of EMVCo, LLC.
Google Play™ store, Google Wallet™ payment service, and Android™ platform are trademarks of
Google Inc.
Apple Pay®, iPhone®, iPod®, Mac®, and OS X® are registered trademarks of Apple Inc., registered in
the U.S. and other countries. iPad™ is a trademark of Apple. Inc. App StoreSM is a service mark of
Apple Inc., registered in the U.S. and other countries. IOS is a trademark or registered trademark of
Cisco in the U.S. and other countries and is used by Apple Inc. under license.
Microsoft®, Windows®, and .NET® are registered trademarks of Microsoft Corporation.
All other system names and product names are the property of their respective owners.

mDynamo with Outdoor Bezel| IP34 Rated EMV Chip Card Module | Installation and Operation Manual
Page 3 of 23 (D998200546-10)
Table 0-1 - Revisions
Rev Number
Date
Notes
10
Jun 30, 2022
Initial Release

mDynamo with Outdoor Bezel| IP34 Rated EMV Chip Card Module | Installation and Operation Manual
Page 4 of 23 (D998200546-10)
LIMITED WARRANTY
MagTek warrants that the products sold pursuant to this Agreement will perform in accordance with
MagTek’s published specifications. This warranty shall be provided only for a period of one year from
the date of the shipment of the product from MagTek (the “Warranty Period”). This warranty shall apply
only to the “Buyer” (the original purchaser, unless that entity resells the product as authorized by
MagTek, in which event this warranty shall apply only to the first repurchaser).
During the Warranty Period, should this product fail to conform to MagTek’s specifications, MagTek
will, at its option, repair or replace this product at no additional charge except as set forth below. Repair
parts and replacement products will be furnished on an exchange basis and will be either reconditioned or
new. All replaced parts and products become the property of MagTek. This limited warranty does not
include service to repair damage to the product resulting from accident, disaster, unreasonable use,
misuse, abuse, negligence, or modification of the product not authorized by MagTek. MagTek reserves
the right to examine the alleged defective goods to determine whether the warranty is applicable.
Without limiting the generality of the foregoing, MagTek specifically disclaims any liability or warranty
for goods resold in other than MagTek’s original packages, and for goods modified, altered, or treated
without authorization by MagTek.
Service may be obtained by delivering the product during the warranty period to MagTek (1710 Apollo
Court, Seal Beach, CA 90740). If this product is delivered by mail or by an equivalent shipping carrier,
the customer agrees to insure the product or assume the risk of loss or damage in transit, to prepay
shipping charges to the warranty service location, and to use the original shipping container or equivalent.
MagTek will return the product, prepaid, via a three (3) day shipping service. A Return Material
Authorization (“RMA”) number must accompany all returns. Buyers may obtain an RMA number by
contacting MagTek Support Services at (888) 624-8350.
EACH BUYER UNDERSTANDS THAT THIS MAGTEK PRODUCT IS
OFFERED AS-IS. MAGTEK MAKES NO OTHER WARRANTY, EXPRESS OR
IMPLIED, AND MAGTEK DISCLAIMS ANY WARRANTY OF ANY OTHER
KIND, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE.
IF THIS PRODUCT DOES NOT CONFORM TO MAGTEK’S
SPECIFICATIONS, THE SOLE REMEDY SHALL BE REPAIR OR
REPLACEMENT AS PROVIDED ABOVE. MAGTEK’S LIABILITY, IF ANY,
SHALL IN NO EVENT EXCEED THE TOTAL AMOUNT PAID TO MAGTEK
UNDER THIS AGREEMENT. IN NO EVENT WILL MAGTEK BE LIABLE TO
THE BUYER FOR ANY DAMAGES, INCLUDING ANY LOST PROFITS, LOST
SAVINGS, OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES
ARISING OUT OF THE USE OF, OR INABILITY TO USE, SUCH PRODUCT,
EVEN IF MAGTEK HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES, OR FOR ANY CLAIM BY ANY OTHER PARTY.

