Makita BJV180Z User manual

18V LXT LITHIUM-ION
CORDLESS JIG SAWS
CUSTOM CUTTING GOES CORDLESS
VERSATILITY
VERSATILITY
4-Position cut settings (3-Orbital and
1-Straight) provides fast and efficient
cutting in all applications
ACCURACY
ACCURACY
Blade roller guide is positioned close to
the workpiece to guarantee accurate
straight and bevel cuts
INNOVATION
INNOVATION
3.0Ah Li-ion battery allows for the
lightest cordless jig saw in its class
COMFORT
COMFORT
Large variable speed trigger and
ergonomically designed handle
enables greater comfort and control
Models
BJV180
BJV180Z
makitatools.com
MAKITA JIGSAW EXCELLENCE DELIVERS CUSTOM CUTTING WITHOUT A CORD
Built-in, Shockproof, High Output, L.E.D. Light Illuminates your Line-of-Cut
“Tool-less” Push-in Lock Blade Change System for more Productivity
Low Vibration and Noise Level for More Control and Comfort
Variable Speed Control Allows for Maximum Cutting Control
4-Position Cut Settings (3-Orbital and 1-Straight) for Fast and Efficient Cutting
in all Applications
MAKITA JIGSAW EXCELLENCE DELIVERS CUSTOM CUTTING WITHOUT A CORD
Built-in, Shockproof, High Output, L.E.D. Light Illuminates your Line-of-Cut
“Tool-less” Push-in Lock Blade Change System for more Productivity
Low Vibration and Noise Level for More Control and Comfort
Variable Speed Control Allows for Maximum Cutting Control
4-Position Cut Settings (3-Orbital and 1-Straight) for Fast and Efficient Cutting
in all Applications
Models
BJV180
BJV180Z

Length of Stroke 1''
Max. Cutting Capacities:
Wood 5-5/16''
Steel 3/8''
Cut Settings 3 Orbital + Straight Cutting
Bevel Capacity 45o
Strokes Per Minute 0 - 2600 SPM
Lithium-Ion Battery 18VDC (3.0Ah)
Overall Length 10-1/8''
Net Weight 6.1 lbs.
UPC (BJV180) 088381-078665
(BJV180Z) 088381-078672
■1 ea. Blade Set (B-10, B-13, B-22) ■Anti-splintering Device (192557-6)
■Cover Plate (417852-6) ■Plastic Case (158310-0)
■2 ea. LXT Lithium-Ion 3.0Ah ■25-minute Rapid Optimum Charger
Battery (BL1830) (DC18RA)
■Built-in, shockproof, high output, LED light illuminates the line-of-cut
■“Tool-less” push-in lock blade change system for more productivity
■Low vibration and noise level for more control and comfort
■Large variable speed trigger allows for total cutting control (0-2,600 SPM)
■4-Position cut settings (3 Orbital and 1 Straight) for fast and efficient cutting in
all applications
■LXT Lithium-Ion provides longer run time, 5x lower self-discharge (for use any time)
and 16 firm holding contact terminals (for constant high power)
■25-minute Rapid Optimum Charger communicates with the battery throughout the
charging process using the built-in chip in the battery and built-in CPU chip in the
charger - charger actively controls current, voltage, and temperature to optimize
battery life.
■Accepts“T” (Tang) shank blades
All specifications subject to change without prior notice. All models and accessories subject to stock on hand.
NTF-0407-3M MA-0346-07 For more information, call 1-800-4MAKITA or visit makitatools.com Makita U.S.A.,14930 Northam St., La Mirada,CA 90638
Models BJV180/BJV180Z
18V LXT LITHIUM-ION CORDLESS JIG SAWS
Makita offers a wide variety of accessories for Jig Saws. For a complete listing, please
refer to the Makita General Catalog, or visit our website at makitatools.com, or call 1-800-4MAKITA.
Model BJV180
FEATURES & BENEFITS
FEATURES & BENEFITS
STANDARD EQUIPMENT
STANDARD EQUIPMENT
SPECIFICATIONS
SPECIFICATIONS
■Guide Rail Adapter (417894-0) ■Guide Rail Set (193517-1)
■Dust Nozzle (417853-4) ■Hose (A-34229)
■Jig Saw Blades
OPTIONAL ACCESSORIES
OPTIONAL ACCESSORIES
"T" (Tang) Shank
Overall
Length
Cutting
Length TPI Application 5/Pkg. Part #
1-3/4" Scroll cutting of wood and plastics 792470-4
14
3"
Overall
Length
Cutting
Length TPI Application 5/Pkg. Part #
2" Decorative veneers 792474-6
14
3''
2" Thin materials 792466-5
18
3''
3-1/8'' Thin materials 792467-3
18
3''
2'' Mild steel,Stainless steel & tough plastics 792473-8
24
3''
2'' Scroll cutting & mild steel 792478-8
24
3''
2'' Thin mild & stainless steel 792475-4
32
3''
2-1/2'' Decorative veneers with splinter-free
down cutting teeth 792471-2
12
3-1/2''
Thin mild & stainless steel 792475-4
3-1/2'' 2-1/2'' 24
2-3/4'' Scroll cutting in wood & plastics
(fast cutting) 792469-9
6
3-7/8''
Scroll cutting in hardwood & plastics 792477-0
3-7/8'' 2-3/4'' 9
Fast finish work in wood and plastics 792463-1
3-7/8'' 3'' 9
3'' Hardwood, thick mild steel plate and
tough plastics 792476-2
9
3-7/8''
Finish work,plastics & aluminum 792472-0
3-7/8'' 3'' 12
Fast cutting of wood & plastics 792468-1
4-1/8'' 2-3/4'' 6
Fast finish work in wood and plastics 792472-0
4-1/8'' 2-3/4'' 6
General cutting of wood and plastics 792465-7
4-1/8'' 3-1/8'' 8
Fast cutting of wood & plastics 792429-1
4-1/8'' 3-1/8'' 8
Fast finish work in wood and plastics 792430-6
4-1/8'' 3-1/8'' 8
Splinter-free cuts in wood with no sanding 792729-9
4-1/8'' 2-1/2'' 9
Fast finish work,especially in plywood 792529-7
4-1/8'' 3-1/8'' 9
"T" (Tang) Shank
Model BJV180Z
