Mainstays Sand Dune MSD128059664021 User manual

Warranty Coverage Requirements:
1. Copy of your Original Store Receipt.
2. Pictures of the damaged parts.
3. You must know the name of your product and any corresponding item
numbers as well as the name of the store where you purchased the item.
4. Please gather all of this informa on BEFORE you call customer service.
DO NOT RETURN TO RETAILER
IF YOU HAVE ANY QUESTIONS OR CONCERNS
PLEASE VISIT OUR WEBSITE
AT:
www.yotrioint.com
www.yotrioint.com
www.yotrioint.com
www.yotrioint.com
OR TOLL FREE AT:
1-866-905-4107
1-866-905-4107
1-866-905-4107
1-866-905-4107
MONDAY-FRIDAY 8:30 AM TO 5:00 PM PACIFIC STANDARD TIME / 11:30
AM TO 8:00PM EASTERN STANDARD TIME
YOTRIO
YOTRIO
YOTRIO
YOTRIO CUSTOMER
CUSTOMER
CUSTOMER
CUSTOMER CARE
CARE
CARE
CARE
1

2
CARE AND MAINTENANCE
Before using, wipe the product completely with a so , dry cloth.
Spot-clean Cushions and slings using a sponge, mild soap and water. Rinse thoroughly with clean water. To
prevent mildew, allow to air dry completely before using or storing.
Never machine wash or tumble dry cushions, slings or umbrella covers as this will result in shrinkage or
damage.
Rinse wicker furniture with a hose or pressure washer. If the wicker is really dirty, you can use mild
soap with water. Allow to dry completely before using or storing.
To clean your umbrella, use a brush and mild soap and water. Allow to dry completely before
storing.
Avoid placing hot objects directly onto table top surface without a heat protector.
Always store and/or cover your pa o furniture in a cool dry place when not in used and away from direct
sunlight.
When storing, never wrap cushions in plas c. Plas doesn't allow the cushion to breathe and can cause it
to mildew if there's any moisture present.
Always place your o furniture away from fire, extreme heat, freezing condi ons and inclement weather
such as rain, hail, sleet, snow or wind.
Never use bleach or strong solvents to clean as this will cause damage to both fabric and metal finishes.
Do not allow water to build up in frames as this will cause corrosion and damage.
ONE-YEAR FRAME AND ONE-YEAR FABRIC/WICKER/FINISH ETC. LIMITED WARRANTY
You must retain the original receipt to obtain warranty service.
Frames are warranted against defects in materials and workmanship for a period of one year from the date
of original purchase.
This warranty does not cover damage to frames or welds due to commercial use, improper assembly, acts
of nature, fire, freezing and abusive use.
Rust, corrosion, and/ or rust stains are not covered by warranty.
Purchased parts are not covered under this warranty.
Fabric on cushions, slings and umbrella is warranted one year against separa on at the seams.
Fading, mildew, and color discolora n due to exposure to the elements, chemicals and spills are not
covered.
The Powder coat and/ or paint are warranted one year against blistering, peeling, or crackling.
Fading due to exposure to elements, chemicals and spills is not covered. Scratches and chips due to normal
wear and use are not covered.
Wicker Weave are warranted one year against breakage, separa on, or tearing.
Fading or discolora on due to exposure from chemicals, spills and/ or the elements is not covered.
Warranty covers free replacement of item within one year of purchase. A the one year it remains the
customer's responsibility for freight and packaging charges to and from our service center.
We do not compensate the individual or any outside party for assembling or disassembling the product.
Any replacement of warranted items will be in the original style and color, or similar style and color if the
original is un-available or has been discon nued.
Ques ons, problems, missing parts? Before returning to your retailer, call our customer service department
at [phone], 8:30 a.m. – 5:00 p.m. PST /11:30 a.m.- 8:00 p.m., EST, Monday- Friday.
Check all nuts and bolts for tightness each time before and during use.
Oil all metallic moving parts during usage season.

Questions, problems, missing parts? Before returning to your retailer, call our customer service department
at (866) 905 - 4107, 8:30 a.m. - 5:00 p.m. PST/11:30 a.m. - 8:00 p.m., EST, Monday - Friday.
Walmart Assembly Instruction
Vendor stock No.: MSD128059664021
MS Sand Dune 3-Person Outdoor Sling Canopy
Porch Swing With Canopy
Package Contents
3
NOTE: The M8 Bolt Cover (JJ), M6 Bolt Cover (II), in step 1 to 7 are only for
reference. Please attach them to bolts in step 7.
Install on level ground , Install not less than 6ft distance from any obstruction
(e.g.fence,garage,house,overhanging branches,laundry lines,electrical wires).
This swing unit is heavy, and may require two adults for safe assembly.

Questions, problems, missing parts? Before returning to your retailer, call our customer service department
at (866) 905 - 4107, 8:30 a.m. - 5:00 p.m. PST/11:30 a.m. - 8:00 p.m., EST, Monday - Friday.
4
PART
NO.
PICTURE DESCRIPTION QTY
A 1
B 2
C 2
D 1
E
1
F
G
2
I
1
J
3
K
2
L
2
M
2
H
2
PART
NO. PICTURE DESCRIPTION QTY
AA M8x85
Bolt & Washer 4+1
BB 8+1
CC 4+1
DD 2+1
EE
FF
GG
HH
II
2+1
JJ
KK
LL Hook
Open Hex
Wrench 1
1
Allen Wrench
Arm
Hanging Bar
Top Bar
Rear Leg
Leg connector
Seat&back
M8x50
Bolt & Washer
M6x65
Bolt & Washer
M6x40
Bolt & Washer
4
Short Leg
Connector
Canopy
Support 1
Plastic Clip
Knob
N
Foot Cap
4
Front Leg
Canopy
Support 2
Canopy
8+1
6+1
8+1
6+1
M8Washer
M6Washer
M8 Nut
M6 Nut
Plastic
Washer
Walmart Assembly Instruction
MS Sand Dune 3-Person Outdoor Sling Canopy
Porch Swing With Canopy
OO Ratchet
Wrench 1
MM
NN
1
M6
Bolt Cover 6+1
M8
Bolt Cover
8+1
Vendor stock No.: MSD128059664021
NOTE: The M8 Bolt Cover (JJ), M6 Bolt Cover (II), in step 1 to 7 are only for
reference. Please attach them to bolts in step 7.
Install on level ground , Install not less than 6ft distance from any obstruction
(e.g.fence,garage,house,overhanging branches,laundry lines,electrical wires).
This swing unit is heavy, and may require two adults for safe assembly.

