Parts Breakdown HR2470F
Page 1 of 3 2/8/2008

Parts Breakdown HR2470F
Fig # Part ID Part Name Quantity
1 286263-4 CAP 35, HR2450F 1
2 233940-9 RING SPRING 19, HR2450F 1
3 417629-9 CHUCK COVER,HR2450F 1
4 257241-1 RING 21, HR2450F 1
5 345187-4 GUIDE WASHER, HR2450F 1
6 233916-6 CONICAL COMP. SPRING 21-29 1
7 921923-8 HEX. BOLT M8 X 120, HP2050F 1
8 345280-4 HEX. WASHER, HP2050F 1
9 417630-4 GRIP BASE, HP2070F 1
10 158057-6 GRIP 36 CPL., HR2470F 1
13 162245-9 CHANGE LEVER, HR2470F 1
14 233459-8 NG 3, HR1830F 1
15 419192-8 LOCK BUTTON, HR1830F 1
16 213278-8 O RING 17,HR2450F 1
17 158216-2 GEAR HOUSING CPL., HR2470F 1
18 266351-3 TAPPING SCREW 4X35, 9557PB 4
19 153290-5 NEEDLE BEARING CPL., HR2450F 1
20 233929-7 RING SPRING 29, BHR240 1
21 267791-8 WASHER 32, BHR240 1
22 233401-9 COMP. SPRING 32, BHR240 1
23 227109-5 SPUR GEAR 51, BHR240 1
24 216022-2 STEEL BALL 7.0, HR2400 1
25 158217-0 N/A 1
25 158574-6 TOOL HOLDER CPL., HR2470F 1
26 267229-3 FLAT WASHER 28 1
27 331769-8 SLEEVE 9, HR2470F 1
28 324669-9 IMPACT BOLT, BHR240 1
29 324402-9 RING 10, BHR240 1
30 421955-0 CUSHION RING 13, BHR240 1
31 324216-6 O RING CASE, HR2450F 1
32 213073-6 O RING 9,HR2450F 1
33 233917-4 RING SPRING 28, HR2450F 1
34 324733-6 STRIKER, HR2470F 1
35 213227-5 O RING 16M, HR2455 1
36 318132-2 PISTON CYLINDER, HR2470F 1
37 267104-3 FLAT WASHER 12, HR2400 1
38 324215-8 PISTON JOINT, HR2450F 1
39 267104-3 FLAT WASHER 12, HR2400 1
40 213727-5 O-RING 63, BHR240 1
41 211012-0 BALL BEARING 606ZZ, HR2410 1
42 961003-8 RETAINING RING S-7, 9015B 1
43 233343-7 COMP. SPRING 7, HR2450F 1
44 331768-0 N/A 1
45 324668-1 CAM SHAFT, BHR240 1
46 219014-0 SWASH BEARING 10,BHR200SH 1
47 226656-3 HELICAL GEAR 26, HR2470F 1
48 266273-7 H.S.H. BOLT M4X12, HR2450F 2
49 345179-3 BEARING RETAINER, HR2450F 1
50 267234-0 FLAT WASHER 8, HM1304B 1
51 211032-4 B. BEARING 608ZZ, N1900B 1
52 324212-4 RING 8, HR2450F 1
53 961011-9 STOP RING E-4, 4301BV 1
54 233342-9 COMP. SPRING 6, HR2450F 1
55 345363-0 CHANGE PLATE, HR2450F 1
56 158215-4 INNER HOUSING CPL., HR2470F 1
57 443126-9 FELT, HR2470F 1
58 213407-3 O RING 26, 4200H 1
59 213077-8 OIL SEAL 10, HR2470F 1
60 210059-1 BALL BEARING 6000DDW, HR4040C 1
61 267213-8 FLAT WASHER 10, HR2431 1
Page 2 of 3 2/8/2008

Parts Breakdown HR2470F
62 240092-9 FAN 64, HR2470F 1
63 515286-8 ARMATURE ASS'Y 115V, HR2470F 1
64 681652-2 INSULATION WASHER, JR180DWB 1
64 681670-0 N/A 1
65 210023-2 BALL BEARING 627DDW, 9910 1
66 267804-5 WAVE WASHER 15, HR2470F 1
67 266334-3 TAPPING SCREW 4X60, HR2470F 2
68 344871-8 RETAINER, GD0800C 2
69 419716-0 BAFFLE PLATE, HR2470F 1
70 626576-5 FIELD 115V, HR2470F 1
71 419718-6 MOTOR HOUSING, HR2470F 1
72 863533-4 NAME PLATE, HR2470F 1
73 194074-2 CARBON BRUSH CB325,9553NB 1
74 638500-6 BRUSH HOLDER UNIT, HR2470F 1
75 650589-4 SWITCH, HR2470F 1
76 814961-6 S/N LABEL, HR2470F 1
77 682559-5 CORD GUARD 8, 6824 1
78 664895-1 CORD 1
79 687260-7 CORD CLAMP, GA5020 1
80 266324-6 TAPPING SCREW 4X22, HR2470F 1
81 631745-5 LIGHT CIRCUIT, HR2470F 1
82 419717-8 HANDLE COVER, HR2470F 1
83 266324-6 TAPPING SCREW 4X22, HR2470F 1
84 266324-6 TAPPING SCREW 4X22, HR2470F 2
85 961017-7 STOP RING E-3, 4304 2
86 417796-0 GUIDE BASE, HR2455 1
87 233344-5 COMP. SPRING 4, HR2450F 2
88 266374-1 TAPPING SCREW 4X25, GA7021 2
89 163430-7 LOCK PLATE CPL. 1
90 227179-4 SPUR GEAR 10, HR2470F 1
91 941102-2 F. WASHER 5, HM1100C 1
1,001 324219-0 DEPTH GAUGE,HP2050F 1
1,002 824799-1 PLASTIC TOOL CSE, HR2470F 1
1,003 805452-8 LABEL, HR2470F 1