mDynamo with Outdoor Bezel| IP34 Rated EMV Chip Card Module | Installation and Operation Manual
Page 5 of 23 (D998200546-10)
LIMITATION ON LIABILITY
EXCEPT AS PROVIDED IN THE SECTIONS RELATING TO MAGTEK’S LIMITED WARRANTY,
MAGTEK’S LIABILITY UNDER THIS AGREEMENT IS LIMITED TO THE CONTRACT PRICE OF
THIS PRODUCT.
MAGTEK MAKES NO OTHER WARRANTIES WITH RESPECT TO THE PRODUCT, EXPRESSED
OR IMPLIED, EXCEPT AS MAY BE STATED IN THIS AGREEMENT, AND MAGTEK
DISCLAIMS ANY IMPLIED WARRANTY, INCLUDING WITHOUT LIMITATION ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
MAGTEK SHALL NOT BE LIABLE FOR CONTINGENT, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES TO PERSONS OR PROPERTY. MAGTEK FURTHER LIMITS ITS LIABILITY OF ANY
KIND WITH RESPECT TO THE PRODUCT, INCLUDING NEGLIGENCE ON ITS PART, TO THE
CONTRACT PRICE FOR THE GOODS.
MAGTEK’S SOLE LIABILITY AND BUYER’S EXCLUSIVE REMEDIES ARE STATED IN THIS
SECTION AND IN THE SECTION RELATING TO MAGTEK’S LIMITED WARRANTY.

mDynamo with Outdoor Bezel| IP34 Rated EMV Chip Card Module | Installation and Operation Manual
Page 6 of 23 (D998200546-10)
FCC INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Changes or modifications not expressly approved by MagTek could void the
user’s authority to operate this equipment.
CE STANDARDS
Testing for compliance with CE requirements was performed by an independent laboratory. The unit
under test was found compliant with standards established for Class B devices.
UL/CSA/CUR/UR
This product is recognized per UL 60950-1, 2nd Edition, 2011-12-19 (Information Technology
Equipment - Safety - Part 1: General Requirements), CSA C22.2 No. 60950-1-07, 2nd Edition,
2011-12 (Information Technology Equipment - Safety - Part 1: General Requirements).
ROHS STATEMENT
When ordered as RoHS compliant, this product meets the Electrical and Electronic Equipment (EEE)
Reduction of Hazardous Substances (RoHS) European Directive 2002/95/EC. The marking is clearly
recognizable, either as written words like “Pb-free,” “lead-free,” or as another clear symbol ( ).

0 - Table of Contents
mDynamo with Outdoor Bezel| IP34 Rated EMV Chip Card Module | Installation and Operation Manual
Page 7 of 23 (D998200546-10)
Table of Contents
Limited Warranty .............................................................................................................................................. 4
FCC Information ................................................................................................................................................ 6
CE STANDARDS................................................................................................................................................. 6
UL/CSA/CUR/UR............................................................................................................................................... 6
RoHS STATEMENT............................................................................................................................................. 6
Table of Contents .............................................................................................................................................. 7
1Introduction ............................................................................................................................................... 8
1.1 Engineering Easier Solutions.......................................................................................................... 8
1.2 Delivering Flexible Solutions .......................................................................................................... 8
1.3 Key Features ..................................................................................................................................... 8
1.4 Built for Easier Integration.............................................................................................................. 8
1.5 The Next Generation of Security .................................................................................................... 8
1.6 Magensa Web Services ................................................................................................................... 8
1.7 About Terminology ........................................................................................................................... 8
1.8 About Solution Planning.................................................................................................................. 8
1.9 Handling...........................................................................................................................................10
2Electrical Integration..............................................................................................................................11
2.1 Overview...........................................................................................................................................11
2.2 About the Connectors ....................................................................................................................12
2.3 Grounding / ESD Protection .........................................................................................................13
2.4 Shielding and Conditioning........................................................................................................... 14
3Mechanical Integration..........................................................................................................................15
3.1 Overview...........................................................................................................................................15
3.2 Dimensions .....................................................................................................................................16
3.3 Orientation....................................................................................................................................... 16
3.4 Mounting.......................................................................................................................................... 17
4Operation .................................................................................................................................................18
4.1 Card Reading / Transactions........................................................................................................18
4.2 About the General Status LED...................................................................................................... 18
5Maintenance............................................................................................................................................ 19
5.1 Mechanical Maintenance.............................................................................................................. 19
5.2 Updates to Firmware, Documentation, Security Guidance...................................................... 19
6Developing Host Software..................................................................................................................... 20
Appendix A Technical Specifications .......................................................................................................21

