Parts Breakdown G4300L
Page 1 of 18 8/18/2010

Parts Breakdown G4300L
Page 2 of 18 8/18/2010

Parts Breakdown G4300L
Page 3 of 18 8/18/2010

Parts Breakdown G4300L
Page 4 of 18 8/18/2010

Parts Breakdown G4300L
Page 5 of 18 8/18/2010

Parts Breakdown G4300L
Page 6 of 18 8/18/2010

Parts Breakdown G4300L
Page 7 of 18 8/18/2010

Parts Breakdown G4300L
Page 8 of 18 8/18/2010

Parts Breakdown G4300L
Page 9 of 18 8/18/2010

Parts Breakdown G4300L
Page 10 of 18 8/18/2010

Parts Breakdown G4300L
Page 11 of 18 8/18/2010

Parts Breakdown G4300L
Page 12 of 18 8/18/2010

Parts Breakdown G4300L
Page 13 of 18 8/18/2010

Parts Breakdown G4300L
Fig # Part ID Part Name Quantity
Products with multiple versions are listed in subsiding order with the newest version on top not indented
1 279-10102-51 CRANKCASE CP.,G4300L 1
2 237-14202-03 VALVE GUIDE(OVER SIZE), G2800R 2
3 277-16010-01 STEM SEAL, G1100 1
4 044-03001-60 OIL SEAL. G4300L 1
5 060-03003-41 BALL BEARING, G4300L 1
6 277-15011-03 PIPE KNOCK, G1100 2
7 010-50604-10 STUD, G4300L 2
8 044-00600-20 OIL SEAL, G1100 1
9 040-11400-30 PLUG, G2800R 2
10 021-11400-20 GASKET, G2800R 2
11 279-11001-21 MAIN BEARING COVER CP.,G4300L 1
12 044-03001-60 OIL SEAL. G4300L 1
13 060-03003-70 BALL BEARING, G4300L 1
14 277-45004-H1 GOVERNOR GEAR CP.,G2800L 1
14 27745004J1 N/A 1
15 277-41901-03 GOVERNOR SLEEVE, G2800L 1
16 279-63601-13 OIL GAUGE, G4300L 2
16 279-63601-23 OIL GAUGE, G4300L 2
17 021-32000-50 GASKET, G4300L 2
18 001-04083-50 FLANGE BOLT, G2800L 7
19 279-13005-01 CYLINDER HEAD CP.,G4300L 1
20 2791500133 N/A 1
21 011-00802-40 FLANGE BOLT, G2800L 4
22 011-00803-10 FLANGE BOLT, G2800L 1
23 277-15501-01 ROCKER COVER CP.,G2800L 1
23 2771550301 N/A 1
24 277-16001-13 GASKET (ROCKER COVER), G2800L 1
25 277-15011-03 PIPE KNOCK, G1100 2
26 011-00600-20 FLANGE BOLT, G6100R 4
27 2799900127 N/A 1
28 279-20501-01 CRANKSHAFT CP.,G4300L 1
29 018-01800-10 FLANGE NUT, G4300L 1
30 032-30300-10 WOODRUFF KEY, 3X6MM, G2800R 1
31 279-22501-20 CONNECTING ROD AY, G4300L 1
31 2792250130 N/A 1
32 279-23001-03 CONNECTING ROD BOLT, G4300L 2
33 279-23301-03 PISTON PIN, G4300L 1
34 279-23401-03 PISTON STD., G4300L 1
34 279-23403-03 PISTON 0.25 O.S, G4300L 1
34 279-23404-03 PISTON 0.50 O.S, G4300L 1
35 279-23511-17 PISTON RING SET STD.,G4300L 1
35 279-23512-17 PISTON RING SET 0.25, G4300L 1
35 279-23513-17 PISTON RING SET 0.50,G4300L 1
36 056-51800-10 CLIP, G3510R 2
37 279-31602-11 CAM SHAFT CP., G4300L 1
38 2773510101 N/A 1
38 277-35101-03 PIN (CAM SHAFT), G2800L 1
39 024-00600-10 O RING , G2800L 1
40 277-38601-03 PIN (SPRING), G2800L 1
41 279-36401-03 RELEASE LEVER, G4300L 1
42 277-36501-03 CLIP, G2800L 1
43 279-38701-13 RETURN SPRING, G2800L 1
44 279-33601-03 VALVE SPRING, G2800L 2
45 269-33701-03 SPRING RETAINER, G2800L 2
46 279-33401-13 INTAKE VALVE, G4300L 1
46 27933401H3 N/A 1
47 279-33501-13 EXHAUST VALVE, G4300L 1
47 279-33501-H3 EXHAUST VALVE, G4300L 1
48 132-10KA0-31 COLLET VALVE, G2800R 4
49 279-35601-11 TIMING CHAIN CP., G4300L 1
50 277-36911-03 TENSIONER, G2800L 1
51 277-37101-03 SPRING (TENSIONER), G2800L 1
52 277-36902-03 PIN (TENSIONER), G2800L 1
53 277-36913-13 CHAIN GUIDE, G2800L 1
Page 14 of 18 8/18/2010

