ENGLISH (Original instructions)
SPECIFICATIONS
Model: DLM382 DLM432
Mowing width (blade diameter) 380 mm 430 mm
No load speed 3,700 min-1 3,600 min-1
Part number of replacement mower blade 191D41-2 191D43-8
Dimensions
(L x W x H)
during operation L: 1,380 mm to 1,410 mm
W: 450 mm
H: 985 mm to 1,005 mm
L: 1,435 mm to 1,490 mm
W: 460 mm
H: 1,005 mm to 1,045 mm
when stored
(without grass basket)
860 mm x 450 mm x 475 mm 865 mm x 460 mm x 475 mm
Rated voltage D.C. 36 V
Net weight 15.0 - 16.5 kg 15.4 - 17.1 kg
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsmaydi󰀨erfromcountrytocountry.
• Theweightmaydi󰀨erdependingontheattachment(s),includingthebatterycartridge.Thelightestandheavi-
estcombination,accordingtoEPTA-Procedure01/2014,areshowninthetable.
Applicable battery cartridge and charger
Batterycartridge BL1815N/BL1820/BL1820B/BL1830/BL1830B/BL1840/
BL1840B/BL1850/BL1850B/BL1860B
Charger DC18RC/DC18RD/DC18RE/DC18SD/DC18SE/DC18SF/
DC18SH
• Someofthebatterycartridgesandchargerslistedabovemaynotbeavailabledependingonyourregionof
residence.
WARNING: Only use the battery cartridges and chargers listed above.Useofanyotherbatterycartridges
andchargersmaycauseinjuryand/orre.
WARNING: Do not use a corded power supply such as battery adapter or portable power pack with
this machine.Thecableofsuchpowersupplymayhindertheoperationandresultinpersonalinjury.
Symbols
Thefollowingsshowthesymbolswhichmaybeused
fortheequipment.Besurethatyouunderstandtheir
meaning before use.
Takeparticularcareandattention.
Read instruction manual.
Danger;beawareofthrownobjects.
Thedistancebetweenthetooland
bystandersmustbeatleast15m.
Neverputyourhandsandfeetnearthe
blade under the mower. Blades continue to
rotateafterthemotorisswitchedo󰀨.
Removethelockkeybeforeinspecting,
adjusting,cleaning,servicing,leavingand
storing the mower.
Ni-MH
Li-ion
OnlyforEUcountries
Do not dispose of electric equipment or
batterypacktogetherwithhouseholdwaste
material!
In observance of the European Directives,
on Waste Electric and Electronic
EquipmentandBatteriesandAccumulators
andWasteBatteriesandAccumulators
and their implementation in accordance
with national laws, electric equipment and
batteriesandbatterypack(s)thathave
reached the end of their life must be col-
lectedseparatelyandreturnedtoanenvi-
ronmentallycompatiblerecyclingfacility.
Intended use
Themachineisintendedforlawnmowing.

8ENGLISH
SAFETY WARNINGS
IMPORTANT SAFETY
INSTRUCTIONS
WARNING: Read all safety warnings and
all instructions. Failuretofollowthewarningsand
instructionsmayresultinelectricshock,reand/or
seriousinjury.
Save all warnings and instruc-
tions for future reference.
Training
1. Read the instructions carefully. Be familiar
with the controls and the proper use of the
mower.
2. Never allow children or people unfamiliar with
these instructions to use the mower. Local
regulations can restrict the age of the operator.
3. Never operate the mower while people, espe-
cially children, or pets are nearby.
4. Keep in mind that the operator or user is
responsible for accidents or hazards occurring
to other people or their property.
5. Children should be supervised to ensure that
they do not play with the mower.
6. Physical condition - Do not operate mower
while under the inuence of drugs, alcohol, or
any medication.
Preparation
1. While operating the mower, always wear sub-
stantial footwear and long trousers. Do not
operate the mower when barefoot or wearing
open sandals. Avoid wearing clothing or jew-
elry that is loose tting or that has hanging
cords or ties. They can be caught in moving
parts.
2. Before use, always visually inspect the mower
for damaged, missing or misplaced guards or
shields.
3. Be sure the area is clear of other people before
mowing. Stop mower if anyone enters the area.
4. Do not insert the lock key into mower until it is
ready to be used.
5. Always wear protective goggles to protect
your eyes from injury when using power tools.
The goggles must comply with ANSI Z87.1 in
the USA, EN 166 in Europe, or AS/NZS 1336
in Australia/New Zealand. In Australia/New
Zealand, it is legally required to wear a face
shield to protect your face, too.
It is an employer's responsibility to enforce
the use of appropriate safety protective equip-
ments by the tool operators and by other per-
sons in the immediate working area.
6. Check the blades or blade bolts carefully for
cracks or damage before operation. Replace
cracked or damaged blades or blade bolts
immediately.
7. Remove foreign matters such as rocks, wire,
bottles, bones and large sticks from the work
area before mowing to prevent personal injury
or damage to the mower.
8. Objects struck by the mower blade can cause
severe injuries to persons. The lawn should
always be carefully examined and cleared of
all objects prior to each mowing.
9. Watch for holes, ruts, bumps, rocks, or other
hidden objects. Uneven terrain could cause a slip
andfallaccident.Tallgrasscanhideobstacles.
Operation
1. Do not overreach. Keep the balance at all
times. Always be sure of the footing on slopes.
Walk, never run.
2. Stop the mower and remove the lock key, and
make sure that all moving parts have come to
a complete stop:
- whenever you leave the mower,
- before clearing blockages or unclogging
chute,
- before checking, cleaning or working on the
mower,
- after striking a foreign object. Inspect the
mower for damage and make repairs before
restarting and operating the mower,
- whenever the mower starts vibrating
abnormally.
3. Never operate the mower with defective
guards or shields, or without safety devices,
for example deectors and/or grass basket, in
place.
4. Avoid using the mower in bad weather con-
ditions especially when there is a risk of
lightning.