1 - Introduction
mDynamo with Outdoor Bezel| IP34 Rated EMV Chip Card Module | Installation and Operation Manual
Page 8 of 23 (D998200546-10)
1Introduction
1.1 Engineering Easier Solutions
mDynamo with Outdoor Bezel is an IP34 rated EMV chip card module that is designed for integration
into indoor and outdoor, unattended kiosks. The card insertion slot features a spring-loaded door to help
prevent dust and moisture from entering the reader.
1.2 Delivering Flexible Solutions
mDynamo with Outdoor Bezel contact only EMV chip card reader ideal for use in unattended kiosks,
vending, parking garages, car wash establishments, ATMs, and fuels pumps can benefit from this cost-
effective solution.
1.3 Key Features
mDynamo with Outdoor Bezel is an affordable and flexible card reading module. It is designed to read
contact chip cards that conform to ISO 7816 standards. mDynamo with Outdoor Bezel is easy to install
and configure, and has key features that include:
•USB interface allows for easy-to-use plug-n-play connectivity
•Available with custom bezel
1.4 Built for Easier Integration
mDynamo with Outdoor Bezel is supported with a variety of software developer kits (SDKs), mDynamo
with Outdoor Bezel is supported by the full suite of Magensa's Services: data decryption, card and device
authentication, gateway, device configuration and key injection. MagTek provides well-defined and
documented web services and several off-the-shelf applications for reader configuration on Windows and
Android platforms.
1.5 The Next Generation of Security
mDynamo with Outdoor Bezel is built on the MagneSafe® Security Architecture which uses 3DES
encryption and DUKPT key management to protect EMV chip data.
1.6 Magensa Web Services
•Gateway
•Data Protection
•Remote Services
1.7 About Terminology
In this document, mDynamo with Outdoor Bezel is referred to as the device. It is designed to be
connected to a host, which is a piece of general-purpose electronic equipment which can send commands
and data to, and receive data from, the device. Host types include PC computers/laptops, tablets, and
smartphones. Generally, the host must have software installed that communicates with the device and is
capable of processing transactions. During a transaction, the host and its software interact with the
operator, such as a cashier or bank teller, while the device interacts with the cardholder.
1.8 About Solution Planning
A smooth deployment of a solution that integrates mDynamo with Outdoor Bezel requires some up-front
planning and decision-making:
•Determine the overall functional requirements and desired user experience of the solution
mDynamo with Outdoor Bezel will be integrated into.

1 - Introduction
mDynamo with Outdoor Bezel| IP34 Rated EMV Chip Card Module | Installation and Operation Manual
Page 9 of 23 (D998200546-10)
•Determine what documentation and training will be required from solution design through testing
and field deployment.
•Determine what type of host mDynamo with Outdoor Bezel will connect to. When planning, include
any additional support or devices required by the host and its connection, such as physical locations,
mounting, and power connections.
•Determine which model of mDynamo with Outdoor Bezel the solution will include, and what
accessories you need. Table 1-1 provides a list of available devices, auxiliary devices, and
accessories.
•Determine what software will be installed on the host and how it will be configured. Software can
include operating system, transaction processing software, security software, and so on. Include any
additional support required by the software, such as network connections.
•Determine how mDynamo with Outdoor Bezel should be configured and specify that when you order
devices. MagTek or your reseller can advise. For deep detail about configuration options and how
they affect device behavior, see D998200151 mDynamo Programmer’s Manual (COMMANDS).
•Determine how the solution design will integrate mDynamo with Outdoor Bezel electrically (see
section 2 Electrical Integration for details).
•Determine how the solution design will integrate mDynamo with Outdoor Bezel mechanically (see
section 3 Mechanical Integration for details).
•Determine how the solution will be tested and, if appropriate, how it will be certified.
•Develop an installation procedure. Installing technicians will need solution-specific materials. In
addition, technicians may be supported by incorporating a Maintenance Mode into the host software
for configuration, updates, and diagnostic tests.
•Determine how the solution will be maintained. See section 5 Maintenance for guidance on
maintaining the mDynamo with Outdoor Bezel portion of the solution.
•Determine how the solution will be regularly inspected. Proper inspection will require solution-
specific training, instructions, and visual references for inspecting the entire solution for tampering,
unauthorized added components such as eavesdropping or skimming devices, and so on.
Table 1-1 - Available Accessories
Part Number
Description
21079852
MDYNAMO WITH OUTDOOR BEZEL FLAT BEZEL
96700004
CLEANING CARD, DOUBLE SIDED