Parts Breakdown G4300L
54 277-35002-01 PIN (ROCKER)CP., G2800L 1
54 2773500401 N/A 1
55 003-13050-00 CLIP, G1100 1
56 277-36201-00 ROCKER ARM (IN)AY, G4300L 1
57 277-36202-00 ROCKER ARM (EX) AY, G2800L 1
58 014-90500-20 ADJUST SCREW M5, G2800L 1
59 014-90500-20 ADJUST SCREW M5, G2800L 1
60 017-00500-30 NUT, G2800L 1
61 017-00500-30 NUT, G2800L 1
62 011-00600-20 FLANGE BOLT, G6100R 1
63 277-42201-33 GOVERNOR SHAFT, G2800L 1
64 003-13050-00 CLIP, G1100 1
65 279-52711-11 BAFFLE 1 (CASE) CP.,G4300L 1
66 001-65081-20 HEX BOLT, G5711R 1
67 279-79262-01 FLYWHEEL CP.,G4300L 1
68 279-79430-01 IGNITION COIL CP.,G4300L 1
69 001-14062-50 BOLT & WASHER, G2800R 2
70 277-73102-H1 WIRE 2 CP., G2800L 1
71 065-01401-50 SPARK PLUG BR6HS, G2800R 1
72 065-50002-70 SPARK PLUG CAP, G2800L 1
73 279-76301-31 OIL SENSOR CP.,G4300L 1
73 279-76301-41 OIL LEVEL SENSOR, G4300L 1
73 2797630151 N/A 1
74 001-14061-60 BOLT & WASHER, G2800R 1
75 013-00602-60 BOLT & WASHER AY, G2800L 1
76 279-75501-03 WIRE CLAMP, G4300L 1
77 015-20600-50 TAPPING BOLT, G5710R 1
78 010-50802-90 STUD, G2800R 1
79 010-50804-40 STUD, G4300L 1
80 011-00801-50 FLANGE BOLT, G2800L 2
81 277-87001-03 COVER (CRANKSHAFT), G2800L 1
82 33D-35001-01 BOTTOM EXT. PLATE, G4300L 1
83 011-00802-70 FLANGE BOLT M8X33L, G4300L 2
84 011-00801-50 FLANGE BOLT, G2800L 2
85 279-30401-21 MUFFLER CP., G4300L 1
86 33D-52601-03 BAFFLE, G4300L 1
87 011-00802-70 FLANGE BOLT M8X33L, G4300L 2
88 002-38080-00 FLANGE NUT, G6100R 2
89 011-00803-20 FLANGE BOLT, G4300L 1
90 011-00600-10 FLANGE BOLT, G6100R 1
91 277-35201-13 GASKET (MUFFLER), G2800L 2
92 980-20082-80 FLANGE NUT, G2800L 2
93 279-39201-03 FLANGE, G4300L 1
94 27737210-03 TAIL SCREEN, G2800L 1
95 004-35051-60 SCREW, EH561 1
96 002-18050-00 NUT, RBC225 1
97 279-32622-00 AIR CLEANER AY., G4300L 1
97 2793262210 N/A 1
98 279-32635-08 CLEANER BODY CP., G4300L 1
98 279-32635-18 BASE CP., G4300L 1
99 279-32650-08 GASKET, G4300L 1
99 2793265018 N/A 1
100 279-32646-08 COVER CP., G4300L 1
101 279-32612-08 FILTER, G4300L 1
102 002-38060-00 FLANGE NUT, G6101R 2
103 085-10800-00 RUBBER PIPE, G2800R 1
104 279-32902-H3 INSULATOR, G4300L 1
104 279-32902-J1 INSULATOR CPL., G4300L 1
105 279-35902-J3 GASKET 1 (ISSULATOR), G4300L 1
106 279-35903-J3 GASKET 2 (INSULATOR), G4300L 1
107 279-39004-01 BRACKET (A/C) CP.,G4300L 1
108 011-00601-50 FLANGE BOLT, G2800L 1
109 011-00600-50 FLANGE BOLT, G5501R 1
110 279-42301-23 GOVERNOR LEVER, G4300L 1
110 2794230153 N/A 1
110 2794230160 N/A 1
110 2794230163 N/A 1
Page 15 of 18 8/18/2010