5. Wear eye protection and stout shoes at all
times while operating the mower.
6. Operate the mower only in daylight or in good
articial light.
7. Switch on the mower carefully according to
instructions and with feet well away from the
blade(s).

9ENGLISH
8. Take care against injury to feet and hands from
the mower blades.
9. Always ensure that the ventilation openings
are kept clear of debris.
10. Mow across the face of slopes, never up and
down. Exercise extreme caution when chang-
ing direction on slopes. Do not mow exces-
sively steep slopes.
11. Use extreme caution when reversing or pulling
the mower towards you.
12. Stop the blade(s) if the mower has to be tilted
for transportation when crossing surfaces
other than grass, and when transporting the
mower to and from the area to be used.
13. Do not tilt the mower when switching on the
motor, except if the mower has to be tilted
for starting. In this case, do not tilt it more
than absolutely necessary and lift only the
part, which is away from the operator. Always
ensure that both hands are in the operating
position before returning the mower to the
ground.
14. Do not put hands or feet near or under rotating
parts. Keep clear of the discharge opening at
all times.
15. Do not transport the mower while the mower is
turned on.
16. Avoid operating the mower in wet grass.
17. Never operate the mower in the rain.
18. Always keep a rm hold on the handle.
19. Don't grasp the exposed cutting blades or
cutting edges when picking up or holding the
mower.
20. Keep hands and feet away from rotating
blades. Caution - Blades coast after the mower
is switched o󰀨.
21. Stop operation immediately if you notice
anything unusual. Switch o󰀨 the mower and
remove the lock key. Then inspect the mower.
22. Never attempt to make cutting height adjust-
ments while mower is running if the mower
has cutting height adjustment feature.
23. Release switch lever and wait for blade rota-
tion to stop before crossing driveways, walks,
roads, and any gravel-covered areas. Also
remove the lock key if you leave the mower,
reach to pick up or remove something out of
your way, or for any other reason that may
distract you from what you are doing.
24. If the mower strikes a foreign object, follow
these steps:
- Stop the mower, release the switch lever and
wait until the blade comes to a complete stop.
- Remove the lock key and the battery
cartridge.
- Thoroughly inspect the mower for any
damage.
- Replace the blade if it is damaged in any way.
Repair any damage before restarting and con-
tinuing to operate the mower.
25. Do not start the mower when standing in front
of the discharge opening.
26. If the mower starts to vibrate abnormally
(check immediately)
- inspect for damage,
- replace or repair any damaged parts,
- check for and tighten any loose parts.
27. Never direct discharged material toward
anyone. Avoid discharging material against a
wall or obstruction.Materialmayricochetback
towardtheoperator.Stopthebladewhencrossing
gravel surfaces.
28. Do not pull the mower backwards unless
absolutely necessary.Whenyouarecompelled
to back the mower from a fence or other similar
obstruction, look down and behind before and
while moving backwards.
29. Shut the motor o󰀨 and wait until the blade
comes to a complete stop before removing the
grass catcher. Beware that the blades coast after
turno󰀨.
Maintenance and storage
1. Replace worn or damaged parts for safety.
Use only genuine replacement parts and
accessories.
2. Inspect and maintain the mower regularly.
3. When not in use, store the mower out of the
reach of children.
4. Keep all nuts, bolts, and screws tight to
be sure the equipment is in safe working
condition.
5. Check the grass basket frequently for wear or
deterioration. For storage, always make sure
the grass basket is empty. Replace a worn
grass basket with a new factory replacement
for safety.
6. Use only the manufacturer genuine blades
specied in this manual.
7. Be careful during adjustment of the mower
to prevent entrapment of the ngers between
moving blades and xed parts of the mower.
8. Do not wash with a hose; avoid getting water
in motor and electrical connections.
9. Check the blade mounting bolt at frequent
intervals for proper tightness.
10. Always allow the mower to cool down before
storing.
11. When servicing the blades be aware that, even
though the power source is switched o󰀨, the
blades can still be moved.
12. Never remove or tamper with safety devices.
Check their proper operation regularly. Never
do anything to interfere with the intended
function of a safety device or to reduce the
protection provided by a safety device.
Battery tool use and care
1. Recharge only with the charger specied by
the manufacturer.Achargerthatissuitablefor
onetypeofbatterypackmaycreateariskofre
whenusedwithanotherbatterypack.
2. Use power tools only with specically desig-
nated battery packs.Useofanyotherbattery
packsmaycreateariskofinjuryandre.

10 ENGLISH
3. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another.Shortingthebatterytermi-
nalstogethermaycauseburnsorare.
4. Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If con-
tact accidentally occurs, ush with water. If
liquid contacts eyes, additionally seek medical
help.Liquidejectedfromthebatterymaycause
irritation or burns.
5. Do not use a battery pack or tool that is dam-
aged or modied.Damagedormodiedbatteries
mayexhibitunpredictablebehaviourresultingin
re,explosionorriskofinjury.
6. Do not expose a battery pack or tool to re or
excessive temperature.Exposuretoreortem-
peratureabove130°Cmaycauseexplosion.
7. Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specied in the instruc-
tions.Chargingimproperlyorattemperatures
outsidethespeciedrangemaydamagethe
batteryandincreasetheriskofre.
Electrical and battery safety
1. Do not dispose of the battery(ies) in a re.
Thecellmayexplode.Checkwithlocalcodesfor
possible special disposal instructions.
2. Do not open or mutilate the battery(ies).
Releasedelectrolyteiscorrosiveandmaycause
damagetotheeyesorskin.Itmaybetoxicif
swallowed.
3. Do not charge battery in rain, or in wet
locations.
4. Do not charge the battery outdoors.
5. Do not handle charger, including charger plug,
and charger terminals with wet hands.
Service
1. Have your power tool serviced by a qualied
repair person using only identical replacement
parts.Thiswillensurethatthesafetyofthepower
tool is maintained.
