Makita 9227CY Quick start guide

7" Electronic SANDER-POLISHER MODEL 9227CY
12-02 1Model 9227CY
13
23
5
4
3
2
44
42
43
20
52
51
53
39
38
22
40
25
24
33
34
35
36
37
32
31
26 27
29
30
1
7
6
14
9
8
10
11
45
46
47
48
49
50
15
19
16
18
17
21

Item Part Qty. Item Part Qty.
No. No. Used Description No. No. Used Description
1632679-5 1SUPPORT COMPLETE ACCESSORIES
2634291-7 1FIELD 115V 51 743052-5 1PAD 165
3416253-5 1BAFFLE PLATE A02 262542-4 1SLEEVE 18
4211031-6 1BALL BEARING 608LLB
5681644-1 1INSULATION WASHER
6516306-1 1ARMATURE ASS'Y 115V
(INCL. FIG. 4, 5, & 7)
7240002-6 1FAN 70
8285687-1 1BEARING RETAINER 48
9211106-1 1BALL BEARING 6201LLB
10 961052-5 1RETAINING RING S-12
11 266012-5 4TAPPING SCREW 5X35
13 152490-4 1GRIP 36 COMPLETE
14 415491-6 1PIN CAP
15 233072-2 1COMPRESSION SPRING 8
16 911221-8 1PAN HEAD SCREW M5X16
17 911211-1 1PAN HEAD SCREW M5X12
18 159951-5 1GEAR HOUSING COMPLETE
19 256446-0 1PIN 6
20 632783-0 1LEAD UNIT
21 652014-1 1PAN HEAD SCREW M4X8
22 816330-7 1INDICATION LABEL
23 266038-7 2TAPPING SCREW 5X70
24 688110-9 1MAGNET SLEEVE
25 961012-7 1STOP RING E-6
26 255058-6 1RIVET 2
27 233002-3 1COMPRESSION SPRING 3
29 182917-0 1HANDLE SET (INCL. FIG. 52)
30 664630-7 1POWER SUPPLY CORD (3x18x8 SJ)
31 682503-2 1CORD GUARD 8-90
32 687063-9 1STRAIN RELIEF
33 265995-6 2TAPPING SCREW 4X18
34 654571-5 1TERMINAL BLOCK
35 265995-6 1TAPPING SCREW 4X18
36 652014-1 2PAN HEAD SCREW M4X8
37 651282-3 1SWITCH
38 631226-9 1CONTROLLER 100-130V
39 271417-6 1DIAL 28
40 182918-8 1MOTOR HOUSING SET
(INCL. 2 EA. 643708-9 BRUSH
HOLDER 5-11, & FIG. 22, & 44)
42 191963-2 1CARBON BRUSH CB-303 SET
43 643750-0 2BRUSH HOLDER CAP
44 819001-5 2MAKITA LABEL
45 226744-6 1SPIRAL BEVEL GEAR 52
46 962151-6 1RETAINING RING R-32
47 211106-1 1BALL BEARING 6201LLB
48 316896-2 1BEARING BOX
49 266034-5 4TAPPING SCREW CT 4X16
50 152552-8 1SPINDLE COMPLETE
(INCL. 344347-5 LABYRINTH RING)
52 182917-0 1HANDLE SET (INCL. FIG. 29)
53 265995-6 4TAPPING SCREW 4X18
12-02 2Model 9227CY