1 - Introduction
mDynamo with Outdoor Bezel| IP34 Rated EMV Chip Card Module | Installation and Operation Manual
Page 10 of 23 (D998200546-10)
1.9 Handling
Proper handling of the device throughout delivery, assembly, shipping, installation, usage,
and maintenance is very important. Not following the guidelines in this document could
damage the device, render it inoperable, and/or violate the conditions of the warranty.
From device delivery through assembly, shipping, installation, usage, and maintenance, the device must
not be exposed to conditions outside the ratings in Appendix A Technical Specifications.
If the device is exposed to cold temperatures, adjust it to warmer temperatures gradually to avoid
condensation, which can interfere with the operation of the device or cause permanent damage.
Upon receiving the device, inspect it to make sure it originated from an authentic source and has not been
tampered with.
Do not drop or shake the device.
The device should be transported/stored inside an anti-static bag at all times.
Before removing the device from the package, remove any static charge from your body by touching an
earth-grounded metal surface.
Avoid touching the exposed pins on the connectors when handling the device.
For information about ongoing maintenance of the device, such as cleaning, see section 5 Maintenance.

2 - Electrical Integration
mDynamo with Outdoor Bezel| IP34 Rated EMV Chip Card Module | Installation and Operation Manual
Page 11 of 23 (D998200546-10)
2Electrical Integration
2.1 Overview
This section provides information and guidelines for designing the electrical aspects of a solution that
incorporates mDynamo with Outdoor Bezel. MagTek strongly recommends vetting and testing solution
designs before finalizing and deploying them, to make sure the design meets all requirements (e.g.,
functional, legal, security, certification, safety, and so on).
When designing a solution that incorporates mDynamo with Outdoor Bezel, consider the following:
•Review section 1.6 Magensa Web Services
•Gateway
•Data Protection
•Remote Services
•for an overall introduction to the device’s physical features and what they are called.
•Review section 3.4 Mounting for recommended mounting configuration.
•Review Appendix A Technical Specifications to make sure the device is suitable for the solution.
•Review safe handling practices in section 1.9 Handling to make sure the logistical aspects of the
solution design meet the device’s handling requirements.
•Develop solution-specific installation procedures and training materials before distribution to
installation technicians.
•Review section 5 Maintenance and develop a maintenance procedure and schedule. When installed
in the solution-specific enclosure, the device may require additional maintenance not covered in the
general guidelines provided here.

2 - Electrical Integration
mDynamo with Outdoor Bezel| IP34 Rated EMV Chip Card Module | Installation and Operation Manual
Page 12 of 23 (D998200546-10)
2.2 About the Connectors
mDynamo with Outdoor Bezel provides a permanently attached USB cable (see Figure 2-1 - Using the
Alternate Earth Grounding Standoff). A USB Device port must be connected directly to a host’s USB
port, or connected to the host via a powered USB hub, to provide power to the device and bidirectional
communication with the host. The device’s USB connector is a Micro-USB B receptacle designed to
mate with a standard Micro-USB B connector found on the peripheral end of commercially available
cables. MagTek does not support connecting multiple mDynamo with Outdoor Bezel devices
simultaneously to the same host. Depending on usage, the device expects to draw up to 500mA at 5V
from the USB port, and the solution design must ensure 500mA is available to the device at all times.
The mDynamo controller board in mDynamo with Outdoor Bezel draws a maximum of 300mA.

2 - Electrical Integration
mDynamo with Outdoor Bezel| IP34 Rated EMV Chip Card Module | Installation and Operation Manual
Page 13 of 23 (D998200546-10)
2.3 Grounding / ESD Protection
To guard against ground loops and to protect the device against electrostatic discharge (ESD), it is
important for the solution design to ground the device correctly. MagTek strongly recommends checking
whether the host’s USB port provides earth ground, and whether the selected USB cable carries that
ground all the way to the shield of USB port on the device’s board. This will help make an informed
decision about proper grounding. There are two paths to provide earth ground to the device; MagTek
recommends all solution designs bring in earth ground to the device using one and only one of the
possible paths:
•Bring in earth ground from the host through the USB cable’s metal connector shell to the USB Device
Port, See Figure 2-1 for details.
•Bring in earth ground through the Alternate Earth Grounding Standoff. See Figure 2-1 for details.
Figure 2-1 - Using the Alternate Earth Grounding Standoff
After deciding which point will be grounded, make sure none of the remaining ground points are
connected to a different ground.
In addition, solutions that incorporate devices with a metal bezel must ground the bezel to the same earth
ground potential as the point chosen above. This provides an additional path to protect the device from
electrostatic discharge during card insertion and provides additional protection for the device’s
electronics. MagTek recommends this earth grounding cable comprise 18AWG stranded wires.