Parts Breakdown G4300L
111 279-42701-01 GOVERNOR ROD CP.,G4300L 1
111 2794270111 N/A 1
112 277-42801-23 ROD SPRING, G2800L 1
113 013-00602-40 BOLT & WASHER AY, G2800L 1
114 018-60600-20 NUT, G2800R . 1
115 277-42520-03 GOVERNOR SPRING, G4300L 1
116 277-48001-01 PLATE CP.(S.ADJUST), G2800L 1
117 004-31055-50 SCREW, G2800L 1
118 279-52001-13 BLOWER HOUSING, G4300L 1
119 001-14063-00 BOLT & WASHER ASS'Y, G5710R 1
120 001-14066-00 BOLT & WASHER AY, G4300L 1
121 980-40081-10 STR PIN 8X10, G2800L 2
122 277-50401-10 RECOIL STARTER, G2800L 1
122 277-50401-20 RECOIL STARTER ASS'Y, G2800L 1
122 2775040130 N/A 1
122 2775040140 N/A 1
123 277-50402-08 SPIRAL SPRING, G2800L 1
124 277-50403-08 REEL, G2800L 1
125 277-50408-08 STARTER ROPE, G2800L 1
126 277-50409-08 STARTER KNOB, G2800L 1
126 2775040918 N/A 1
127 277-50404-08 RATCHET, G2800L 1
128 277-50405-08 FRICTION SPRING, G2800L 1
129 277-50407-08 FRICTION PLATE, G2800L 1
130 277-50406-08 RETAINING RING, G2800L 1
131 011-00601-40 FLANGE BOLT, G2410R 3
132 279-54110-03 COOLING BLOWER, G4300L 1
133 279-52702-13 BAFFLE 2 (HEAD) CP.,G4300L 1
134 011-00600-20 FLANGE BOLT, G6100R 1
135 277-24401-03 DRIVING SHAFT, G2800L 1
136 011-01001-10 FLANGE BOLT, G2800L 4
137 279-62331-00 CARBURETOR AY.,G4300L 1
138 279-62535-08 THROTTLE VALVE, G4300L 1
139 251-62450-08 SCREW, G4300L 2
140 279-62526-08 CHOKE VALVE, G4300L 1
141 251-62450-08 SCREW, G4300L 2
142 279-62420-08 PILOT JET, G4300L 1
143 279-62521-08 CHOKE LEVER, G4300L 1
144 279-62530-08 THROTTLE SHAFT-A, G4300L 1
145 251-62453-08 BOLT, G4300L 1
146 279-62500-08 VALVE ASS'Y, G1100 1
147 279-62515-08 PIN, G4300L 1
148 279-62553-08 FLOAT BODY, G4300L 1
149 251-62350-08 GASKET, G1100 1
150 279-62540-08 CHAMBER PACKING, G4300L 1
151 279-62505-08 FLOAT AY, G4300L 1
152 279-62400-08 MAIN JET, G4300L 1
153 284-62456-08 SCREW, G1100 1
154 279-62447-08 SPRING (CHOKE), G4300L 1
155 279-62581-08 SCREW, G4300L 1
156 279-62561-08 BUSH, G4300L 1
157 279-62353-18 ADJUST SCREW, G4300L 1
158 279-62445-08 SPRING, G1100 1
159 279-62562-08 COLLAR, G4300L 1
160 279-62452-08 O RING, G4300L 1
161 279-62451-08 O RING, G4300L 1
162 279-62590-08 VINYL PIPE, G4300L 1
163 279-62576-08 BRACKET, G4300L 1
164 279-62580-08 SCREW, G4300L 2
165 KU3-11043-11 FLOAT C/U CP3, G2800L 1
166 011-00600-20 FLANGE BOLT, G6100R 1
167 056-60002-50 CLAMP (ELEC STARTER),G2800R 1
168 33D-22352-01 STATOR AY, G4300L 1
169 33C-21052-08 BOLT M5X135L, G4300L 2
170 33D-21161-01 ROTOR, G4300L 1
171 32D-21001-08 BALL BEARING, G2800L 1
172 33D-21053-08 ROTOR BOLT M10X185L, G4300L 1
Page 16 of 18 8/18/2010