2. Never service damaged battery packs.Service
ofbatterypacksshouldonlybeperformedbythe
manufacturer or authorized service providers.
SAVE THESE INSTRUCTIONS.
WARNING: DO NOT let comfort or familiarity
with product (gained from repeated use) replace
strict adherence to safety rules for the subject
product.
MISUSE or failure to follow the safety rules stated
in this instruction manual may cause serious
personal injury.
Important safety instructions for
battery cartridge
1. Before using battery cartridge, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using
battery.
2. Do not disassemble or tamper with the battery
cartridge.Itmayresultinare,excessiveheat,
or explosion.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical atten-
tion right away. It may result in loss of your
eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any con-
ductive material.
(2) Avoid storing battery cartridge in a con-
tainer with other metal objects such as
nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
A battery short can cause a large current
ow, overheating, possible burns and even a
breakdown.
6. Do not store and use the tool and battery car-
tridge in locations where the temperature may
reach or exceed 50 °C (122 °F).
7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn
out. The battery cartridge can explode in a re.
8. Do not nail, cut, crush, throw, drop the battery
cartridge, or hit against a hard object to the
battery cartridge.Suchconductmayresultina
re,excessiveheat,orexplosion.
9. Do not use a damaged battery.
10. The contained lithium-ion batteries are subject
to the Dangerous Goods Legislation require-
ments.
Forcommercialtransportse.g.bythirdparties,
forwarding agents, special requirement on pack-
aging and labeling must be observed.
Forpreparationoftheitembeingshipped,consult-
ing an expert for hazardous material is required.
Pleasealsoobservepossiblymoredetailed
national regulations.
Tapeormasko󰀨opencontactsandpackupthe
batteryinsuchamannerthatitcannotmove
around in the packaging.
11. When disposing the battery cartridge, remove
it from the tool and dispose of it in a safe
place. Follow your local regulations relating to
disposal of battery.
12. Use the batteries only with the products
specied by Makita. Installing the batteries to
non-compliantproductsmayresultinare,exces-
siveheat,explosion,orleakofelectrolyte.
13. If the tool is not used for a long period of time,
the battery must be removed from the tool.

11 ENGLISH
14. During and after use, the battery cartridge may
take on heat which can cause burns or low
temperature burns. Pay attention to the han-
dling of hot battery cartridges.
15. Do not touch the terminal of the tool imme-
diately after use as it may get hot enough to
cause burns.
16. Do not allow chips, dust, or soil stuck into the
terminals, holes, and grooves of the battery
cartridge.Itmayresultinpoorperformanceor
breakdownofthetoolorbatterycartridge.
17. Unless the tool supports the use near
high-voltage electrical power lines, do not use
the battery cartridge near high-voltage electri-
cal power lines.Itmayresultinamalfunctionor
breakdownofthetoolorbatterycartridge.
18. Keep the battery away from children.
SAVE THESE INSTRUCTIONS.
CAUTION: Only use genuine Makita batteries.
Use of non-genuine Makita batteries, or batteries that
havebeenaltered,mayresultinthebatterybursting
causingres,personalinjuryanddamage.Itwill
alsovoidtheMakitawarrantyfortheMakitatooland
charger.
Tips for maintaining maximum
battery life
1. Charge the battery cartridge before completely
discharged. Always stop tool operation and
charge the battery cartridge when you notice
less tool power.
2. Never recharge a fully charged battery car-
tridge. Overcharging shortens the battery
service life.
3. Charge the battery cartridge with room tem-
perature at 10 °C - 40 °C (50 °F - 104 °F). Let
a hot battery cartridge cool down before
charging it.
4. When not using the battery cartridge, remove
it from the tool or the charger.
5. Charge the battery cartridge if you do not use
it for a long period (more than six months).
ASSEMBLY
WARNING: Always be sure that the lock key
and battery cartridge are removed before carrying
out any work on the mower.Failuretoremovethe
lockkeyandthebatterycartridgemayresultinseri-
ouspersonalinjuryfromaccidentalstart-up.
WARNING: Never start the mower unless it is
completely assembled. Operation of the machine
inapartiallyassembledstatemayresultinserious
personalinjuryfromaccidentalstart-up.
Installing the battery cover
WARNING: Do not insert the lock key and bat-
tery cartridge before installing the battery cover.
Failuretodosomaycauseaseriousinjury.
Installthebatterycovercompletelybeforetheopera-
tion.Thebatterycoverprotectsthemowerandbattery
cartridge from mud, dirt, and water.
1. Placethebatterycoverwiththeprotrusionsonthe
moweralignedwiththeholesonthebatterycover.
►Fig.1: 1. Protrusion 2. Hole 3.Batterycover
2. Placeyourhandsinthemiddleofthebattery
cover and push it.
►Fig.2
3. Beforetherstoperation,checkthatthepivot
pointofthebatterycoverisattachedproperly.Ifthe
batterycoverisinstalledcorrectly,itwillnotopenuntil
thebatterycoverlockingleverispulled.
►Fig.3: 1. Pivot point 2.Batterycoverlockinglever
Installing the handle
NOTICE: When installing handles, position the
cords so that they are not caught by anything
between the handles. If the cord is damaged, the
mower switch may not work.
1. Slidethebothendsoflowerhandleintothe
groovesofthemowerthenfullytightentheclamping
screws.
►Fig.4: 1. Clamping screw 2. Lower handle
2. Alignthescrewholesofupperhandleandlower
handle.Securethemwiththeclampingscrewsand
nuts.
►Fig.5: 1. Clamping nut 2. Clamping screw
NOTE:Holdtheupperhandlermlysothatitdoes
notdropo󰀨yourhand.
3. Attachtheholderstothehandle.Positionthe
powersupplycordasshowninthegure.
►Fig.6: 1. Holder

12 ENGLISH
Removing the mulching plug
Optional accessory
1. Open the rear cover.
►Fig.7: 1. Rear cover
2. Holdthemulchingplugbythehandle,andthen
pullitoutfromthemowerbodyasshowninthegure.
