Makita HR2455 Quick start guide

Parts Breakdown HR2455
Page 1 of 3 2/8/2008

Parts Breakdown HR2455
Fig # Part ID Part Name Quantity
1 286263-4 CAP 35, HR2450F 1
2 233915-8 RING SPRING 19, HR2450F 1
2 233940-9 RING SPRING 19, HR2450F 1
3 417629-9 CHUCK COVER,HR2450F 1
4 257241-1 RING 21, HR2450F 1
5 345187-4 GUIDE WASHER, HR2450F 1
6 233916-6 CONICAL COMP. SPRING 21-29 1
7 921923-8 HEX. BOLT M8 X 120, HP2050F 1
8 417630-4 GRIP BASE, HP2070F 1
9 134943-5 GRIP 36, HR2450F 1
10 266069-6 T. SCREW FLANGE PT4X45 HR2410 4
11 417794-4 CAP, HR2455 1
12 162229-7 CHANGE LEVER,HR2455 1
13 213278-8 O RING 17,HR2450F 1
14 183441-6 GEAR HOUSING SET,HR2450F 1
15 153290-5 NEEDLE BEARING CPL., HR2450F 1
16 233918-2 RING SPRING 28, HR2450F 1
17 267228-5 WASHER 30, HR2450F 1
18 233328-3 COMP. SPRING 31, HR2450F 1
19 227028-5 SPUR GEAR 51, HR2450F 1
20 216022-2 STEEL BALL 7.0, HR2400 1
21 153365-0 TOOL HOLDER CPL. 1
22 267229-3 FLAT WASHER 28 1
23 213128-7 O RING 12,HR2450F 1
24 324278-4 IMPACT BOLT, HR2445 1
24 324396-8 IMPACT BOLT, HR2455 1
25 324218-2 RING 9, HR2450F 1
26 213232-2 O RING 15,HR2450F 1
27 324216-6 O RING CASE, HR2450F 1
28 213073-6 O RING 9,HR2450F 1
29 233917-4 RING SPRING 28, HR2450F 1
30 324214-0 STRIKER, HR2450F 1
31 213227-5 O RING 16M, HR2455 1
32 331632-5 PISTON CYLINDER, HR2450F 1
33 267104-3 FLAT WASHER 12, HR2400 1
34 324215-8 PISTON JOINT, HR2450F 1
35 267104-3 FLAT WASHER 12, HR2400 1
36 211012-0 BALL BEARING 606ZZ, HR2410 1
37 961003-8 RETAINING RING S-7, 9015B 1
38 233343-7 COMP. SPRING 7, HR2450F 1
39 331634-1 CLUTCH CAM, HR2450F 1
40 324248-3 CAM SHAFT, HR2450F 1
41 219014-0 SWASH BEARING 10,BHR200SH 1
42 226550-9 HELICAL GEAR 26,HR2450F 1
43 266273-7 H.S.H. BOLT M4X12, HR2450F 2
44 345179-3 BEARING RETAINER, HR2450F 1
45 267234-0 FLAT WASHER 8, HM1304B 1
46 211032-4 B. BEARING 608ZZ, N1900B 1
47 324212-4 RING 8, HR2450F 1
48 213725-9 O RING 68,HR2450F 1
49 153610-3 INNER HOUSING CPL.,HR2445 1
49 153687-8 INNER HOUSING, HR2450F 1
50 213380-7 O RING 24, 6805BV 1
51 210060-6 BALL BEARING 609LLU, HR2431 1
52 267231-6 FLAT WASHER 9, HR2450F 1
53 240047-4 FAN 60, HR2450F 1
53 240084-8 N/A 1
54 515666-8 ARMATURE ASS'Y, HR2450F 1
54 517376-3 ARMATURE ASS'Y 115V, HR2450F 1
55 681636-0 INSULATION WASHER, 4304 1
Page 2 of 3 2/8/2008

Parts Breakdown HR2455
56 211021-9 BALL BEARING 607LLB, LS1013 1
57 266052-3 TAPPING SCREW FLANGE PT4X60,HR2410 2
58 418085-6 BAFFLE PLATE, HR2445 1
59 633556-4 FIELD 115V, HR2445 1
60 183580-2 MOTOR HOUSING,HR2445 1
61 850414-1 NAME PLATE, HR2455 1
64 819064-1 MAKITA MARK, HM1100C 1
65 191927-6 CARBON BRUSH SET CB-407, 6821 1
66 643936-6 BRUSH HOLDER, 6821 2
67 819064-1 MAKITA MARK, HM1100C 1
68 650508-0 SWITCH, HR2450F 1
69 418086-4 HANDLE COVER, HR2445 1
70 265995-6 TAPPING SCREW 4X18, 4323K 6
71 682559-5 CORD GUARD 8, 6824 1
72 664895-1 CORD 1
74 687063-9 STRAIN RELIEF, 4323K 1
75 265995-6 TAPPING SCREW 4X18, 4323K 2
77 421494-0 LABYRINTH RUBBER RING, 4304 1
78 417795-2 LOCK BUTTON, HR2455 1
79 233341-1 COMP. SPRING 3, HR2450F 1
80 226399-7 SPUR GEAR 10, BHR200SH 1
81 265999-8 TAPPING SCREW M4X25, HM1800 2
82 345220-2 CHANGE PLATE, HR2450F 1
82 345363-0 CHANGE PLATE, HR2450F 1
83 961017-7 STOP RING E-3, 4304 2
84 417796-0 GUIDE BASE, HR2455 1
85 233344-5 COMP. SPRING 4, HR2450F 2
86 961011-9 STOP RING E-4, 4301BV 1
87 941102-2 F. WASHER 5, HM1100C 1
88 233342-9 COMP. SPRING 6, HR2450F 1
89 163430-7 LOCK PLATE CPL. 1
90 345280-4 HEX. WASHER, HP2050F 1
91 267271-4 FLAT WASHER 9, HR2445 1
1,001 324219-0 DEPTH GAUGE,HP2050F 1
1,002 824695-3 PLASTIC CARRYING CASE, HR2445 1
1,003 D-07973 5 PC SDS PLUS BIT ASSORT.HR2455X 1
5,001 810134-9 N/A 1
Page 3 of 3 2/8/2008