2 - Electrical Integration
mDynamo with Outdoor Bezel| IP34 Rated EMV Chip Card Module | Installation and Operation Manual
Page 14 of 23 (D998200546-10)
2.4 Shielding and Conditioning
MagTek recommends using shielded cables to provide noise immunity and to prevent radiated emissions.
The device itself has been tested by an FCC lab for Class B radiated susceptibility and has no special
shielding requirements. For details, see the FCC information provided at the beginning of this document.
MagTek also recommends that all communication cabling (i.e., USB) should be draped together where
possible, and isolated from any unrelated earth ground cables and other wiring nearby that could
potentially couple noise into the device.
The device has no special requirements for power conditioning or signal conditioning.

3 - Mechanical Integration
mDynamo with Outdoor Bezel| IP34 Rated EMV Chip Card Module | Installation and Operation Manual
Page 15 of 23 (D998200546-10)
3Mechanical Integration
3.1 Overview
This section provides information and guidelines for designing the mechanical aspects of a solution that
incorporates mDynamo with Outdoor Bezel. MagTek strongly recommends vetting and testing solution
designs before finalizing and deploying them, to make sure the design meets all requirements (e.g.,
functional, legal, security, certification, safety, and so on).
When designing the mechanical portions of a solution that incorporates mDynamo with Outdoor Bezel,
consider the following:
•Review section 1.6 Magensa Web Services
•Gateway
•Data Protection
•Remote Services
•for an overall introduction to the device’s physical features and what they are called.
•Review Appendix A Technical Specifications to make sure the device is suitable for the solution.
•See section 3.2 Dimensions for overall device dimensions.
•Determine device orientation. Options and constraints are provided in section 3.3 Orientation.
•Determine how the device will be mounted. See section 3.4 Mounting for details. Coordinate with
the electrical design team to make sure the panel design, mounting hardware, and solution-specific
installation instructions meet electrical requirements.
•Review safe handling practices in section 1.9 Handling to make sure the logistical aspects of the
solution design meet the device’s handling requirements.
•Develop solution-specific installation procedures and training materials before distribution to
installation technicians.
•Review section 5 Maintenance and develop a maintenance procedure and schedule. When installed
in the solution-specific enclosure, the device may require additional maintenance not covered in the
general guidelines provided here.

3 - Mechanical Integration
mDynamo with Outdoor Bezel| IP34 Rated EMV Chip Card Module | Installation and Operation Manual
Page 16 of 23 (D998200546-10)
3.2 Dimensions
Overall dimensions of the device are shown in Figure 3-1 - mDynamo with Outdoor Bezel Mechanical
Dimensions in Inches [mm] - Front View. On request, MagTek can provide a 3D model of the device’s
envelope to assist with the mechanical portion of solution design. MagTek strongly recommends building
and testing prototypes with actual devices before finalizing the solution design.
Figure 3-1 - mDynamo with Outdoor Bezel Mechanical Dimensions in Inches [mm] - Front View
3.3 Orientation
The device can be oriented horizontally only (see Figure 3-2).
Figure 3-2 - mDynamo with Outdoor Bezel Mounting Orientations

3 - Mechanical Integration
mDynamo with Outdoor Bezel| IP34 Rated EMV Chip Card Module | Installation and Operation Manual
Page 17 of 23 (D998200546-10)
The device should be installed such that cardholders have a full, unobstructed view of the housing around
the card insertion slot opening (“entry zone”) prior to insertion. This is to allow cardholders to easily
detect suspicious objects in or around the card slot entry, such as bugs / skimmers / tapping mechanisms,
and their wires or antennas. Installation height and pitch are factors in meeting this requirement.
3.4 Mounting
mDynamo with Outdoor Bezel is an IP34 rated device. Mounting is dependent on customer design;
however, it is recommended that the built-in external drain be facing down to ensure proper drainage
should moisture enter the interior of the device.
Figure 3-3 - Recommended Drain Position