Parts Breakdown G4300L
173 33D-23061-01 STATOR COVER, G4300L 1
174 32D-23071-01 REAR COVER, G2800L 1
174 32D2307201 N/A 1
175 33D-21051-08 STARTOR BOLT, G4300L 4
176 33B-23051-01 END COVER, G2800L 1
177 33B-21052-08 BOLT M5X10L, G2800L 2
178 32D-23101-01 BRUSH CP., G2800L 1
179 32D-21062-08 SCREW, G2800L 1
180 33B-23001-00 AVR AY., G2800L 1
181 32D-21055-08 SCREW M5X14L, G2800L 2
182 32D-21052-08 BASE, G2800L 1
183 32D-21055-08 SCREW M5X14L, G2800L 2
184 32D-21061-08 BOLT, G2800L 2
185 32D-21051-08 NUT M5, G2800L 4
186 32D-21053-08 WASHER, G2800L 2
187 32D-21054-08 SPRING WASHER, G2800L 4
188 32B-45002-03 GROMMET, G2800L 1
189 32D-21060-08 CLAMP, G1100 1
190 32B-21053-08 SCREW, G1100 1
190 32D-21063-08 SCREW M5X12L, G4300L 1
191 33D-30001-11 FRAME CP.,G4300L 1
191 33D-30101-01 FRAME, G4300L 1
192 32B-30213-01 MOUNT CP.(R), G4300L 1
193 32B-30214-01 MOUNT CP.(L), G4300L 1
194 32B-30203-01 MOUNT CP.(R), G4300L 1
195 32B-30204-01 MOUNT CP.(L), G4300L 1
196 002-38080-00 FLANGE NUT, G6100R 8
197 33B-48091-01 EARTH WIRE CP.,G2800L 1
198 014-00601-21 SCREW, G2800L 1
199 33B-50002-01 FRONT COVER CP. (UPPER), G4300L 1
200 015-00400-70 TAPPING SCREW, G2800R 2
201 33B-46001-03 COVER (COCK), G2800L 1
202 003-10040-00 WASHER, G6101R 2
203 33B-46012-01 BRACKET (COCK), G2800L 1
203 33B-46012-11 BRACKET (COCK), G2800L 1
204 34B-57311-03 SEAL SPONGE FC2, G2800L 1
205 353-49904-08 TAPPING SCREW, G2800R 6
206 33D-43975-00 CONTROL PANEL AY.,G4300L 1
207 33B-45114-01 PANEL PLATE CP.,G4300L 1
208 33B-49264-03 SHEET (PANEL AR)2, G4300L 1
209 227-75001-03 GROMMET, G2800L 1
210 33K4995101 N/A 1
210 388-85003-01 AC RECEPTACLE (125V-20A),G6101R 1
211 004-35041-00 SCREW & WASHER, G2800R 2
212 002-27040-00 NUT, G2800L 2
213 003-10040-00 WASHER, G6101R 2
214 393-40665-08 NEON LAMP (GR.), G2800L 1
215 33K-41811-03 MICRO SWITCH, G1100 2
216 33K-42010-03 CONTROL DIAL, G1100 1
217 33K-42020-03 CHOKE REEL, G1100 1
218 33K-42030-13 PLATE, G2800L 1
218 33K-42030-23 PLATE, G2800L 1
219 33B-46015-01 BRACKET (MICRO), G2800L 1
220 33K-41814-08 TAPPING SCREW, G2800L 2
221 015-00400-70 TAPPING SCREW, G2800R 1
222 32B-43166-01 CIRCUIT BREAKER 30A, G4300L 1
223 31B-79011-03 SCREW & WASHER ASSY(M3X5MM)G12000R 6
224 388-88001-03 SCREW (M5), G5711R 1
225 332-00050-08 SPRING WASHER, G2800R 2
226 353-49903-08 WASHER, G2800R 1
227 353-49902-08 NUT, G2800R 1
228 003-30050-00 LOCK WASHER, G2800R 1
229 353-49901-08 WING NUT, G2800R 1
230 33B-46021-01 CHOKE WIRE CP.,G2800L 1
231 014-00601-90 SCREW, G2800L 4
232 056-30000-20 WIRE BAND, G2400R 5
233 33D-90011-13 LABEL (TRADE MARK),G4300L 1
Page 17 of 18 8/18/2010

