Parts Breakdown 9403
Page 1 of 3 2/8/2008

Parts Breakdown 9403
Fig # Part ID Part Name Quantity
1 265995-6 TAPPING SCREW 4X18, 4323K 4
2 416496-9 HANDLE COVER, 9921 1
3 664276-9 CORD (2X16X16 SJ), HR5000 1
4 682505-8 CORD GUARD, 2711 1
5 650230-9 SWITCH, 9403 1
5 651284-9 SWITCH, 9920 1
6 150981-9 MOTOR HOUSING CPL., 9921 1
7 266034-5 TAPPING SCREW 4X16, 9524NB 1
8 416495-1 BELT COVER, 9921 1
9 222147-2 PULLEY 10-24.1, 9921 1
10 643750-0 BRUSH HOLDER CAP, HM1100C 2
11 191963-2 CARBON BRUSH CB-303 SET, 9227C 1
12 265995-6 TAPPING SCREW 4X18, 4323K 1
13 266056-5 T. SCREW FLANGE PT5X45,9046 2
14 687063-9 STRAIN RELIEF, 4323K 1
15 265995-6 TAPPING SCREW 4X18, 4323K 2
16 416497-7 DUST NOZZLE, 9921 1
17 213415-4 O RING 28, 5005BA 1
18 266069-6 T. SCREW FLANGE PT4X45 HR2410 2
19 265995-6 TAPPING SCREW 4X18, 4323K 1
20 819064-1 MAKITA MARK, HM1100C 1
21 266203-8 T.SCREW BIND CT 4X40, 9403 1
22 317018-7 DUST COLLECTOR COVER, 9403 1
23 416494-3 SEPARATOR, 9921 1
24 911213-7 P.H. SCREW M5X12, LS1040 1
25 241662-7 FAN 80, 9921 1
26 265995-6 TAPPING SCREW 4X18, 4323K 2
27 317021-8 DUST COLLECTOR BRACKET, 9921 1
28 211088-7 BALL BEARING 6000DDW, 9005B 1
29 240013-1 FAN 84, 9403 1
30 516781-1 ARMATURE ASS'Y 115V, 9921 1
31 416498-5 BAFFLE PLATE, 9921 1
32 681649-1 INSULATION WASHER, 9921 1
33 211088-7 BALL BEARING 6000DDW, 9005B 1
34 253946-1 W. WASHER 18, 9403, T1 1
34 267715-4 WAVE WASHER 20, 9403 1
35 596191-8 FIELD ASS'Y 115V, 9921 1
36 225081-5 SYNCHRO BELT, 9921 1
37 931503-2 HEX NUT M10, 2711 1
38 222148-0 PULLEY 11-55.6, 9921 1
39 266034-5 TAPPING SCREW 4X16, 9524NB 3
40 317020-0 GEAR COVER, 9921 1
41 153265-4 HELICAL GEAR 43, 9921-T1 1
41 153291-3 HELICAL GEAR 43 COMPLETE, 9921 1
42 150979-6 FRAME COMPLETE, 9403 1
43 265995-6 TAPPING SCREW 4X18, 4323K 4
44 150846-5 EDGE SLIDER, 9921 1
45 211131-2 BALL BEARING 6001DDW,9218PBL 1
46 162199-0 DRIVING ROLLER, 9403 1
47 252087-0 HEX NUT M12-19, 9921 1
48 266026-4 TAPPING SCREW 4X12,9046 2
49 344622-9 SAFETY COVER, 9921 1
50 163398-7 TENSION ROLLER ARM, 9403 1
51 233235-0 COMP. SPRING 12, 9921 1
52 231819-8 TENSION SPRING 4, 9921 1
53 321980-0 SUPPORT PIN, 9901 1
54 323829-0 TENSION ROLLER SHAFT, 9403 1
55 253922-5 CUP WASHER 12, 9900B 1
56 150978-8 TENSION ROLLER COMPLETE, 9403 1
57 253922-5 CUP WASHER 12, 9900B 1
Page 2 of 3 2/8/2008

Parts Breakdown 9403
58 961052-5 RETAINING RING S-12, 9218PBL 1
59 911118-1 P.H. SCREW M4X12, 6221D 3
60 344623-7 STRAP WASHER, 9403 1
61 150980-1 STEEL PLATE CPL.,9403 1
62 416499-3 FRONT GRIP, 9921 1
63 266034-5 TAPPING SCREW 4X16, 9524NB 2
64 226506-2 HELICAL GEAR 12, 9921-T1 1
64 226551-7 HELICAL GEAR 12, 9921 1
65 211066-7 B. BEARING 6200LLB, BO4552 1
66 911213-7 P.H. SCREW M5X12, LS1040 1
67 859611-6 NAME PLATE, 9403 1
68 231225-7 COMP. SPRING 16, 9900B 1
69 253707-9 F. WASHER 16, 6802BV 1
70 251815-0 SCREW M6X25, 9900B 1
1,001 794135-4 ABRASIVE BELT 100X610 WA80,9401 1
1,002 122562-9 DUST BAG ASS'Y, 9921 1
5,001 654575-7 N/A 1
5,002 810134-9 N/A 1
5,002 810277-7 N/A 1