►Fig.8: 1. Mulching plug 2. Handle
Installing the grass basket
1. Open the rear cover.
►Fig.9: 1. Rear cover
2. Hook the grass basket on the rod of the mower
bodyasshowninthegure.
►Fig.10: 1. Hook 2. Rod 3. Grass basket
Attaching the mulching plug
Optional accessory
1. Open the rear cover, and then remove the grass
basket.
►Fig.11: 1. Rear cover 2. Grass basket
2. Holdthemulchingplugbythehandle,andthen
attachittothemowerbodyasshowninthegure.
►Fig.12: 1. Mulching plug 2. Handle
FUNCTIONAL
DESCRIPTION
Installing or removing battery
cartridge
CAUTION: Always switch o󰀨 the machine
before installing or removing of the battery
cartridge.
CAUTION: Make sure that you lock the battery
cover before use. Otherwise,mud,dirt,orwatermay
causedamagetotheproductorthebatterycartridge.
CAUTION: Always install the battery cartridge
fully until the red indicator cannot be seen. If not,
itmayaccidentallyfalloutofthemachine,causing
injurytoyouorsomeonearoundyou.
CAUTION: Do not install the battery cartridge
forcibly.Ifthecartridgedoesnotslideineasily,itis
notbeinginsertedcorrectly.
NOTE:Themachinedoesnotworkwithonlyone
batterycartridge.
To install the battery cartridge;
1. Slidethebatterycoverlockingleverandopenthe
batterycover.
►Fig.13: 1.Batterycover2.Batterycoverlocking
lever
2. Alignthetongueonthebatterycartridgewiththe
slot on the mower then slide the cartridge until it locks in
place with a little click.
►Fig.14: 1.Batterycartridge
3. Insertthelockkeyintheplaceshowninthegure
as far as it will go.
►Fig.15: 1.Lockkey
4. Closethebatterycoverandpushituntilitis
latched with the locking lever.
To remove the battery cartridge from the mower;
1. Slidethebatterycoverlockingleverandopenthe
batterycover.
2. Pulloutthebatterycartridgefromthemowerwhile
sliding the button on the front of the cartridge.
3. Pulloutthelockkey.
4. Closethebatterycover.
Machine / battery protection system
Themachineisequippedwithamachine/battery
protectionsystem.Thissystemautomaticallycutso󰀨
powertothemotortoextendtoolandbatterylife.The
machinewillautomaticallystopduringoperationifthe
machineorbatteryisplacedunderoneofthefollowing
conditions.
Overload protection
When the machine is operated in a manner that causes
ittodrawanabnormallyhighcurrent,themachine
automaticallystopswithoutanyindication.Inthissitu-
ation,turnthemachineo󰀨andstoptheapplicationthat
causedthemachinetobecomeoverloaded.Thenturn
the machine on to restart.
Overheat protection
When the machine is overheated, the machine stops
automatically.Letthemachinecooldownbeforeturning
the machine on again.
Overdischarge protection
Whenthebatterycapacitybecomeslow,themachine
stopsautomatically.Iftheproductdoesnotoperate
even when the switches are operated, remove the bat-
teries from the machine and charge the batteries.
Indicating the remaining battery
capacity
►Fig.16: 1.Batteryindicator
Whentheremainingbatterycapacitygetslow,thebat-
teryindicatorblinksontheapplicablebatteryside.By
furtheruse,themachinestopsandthebatteryindicator
lights up about 10 seconds. In this situation, charge the
batterycartridge.

13 ENGLISH
Indicating the remaining battery
capacity
Only for battery cartridges with the indicator
►Fig.17: 1. Indicator lamps 2. Check button
Pressthecheckbuttononthebatterycartridgetoindi-
catetheremainingbatterycapacity.Theindicatorlamps
light up for a few seconds.
Indicator lamps Remaining
capacity
Lighted O󰀨 Blinking
75% to 100%
50% to 75%
25% to 50%
0% to 25%
Charge the
battery.
Thebattery
mayhave
malfunctioned.
NOTE: Depending on the conditions of use and the
ambienttemperature,theindicationmaydi󰀨erslightly
fromtheactualcapacity.
NOTE:Therst(farleft)indicatorlampwillblinkwhen
thebatteryprotectionsystemworks.
Switch action
WARNING: Before installing the battery car-
tridge, always check to see that the switch lever
actuates properly and returns to the original
position when released. Operating a machine with a
switchthatdoesnotactuateproperlycanleadtoloss
ofcontrolandseriouspersonalinjury.
NOTE:Themowerdoesnotstartwithoutpressingthe
switch button even the switch lever is pulled.
NOTE:Mowermaynotstartduetotheoverload
whenyoutrytomowlongordensegrassatatime.
Increase the mowing height in this case.
Thismowerisequippedwiththeinterlockswitchand
handleswitch.Ifyounoticeanythingunusualwitheither
oftheseswitches,stopoperationimmediatelyand
havethemcheckedbyyournearestMakitaAuthorized
ServiceCenter.
1. Installthebatterycartridges.Insertthelockkey
intotheinterlockswitchandthenclosethebattery
cover.
►Fig.18: 1.Batterycartridge2.Lockkey
2. Press the switch button and hold it.
3. Grab the upper handle and pull the switch lever.
►Fig.19: 1.Switchbutton2.Switchlever
4. Release the switch button as soon as the motor
startsrunning.Themowerwillcontinuetorununtilyou
release the switch lever.
5. Release the switch lever to stop the motor.
Adjusting the mowing height
WARNING: Never put your hand or leg under
the mower body when adjusting the mowing
height.
WARNING: Always make sure that the lever
ts in the groove properly before operation.
Themowingheightcanbeadjustedintherangeof
between 20 mm and 75 mm.
1. Removethelockkey.
2. Pullthemowingheightadjustinglevertothe
outwardofthemowerbodyandmoveittoyourdesired
mowing height.
