Magtek DynaProx User manual

DynaProx and DynaProx BCR
Quick Installation Guide
Secure Module
Quick Installation Guide
Setup and Installation
MagTek®Inc., 1710 Apollo Court, Seal Beach CA 90740 | p 562-546-6400 | support 651-415-6800 | f 562-546-6301 | www.magtek.com
Power
DynaProx products implement active tamper detection, which use a small
amount of electricity even when the device is completely powered off. When
un-powered, the device powers its active tamper detection circuitry. When
properly powered through its USB port or RS232 port, the device powers on
automatically. Device does not support USB suspend mode. To power off the
device, disconnect the device from USB power or RS232 Power. If all LEDs
are off, the device is Off.
Commands
DynaProx products are designed to be connected to a host, which is a piece
of general-purpose electronic equipment which can send commands and
data to, and receive data from, the device. Host types include PC and Mac
computers/laptops, tablets, and smartphones. Generally, the host must
have software installed that communicates with the device and is capable of
processing transactions.
How to connect to Host
Steps for connecting DynaProx products to a host via the available physical
connection types.
Connect Using USB-C
To connect DynaProx products to a USB host using the USB-C port, for best
results, use the cable that is included with the device.
• Connect the USB-C end of the cable to DynaProx.
• Connect the other end of the USB cable to the host’s USB port.
• Power through USB automatically powers on the device.
Connect Using RS-232
The RS232 interface on DynaProx products provides a UART interface
at RS232 signal levels. No ow control is provided. The RS232 cable is
customer dependent. A sample cable can be provided that has the mating
connector for DynaProx and color-coded wires. See MagTek part number:
1000008345. The chassis ground connection is a custom cable depending
on the customer’s requirement.
Mounting Device
DynaProx products are designed to provide exible mounting options:
• The device can be mounted to custom mounting brackets or mounted
in an enclosure as part of a larger solution design.
• The device can be mounted to the optional stand for countertop use.
Build and test prototypes with actual devices before nalizing the solution
design. The screw hole placement on the bottom of DynaProx products are
designed to accommodate screw size M4 x 0.7mm and a maximum screw
depth of 0.315 inches (8mm) into the device. The recommended torque
range for installing the screws is 20 to 22 in-lbs. (2.3 to 2.5 N-m). Make sure
gasket is seated properly to ensure IP65 rating. Panel cutouts for the USB
and RS232 connectors are needed. Make sure there is adequate clearance
for cardholders to tap or users to present a barcode.
DynaProx Products Overview
DynaProx and Dynaprox BCR [DynaProx products] deliver the next
generation in contactless EMV and near eld communication (NFC)
technology for original equipment manufacturers (OEM), merchants, banks,
and other developers looking to build a secure payment solution.
The Purpose of this document
The purpose of this document is to provide a brief overview for the
installation and operation of DynaProx products.
Environmental Conditions
DynaProx Temperature Operating and Storage
-30°C to +85°C(-22°F to 185°F)
DynaProx BCR Temperature Operating
-20°C to +55°C(-4°F to 131°F)
Storage
-30°C to +70°C(-22°F to 158°F)
Storage and Operating Humidity 5% to 90% non-condensing
Ratings IP 65
Major Components
Barcode reader lens and barcode reader indicator LED apply only to
DynaProx BCR models.

Please note that the use of this accessory with an Apple product may affect wireless performance. Apple®, Apple Pay®, OS X®, iPhone®, iPad®, iPad Air®, iPad Pro®, Lightning®, and Mac® are trademarks of Apple Inc., registered in the U.S. and other countries.
EMV® is a registered trademark in the U.S. and other countries and an unregistered trademark elsewhere. The EMV trademark is owned by EMVCo, LLC. The Contactless Indicator mark, consisting of four graduating arcs, is a trademark owned by and used with
permission of EMVCo, LLC.
MAGTEK: Registered to ISO 9001:2015 © Copyright 2022 MagTek, Inc. PN D998200500 rev 10 6/22
MagTek®Inc., 1710 Apollo Court, Seal Beach CA 90740 | p 562-546-6400 | support 651-415-6800 | f 562-546-6301 | www.magtek.com
Use and Compliance
Compliance
FCC INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Changes or modications not expressly approved by MagTek could void the user’s authority to operate this equipment.
CANADIAN DECLARATION OF CONFORMITY
This digital apparatus does not exceed the Class B limits for radio noise from digital apparatus set out in the Radio Interference Regulations of the
Canadian Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la classe B
prescrites dans le Réglement sur le brouillage radioélectrique édicté par le ministère des Communications du Canada.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conformé à la norme NMB-003 du Canada.
INNOVATION, SCIENCE AND ECONOMIC DEVELOPMENT CANADA (ISED)
This device complies with ISED Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not
cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux
deux conditions suivantes: (1) L’appareil ne doit pas produire de brouillage, et (2) L’utilisateur de l’appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
CE STANDARDS
Testing for compliance with CE requirements was performed by an independent laboratory. The unit under test was found compliant with standards
established for Class B devices.