Questions, problems, missing parts? Before returning to your retailer, call our customer service department
at (866) 905 - 4107, 8:30 a.m. - 5:00 p.m. PST/11:30 a.m. - 8:00 p.m., EST, Monday - Friday.
5
Step 2
- Connect the Front Leg (B) and Rear Leg (C) with
the Short Leg Connector (H) with M8 x 50 Bolt &
Washer (BB), M8 Washer (FF) and M8 Nut (HH).
- Loosely tighten by hand.
- Repeat the same procedure for both sides.
Step 1
- Insert the Foot Cap (N) into the leg (B&C).
- Insert the Front Leg (B) and Rear Leg (C) to the
Top Bar (A) with M8x85 Bolt & Washer (AA),
M8 Washer (FF) and M8 Nut (HH).
- Loosely tighten by hand.
Step 3
- Attach the Leg Connector (D) to the Rear Leg (C)
with M6 x 65 Bolt & Washer (CC), M6 Washer (GG),
and M6 Nut (II).
- Repeat the same procedure for both sides.
- Completely tighten all bolts with Open Hex Wrench (NN)
and Allen Wrench (MM) or Ratchet Wrench (OO).
STEP 1
STEP 2
STEP 3
Walmart Assembly Instruction
MS Sand Dune 3-Person Outdoor Sling Canopy
Porch Swing With Canopy
Vendor stock No.: MSD128059664021
NOTE: The M8 Bolt Cover (JJ), M6 Bolt Cover (II), in step 1 to 7 are only for
reference. Please attach them to bolts in step 7.
Install on level ground , Install not less than 6ft distance from any obstruction
(e.g.fence,garage,house,overhanging branches,laundry lines,electrical wires).
This swing unit is heavy, and may require two adults for safe assembly.

Questions, problems, missing parts? Before returning to your retailer, call our customer service department
at (866) 905 - 4107, 8:30 a.m. - 5:00 p.m. PST/11:30 a.m. - 8:00 p.m., EST, Monday - Friday.
STEP 4
6
STEP 5
Step 5
- Hang the Hook (LL) in the holes on the Top Bar (A).
- Completely tighten all bolts with Open Hex Wrench (NN) and Allen Wrench (MM) or Ratchet Wrench (OO).
Walmart Assembly Instruction
MS Sand Dune 3-Person Outdoor Sling Canopy
Porch Swing With Canopy
Step 4
- Attach the Hanging Bar (G) to the Arm (F) , Seat & Back (E), with M8 x 50 Bolt & Washer (BB).
- Attach the Hanging Bar (G) to the Arm (F) with M8 x 40 Bolt & Washer (DD), Plastic Washer (EE),
M6 Washer (GG) and M6 Nut (II) as shown in the picture.
- Bring the holes in the free ends of Hang Bars (G) together and thread them onto Hook (LL).
- Loosely tighten by hand.
- Repeat the same procedure for both sides.
Vendor stock No.: MSD128059664021
NOTE: The M8 Bolt Cover (JJ), M6 Bolt Cover (II), in step 1 to 7 are only for
reference. Please attach them to bolts in step 7.
Install on level ground , Install not less than 6ft distance from any obstruction
(e.g.fence,garage,house,overhanging branches,laundry lines,electrical wires).
This swing unit is heavy, and may require two adults for safe assembly.

Questions, problems, missing parts? Before returning to your retailer, call our customer service department
at (866) 905 - 4107, 8:30 a.m. - 5:00 p.m. PST/11:30 a.m. - 8:00 p.m., EST, Monday - Friday.
7
STEP 6
Step 6
- Install the Canopy Support 2 (K) through the Canopy (I) .
- Install the Canopy Support 2 (K) to the Canopy Support 1 (J) .
- Clamp the Plastic Card (L) on the Canopy Support 1 (J).
- Repeat the same procedure for both sides.
STEP 7
Step 7
- Attach the assembled Canopy ( I , J , K , L ) to the Top Bar (A) with Knob (M).
- Repeat the same procedure for both sides.
- Completely tighten all bolts with Open Hex Wrench (NN) and Allen Wrench (MM) or Ratchet Wrench (OO).
- Make sure all connections are secure, befor use it.
Walmart Assembly Instruction
MS Sand Dune 3-Person Outdoor Sling Canopy
Porch Swing With Canopy
Vendor stock No.: MSD128059664021
NOTE: The M8 Bolt Cover (JJ), M6 Bolt Cover (II), in step 1 to 7 are only for
reference. Please attach them to bolts in step 7.
Install on level ground , Install not less than 6ft distance from any obstruction
(e.g.fence,garage,house,overhanging branches,laundry lines,electrical wires).
This swing unit is heavy, and may require two adults for safe assembly.