►Fig.20: 1.Mowingheightadjustinglever
NOTE:Themowingheightguresshouldbeused
justasaguideline.Dependingontheconditionsof
thelawnortheground,theactuallawnheightmay
becomeslightlydi󰀨erentfromthesetheight.
NOTE:Tryatestmowingofgrassinalessconspicu-
ousplacetogetyourdesiredheight.
Grass level indicator
►Fig.21: 1. Grass level indicator
Grass level indicator shows the volume of mowed
grass.
• Whenthegrassbasketisnotfull,theindicator
oatsduringmowing.
• Whenthegrassbasketisfull,theindicatordoes
notoatduringmowing.Inthiscase,stopmowing
immediatelyandemptythebasket.Afteremptying
the basket, clean it so that its meshwork vents the
air.
NOTE:Thisindicatorisaroughguide.Dependingon
the conditions of inside of the basket, this indicator
maynotworkproperly.
Using mulching plug
Optional accessory
Themulchingplugallowsyoutoreturnthecutgrassto
the ground without gathering the cut grass in the grass
basket.Whenyouoperatethemachinewiththemulch-
ing plug, be sure to remove the grass basket.
NOTICE: When using the machine with the
mulching plug, make sure that the total length of
grass after cutting is 30 mm or more, and the cut
length is 15 mm or less.
►Fig.22: (1) 30 mm or more (2) 15 mm or less

14 ENGLISH
OPERATION
Mowing
WARNING: Before mowing, clear away sticks
and stones from mowing area. Furthermore, clear
away any weeds from mowing area in advance.
WARNING: Always wear the safety goggles or
safety glasses with side shields when operating
the mower.
CAUTION: If the cut grass or foreign object
blocks up inside of the mower body, be sure to
remove the lock key and battery cartridge and
wear gloves before removing the grass or foreign
object.
NOTICE: Use this machine for mowing lawn only.
Do not mow weeds with this machine.
►Fig.23
Firmlyholdthehandlewithbothhandswhenmowing.
Themowingspeedguidelineisapproximately1meter
per 4 seconds.
►Fig.24
Theoutsideedgesofthefrontwheelsareguidelines
to mowing width. Using the outside edges of the front
wheelsasguidelines,mowinstrips.Overlapbyonehalf
toonethirdthepreviousstriptomowthelawnevenly.
►Fig.25: 1. Mowing width 2. Overlapping area
3. Outside edge
Change the mowing direction each time to prevent the
grassgrainpatternfromforminginjustonedirection.
►Fig.26
Periodicallycheckthegrassbasketformowedgrass.
Emptythegrassbeforeitbecomesfull.Beforeevery
periodical check, be sure to stop the mower then
removethelockkeyandthebatterycartridge.
NOTICE: Using the mower with the grass basket
full prevents smooth blade rotation and places
an extra load on the motor, which may cause
breakdown.
Mowing a long-grass lawn
Donottrytocutlonggrassallinonego.Instead,mow
thelawninsomesteps.Leaveadayortwobetween
mowsuntilthelawnbecomesevenlyshort.
NOTE: Mowing long grass to a short length all in one
gomaycausethegrasstodie.Thecutgrassmay
alsoblockupinsideofthemowerbody.
Emptying the grass basket
WARNING: To reduce a risk of accident, reg-
ularly check the grass basket for any damage or
weakened strength. Replace the grass basket if
necessary.
1. Release the switch lever.
2. Removethelockkey.
3. Open the rear cover and take out the grass basket
byholdingthehandle.
►Fig.27: 1. Rear cover 2. Handle
4. Emptythegrassbasket.
MAINTENANCE
WARNING: Always be sure that the lock
key and battery cartridge are removed from the
mower before storing or carrying the mower or
attempting to perform inspection or maintenance.
WARNING: Always remove the lock key when
the mower is not in use. Store the lock key in a
safe place out of reach of children.
WARNING: Wear gloves when performing
inspection or maintenance.
WARNING: Always wear the safety goggles or
safety glasses with side shields when performing
inspection or maintenance.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
TomaintainproductSAFETYandRELIABILITY,
repairs,anyothermaintenanceoradjustmentshould
beperformedbyMakitaAuthorizedorFactoryService
Centers,alwaysusingMakitareplacementparts.
Maintenance
1. Removethelockkey.Storeitinasafeplaceoutof
the reach of children.
2. Cleanthemowerusingonlyawetcloth.Donot
sprayorpourwateronthemowerwhencleaning.
3. Put the mower on its side and clean grass clip-
pings accumulated on the underside of mower deck.
4. Check all nuts, bolts, knobs, screws, fasteners etc.
for tightness.
5. Inspect moving parts for damage, breakage, and
wear. Damaged or missing parts should be repaired or
replaced.

15 ENGLISH
Storage
WARNING: When carrying or storing the
mower, do not hold the folded handles but the
front grip of the mower. Holding the folded handles
maycauseaseriousinjuryordamagetothemower.
Beforestoringthemower,removethebatterycartridge
andlockkey.
Storemowerindoorsinacool,dryandlockedplace.
Don't store the mower and charger in locations where
thetemperaturemayreachorexceed40°C.
►Fig.28: 1.Frontgrip2. Rear grip
1. Loosen the clamping screws and expand the
lower handle to both sides. Move down the handle for-
ward.Atthistime,keeparmgriponthelowerhandle
so that the handle does not fall down to the far side from
themowerbody.
►Fig.29: 1. Clamping screw 2. Lower handle
2. Loosen the clamping nuts and pivot the upper
handle back while expanding the both sides.
►Fig.30: 1. Clamping nut 2. Upper handle
3. Storethegrassbasketbetweenthehandleand
themowerbody.
►Fig.31: 1. Grass basket
NOTE: When putting the mower in the upright posi-
tion, do not hold the handle but use the front grip of
the mower.