EU STATEMENT
Hereby, MagTek Inc. declares that the radio equipment types Wideband Transmission System (802.11 wireless and Bluetooth Low Energy), and Non-
Specic Short Range Device (contactless) are in compliance with Directive 2014/53/EU. The full text of the EU declarations of conformity is available
at the following internet address:
https://www.magtek.com/Content/DocumentationFiles/D998200505.pdf
UKCA STANDARDS
Hereby, MagTek Inc. declares that the radio equipment types Wideband Transmission System (Wireless LAN and Bluetooth Low Energy), and Non-
Specic Short Range Device (contactless) are in compliance with Radio Equipment Regulations 2017 Directive S.I.2017:1206. The full text of the
UKCA declarations of conformity is available at the following Internet addresses:
• https://www.magtek.com/Content/DocumentationFiles/D998200506.pdf
AUSTRALIA / NEW ZEALAND STATEMENT
Testing for compliance with AS/NZS standards was performed by a registered and accredited laboratory. The unit under test was found compliant
with standards established under AS/NZS CISPR 32 (2013), AS/NZS 4268 Table 1, Row 59 DTS 2400-2483MHz SRD (802.11), and AS/NZS 4268
(2017) Table 1, Row 43 13.553-13.567MHz (contactless reader).
UL/CSA/IEC
This product is recognized per UL/CSA/IEC 62368-1, 2nd edition
ROHS STATEMENT
When ordered as RoHS compliant, this product meets the Electrical and Electronic Equipment (EEE) Reduction of Hazardous Substances (RoHS)
Directive (EU) 2015/863 amending Annex II to Directive 2011/65/EU. The marking is clearly recognizable, either as written words like “Pb-free,”
“lead-free,” or as another clear symbol ( ).
PCI STATEMENT
PCI Security Standards Council, LLC (“PCI SSC”) has approved this PTS POI device (SCR class) to be compliant with the PCI PTS POI Security
Requirements v5.1.
When granted, PCI SSC approval is provided by PCI SSC to ensure certain security and operational characteristics important to the achievement of
PCI SSC’s goals, but PCI SSC approval does not under any circumstances include any endorsement or warranty regarding the functionality, quality
or performance of any particular product or service. PCI SSC does not warrant any products or services provided by third parties. PCI SSC approval
does not under any circumstances include or imply any product warranties from PCI SSC, including, without limitation, any implied warranties of
merchantability, tness for purpose, or non-infringement, all of which are expressly disclaimed by PCI SSC. All rights and remedies regarding products
and services which have received PCI SSC approval shall be provided by the party providing such products or services, and not by PCI SSC.
Accepting Payments
The steps for starting a transaction and reading a contactless payment
device are different depending on the device’s conguration and on the
design of the host software.
NOTE: If the cardholder is using an electronic payment device, such as a
smartphone, make sure the payment device has NFC turned On and has a
payment app congured to process transactions. Because each smartphone
model may have its NFC antenna placed differently, the ideal tap position
may vary by make and model. For example, Samsung users may need to
center the phone on the contactless landing zone, while Apple users may
need to tap the top of the phone on the contactless landing zone.
How to Tap Contactless Cards / Devices
To tap a contactless card or smartphone, follow these steps:
• Check LED status is set to ready. Briey hold the card, smartphone, or
other contactless payment device over the contactless landing zone
• Wait for LED status to show it is processing.
• The device beeps once. The device ends the transaction and reports
the transaction status to the host.
How to Scan Barcodes (DynaProx BCR models ONLY)
Make sure you are using a DynaProx BCR that includes a barcode reader.
If the barcode being scanned is not on a self-illuminated source such as
a smartphone, make sure there is enough ambient light for the camera to
read the barcode. In low light conditions, the barcode reader will only be
able to read self-illuminated sources.
• Wait for the device, the host, or the operator to prompt for a barcode
read: The device lights the barcode reader indicator LED next to the
barcode reader lens.
• Hold the barcode in front of the barcode reader camera: use the light
from the barcode reader indicator LED to align the barcode within
the barcode reader’s eld of view, which extends 16 degrees above
/ below and 21 degrees to the left / right of a line perpendicular to
the barcode reader lens. Hold the barcode as close as 1 inch from
the lens. For smaller barcodes, the device will read immediately. If it
does not, gradually pull back to up to 14 inches from the lens until the
device reports a successful read. Larger barcodes must be far enough
away from the device that the whole barcode is within the camera’s
eld of view; if a large barcode is too close, the barcode reader can
only see a zoomed in portion of the barcode. Do not tilt the barcode
more than 60 degrees from parallel to the device’s face.
• Wait for the device or the host to report the barcode has been read
successfully: The device beeps once and turns off the barcode reader
indicator LED.
Auditory Feedback
The device sounds one short beep after it has successfully read a
contactless tap and the cardholder can safely remove the card or device
from the contactless landing zone. The device provides an internal setting
the host can use to adjust the global system volume.
LEDs
DynaProx products provide four mono LEDs, numbered LED1 through LED4,
which report the device’s current operating status. The meaning of each LED
depends on the device’s operating mode. A blinking LED generally means
the device is actively doing something to change the state that the LED is
indicating and solid indicates a persistent state that would require an operator
or cardholder to take action to change. See Installation and Operation Manual
(PN D998200490) for full details.
Pb
DynaProx and DynaProx BCR | Quick Installation Guide
