Parts Breakdown GD0800C
Page 1 of 3 2/8/2008

Parts Breakdown GD0800C
Fig # Part ID Part Name Quantity
1 763645-2 COLLET NUT, GD0800C 1
2 192986-3 COLLET CONE 1/4, GD0800C 1
3 324042-3 SPINDLE, GD0800C 1
4 213209-7 OIL SEAL 16, GD0810C 1
5 285700-5 BEARING RETAINER, GD0800C 1
6 211141-9 BALL BEARING 6901LLB, GD0800C 1
7 961052-5 RETAINING RING S-12, 9218PBL 1
8 317368-0 BARREL, GD0800C 1
9 961052-5 RETAINING RING S-12, 9218PBL 1
10 211142-7 BALL BEARING 6001LLB, 9565CV 1
10 211148-5 BALL BEARING 6001ZZ,GD0800C 1
11 962106-1 RETAINING RING R-28,GD0800C 1
12 233901-9 LOCK SPRING 12, GD0800C 1
13 323989-8 COUPLING, GD0800C 1
14 265082-1 P.H.SCREW M4X8, GD0800C 1
17 962106-1 RETAINING RING R-28,GD0800C 1
18 961052-5 RETAINING RING S-12, 9218PBL 1
19 211148-5 BALL BEARING 6001ZZ,GD0800C 1
19 211142-7 BALL BEARING 6001LLB, 9565CV 1
20 253084-9 F. WASHER 12, 5014NB 1
21 317367-2 HOUSING W/O BEARING, GD0800C 1
22 240036-9 FAN 57, GD0800C 1
23 515191-9 ARMATURE ASS'Y 115V, GD0800C 1
23 515216-9 ARMATURE ASSEMBLY, GD0800C 1
24 681656-4 INSULATION WASHER, GD0800C 1
25 253823-7 F. WASHER 7, LS1011 1
26 210023-2 BALL BEARING 627DDW, 9910 1
28 421770-2 LABYRINTH RUBBER RING 22, GD0800C 1
29 688117-5 MAGNET SLEEVE, GD0800C 1
30 961011-9 STOP RING E-4, 4301BV 1
30 259039-2 SELF LOCK 6, 3707FC 1
31 413076-2 BAFFLE PLATE, GD0800C 1
32 266259-1 TAPPING SCREW 4X60, GD0800C 2
33 344871-8 RETAINER, GD0800C 2
34 417237-6 INSULATION COVER, GD0800C 2
35 626521-0 FIELD 115V, GD0800C 1
38 852410-5 NAME PLATE, GD0800C 1
39 266256-7 TAPPING SCREW PT3X10, GD0800C 4
40 643760-7 BRUSH HOLDER, BO6040 1
40 643762-3 BRUSH HOLDER, GD0800C 1
41 191974-7 CARBON BRUSH 1
41 191978-9 CARBON BRUSH SET CB-318,GD0800C 1
42 265995-6 TAPPING SCREW 4X18, 4323K 2
43 687063-9 STRAIN RELIEF, 4323K 1
44 632999-7 SWITCH BLOCK, GD0800C 1
45 664064-4 CORD (2X18X8 SJ), HR2400 1
46 682559-5 CORD GUARD 8, 6824 1
47 651418-4 SWITCH, JN1601 1
48 687113-0 COVER, GD0800C 1
49 816801-4 INDICATION LABEL, GD0800C 1
50 158189-9 REAR COVER, GD0800C 1
50 417185-9 REAR COVER, BO6040 1
51 265995-6 TAPPING SCREW 4X18, 4323K 1
52 631390-6 CONTROLLER, GD0800C 1
53 417187-5 SWITCH LEVER, GD0800C 1
54 233071-4 COMPRESSION SPRING 4, JN1601 1
55 643760-7 BRUSH HOLDER, BO6040 1
55 643762-3 BRUSH HOLDER, GD0800C 1
56 417812-8 MOTOR HOUSING, BO6040 1
56 152865-7 N/A 1
Page 2 of 3 2/8/2008

Parts Breakdown GD0800C
56 153296-3 MOTOR HOUSING, GD0800C 1
56 153559-7 MOTOR HOUSING, GD0800C 1
56 153564-4 MOTOR HOUSING CPL,GD0800C 1
57 819720-3 MAKITA LABEL, 3707fc 1
58 417813-6 SWITCH KNOB, BO6040 1
58 417188-3 SWITCH KNOB, 9560CV 1
59 265999-8 TAPPING SCREW M4X25, HM1800 4
60 800092-7 INDICATION LABEL 1
1,001 781203-2 SPANNER 13, 5007NB 1
1,002 781206-6 WRENCH 19, 3803A 1
1,003 192985-5 SIDE HANDLE SET, GD0800C 1
5,001 810243-4 N/A 1
