Mainstays AYDEN PARK MSS129900298006 User manual

Need Assistance?
ASSEMBLY AND CARE GUIDE
MAINSTAYS AYDEN PARK 5 PIECE
PATIO HIGH DINING SET
Contact our toll free Customer Service Hotline at:
[phone]
MSS129900298006
-Monday through Friday 7:30am until 3:30pm PST-

Warranty
2 YEAR LIMITED WARRANTY
WHAT IS COVERED
We warrant the frame to be free of manufacturing defects to the original purchaser for two years.
WHAT IS NOT COVERED
This warranty does not cover commercial use, hardware, acts of nature, fire, freezing, and abusive use. In
addition, purchased parts are not covered under this warranty. We reserve the right to make substitutions
with similar merchandise, if the model in question is no longer in production.
Important Safety Instructions
PLANNING ASSEMBLY
Read all instructions before assembly
To avoid damanging this product, assembly it on a soft non-abrasive surface such as carpet or carboard.
NOTE: More than one person may be required to assemble this product.
Attention
○Use the correct bolts as indicated. Do not tighten any of the bolts until the product is completely assembled
○Do not discard of any of the packaging until you have checked that you have all of the parts and fittings
required
○Keep children away during assembly. This item contains small parts that can be swallowed by children.
Children should always be under direct adult supervision while using this product.
○Retain these assembly instruction for future reference.
1
MSS129900298006

A. Read instructions thoroughly. Acquaint yourself with the inventory of parts and the accompanying
drawings to ensure safe and proper assembly.
No. Qty Picture
D
E
F
G
B. Lay out all of the parts on a flat surface and identify them using the table below.
2
Single chair*4
No. Qty Picture
B
C
A1
4
1*4
1*4
2*4
2*4
12*4
1
DD
AA
CC
Top Frame
Top Frame
Leg
Cap
Support Frame
Left Leg
Right Leg
BB 8
Table
Bolt
M6X15
Bolt
M8X30
Ratchet Tool
MSS129900298006
Wrench

Assembly
Step 1: Attach left and right legs(F&G) to the tabletop using bolts(AA) and ratchet tool(DD).
Step 2: Attach support frame (E) to the legs(F&G) using bolts(AA) and ratchet tool(DD).
Note: Do not tighten bolts until all parts are connected
Single chair
3
Step 1:
Step 2:
Note: Do not tighten bolts until all parts are connected.
Step 1.
Step 1.
Step 2.
Step 2.
Table
Attach four legs(B) to the table top(A) by using bolts(BB) and wrench(CC).
Put the cap(C) on the umbrella hole.
MSS129900298006
B
B
B
B
BB
BB
A
A
BB
BB
C
Note:the leg(F) must in opposite position an same for leg(G).
D
G
F
G
F
AA AA DF
G
F
G
E
AA

4
Maintenance
We recommend the use of furniture covers when not in use.
In order to prolong the life and beauty of your furniture , we recommend that it be stored in a dry and
protected area during off season periods.
.
○
○
○
Inspect and tighten all bolts and fasteners on a regular basis to ensure the proper performance and
safety of your product.
MSS129900298006