4 - Operation
mDynamo with Outdoor Bezel| IP34 Rated EMV Chip Card Module | Installation and Operation Manual
Page 18 of 23 (D998200546-10)
4Operation
4.1 Card Reading / Transactions
Transactions begin when the host software initiates them. Cardholders should insert cards according to
the card orientation guide on the bezel (see Figure 3-2 - mDynamo with Outdoor Bezel Mounting
Orientations).
If a cardholder inserts a contact chip card, the device detects the chip and attempts to communicate with
the card. The host software may choose to use the notifications from the device as events to trigger
additional guidance (such as audible, visual, or tactile feedback) to the cardholder. For example, for chip
cards, the host software may direct cardholders to leave the card inserted until the transaction is complete,
then to remove the card.
Before and during transactions, an operator may control or monitor the device using the host software
and/or the General Status LED, which is a red/green LED that can be host-controlled.
Programmers of host software should see section 6 Developing Host Software for cross-references to
programming tools and documentation for communicating with the device.
4.2 About the General Status LED
The device’s General Status LED can be used to provide feedback to operators and cardholders about the
internal state of the device. Custom software on the host the device is connected to may completely
customize / override the External LED behavior.
Table 4-1 shows how to interpret the colors and flashing patterns of the General Status LED if the host is
not overriding the LED behavior.
Table 4-1 –General Status LED Meaning
Color
Flashing Pattern
Meaning
Off
Off
The device is not receiving adequate power from
the host via the USB port.
Green
Steady On
The device is ready to read a card.
Red
Steady On
An operator is updating the firmware. On
completion, the device will reset and the LED will
turn off briefly.

5 - Maintenance
mDynamo with Outdoor Bezel| IP34 Rated EMV Chip Card Module | Installation and Operation Manual
Page 19 of 23 (D998200546-10)
5Maintenance
5.1 Mechanical Maintenance
To avoid damaging the read head, only clean the card path with approved cleaning cards.
DO NOT use liquid cleaning products or insert any other objects into the device.
Periodic cleaning of mDynamo with Outdoor Bezel’s exterior may be required. To clean the outside of
the device, wipe down the device with a soft, damp cloth and then wipe with a dry cloth.
Solution training should direct assemblers, operators, and maintenance personnel to use a clean, dry cloth
to clean the device. Do not use chemicals or solvents.
5.2 Updates to Firmware, Documentation, Security Guidance
In addition to the security guidance in the product manuals, MagTek may provide updates to this
document, as well as supplemental security guidance or notices regarding vulnerabilities, at
www.magtek.com. MagTek advises checking the product’s home page periodically for the most up-to-
date information.
MagTek may also contact customers when it is necessary to update firmware to address critical product
bugs or security vulnerabilities. For details about obtaining and updating the device’s firmware, contact
MagTek Support Services or your reseller.

6 - Developing Host Software
mDynamo with Outdoor Bezel| IP34 Rated EMV Chip Card Module | Installation and Operation Manual
Page 20 of 23 (D998200546-10)
6Developing Host Software
This section provides high-level information about communicating with the device in various software
development frameworks, and provide pointers to available SDKs, which include sample code. All
product documentation and SDKs are available for download by searching for the product name on
www.magtek.com and navigating to the Support tab.
When developing host software, it is important to note that mDynamo with Outdoor Bezel is a
combination of two devices integrated into a common enclosure:
•mDynamo with Outdoor Bezel’s primary control unit and chip card reader is MagTek’s mDynamo.
When the host communicates with the device through the USB port, it is communicating directly with
mDynamo.
MagTek produces software development kits (SDKs) with API libraries that provide higher-level
functions wrapped around USB HID communication protocols. These libraries simplify the development
of custom host software that interfaces with mDynamo with Outdoor Bezel. See:
•99510109 SOFTWARE, SDK, ADYNAMO, BULLET, DYNAMAG, DYNAMAX, DYNAWAVE,
EDYNAMO, IDYNAMO 6, MDYNAMO, TDYNAMO, UDYNAMO (ANDROID)
•99510132 SOFTWARE, SDK, ADYNAMO, DYNAMAG, DYNAMAX, DYNAWAVE,
EDYNAMO, IDYNAMO 6, MDYNAMO, TDYNAMO, UDYNAMO (WINDOWS .NET)
•99510133 SOFTWARE, SDK, DYNAMAG, DYNAMAX, DYNAWAVE, EDYNAMO,
IDYNAMO 6, MDYNAMO, TDYNAMO (WINDOWS C++ / JAVA)
In addition to MagTek’s SDKs, custom software on any operating system can communicate directly with
the device using the operating system’s native USB libraries and protocols. For details, see D998200151
mDynamo Programmer’s Manual (COMMANDS).
For more information about developing custom applications that integrate with mDynamo with Outdoor
Bezel, see the MagTek web site or contact your reseller or MagTek Support Services.