Removing or installing the mower
blade
WARNING: Always remove the lock key and
battery cartridge when removing or installing the
blade. Failure to remove the lock key and battery
cartridge may cause a serious injury.
WARNING: The blade coasts for a few sec-
onds after releasing the switch. Do not start any
operation until the blade comes to a complete
stop.
WARNING: Always wear gloves when han-
dling the blade.
Removing the mower blade
For DLM382
1. Put the mower on its side so that the mowing
heightadjustinglevercomestotheupperside.
2. Tolockthebladerotation,insertascrewdriverora
similartoolintoaholeonthemowerbody.
3. Turntheboltcounterclockwisewiththewrench.
►Fig.32: 1. Mower blade 2.Screwdriver3. Wrench
4. Remove the bolt and blade in order.
►Fig.33: 1. Blade support 2. Mower blade 3. Bolt
For DLM432
1. Put the mower on its side so that the mowing
heightadjustinglevercomestotheupperside.
2. Tolockthebladerotation,insertascrewdriverora
similartoolintoaholeonthemowerbody.
3. Turntheboltcounterclockwisewiththewrench.
►Fig.34: 1. Mower blade 2.Screwdriver3. Wrench
4. Removethebolt,outerange,mowerblade,and
innerangeinorder.
►Fig.35: 1.Innerange2. Mower blade 3. Outer
ange4. Bolt
Installing the mower blade
Toinstallthemowerblade,taketheremovalprocedure
in reverse.
WARNING: Install the mower blade carefully.
It has a top/bottom facing. Place the blade so that
the rotational direction arrow faces outward.
WARNING: Tighten the bolt clockwise rmly
to secure the blade.
WARNING: Make sure that the mower blade
and all the xing parts are installed correctly and
tightened securely.
WARNING: When you replace the blades,
always follow the instructions provided in this
manual.

TROUBLESHOOTING
Beforeaskingforrepairs,conductyourowninspectionrst.Ifyoundaproblemthatisnotexplainedinthemanual,
donotattempttodismantlethetool.Instead,askMakitaAuthorizedServiceCenters,alwaysusingMakitareplace-
ment parts for repairs.
State of abnormality Probable cause (malfunction) Remedy
Mower does not start. Twobatterycartridgesarenotinstalled. Installthechargedbatterycartridges.
Batteryproblem(undervoltage) Rechargethebatterycartridge.Ifrechargingisnot
e󰀨ective,replacebatterycartridge.
Thelockkeyisnotinserted. Insertthelockkey.
Motor stops running after a little use. Battery'schargelevelislow. Rechargethebatterycartridge.Ifrechargingisnot
e󰀨ective,replacebatterycartridge.
Cutting height is too low. Increase the cutting height.
Motor does not reach maximum
RPM.
Batterycartridgeisinstalledimproperly. Installthebatterycartridgeasdescribedinthis
manual.
Batterypowerisdropping. Rechargethebatterycartridge.Ifrechargingisnot
e󰀨ective,replacebatterycartridge.
Thedrivesystemdoesnotwork
correctly.
Askyourlocalauthorizedservicecenterforrepair.
Mower blade does not rotate:
stopthemowerimmediately!
Foreignobjectsuchasabranchis
jammedneartheblade.
Removetheforeignobject.