Parts Breakdown G4300L
234 33B-50101-01 FRONT COVER CP.,G2800L 1
235 33B-35501-01 BRACKET (COVER) CP.,G2800L 1
236 33B-50501-01 REAR COVER CP.,G2800L 1
237 011-00601-80 FLANGE BOLT, G2410R 3
238 34B-57311-03 SEAL SPONGE FC2, G2800L 1
239 33B-56201-01 MUFFLER COVER CP.,G2800L 1
240 33D-56051-01 MUFFLER COVER(L)CP.,G4300L 1
241 33B-57005-03 SEAL RUBBER,G2800L 1
242 011-00601-80 FLANGE BOLT, G2410R 4
243 011-00600-80 FLANGE BOLT, G2400R 4
244 33B-97132-13 LABEL (TM-RC), G2800L 1
245 33D-95154-03 LABEL (SPEC), G4300L 1
246 33D-60102-11 FUEL TANK CP.,G4300L 1
247 043-05900-11 FUEL TANK CAP COMPL., G2800R 1
248 064-15400-11 FUEL FILTER, G6101R 1
249 064-80015-00 FUEL GAUGE COMPL. G12000R 1
250 064-20103-00 FUEL STRAINER, G2800L 1
251 064-20093-20 FILTER, G2800L 1
252 064-20064-10 RUBBER PACKING, G2800R 1
253 064-20078-10 CUP, G2800R 1
254 064-20047-90 P.H. SCREW, G2800R 2
255 011-00600-20 FLANGE BOLT, G6100R 1
256 085-10600-00 RUBBER PIPE, G2410R,1M 1
257 085-10700-40 RUBBER PIPE, G4300L 1
258 251-17302-03 MESH PROTECTOR, G2800L 1
259 056-11100-20 HOSE CLAMP, G2800R 2
260 056-11300-10 HOSE CLAMP, G1100 2
261 011-00602-20 FLANGE BOLT, G2800R 4
262 391-39000-13 RUBBER WASHER, G2800R 4
263 33B-97102-13 LABEL (CAUTION),G2800L 1
264 279-37601-01 SPARK ARRESTER CP.,G2800L 1
265 355-45613-11 SWITCH, G5500R 1
266 356-45711-08 AC RECEPTACLE, G3510R 1
267 353-45724-08 AC RECEPTACLE, G3510R 1
268 356-59937-08 SCREW, G3510R 4
269 326-00335-08 SPRING WASHER, G3510R 4
270 32B-43196-01 CIRCUIT BREAKER 16A, G4300L 1
271 31C-73008-03 CIRCUIT BREAKER 20A, G4300L 1
272 277-37220-03 SCREEN, G2800L 2
273 2264500103 N/A 1
1,001 27790301H0 ACCESSORY TOOL KIT, G2800L 1
Page 18 of 18 8/18/2010