Thedrivesystemdoesnotwork
correctly.
Askyourlocalauthorizedservicecenterforrepair.
Abnormalvibration:
stopthemowerimmediately!
Bladeisimbalanced,excessivelyor
unevenlyworn.
Replace the blade.
OPTIONAL
ACCESSORIES
CAUTION: These accessories or attachments
are recommended for use with your Makita tool
specied in this manual.Theuseofanyother
accessories or attachments might present a risk of
injurytopersons.Onlyuseaccessoryorattachment
for its stated purpose.
Ifyouneedanyassistanceformoredetailsregard-
ingtheseaccessories,askyourlocalMakitaService
Center.
• Mowerblade
• Mulchingplug
• Makitagenuinebatteryandcharger
NOTE:Someitemsinthelistmaybeincludedinthe
toolpackageasstandardaccessories.Theymay
di󰀨erfromcountrytocountry.
16 ENGLISH

17
中文简体
中文简体 (原本)
规格
型号： DLM382 DLM432
修剪宽度（刀片直径） 380 mm 430 mm
空载速度 3,700/min 3,600/min
草坪机备用刀片零件编号 191D41-2 191D43-8
尺寸
（长 ×宽×
高）
操作期间 长：1,380 mm至1,410 mm
宽：450 mm
高：985 mm至1,005 mm
长：1,435mm至1,490mm
宽：460mm
高：1,005mm至1,045mm
存放时
（不带草篮）
860 mm ×450 mm ×
475 mm
865 mm ×460 mm ×
475 mm
额定电压 D.C. 36 V
净重 15.0 - 16.5 kg 15.4 - 17.1 kg
•生产者保留变更规格不另行通知之权利。
•规格可能因销往国家之不同而异。
•重量因附件（包括电池组）而异。根据EPTA-Procedure01/2014，最重与最轻的组合
见表格。
适用电池组和充电器
电池组 BL1815N/BL1820/BL1820B/BL1830/
BL1830B/BL1840/BL1840B/BL1850/
BL1850B/BL1860B
充电器 DC18RC/DC18RD/DC18RE/DC18SD/
DC18SE/DC18SF/DC18SH
•部分以上所列电池组和充电器是否适用视用户所在地区而异。
警告： 请仅使用以上所列电池组和充电器。使用其他类型的电池组或充电器可能会导
致人身伤害和／或失火。
警告： 请勿对此机器使用带线电源，例如电池连接转换器或者便携电源装置。此类电
源电缆可能会阻碍操作并导致人员受伤。
符号
以下显示本设备可能会使用的符号。在使用
工具之前，请务必理解其含义。
特别小心和注意。
阅读使用说明书。
危险；注意抛掷物体。
工具和旁观者的距离至少为
15米。
切勿使手和脚靠近修剪机下
面的刀片。电机关闭后刀片
还会继续旋转。
检查、调节、清洁、维修、
放置或存放修剪机前，请务
必拔下锁定钥匙。

18
中文简体
Ni-MH
Li-ion 仅限于欧盟国家
请勿将电气设备或电池组与
家庭普通废弃物一同丢弃！
请务必遵守欧洲关于废弃电
子电气设备、电池和蓄电池
以及废弃电池和蓄电池的指
令并根据法律法规执行。达
到使用寿命的电气设备和电
池组必须分类回收至符合环
境保护规定的再循环机构。
用途
本机用于修剪草坪。
安全警告
重要安全注意事项
警告： 阅读所有警告和所有说明。不遵
照以下警告和说明会导致电击、着火和／或
严重伤害。
保存所有警告和说明书以备
查阅。
培训
1. 请仔细阅读说明。熟悉控制和正确操作
本修剪机。
2. 切勿允许儿童或不熟悉这些使用须知的
人员使用本修剪机。当地法规可能会限
制操作人员的年龄。
3. 切勿在附近有人（特别是儿童）或宠物
的情况下操作本修剪机。
4. 操作时要时刻谨记，如果给他人及其
财产造成损失，操作者或用户要为此
负责。
5. 应看管好儿童，勿让其玩耍本工具。
6. 身体状态 - 请勿在药品、酒精或其他接
受医疗的情况下操作修剪机。
准备
1. 操作本修剪机时，务必穿戴厚实的鞋子
和长裤。请勿在赤脚或穿着露趾凉鞋时
操作本修剪机。避免穿着或佩戴宽松或
带有线绳的衣服或首饰。它们可能会被
卷入运动部件中。
2. 使用前，务必观察修剪机是否有损坏，保
护罩或隔离罩是否缺失或者位置错误。
3. 修剪草坪前确保作业区域内无其他人
员。如有任何人进入作业区域，请停止
修剪机。
4. 准备使用时才可将锁定钥匙插入草
坪机。
5. 使用电动工具时请始终佩带护目镜以
免伤害眼睛。护目镜须符合美国ANSI
Z87.1、欧洲EN 166或者澳大利亚／新
西兰的AS/NZS 1336的规定。在澳大
利亚／新西兰，法律要求佩带面罩保护
脸部。
雇主有责任监督工具操作者和其他近工
作区域人员佩带合适的安全防护设备。
6. 操作之前，请仔细检查刀片或刀片螺栓
上是否有裂缝或损坏。应立即更换有裂
缝或损坏的刀片或刀片螺栓。
7. 修剪草坪前，请清除作业区域内的石块、
铁丝、瓶子、骨头和大的树枝等异物，以
防止人员受伤或损坏修剪机。
8. 修剪机刀片撞击异物会导致严重的人身
伤害。每次修剪前，请务必仔细检查草
坪并清除所有异物。
9. 观察有无孔洞、坑槽、鼓包、石头或其
它隐藏的物体。地面不平会导致打滑和
摔倒。高草丛会隐藏障碍物。
操作
1. 操作时手不要伸得太长。始终保持平
衡。在斜坡上时，请确保立足稳固。操
作时请行走，切勿跑动。
2. 停止修剪机并拔下锁定钥匙，确保所有
运动部件已完全停止：
- 放置修剪机时；
- 清除堵塞物或疏通滑槽前；
- 检查、清洁或处理机器前；
- 击打到异物后。在重新启动并操作机器
前，检查修剪机有无损坏并进行修理。
- 修剪机开始异常振动时。

19
中文简体
3. 在保护罩或隔离罩有损坏，或者安全装
置（如火花挡板和／或草篮）未安装到
位时，请勿操作修剪机。
4. 请避免在恶劣天气尤其是雷电天气条件
下使用修剪机。
5. 操作修剪机时，请务必穿戴护目眼镜和
结实的鞋子。
6. 仅可在光线充足或良好照明的情况下操
作本修剪机。
7. 根据操作指示小心开启修剪机，并使脚
远离刀片。
8. 小心避免修剪机刀片伤及脚和手。
9. 务必确保通风口无任何碎片。
10. 修剪斜面草坪时，切勿上下颠簸。在斜
面上改变方向时，请务必小心谨慎。请
勿修剪较陡的倾斜面。
11. 反转或向自身拉修剪机时，务必小心
谨慎。
12. 如果必须倾斜修剪机以搬运修剪机通过
非草坪表面，以及修剪机进出作业区域
时，请停止刀片。
13. 除必须倾斜修剪机进行启动的情况外，
请勿在开启电机时倾斜修剪机。需要倾
斜修剪机时，切勿使倾斜度大于必要的
程度，并仅提起离操作者较远的部分。
将本修剪机放回地面时，务必将双手放
在操作位置上。
14. 勿使手和脚靠近旋转部件或置于其下。
请勿在任何时间与排出口成直线站立。
15. 请勿在修剪机开启时进行搬运。
16. 避免在湿草上操作本修剪机。
17. 切勿在雨中操作本修剪机。
18. 请务必紧握手柄。
19. 搬动或握住修剪机时，请勿抓握外露的
刀片或切割边。
20. 手和脚应远离旋转的刀片。注意 - 关闭
修剪机后刀片仍会旋转。
21. 若发现有任何异常，请立即停止操作。
关闭修剪机并拔下锁定钥匙。然后检查
修剪机。
22. 如果草坪机具有切割高度调节功能，切
勿在草坪机运转时调节切割高度。
23. 在穿过车道、人行道、道路或任何砾石
覆盖的路面前，请释放开关拉杆并等待
刀片停止旋转。在放置修剪机，捡取修
剪路径上的异物或在任何可能分散注意
力的情况下，请务必拔下锁定钥匙。
24. 如果修剪机撞击到异物，请执行以下
步骤：
- 停止修剪机，释放开关柄并等待刀片
完全停止。
- 拔下锁定钥匙并取出电池组。
- 彻底检查修剪机有无损伤。
- 如果刀片有任何损伤，请予以更换。
重新启动并继续操作修剪机前，请修复
任何损伤。
25. 请勿在站立在排出口前部时启动修剪机。
26. 如果修剪机开始异常振动（立即检查）
- 检查损伤；
- 更换或修复任何损坏部件；
- 检查并拧紧松散的部件。
27. 严禁将排出的材料指向任何人。避免将
材料排出至墙壁或障碍物处。材料可能
会朝向操作者反弹。通过砾石面时，停
止刀片。
28. 除非绝对需要，否则禁止向后拉修剪机。
不得不从栅栏或其它类似障碍物处后拉修
剪机时，移动前和移动期间要注意脚下和
身后。
29. 拆下草夹持器前，先关闭电机并等待刀片
完全停止。小心关机后刀片仍会旋转。
保养和存放
1. 出于安全需要，请更换磨损或损坏的部
件。仅使用原厂正品替换部件和附件。
2. 定期检查和保养修剪机。
3. 不使用时，将修剪机存放在儿童无法触
及的地方。
4. 保证所有螺母、螺栓和螺丝都已拧紧，
确保设备处于安全的工作状态。
5. 时常检查草篮是否有磨损或劣化。存放
时，务必确保清空草篮。出于安全需
要，请使用新的原厂替换草篮更换磨损
的草篮。
6. 请仅使用本说明书中指定的正品刀片。
7. 调整修剪机时请小心谨慎，防止手指卷
入移动刀片和修剪机的固定部件之间。
8. 请勿用水管冲洗，避免电机和电气连接
部件进水。
9. 时常检查刀片安装螺栓，确保紧固妥当。
10. 存放前，务必使修剪机充分冷却。
11. 请注意，在维修刀片时，即便已切断电
源，刀片仍可以移动。
12. 严禁拆下或改动安全装置。定期检查是
否正常运行。严禁干扰安全装置的预定
功能或者降低其保护能力。

20
中文简体
电池式工具使用和注意事项
1. 仅使用生产者规定的充电器充电。将适
用于某种电池包的充电器用到其他电池
包时可能会发生着火危险。
2. 仅使用配有专用电池包的电动工具。使
用其他电池包可能会产生伤害和着火
危险。
3. 当电池包不用时，将它远离其他金属物
体，例如回形针、硬币、钥匙、钉子、
螺钉或其他小金属物体，以防电池包一
端与另一端连接。电池组端部短路可能
会引起燃烧或着火。
4. 在滥用条件下，液体可能会从电池组中溅
出；应避免接触。如果意外碰到液体，用
水冲洗。如果液体碰到了眼睛，还应寻求
医疗帮助。从电池中溅出的液体可能会发
生腐蚀或燃烧。
5. 不要使用损坏或改装过的电池包或工
具。损坏或改装过的电池组可能呈现
无法预测的结果，导致着火、爆炸或
伤害。
6. 不要将电池包暴露于火或高温中。电池
包暴露于火或高于130 ℃的高温中可能
导致爆炸。
7. 遵循所有充电说明。不要在说明书中指
定的温度范围之外给电池包或电动工具
充电。 不正确或在指定的温度范围外充
电可能会损坏电池和增加着火的风险。
电气和电池安全
1. 请勿将电池弃于火中。否则会引起电池
爆炸。请查阅当地法规了解适当的特殊
处理说明。
2. 请勿打开或拆解电池。溢出的电解质具
有腐蚀性，可能会对眼睛或皮肤造成损
伤。吞服则有致毒危险。
3. 请勿在雨中或潮湿的地方充电。
4. 勿在室外对电池充电。
5. 请勿用湿手操作充电器，包括充电器插
头和充电器端子。
维修
1. 让专业维修人员使用相同的备件维修电
动工具。这将保证所维修的电动工具的
安全。
2. 决不能维修损坏的电池包。电池包仅
能由生产者或其授权的维修服务商进行
维修。
请保留此说明书。
警告： 请勿为图方便或因对产品足够
熟悉（由于重复使用而获得的经验）而不
严格遵循相关产品安全规则。
使用不当或不遵循使用说明书中的安全规
则会导致严重的人身伤害。
电池组的重要安全注意事项
1. 在使用电池组之前，请仔细通读所有的
说明以及（1）电池充电器，（2）电
池，以及（3）使用电池的产品上的警
告标记。
2. 切勿拆卸或改装电池组。否则可能引起
火灾、过热或爆炸。
3. 如果机器运行时间变得过短，请立即停
止使用。否则可能会导致过热、起火甚
至爆炸。
4. 如果电解液进入您的眼睛，请用清水将
其冲洗干净并立即就医。否则可能会导
致视力受损。
5. 请勿使电池组短路：
(1) 请勿使任何导电材料碰触到端子。
(2) 避免将电池组与其他金属物品如钉
子、硬币等放置在同一容器内。
(3) 请勿将电池组置于水中或使其淋雨。
电池短路将产生大的电流，导致过热，
并可能导致起火甚至击穿。
6. 请勿在温度可能达到或超过50°C
（122°F）的场所存放以及使用工具和
电池组。
7. 即使电池组已经严重损坏或完全磨损，
也请勿焚烧电池组。电池组会在火中
爆炸。
8. 请勿对电池组射钉，或者切削、挤压、
抛掷、掉落电池组，又或者用硬物撞击
电池组。否则可能引起火灾、过热或
爆炸。
9. 请勿使用损坏的电池。
10. 本工具附带的锂离子电池需符合危险品
法规要求。
第三方或转运代理等进行商业运输时，
应遵循包装和标识方面的特殊要求。
有关运输项目的准备作业，咨询危险品
方面的专业人士。同时，请遵守可能更
为详尽的国家法规。
请使用胶带保护且勿遮掩表面的联络信
息，并牢固封装电池，使电池在包装内
不可动。
